Slope Direction Line Alert_001
Download scriptThis tool is designed to analyze market trends by calculating a smoothed "slope" of price movement. Instead of looking at raw, erratic price changes, it uses a multi-layered mathematical approach to filter out market noise and identify the underlying direction of the trend more clearly.
Core Logic and Methodology
The script operates through a three-step calculation process:
1. Weighted Momentum Calculation The tool begins by calculating two different versions of a weighted moving average (WMA). It takes a shorter timeframe and a longer timeframe, then applies a specific mathematical formula to find the difference between them. This highlights the immediate momentum of the market—essentially identifying how fast and in what direction the price is moving relative to its recent history.
2. Smoothing the Signal To prevent the indicator from reacting too quickly to minor fluctuations (which could lead to false signals), the script takes the momentum results from the first step and applies a secondary smoothing pass. This creates a refined "Slope Line." By doing this, the tool ensures that only significant, sustained changes in price direction are highlighted, providing a cleaner visual trend on your chart.
3. Trend Identification and Signal Generation The script constantly compares the current value of the smoothed slope to its previous value to determine the market state:
- Uptrend: When the slope moves upward, the tool identifies an ascending trend and plots this data specifically for "Buy" signals.
- Downtrend: When the slope moves downward, it identifies a descending trend and plots this for "Sell" signals.
Automated Alerts
Beyond visual plotting, the script includes an automated notification system. It is programmed to monitor the moment the market shifts from one trend to another:
- Buy Signals: Triggered immediately when the slope switches from a downward direction to an upward direction.
- Sell Signals: Triggered immediately when the slope switches from an upward direction to a downward direction.
When these transitions occur, the user can be notified via on-screen sound alerts and automated email messages, providing real-time updates on trend changes without needing to watch the charts constantly.
//+------------------------------------------------------------------+
//| HMA.mq4
//| Copyright © 2006 WizardSerg <wizardserg@mail.ru>, ?? ??????? ForexMagazine #104
//| wizardserg@mail.ru
//| Revised by IgorAD,igorad2003@yahoo.co.uk |
//| Personalized by iGoR AKA FXiGoR for the Trend Slope Trading method (T_S_T)
//| Link:
//| contact: thefuturemaster@hotmail.com
//+------------------------------------------------------------------+
#property copyright "MT4 release WizardSerg <wizardserg@mail.ru>, ?? ??????? ForexMagazine #104"
#property link "wizardserg@mail.ru"
#property indicator_chart_window
#property indicator_buffers 3
#property indicator_color2 Blue
#property indicator_color3 Red
#property indicator_color1 Orange
#property indicator_width1 1
#property indicator_width2 1
#property indicator_width3 1
//---- input parameters
extern int period=20;
extern int method=1; // MODE_SMA
extern int price=0; // PRICE_CLOSE
extern int EmailON=1; // 0 = false 1 = true
extern int SoundON=1; // 0 = false 1 = true
//---- buffers
double Uptrend[];
double Dntrend[];
double ExtMapBuffer[];
double buff[];
//+------------------------------------------------------------------+
//| Custom indicator initialization function |
//+------------------------------------------------------------------+
int init()
{
IndicatorBuffers(3);
SetIndexBuffer(1, Uptrend);
//ArraySetAsSeries(Uptrend, true);
SetIndexBuffer(2, Dntrend);
//ArraySetAsSeries(Dntrend, true);
//SetIndexBuffer(2, ExtMapBuffer);
//ArraySetAsSeries(Uptrend, true);
SetIndexBuffer(0, ExtMapBuffer);
ArraySetAsSeries(ExtMapBuffer, true);
SetIndexStyle(0,DRAW_LINE);
SetIndexStyle(1,DRAW_LINE);
SetIndexStyle(2,DRAW_LINE);
IndicatorShortName("Slope Direction Line("+period+")");
return(0);
}
//+------------------------------------------------------------------+
//| Custor indicator deinitialization function |
//+------------------------------------------------------------------+
int deinit()
{
// ???? ????? ?????? ??????
return(0);
}
//+------------------------------------------------------------------+
//| ?????????? ??????? |
//+------------------------------------------------------------------+
double WMA(int x, int p)
{
return(iMA(NULL, 0, p, 0, method, price, x));
}
//+------------------------------------------------------------------+
//| Custom indicator iteration function |
//+------------------------------------------------------------------+
int start()
{
int counted_bars = IndicatorCounted();
if(counted_bars < 0)
return(-1);
int x = 0;
int p = MathSqrt(period);
int e = Bars - counted_bars + period + 1;
double vect[], trend[];
if(e > Bars)
e = Bars;
ArrayResize(vect, e);
ArraySetAsSeries(vect, true);
ArrayResize(trend, e);
ArraySetAsSeries(trend, true);
for(x = 0; x < e; x++)
{
vect[x] = 2*WMA(x, period/2) - WMA(x, period);
// Print("Bar date/time: ", TimeToStr(Time[x]), " close: ", Close[x], " vect[", x, "] = ", vect[x], " 2*WMA(p/2) = ", 2*WMA(x, period/2), " WMA(p) = ", WMA(x, period));
}
for(x = 0; x < e-period; x++)
ExtMapBuffer[x] = iMAOnArray(vect, 0, p, 0, method, x);
for(x = e-period; x >= 0; x--)
{
trend[x] = trend[x+1];
if (ExtMapBuffer[x]> ExtMapBuffer[x+1]) trend[x] =1;
if (ExtMapBuffer[x]< ExtMapBuffer[x+1]) trend[x] =-1;
if (trend[x]>0)
{ Uptrend[x] = ExtMapBuffer[x];
if (trend[x+1]<0) Uptrend[x+1]=ExtMapBuffer[x+1];
Dntrend[x] = EMPTY_VALUE;
}
else
if (trend[x]<0)
{
Dntrend[x] = ExtMapBuffer[x];
if (trend[x+1]>0) Dntrend[x+1]=ExtMapBuffer[x+1];
Uptrend[x] = EMPTY_VALUE;
}
buff[x] = trend[x];
//Print( " trend=",trend[x]);
}
if (EmailON==1 && Dntrend[0] != EMPTY_VALUE && Dntrend[1] == EMPTY_VALUE && isNewBar())
{
if (SoundON==1) Alert("SELL signal at Ask=",Ask,", Bid=",Bid,", Date=",TimeToStr(CurTime(),TIME_DATE)," ",TimeHour(CurTime()),":",TimeMinute(CurTime())," Symbol=",Symbol()," Period=",Period());
SendMail("SELL signal alert","SELL signal at Ask="+DoubleToStr(Ask,4)+", Bid="+DoubleToStr(Bid,4)+", Date="+TimeToStr(CurTime(),TIME_DATE)+" "+TimeHour(CurTime())+":"+TimeMinute(CurTime())+" Symbol="+Symbol()+" Period="+Period());
}
if (EmailON==1 && Uptrend[0] != EMPTY_VALUE && Uptrend[1] == EMPTY_VALUE && isNewBar())
{
if (SoundON==1) Alert("BUY signal at Ask=",Ask,", Bid=",Bid,", Time=",TimeToStr(CurTime(),TIME_DATE)," ",TimeHour(CurTime()),":",TimeMinute(CurTime())," Symbol=",Symbol()," Period=",Period());
SendMail("BUY signal alert","BUY signal at Ask="+DoubleToStr(Ask,4)+", Bid="+DoubleToStr(Bid,4)+", Date="+TimeToStr(CurTime(),TIME_DATE)+" "+TimeHour(CurTime())+":"+TimeMinute(CurTime())+" Symbol="+Symbol()+" Period="+Period());
}
return(0);
}
bool isNewBar()
{
static datetime lastbar=0;
datetime curbar = Time[0];
if(lastbar!=curbar)
{
lastbar=curbar;
return (true);
}
else
{
return(false);
}
}
//+------------------------------------------------------------------+
