Stochastic
Download script
This script functions as a technical analysis tool designed to help traders identify potential overbought or oversold conditions in the market by calculating the momentum of price movements. It transforms complex price action into a simplified visual oscillator that operates on a scale of 0 to 100.
How the Logic Works
The script follows a structured four-step process to generate its visual data:
1. Identifying Price Extremes First, the tool looks back over a specific number of past bars (defined by the user as the "K Period"). During this lookback, it scans for the highest price and the lowest price reached. These two points act as the boundaries for the current market range.
2. Calculating Relative Position Once the high and low boundaries are established, the script determines where the current closing price sits in relation to those extremes. It calculates how much of the "range" has been covered. For example, if the current price is near the top of the recent range, the value will trend toward 100; if it is near the bottom, it will trend toward 0.
3. Smoothing the Data (The Main Line) To prevent the data from being too erratic or "noisy," the script applies a smoothing calculation (the "Slowing" factor). Instead of just showing the raw relative position, it averages the results over a set timeframe. This produces the Main Line (displayed in LightSeaGreen), which represents the primary momentum of the asset.
4. Generating the Signal Finally, the script takes that smoothed Main Line and calculates a Simple Moving Average (SMA) based on a separate period (the "D Period"). This creates the Signal Line (displayed in Red).
Summary for the User
By observing these two lines, traders look for specific interactions:
- Overbought/Oversold: When the Main Line reaches extreme highs or lows.
- Trend Changes: When the Main Line crosses over or under the Signal Line, which can serve as a visual cue for potential shifts in price momentum.
//+------------------------------------------------------------------+
//| Stochastic.mq4 |
//| Copyright © 2004, MetaQuotes Software Corp. |
//| http://www.metaquotes.net/ |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2004, MetaQuotes Software Corp."
#property link "http://www.metaquotes.net/"
#property indicator_separate_window
#property indicator_minimum 0
#property indicator_maximum 100
#property indicator_buffers 2
#property indicator_color1 LightSeaGreen
#property indicator_color2 Red
//---- input parameters
extern int KPeriod=5;
extern int DPeriod=3;
extern int Slowing=3;
//---- buffers
double MainBuffer[];
double SignalBuffer[];
double HighesBuffer[];
double LowesBuffer[];
//----
int draw_begin1=0;
int draw_begin2=0;
//+------------------------------------------------------------------+
//| Custom indicator initialization function |
//+------------------------------------------------------------------+
int init()
{
string short_name;
//---- 2 additional buffers are used for counting.
IndicatorBuffers(4);
SetIndexBuffer(2, HighesBuffer);
SetIndexBuffer(3, LowesBuffer);
//---- indicator lines
SetIndexStyle(0,DRAW_LINE);
SetIndexBuffer(0, MainBuffer);
SetIndexStyle(1,DRAW_LINE);
SetIndexBuffer(1, SignalBuffer);
//---- name for DataWindow and indicator subwindow label
short_name="Sto("+KPeriod+","+DPeriod+","+Slowing+")";
IndicatorShortName(short_name);
SetIndexLabel(0,short_name);
SetIndexLabel(1,"Signal");
//----
draw_begin1=KPeriod+Slowing;
draw_begin2=draw_begin1+DPeriod;
SetIndexDrawBegin(0,draw_begin1);
SetIndexDrawBegin(1,draw_begin2);
//----
return(0);
}
//+------------------------------------------------------------------+
//| Stochastic oscillator |
//+------------------------------------------------------------------+
int start()
{
int i,k;
int counted_bars=IndicatorCounted();
double price;
//----
if(Bars<=draw_begin2) return(0);
//---- initial zero
if(counted_bars<1)
{
for(i=1;i<=draw_begin1;i++) MainBuffer[Bars-i]=0;
for(i=1;i<=draw_begin2;i++) SignalBuffer[Bars-i]=0;
}
//---- minimums counting
i=Bars-KPeriod;
if(counted_bars>KPeriod) i=Bars-counted_bars-1;
while(i>=0)
{
double min=1000000;
k=i+KPeriod-1;
while(k>=i)
{
price=Low[k];
if(min>price) min=price;
k--;
}
LowesBuffer[i]=min;
i--;
}
//---- maximums counting
i=Bars-KPeriod;
if(counted_bars>KPeriod) i=Bars-counted_bars-1;
while(i>=0)
{
double max=-1000000;
k=i+KPeriod-1;
while(k>=i)
{
price=High[k];
if(max<price) max=price;
k--;
}
HighesBuffer[i]=max;
i--;
}
//---- %K line
i=Bars-draw_begin1;
if(counted_bars>draw_begin1) i=Bars-counted_bars-1;
while(i>=0)
{
double sumlow=0.0;
double sumhigh=0.0;
for(k=(i+Slowing-1);k>=i;k--)
{
sumlow+=Close[k]-LowesBuffer[k];
sumhigh+=HighesBuffer[k]-LowesBuffer[k];
}
if(sumhigh==0.0) MainBuffer[i]=100.0;
else MainBuffer[i]=sumlow/sumhigh*100;
i--;
}
//---- last counted bar will be recounted
if(counted_bars>0) counted_bars--;
int limit=Bars-counted_bars;
//---- signal line is simple movimg average
for(i=0; i<limit; i++)
SignalBuffer[i]=iMAOnArray(MainBuffer,Bars,DPeriod,0,MODE_SMA,i);
//----
return(0);
}
//+------------------------------------------------------------------+
