StepChoppy_v2

Author: Copyright � 2007, Forex-TSD.com
StepChoppy_v2

The StepChoppy_v2 indicator is designed to provide traders with a visual breakdown of current market trends by categorizing price action into specific "moods" or stages. Instead of simply showing if the price is going up or down, this tool identifies the quality and strength of that movement, helping users distinguish between a powerful trend, a temporary pause, and a choppy, undecided market.

How the Logic Works

The script operates by analyzing three distinct layers of data simultaneously to determine the "state" of the market:

  1. Trend Direction: It first identifies the primary direction of the market (Upward or Downward) using a specialized moving average logic. This serves as the foundation for all other readings.
  2. Momentum Comparison: It utilizes a Relative Strength Index (RSI) system that compares three different data points: a standard RSI, a "Fast" RSI, and a "Slow" RSI. By comparing these three values against each other, the script can see if the market is accelerating, decelerating, or exhausting its strength.
  3. State Categorization: By combining the Trend Direction with the Momentum Comparison, the logic assigns the market into one of eight specific categories, displayed as visual bars in a separate window:

Upward Market States

  • Strong UpTrend: The primary trend is up, and momentum is moving aggressively in that same direction.
  • Retrace UpTrend: The primary trend is up, but there is a slight "pullback" or cooling-off period in the immediate momentum.
  • Choppy UpTrend: The primary trend is up, but the price movement is inconsistent and lacks clear direction.
  • Be Ready to Change UpTrend: The trend is still technically upward, but the momentum signals suggest a potential reversal or exhaustion is imminent.

Downward Market States

  • Strong DownTrend: The primary trend is down, with aggressive momentum moving consistently lower.
  • Retrace DownTrend: The primary trend is down, but there is a temporary "relief" bounce or pause in the downward movement.
  • Choppy DownTrend: The primary trend is down, but price action is erratic and lacks a clear path.
  • Be Ready to Change DownTrend: The trend is still technically downward, but momentum signals suggest the price may be preparing to turn around.

Summary for the User

This tool acts as a filter for market noise. It helps you see past the simple "up or down" movement of the candles and allows you to identify exactly how the market is moving. For example, it helps you distinguish between a market that is trending healthily and one that is simply "drifting" or becoming exhausted, providing a clearer picture of when to take action and when to wait for a more stable move.

Miscellaneous
Implements a curve of type %1
16 Views
0 Downloads
0 Favorites
StepChoppy_v2
//+------------------------------------------------------------------+
//|                                              StepChoppy_v2.mq4 |
//|                                  Copyright © 2007, Forex-TSD.com |
//|                         Written by IgorAD,igorad2003@yahoo.co.uk |
//|            http://finance.groups.yahoo.com/group/TrendLaboratory |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2007, Forex-TSD.com "
#property link      "http://www.forex-tsd.com/"

#property indicator_separate_window
#property indicator_minimum -0.05
#property indicator_maximum 1.05
#property indicator_buffers 8
#property indicator_color1 MediumBlue
#property indicator_color2 Crimson
#property indicator_color3 DodgerBlue
#property indicator_color4 Tomato
#property indicator_color5 LightBlue
#property indicator_color6 Orange
#property indicator_color7 Aqua
#property indicator_color8 Yellow

#property indicator_width1 3
#property indicator_width2 3
#property indicator_width3 3
#property indicator_width4 3
#property indicator_width5 3
#property indicator_width6 3
#property indicator_width7 3
#property indicator_width8 3
//---- input parameters
extern int     Length         =    10;
extern double  Kv             =   1.0;
extern double  StepSize       =     0;
extern int     MA_Mode        =     0;
extern bool    HighLow        = false;
extern double  StepSizeFast   =     5;
extern double  StepSizeSlow   =    15;

int   MAPeriod =1;
int   Price    =0;
int   Mode     =2;
//---- buffers
double UpBuffer1[];
double UpBuffer2[];
double UpBuffer3[];
double UpBuffer4[];

double DnBuffer1[];
double DnBuffer2[];
double DnBuffer3[];
double DnBuffer4[];

//+------------------------------------------------------------------+
//| Custom indicator initialization function                         |
//+------------------------------------------------------------------+
int init()
  {

//----
   SetIndexStyle(0,DRAW_HISTOGRAM);
   SetIndexBuffer(0,UpBuffer1);
   SetIndexStyle(1,DRAW_HISTOGRAM);
   SetIndexBuffer(1,DnBuffer1);
   SetIndexStyle(2,DRAW_HISTOGRAM);
   SetIndexBuffer(2,UpBuffer2);
   SetIndexStyle(3,DRAW_HISTOGRAM);
   SetIndexBuffer(3,DnBuffer2);
   SetIndexStyle(4,DRAW_HISTOGRAM);
   SetIndexBuffer(4,UpBuffer3);
   SetIndexStyle(5,DRAW_HISTOGRAM);
   SetIndexBuffer(5,DnBuffer3);
   SetIndexStyle(6,DRAW_HISTOGRAM);
   SetIndexBuffer(6,UpBuffer4);
   SetIndexStyle(7,DRAW_HISTOGRAM);
   SetIndexBuffer(7,DnBuffer4);

//----
   string short_name="StepChoppy_v2";
   IndicatorShortName(short_name);
   SetIndexLabel(0,"Strong UpTrend");
   SetIndexLabel(1,"Retrace UpTrend");
   SetIndexLabel(2,"Choppy UpTrend");
   SetIndexLabel(3,"Be ready to change UpTrend");

   SetIndexLabel(4,"Strong DownTrend");
   SetIndexLabel(5,"Retrace DownTrend");
   SetIndexLabel(6,"Choppy DownTrend");
   SetIndexLabel(7,"Be ready to change DownTrend");
//----

   SetIndexDrawBegin(0,Length);
   SetIndexDrawBegin(1,Length);
   SetIndexDrawBegin(2,Length);
   SetIndexDrawBegin(3,Length);
   SetIndexDrawBegin(4,Length);
   SetIndexDrawBegin(5,Length);
   SetIndexDrawBegin(6,Length);
   SetIndexDrawBegin(7,Length);
//----
   return(0);
  }
//+------------------------------------------------------------------+
//| StepChoppy_v1.3                                                  |
//+------------------------------------------------------------------+
int start()
  {
   int  i,counted_bars=IndicatorCounted();
   double RSI, FastRSI, SlowRSI, StepMA, Trend;
//----
   if(Bars<=Length) return(0);
//---- initial zero
   if(counted_bars<1)
      for(i=1;i<=Length;i++)
      {
      UpBuffer1[Bars-i]=0.0;
      UpBuffer2[Bars-i]=0.0;
      UpBuffer3[Bars-i]=0.0;
      UpBuffer4[Bars-i]=0.0;

      DnBuffer1[Bars-i]=0.0;
      DnBuffer2[Bars-i]=0.0;
      DnBuffer3[Bars-i]=0.0;
      DnBuffer4[Bars-i]=0.0;
      }
//----
   if ( counted_bars > 0 )  int limit=Bars-counted_bars;
   if ( counted_bars ==0 )  limit=Bars-Length-1;

   for(i=limit;i>=0;i--)
   {
   Trend  = iCustom(NULL,0,"StepMA_v7",Length,Kv,StepSize,MA_Mode,0,0,HighLow,2,0,5,i);

   RSI=iCustom(NULL,0,"StepRSI_v5.2",Length,StepSizeFast,MAPeriod,Price,Mode,0,i);
   FastRSI=iCustom(NULL,0,"StepRSI_v5.2",Length,StepSizeFast,MAPeriod,Price,Mode,1,i);
   SlowRSI=iCustom(NULL,0,"StepRSI_v5.2",Length,StepSizeSlow,MAPeriod,Price,Mode,1,i);

   UpBuffer1[i] =EMPTY;
   UpBuffer2[i] =EMPTY;
   UpBuffer3[i] =EMPTY;
   UpBuffer4[i] =EMPTY;

   DnBuffer1[i] =EMPTY;
   DnBuffer2[i] =EMPTY;
   DnBuffer3[i] =EMPTY;
   DnBuffer4[i] =EMPTY;

   if (FastRSI > SlowRSI && RSI > FastRSI && Trend > 0)
   {UpBuffer1[i] = 1.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = 0.0;
    DnBuffer1[i] = 0.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = 0.0;}

   else if (FastRSI > SlowRSI && RSI < FastRSI && Trend > 0)
   {UpBuffer1[i] = 0.0;UpBuffer2[i] = 1.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = 0.0;
    DnBuffer1[i] = 0.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = 0.0;}

   else if (FastRSI < SlowRSI && RSI > FastRSI && Trend > 0)
   {UpBuffer1[i] = 0.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = 1.0;UpBuffer4[i] = 0.0;
    DnBuffer1[i] = 0.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = 0.0;}

   else if (FastRSI < SlowRSI && RSI < FastRSI && Trend > 0)
   {UpBuffer1[i] = 0.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = 1.0;
    DnBuffer1[i] = 0.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = 0.0;}


   else if (FastRSI < SlowRSI && RSI < FastRSI && Trend < 0)
   {UpBuffer1[i] = 0.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = 0.0;
    DnBuffer1[i] = 1.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = 0.0;}

   else if (FastRSI < SlowRSI && RSI > FastRSI && Trend < 0)
   {UpBuffer1[i] = 0.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = 0.0;
    DnBuffer1[i] = 0.0;DnBuffer2[i] = 1.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = 0.0;}

   else if (FastRSI > SlowRSI && RSI < FastRSI && Trend < 0)
   {UpBuffer1[i] = 0.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = 0.0;
    DnBuffer1[i] = 0.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = 1.0;DnBuffer4[i] = 0.0;}

   else if (FastRSI > SlowRSI && RSI > FastRSI && Trend < 0)
   {UpBuffer1[i] = 0.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = 0.0;
    DnBuffer1[i] = 0.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = 1.0;}
   }

//----
   return(0);
  }
//+------------------------------------------------------------------+

Dependencies

StepMA_v7

This indicator calculates a quantized price trajectory by determining dynamic step sizes based on average range volatility and applying trend-dependent price boundaries.

StepRSI_v5.2

This indicator applies a staircase-style quantization to relative strength values, identifying significant structural shifts in price velocity while filtering out minor volatility noise.
