4 TF HAS Bar

Download script
Author: Copyright � 2006, Eli hayun
4 TF HAS Bar

Overview and Purpose

This script is a Multi-Timeframe (MTF) visual indicator designed for the MetaTrader 4 platform. Its primary purpose is to allow traders to monitor market trends across four different timeframes simultaneously within a single window. Instead of forcing you to switch between different charts to see what is happening on shorter or longer intervals, this tool aggregates that data into a single view.

Core Logic and Functionality

The indicator operates using the following logic:

1. Dynamic Timeframe Selection The script automatically detects which timeframe chart you currently have open (e.g., 15 minutes, 1 hour, or 4 hours). Based on your current view, it intelligently selects a sequence of four related timeframes to display. For example, if you are looking at a 30-minute chart, it will automatically pull data for the timeframes surrounding that interval to provide a comprehensive "big picture" perspective.

2. Data Source (Heiken Ashi Smoothing) To determine the trend, the script pulls data from an external calculation known as "Heiken Ashi Smoothed." It looks at specific price points (the "Open" and "Close" values) of these smoothed candles. This provides a cleaner, less noisy view of market momentum compared to standard Japanese candlesticks.

3. Trend Identification The script performs a simple but effective comparison:

  • If the closing price is higher than the opening price on a specific timeframe, it identifies an upward trend.
  • If the closing price is lower than the opening price, it identifies a downward trend.

4. Visual Representation Rather than drawing complex lines that might clutter your screen, the script uses distinct visual markers (arrows/bars) stacked vertically in a separate window:

  • Color Coding: It uses Red and Blue colors to instantly differentiate between bearish (downward) and bullish (upward) movements.
  • Vertical Stacking: The four different timeframes are displayed one above the other with a specific "Gap" between them. This allows you to see, at a glance, if all timeframes are aligned (e.g., all blue/up) or if there is a conflict between short-term and long-term trends.
  • Labels: The tool automatically places text labels next to each row so you always know exactly which timeframe corresponds to which set of markers.

Summary for the User

In short, this tool acts as a "Trend Dashboard." It takes the complex task of checking multiple charts and simplifies it into a single visual summary. By observing the colors and positions of the four levels, you can quickly determine if the market is trending in your favor across multiple time horizons simultaneously.

Miscellaneous
Implements a curve of type %1
10 Views
0 Downloads
0 Favorites
4 TF HAS Bar
//+------------------------------------------------------------------+
//|                                                  4TF HAS Bar.mq4 |
//|                  Modified by Matsu, from #MTF Supertrend Bar.mq4 |
//|                                      Copyright © 2006, Eli hayun |
//|                                          http://www.elihayun.com |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2006, Eli hayun"
#property link      "http://www.elihayun.com"

#property indicator_separate_window
#property indicator_minimum 0
#property indicator_maximum 5
#property indicator_buffers 8
#property indicator_color1 Red
#property indicator_color2 Blue
#property indicator_color3 Red
#property indicator_color4 Blue
#property indicator_color5 Red
#property indicator_color6 Blue
#property indicator_color7 Red
#property indicator_color8 Blue

//---- parameters
extern int MaMetod  = 2;
extern int MaPeriod = 6;
extern int MaMetod2  = 3;
extern int MaPeriod2 = 2;
extern int BarWidth = 0;
extern color BarColorUp = Blue;
extern color BarColorDown = Red;
extern color TextColor = White;
extern int MaxBars=500;

double Gap = 1; // Gap between the lines of bars
//---- buffers
double buf4_up[];
double buf4_down[];
double buf3_up[];
double buf3_down[];
double buf2_up[];
double buf2_down[];
double buf1_up[];
double buf1_down[];
double haOpen;
double haClose;


/*
extern int Period_1 = 15;
extern int Period_2 = 30;
extern int Period_3 = 60;
extern int Period_4 = 240;

extern bool AutoDisplay      = false;
*/
string shortname = "";
bool firstTime = true;

int ArrSize = 110;//159;
int UniqueNum = 228;

//+------------------------------------------------------------------+
//| Custom indicator initialization function                         |
//+------------------------------------------------------------------+
int init()
  {


   //SetAutoDisplay();



   firstTime = true;

   //IndicatorShortName(shortname);
//---- indicators
   SetIndexStyle(0,DRAW_ARROW,0,BarWidth,BarColorDown);
   SetIndexArrow(0,ArrSize);
   SetIndexBuffer(0,buf4_up);
   SetIndexEmptyValue(0,0.0);
   SetIndexStyle(1,DRAW_ARROW,0,BarWidth,BarColorUp);
   SetIndexArrow(1,ArrSize);
   SetIndexBuffer(1,buf4_down);
   SetIndexEmptyValue(1,0.0);
   SetIndexStyle(2,DRAW_ARROW,0,BarWidth,BarColorDown);
   SetIndexArrow(2,ArrSize);
   SetIndexBuffer(2,buf3_up);
   SetIndexEmptyValue(2,0.0);
   SetIndexStyle(3,DRAW_ARROW,0,BarWidth,BarColorUp);
   SetIndexArrow(3,ArrSize);
   SetIndexBuffer(3,buf3_down);
   SetIndexEmptyValue(3,0.0);
   SetIndexStyle(4,DRAW_ARROW,0,BarWidth,BarColorDown);
   SetIndexArrow(4,ArrSize);
   SetIndexBuffer(4,buf2_up);
   SetIndexEmptyValue(4,0.0);
   SetIndexStyle(5,DRAW_ARROW,0,BarWidth,BarColorUp);
   SetIndexArrow(5,ArrSize);
   SetIndexBuffer(5,buf2_down);
   SetIndexEmptyValue(5,0.0);
   SetIndexStyle(6,DRAW_ARROW,0,BarWidth,BarColorDown);
   SetIndexArrow(6,ArrSize);
   SetIndexBuffer(6,buf1_up);
   SetIndexEmptyValue(6,0.0);
   SetIndexStyle(7,DRAW_ARROW,0,BarWidth,BarColorUp);
   SetIndexArrow(7,ArrSize);
   SetIndexBuffer(7,buf1_down);
   SetIndexEmptyValue(7,0.0);

   SetIndexLabel(0,NULL);
   SetIndexLabel(1,NULL);
   SetIndexLabel(2,NULL);
   SetIndexLabel(3,NULL);
   SetIndexLabel(4,NULL);
   SetIndexLabel(5,NULL);
   SetIndexLabel(6,NULL);
   SetIndexLabel(7,NULL);

   IndicatorDigits(0);
//----
   return(0);
  }
//+------------------------------------------------------------------+
//| Custom indicator deinitialization function                       |
//+------------------------------------------------------------------+
int deinit()
  {
//----
   //SetAutoDisplay();

//   shortname = "# Forex Freedom("+Period_1+","+Period_2+","+Period_3+","+Period_4+")";
   firstTime = true;
//----
   return(0);
  }
//+------------------------------------------------------------------+
//| Custom indicator iteration function                              |
//+------------------------------------------------------------------+
int start()
  {
   int    counted_bars=IndicatorCounted();
   int i=0, y15m=0, y4h=0, y1h=0, y30m=0, yy;
   int limit=Bars-counted_bars;

   int Period_1, Period_2, Period_3, Period_4;
   switch(Period())
      {
         case 1:
            Period_1=1; Period_2=5; Period_3=15; Period_4=30;
            break;
         case 5:
            Period_1=5; Period_2=15; Period_3=30; Period_4=60;
            break;
         case 15:
            Period_1=15; Period_2=30; Period_3=60; Period_4=240;
            break;
         case 30:
            Period_1=30; Period_2=60; Period_3=240; Period_4=1440;
            break;
         case 60:
            Period_1=60; Period_2=240; Period_3=1440; Period_4=10080;
            break;
         case 240:
            Period_1=240; Period_2=1440; Period_3=10080; Period_4=43200;
            break;
         case 1440:
            Period_1=1440; Period_2=10080; Period_3=43200; Period_4=43200;
            break;
         case 10080:
            Period_1=10080; Period_2=43200; Period_3=43200; Period_4=43200;
            break;
         case 43200:
            Period_1=43200; Period_2=43200; Period_3=43200; Period_4=43200;
            break;

      }


   shortname = "MTF HAS ("+Period_1+","+Period_2+","+Period_3+","+Period_4+")";
   IndicatorShortName(shortname);

   datetime TimeArray_4H[], TimeArray_1H[], TimeArray_30M[], TimeArray_15M[];
//----



   if (firstTime || NewBar())
   {
      firstTime = false;
      int win = UniqueNum; // WindowFind(shortname);
      double dif = Time[0] - Time[1];
      for (int ii=ObjectsTotal()-1; ii>-1; ii--)
      {
         if (StringFind(ObjectName(ii),"FF_"+win+"_") >= 0)
            ObjectDelete(ObjectName(ii));
         else
            ii=-1;
      }

      double shift = 0.2;
      for (ii=0; ii<4; ii++)
      {
         string txt = "??";
         double gp;
         switch (ii)
         {
            case 0: txt = tf2txt(Period_1);  gp = 1 + shift;
break;
            case 1: txt = tf2txt(Period_2);  gp = 1 + Gap + shift;
break;
            case 2: txt = tf2txt(Period_3);  gp = 1 + Gap*2 + shift;
break;
            case 3: txt = tf2txt(Period_4);  gp = 1 + Gap*3 + shift;
break;
         }
         string name = "FF_"+win+"_"+ii+"_"+txt;
         ObjectCreate(name, OBJ_TEXT, WindowFind(shortname),
iTime(NULL,0,0)+dif*3, gp);
         ObjectSetText(name, txt,8,"Arial", TextColor);
      }
   }

   ArrayCopySeries(TimeArray_4H,MODE_TIME,Symbol(),Period_4);
   ArrayCopySeries(TimeArray_1H,MODE_TIME,Symbol(),Period_3);
   ArrayCopySeries(TimeArray_30M,MODE_TIME,Symbol(),Period_2);
   ArrayCopySeries(TimeArray_15M,MODE_TIME,Symbol(),Period_1);

   //for(i=0, y15m=0,  y4h=0,  y1h=0,  y30m=0;i<limit;i++)
   for(i=0, y15m=0,  y4h=0,  y1h=0,  y30m=0;i<MaxBars;i++)
   {
      if (Time[i]<TimeArray_15M[y15m]) y15m++;
      if (Time[i]<TimeArray_4H[y4h])   y4h++;
      if (Time[i]<TimeArray_1H[y1h])   y1h++;
      if (Time[i]<TimeArray_30M[y30m]) y30m++;

      for (int tf = 0; tf < 4; tf++)
      {
         int prd;
         switch (tf)
         {
            case 0: prd = Period_1; yy = y15m;  break;
            case 1: prd = Period_2; yy = y30m;  break;
            case 2: prd = Period_3;  yy = y1h;   break;
            case 3: prd = Period_4;  yy = y4h;   break;
         }


         haOpen = iCustom(NULL,prd,"Heiken_Ashi_Smoothed",MaMetod,MaPeriod,MaMetod2,MaPeriod2,2,yy) ;
         haClose = iCustom(NULL,prd,"Heiken_Ashi_Smoothed",MaMetod,MaPeriod,MaMetod2,MaPeriod2,3,yy) ;

         double dUp = EMPTY_VALUE; //   iCustom(NULL, prd, "SuperTrend", false, 1, yy);
         double dDn = EMPTY_VALUE; //iCustom(NULL, prd, "SuperTrend", false, 0, yy);

         if (haOpen<haClose) dDn = 1; else dUp = 1;

         switch (tf)
         {
            case 0: if (dUp == EMPTY_VALUE)  buf1_down[i] = 1;
else buf1_up[i] = 1; break;
            case 1: if (dUp == EMPTY_VALUE)  buf2_down[i] = 1 + Gap *
1; else buf2_up[i] = 1 + Gap * 1; break;
            case 2: if (dUp == EMPTY_VALUE)  buf3_down[i]  = 1 + Gap *
2; else buf3_up[i]  = 1 + Gap * 2; break;
            case 3: if (dUp == EMPTY_VALUE)  buf4_down[i]  = 1  + Gap *
3; else buf4_up[i]  = 1 + Gap * 3; break;
         }


      }


   }

   return(0);
  }
//+------------------------------------------------------------------+

string tf2txt(int tf)
{
   if (tf == PERIOD_M1)    return("M1");
   if (tf == PERIOD_M5)    return("M5");
   if (tf == PERIOD_M15)    return("M15");
   if (tf == PERIOD_M30)    return("M30");
   if (tf == PERIOD_H1)    return("H1");
   if (tf == PERIOD_H4)    return("H4");
   if (tf == PERIOD_D1)    return("D1");
   if (tf == PERIOD_W1)    return("W1");
   if (tf == PERIOD_MN1)    return("MN1");

   return("??");
}

/*void SetValues(int p1, int p2, int p3, int p4)
{
   Period_1 = p1;   Period_2 = p2; Period_3 = p3; Period_4 = p4;
}


void SetAutoDisplay()
{
   if (AutoDisplay)
   {
      switch (Period())
      {
         case PERIOD_M1  :  SetValues(PERIOD_M1,  PERIOD_M5,
PERIOD_M15,PERIOD_M30); break;
         case PERIOD_M5  :  SetValues(PERIOD_M5,
PERIOD_M15,PERIOD_M30,PERIOD_H1); break;
         case PERIOD_M15 :  SetValues(PERIOD_M5,
PERIOD_M15,PERIOD_M30,PERIOD_H1); break;
         case PERIOD_M30 :  SetValues(PERIOD_M5, PERIOD_M15,PERIOD_M30,
PERIOD_H1); break;
         case PERIOD_H1  :  SetValues(PERIOD_M15, PERIOD_M30,PERIOD_H1,
PERIOD_H4);  break;
         case PERIOD_H4  :  SetValues(PERIOD_M30, PERIOD_H1, PERIOD_H4,
PERIOD_D1);  break;
         case PERIOD_D1  :  SetValues(PERIOD_H1,  PERIOD_H4, PERIOD_D1,
PERIOD_W1); break;
         case PERIOD_W1  :  SetValues(PERIOD_H4,  PERIOD_D1,
PERIOD_W1,PERIOD_MN1); break;
         case PERIOD_MN1 :  SetValues(PERIOD_H4,  PERIOD_D1,
PERIOD_W1,PERIOD_MN1);  break;
      }
   }

}
*/
bool NewBar()
{
   static datetime dt = 0;

   if (Time[0] != dt)
   {
      dt = Time[0];
      return(true);
   }
   return(false);
}
