Stochastic 2,3,3
Download script
This script functions as a Stochastic Oscillator, a technical analysis tool used to determine whether an asset is overbought or oversold by measuring the current price relative to its price range over a specific period. Essentially, it helps traders identify potential turning points in market trends.
The logic behind the indicator follows a structured four-step process:
1. Data Gathering (Highs and Lows)
The script begins by scanning historical price data to identify the highest and lowest prices reached within a set timeframe (defined by the "KPeriod"). By tracking these extremes, the tool establishes the boundaries of the market's "swing" during that specific window.
2. Calculating Market Position (%K Line)
Once the highs and lows are established, the script calculates where the current closing price sits within that range. It compares the distance between the recent low and the closing price against the total range (the distance between the high and the low).
- This value is converted into a percentage from 0 to 100.
- A high percentage suggests the price is near the top of its recent range (potentially overbought).
- A low percentage suggests the price is near the bottom of its recent range (potentially oversold).
3. Smoothing the Movement
To make the data easier to read and less "jittery," the script applies a smoothing effect (defined by the "Slowing" parameter). This averages out the raw percentage values over a small window of time, resulting in a smoother, more continuous line that represents the primary trend of the momentum.
4. Generating the Signal
Finally, the script calculates a secondary line, known as the Signal Line. This is created by taking a simple moving average of the primary smoothed line.
- The interaction between these two lines—the main oscillator and the signal line—is the primary point of interest for users.
- When these lines cross each other or move in specific directions, they provide visual cues regarding shifts in momentum, helping to confirm when a price trend might be gaining strength or beginning to exhaust itself.
//+------------------------------------------------------------------+
//| Stochastic.mq4 |
//| Copyright © 2004, MetaQuotes Software Corp. |
//| http://www.metaquotes.net/ |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2004, MetaQuotes Software Corp."
#property link "http://www.metaquotes.net/"
#property indicator_separate_window
#property indicator_minimum 0
#property indicator_maximum 100
#property indicator_buffers 2
#property indicator_color1 LightSeaGreen
#property indicator_color2 Red
//---- input parameters
extern int KPeriod=2;
extern int DPeriod=3;
extern int Slowing=3;
//---- buffers
double MainBuffer[];
double SignalBuffer[];
double HighesBuffer[];
double LowesBuffer[];
//----
int draw_begin1=0;
int draw_begin2=0;
//+------------------------------------------------------------------+
//| Custom indicator initialization function |
//+------------------------------------------------------------------+
int init()
{
string short_name;
//---- 2 additional buffers are used for counting.
IndicatorBuffers(4);
SetIndexBuffer(2, HighesBuffer);
SetIndexBuffer(3, LowesBuffer);
//---- indicator lines
SetIndexStyle(0,DRAW_LINE);
SetIndexBuffer(0, MainBuffer);
SetIndexStyle(1,DRAW_LINE);
SetIndexBuffer(1, SignalBuffer);
//---- name for DataWindow and indicator subwindow label
short_name="Sto("+KPeriod+","+DPeriod+","+Slowing+")";
IndicatorShortName(short_name);
SetIndexLabel(0,short_name);
SetIndexLabel(1,"Signal");
//----
draw_begin1=KPeriod+Slowing;
draw_begin2=draw_begin1+DPeriod;
SetIndexDrawBegin(0,draw_begin1);
SetIndexDrawBegin(1,draw_begin2);
//----
return(0);
}
//+------------------------------------------------------------------+
//| Stochastic oscillator |
//+------------------------------------------------------------------+
int start()
{
int i,k;
int counted_bars=IndicatorCounted();
double price;
//----
if(Bars<=draw_begin2) return(0);
//---- initial zero
if(counted_bars<1)
{
for(i=1;i<=draw_begin1;i++) MainBuffer[Bars-i]=0;
for(i=1;i<=draw_begin2;i++) SignalBuffer[Bars-i]=0;
}
//---- minimums counting
i=Bars-KPeriod;
if(counted_bars>KPeriod) i=Bars-counted_bars-1;
while(i>=0)
{
double min=1000000;
k=i+KPeriod-1;
while(k>=i)
{
price=Low[k];
if(min>price) min=price;
k--;
}
LowesBuffer[i]=min;
i--;
}
//---- maximums counting
i=Bars-KPeriod;
if(counted_bars>KPeriod) i=Bars-counted_bars-1;
while(i>=0)
{
double max=-1000000;
k=i+KPeriod-1;
while(k>=i)
{
price=High[k];
if(max<price) max=price;
k--;
}
HighesBuffer[i]=max;
i--;
}
//---- %K line
i=Bars-draw_begin1;
if(counted_bars>draw_begin1) i=Bars-counted_bars-1;
while(i>=0)
{
double sumlow=0.0;
double sumhigh=0.0;
for(k=(i+Slowing-1);k>=i;k--)
{
sumlow+=Close[k]-LowesBuffer[k];
sumhigh+=HighesBuffer[k]-LowesBuffer[k];
}
if(sumhigh==0.0) MainBuffer[i]=100.0;
else MainBuffer[i]=sumlow/sumhigh*100;
i--;
}
//---- last counted bar will be recounted
if(counted_bars>0) counted_bars--;
int limit=Bars-counted_bars;
//---- signal line is simple movimg average
for(i=0; i<limit; i++)
SignalBuffer[i]=iMAOnArray(MainBuffer,Bars,DPeriod,0,MODE_SMA,i);
//----
return(0);
}
//+------------------------------------------------------------------+
