#MTF_Heiken Ashi Freedom Bar
Download scriptThis script functions as a multi-timeframe trend analysis tool designed to provide traders with a comprehensive overview of market direction by synchronizing data from four different time horizons simultaneously. Instead of looking at a single timeframe in isolation, it aggregates information to help identify stronger, more consistent trends.
Core Logic and Functionality
Multi-Timeframe Integration The primary logic revolves around analyzing four distinct periods at once (for example: 5-minute, 15-minute, 30-minute, and 1-hour charts). The script automatically identifies the appropriate timeframes to display based on the chart you are currently viewing, ensuring that the analysis remains relevant whether you are a scalper or a long-term swing trader.
Trend Detection via Heiken Ashi The tool utilizes "Heiken Ashi" price action logic as its foundation. Heiken Ashi is a specialized candlestick method known for filtering out market noise and highlighting smooth price trends. The script checks these trends across all four selected timeframes simultaneously.
Visual Representation To make the data easy to read, the script maps the trend of each timeframe to a separate visual level in a dedicated window on your screen:
- Each timeframe is assigned its own "lane" or line.
- The lines are spaced out (using a customizable "Gap") so that the results from different timeframes do not overlap, providing a clean, organized layout.
- The script uses directional arrows to indicate whether the trend on a specific timeframe is currently moving upward or downward.
Confluence and Alerts The most significant feature of this script is its ability to detect "confluence"—when multiple timeframes agree on the same direction.
- Unified Trend: The script monitors all four lanes simultaneously. If every single timeframe (all four) shows an upward trend, it registers a confirmed bullish signal. Conversely, if all four show a downward trend, it registers a confirmed bearish signal.
- Automated Notifications: When this high-level agreement occurs (where the trend is perfectly aligned across all timeframes), the script triggers an audible alert and prints a notification on the screen. This allows traders to identify "high-probability" moves where the short-term, medium-term, and long-term trends are all moving in harmony.
Summary for the User
Essentially, this tool acts as a "trend filter." It removes the guesswork of trying to guess which timeframe is most important by showing you all of them at once. It only signals a move when there is total agreement across the board, helping to filter out "fake-outs" and highlighting moments where the market momentum is strongest and most consistent.
//+------------------------------------------------------------------+
//| #MTF HA Freedom Bar.mq4 |
//| Copyright © 2006, Eli hayun |
//| Heiken Ashi conversion by Rupp |
//| http://www.elihayun.com |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2006, Eli hayun"
#property link "http://www.elihayun.com"
#property indicator_separate_window
#property indicator_minimum -0.5
//#property indicator_maximum 5
#property indicator_buffers 8
#property indicator_color1 Red
#property indicator_color2 White
#property indicator_color3 Red
#property indicator_color4 White
#property indicator_color5 Red
#property indicator_color6 White
#property indicator_color7 Red
#property indicator_color8 White
//---- buffers
double buf4_up[];
double buf4_down[];
double buf3_up[];
double buf3_down[];
double buf2_up[];
double buf2_down[];
double buf1_up[];
double buf1_down[];
extern double Gap = 1; // Gap between the lines of bars
extern int Period_1 = PERIOD_M5;//M15
extern int Period_2 = PERIOD_M15;//M30
extern int Period_3 = PERIOD_M30;//H1
extern int Period_4 = PERIOD_H1;//H4
//extern int cci_1 = 34;//50
//extern int cci_2 = 34;//14
//extern int cci_3 = 14;
//extern int cci_4 = 14;
extern bool AutoDisplay = false;
string shortname = "";
bool firstTime = true;
int UniqueNum = 228;
//+------------------------------------------------------------------+
//| Custom indicator initialization function |
//+------------------------------------------------------------------+
int init()
{
SetAutoDisplay();
shortname = "# Forex Freedom("+Period_1+","+Period_2+","+Period_3+","+Period_4+")";
firstTime = true;
IndicatorShortName(shortname);
//---- indicators
SetIndexStyle(0,DRAW_ARROW,0,3);
SetIndexArrow(0,167);
SetIndexBuffer(0,buf4_up);
SetIndexEmptyValue(0,0.0);
SetIndexStyle(1,DRAW_ARROW,0,3);
SetIndexArrow(1,167);
SetIndexBuffer(1,buf4_down);
SetIndexEmptyValue(1,0.0);
SetIndexStyle(2,DRAW_ARROW,0,3);
SetIndexArrow(2,167);
SetIndexBuffer(2,buf3_up);
SetIndexEmptyValue(2,0.0);
SetIndexStyle(3,DRAW_ARROW,0,3);
SetIndexArrow(3,167);
SetIndexBuffer(3,buf3_down);
SetIndexEmptyValue(3,0.0);
SetIndexStyle(4,DRAW_ARROW,0,3);
SetIndexArrow(4,167);
SetIndexBuffer(4,buf2_up);
SetIndexEmptyValue(4,0.0);
SetIndexStyle(5,DRAW_ARROW,0,3);
SetIndexArrow(5,167);
SetIndexBuffer(5,buf2_down);
SetIndexEmptyValue(5,0.0);
SetIndexStyle(6,DRAW_ARROW,0,3);
SetIndexArrow(6,167);
SetIndexBuffer(6,buf1_up);
SetIndexEmptyValue(6,0.0);
SetIndexStyle(7,DRAW_ARROW,0,3);
SetIndexArrow(7,167);
SetIndexBuffer(7,buf1_down);
SetIndexEmptyValue(7,0.0);
//----
return(0);
}
//+------------------------------------------------------------------+
//| Custom indicator deinitialization function |
//+------------------------------------------------------------------+
int deinit()
{
//----
SetAutoDisplay();
shortname = "# HA Freedom("+Period_1+","+Period_2+","+Period_3+","+Period_4+")";
firstTime = true;
//----
return(0);
}
//+------------------------------------------------------------------+
//| Custom indicator iteration function |
//+------------------------------------------------------------------+
int start()
{
int counted_bars=IndicatorCounted();
int i=0, y5m=0, y1h=0, y30m=0, y15m=0, yy;
int limit=Bars-counted_bars;
datetime TimeArray_1H[], TimeArray_30M[], TimeArray_15M[], TimeArray_5M[];
//----
if (firstTime || NewBar())
{
firstTime = false;
int win = UniqueNum; // WindowFind(shortname);
double dif = Time[0] - Time[1];
for (int ii=ObjectsTotal()-1; ii>-1; ii--)
{
if (StringFind(ObjectName(ii),"FF_"+win+"_") >= 0)
ObjectDelete(ObjectName(ii));
else
ii=-1;
}
double shift = 0.2;
for (ii=0; ii<4; ii++)
{
string txt = "??";
double gp;
switch (ii)
{
case 0: txt = tf2txt(Period_1); gp = 1 + shift; break;
case 1: txt = tf2txt(Period_2); gp = 1 + Gap + shift; break;
case 2: txt = tf2txt(Period_3); gp = 1 + Gap*2 + shift; break;
case 3: txt = tf2txt(Period_4); gp = 1 + Gap*3 + shift; break;
}
string name = "FF_"+win+"_"+ii+"_"+txt;
ObjectCreate(name, OBJ_TEXT, WindowFind(shortname), iTime(NULL,0,0)+dif*3, gp);
ObjectSetText(name, txt,8,"Arial", Silver);
}
}
ArrayCopySeries(TimeArray_1H,MODE_TIME,Symbol(),Period_4);
ArrayCopySeries(TimeArray_30M,MODE_TIME,Symbol(),Period_3);
ArrayCopySeries(TimeArray_15M,MODE_TIME,Symbol(),Period_2);
ArrayCopySeries(TimeArray_5M,MODE_TIME,Symbol(),Period_1);
for(i=0, y5m=0, y1h=0, y30m=0, y15m=0;i<limit;i++)
{
if (Time[i]<TimeArray_5M[y5m]) y5m++;
if (Time[i]<TimeArray_1H[y1h]) y1h++;
if (Time[i]<TimeArray_30M[y30m]) y30m++;
if (Time[i]<TimeArray_15M[y15m]) y15m++;
// int cci_n = cci_1;
for (int tf = 0; tf < 4; tf++)
{
int prd;
switch (tf)
{
case 0: prd = Period_1; yy = y5m; break;
case 1: prd = Period_2; yy = y15m; break;
case 2: prd = Period_3; yy = y30m; break;
case 3: prd = Period_4; yy = y1h; break;
}
double HA = iCustom(NULL,prd,"Heiken Ashi-Overlay",0,yy) ;
double dUp = EMPTY_VALUE; // iCustom(NULL, prd, "SuperTrend", false, 1, yy);
double dDn = EMPTY_VALUE; //iCustom(NULL, prd, "SuperTrend", false, 0, yy);
if (HA == 1) dUp = 1; else dDn = 1;
switch (tf)
{
case 0: if (dUp == EMPTY_VALUE) buf1_down[i] = 1; else buf1_up[i] = 1; break;
case 1: if (dUp == EMPTY_VALUE) buf2_down[i] = 1 + Gap * 1; else buf2_up[i] = 1 + Gap * 1; break;
case 2: if (dUp == EMPTY_VALUE) buf3_down[i] = 1 + Gap * 2; else buf3_up[i] = 1 + Gap * 2; break;
case 3: if (dUp == EMPTY_VALUE) buf4_down[i] = 1 + Gap * 3; else buf4_up[i] = 1 + Gap * 3; break;
}
if (NewBar())
{
string sDir = "";
if (buf1_up[0] + buf2_up[0] + buf3_up[0] + buf4_up[0] == 4)
sDir = "Up";
if (buf1_down[0] + buf2_down[0] + buf3_down[0] + buf4_down[0] == 4)
sDir = "Down";
if (sDir != "")
{
PlaySound("alert1.wav");
Print("Forex freeway - Direction ",sDir);
}
}
}
}
return(0);
}
//+------------------------------------------------------------------+
string tf2txt(int tf)
{
if (tf == PERIOD_M1) return("M1");
if (tf == PERIOD_M5) return("M5");
if (tf == PERIOD_M15) return("M15");
if (tf == PERIOD_M30) return("M30");
if (tf == PERIOD_H1) return("H1");
if (tf == PERIOD_H4) return("H4");
if (tf == PERIOD_D1) return("D1");
if (tf == PERIOD_W1) return("W1");
if (tf == PERIOD_MN1) return("MN1");
return("??");
}
void SetValues(int p1, int p2, int p3, int p4)
{
Period_1 = p1; Period_2 = p2; Period_3 = p3; Period_4 = p4;
}
void SetAutoDisplay()
{
if (AutoDisplay)
{
switch (Period())
{
case PERIOD_M1 : SetValues(PERIOD_M1, PERIOD_M5, PERIOD_M15,PERIOD_M30); break;
case PERIOD_M5 : SetValues(PERIOD_M5, PERIOD_M15,PERIOD_M30,PERIOD_H1); break;
case PERIOD_M15 : SetValues(PERIOD_M5, PERIOD_M15,PERIOD_M30,PERIOD_H1); break;
case PERIOD_M30 : SetValues(PERIOD_M5, PERIOD_M15,PERIOD_M30, PERIOD_H1); break;
case PERIOD_H1 : SetValues(PERIOD_M15, PERIOD_M30,PERIOD_H1, PERIOD_H4); break;
case PERIOD_H4 : SetValues(PERIOD_M30, PERIOD_H1, PERIOD_H4, PERIOD_D1); break;
case PERIOD_D1 : SetValues(PERIOD_H1, PERIOD_H4, PERIOD_D1, PERIOD_W1); break;
case PERIOD_W1 : SetValues(PERIOD_H4, PERIOD_D1, PERIOD_W1,PERIOD_MN1); break;
case PERIOD_MN1 : SetValues(PERIOD_H4, PERIOD_D1, PERIOD_W1,PERIOD_MN1); break;
}
}
}
bool NewBar()
{
static datetime dt = 0;
if (Time[0] != dt)
{
dt = Time[0];
return(true);
}
return(false);
}
