Fisher_m11_v3
Download scriptThe Fisher Transformer is a technical analysis tool designed to identify price trends by calculating the momentum of market movements. Instead of simply showing where the price is, it focuses on the "speed" and direction of those moves, filtering out market noise to provide a clearer visual of the current trend.
Core Logic Overview
The script operates by analyzing specific price ranges over a set number of periods. It seeks to determine how far the current price is moving relative to the high and low points of that period. The logic follows a three-step process:
1. Price Position Mapping For every bar on the chart, the tool identifies the highest high and the lowest low within a predefined range (the "RangePeriods"). It then calculates the midpoint of the current price and determines where that midpoint sits relative to the highs and lows.
- If the price is near the top of the range, it produces a positive value.
- If the price is near the bottom, it produces a negative value.
2. Multi-Stage Smoothing To prevent the indicator from reacting too violently to tiny, insignificant price fluctuations (market "noise"), the script applies two layers of smoothing:
- Price Smoothing: It blends the current price location with previous data points based on a user-defined factor. This ensures that a single erratic tick doesn't cause a massive jump in the reading.
- Index Smoothing: Once the price location is stabilized, the script applies a second round of smoothing to the resulting index. This creates a fluid, continuous line rather than a jagged graph.
3. Trend Identification (The Fisher Index) The final calculation uses a logarithmic formula to convert the smoothed price data into a "Fisher Index." This specific mathematical approach helps highlight momentum shifts more effectively than standard moving averages.
- Upward Trend: When the final result is greater than zero, the indicator displays as a green histogram.
- Downward Trend: When the result falls below zero, it switches to a red histogram.
Summary for the User
Essentially, this tool acts as a momentum filter. By looking at the relationship between price extremes and smoothing out the "jitter" of the market, it attempts to give traders a visual cue of whether the current momentum is pushing upward or downward. It transforms raw price action into a cleaner visual signal of market direction.
//+------------------------------------------------------------------+
//| #(e-ValTrg)-HA MT.mq4 |
//| Fisher_m11.mq4 |
//| Copyright © 23.07.2006 MartinG |
//| http://home.arcor.de/cam06/fisher |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2007 ValTrg"
// #property copyright "Copyright © 23.07.2006 MartinG"
// #property link "http://home.arcor.de/cam06/fisher"
#property indicator_separate_window
//#property indicator_minimum -1
//#property indicator_maximum 1
#property indicator_buffers 3
#property indicator_color2 Lime
#property indicator_color3 Red
#property indicator_width2 2
#property indicator_width3 2
int LeftNum1=56;
int LeftNum2=56;
extern int RangePeriods=10;
extern double PriceSmoothing=0.67; // =0.67 bei Fisher_m10
extern double IndexSmoothing=0.50; // =0.50 bei Fisher_m10
string ThisName="Fisher_m11";
int DrawStart;
//---- buffers
double ExtMapBuffer1[];
double ExtMapBuffer2[];
double ExtMapBuffer3[];
double ExtMapBuffer4[];
//+------------------------------------------------------------------+
//| Custom indicator initialization function |
//+------------------------------------------------------------------+
int init()
{
//---- indicators
IndicatorBuffers(4);
SetIndexLabel(0,"Fish");
SetIndexStyle(0,DRAW_NONE);
SetIndexBuffer(0,ExtMapBuffer1);
SetIndexStyle(1,DRAW_HISTOGRAM);
SetIndexBuffer(1,ExtMapBuffer2);
SetIndexStyle(2,DRAW_HISTOGRAM);
SetIndexBuffer(2,ExtMapBuffer3);
SetIndexStyle(3,DRAW_NONE);
SetIndexBuffer(3,ExtMapBuffer4);
string Text=ThisName;
Text=Text+" (rPeriods "+RangePeriods;
Text=Text+", pSmooth "+DoubleToStr(PriceSmoothing,2);
Text=Text+", iSmooth "+DoubleToStr(IndexSmoothing,2);
Text=Text+") ";
IndicatorShortName(Text);
SetIndexLabel(1,NULL);
SetIndexLabel(2,NULL);
DrawStart=2*RangePeriods+4; // DrawStart= BarNumber calculated from left to right
SetIndexDrawBegin(1,DrawStart);
SetIndexDrawBegin(2,DrawStart);
if (PriceSmoothing>=1.0)
{
PriceSmoothing=0.9999;
Alert("Fish61: PriceSmothing factor has to be smaller 1!");
}
if (PriceSmoothing<0)
{
PriceSmoothing=0;
Alert("Fish61: PriceSmothing factor mustn''t be negative!");
}
if (IndexSmoothing>=1.0)
{
IndexSmoothing=0.9999;
Alert("Fish61: PriceSmothing factor has to be smaller 1!");
}
if (IndexSmoothing<0)
{
IndexSmoothing=0;
Alert("Fish61: PriceSmothing factor mustn''t be negative!");
}
//----
return(0);
}
//+------------------------------------------------------------------+
//| Custom indicator deinitialization function |
//+------------------------------------------------------------------+
int deinit()
{
//----
//----
return(0);
}
//+------------------------------------------------------------------+
//| Custom indicator iteration function |
//+------------------------------------------------------------------+
int start()
{
if (Bars<DrawStart)
{
Alert("Fish84: Not enough Bars loaded to calculate FisherIndicator with RangePeriods=",RangePeriods);
return(-1);
}
//----
int counted_bars=IndicatorCounted();
if (counted_bars<0) return(-1);
if (counted_bars>0) counted_bars--;
//----
int Position=Bars-counted_bars; // Position = BarPosition calculated from right to left
int LeftNum1=Bars-Position; // when more bars are loaded the Position of a bar changes but not its LeftNum
if (LeftNum1<RangePeriods+1)Position=Bars-RangePeriods-1;
while(Position>=0)
{
CalculateCurrentBar(Position);
Position--;
}
//----
return(0);
}
//+------------------------------------------------------------------+
//| Single Bar Calculation function |
//+------------------------------------------------------------------+
int CalculateCurrentBar(int pos)
{
double LowestLow, HighestHigh, GreatestRange, MidPrice;
double PriceLocation, SmoothedLocation, FishIndex, SmoothedFish;
//----
LowestLow = Low[Lowest(NULL,0,MODE_LOW,RangePeriods,pos)];
HighestHigh = High[Highest(NULL,0,MODE_HIGH,RangePeriods,pos)];
if (HighestHigh-LowestLow<0.1*Point)HighestHigh=LowestLow+0.1*Point;
GreatestRange=HighestHigh-LowestLow;
MidPrice = (High[pos]+Low[pos])/2;
// PriceLocation in current Range
if (GreatestRange!=0)
{
PriceLocation=(MidPrice-LowestLow)/GreatestRange;
PriceLocation= 2.0*PriceLocation - 1.0; // -> -1 < PriceLocation < +1
}
// Smoothing of PriceLocation
ExtMapBuffer4[pos]=PriceSmoothing*ExtMapBuffer4[pos+1]+(1.0-PriceSmoothing)*PriceLocation;
SmoothedLocation=ExtMapBuffer4[pos];
if (SmoothedLocation> 0.99) SmoothedLocation= 0.99; // verhindert, dass MathLog unendlich wird
if (SmoothedLocation<-0.99) SmoothedLocation=-0.99; // verhindert, dass MathLog minuns unendlich wird
// FisherIndex
if(1-SmoothedLocation!=0) FishIndex=MathLog((1+SmoothedLocation)/(1-SmoothedLocation));
else Alert("Fisher129: Unerlaubter Zustand bei Bar Nummer ",Bars-pos);
// Smoothing of FisherIndex
ExtMapBuffer1[pos]=IndexSmoothing*ExtMapBuffer1[pos+1]+(1.0-IndexSmoothing)*FishIndex;
if (Bars-pos<DrawStart)ExtMapBuffer1[pos]=0;
SmoothedFish=ExtMapBuffer1[pos];
if (SmoothedFish>0) // up trend
{
ExtMapBuffer2[pos]=SmoothedFish;
ExtMapBuffer3[pos]=0;
}
else // else down trend
{
ExtMapBuffer2[pos]=0;
ExtMapBuffer3[pos]=SmoothedFish;
}
//----
return(0);
}
//+------------------------------------------------------------------+
