This script is designed as a multi-timeframe analysis tool for the MetaTrader platform. It provides visual feedback on market trends by comparing current price action against a "fan" of moving averages across various timeframes simultaneously.
Core Functionality
1. Multi-Timeframe Analysis The tool allows you to monitor several different timeframes at once (e.g., M1, M5, H1, D1). For each timeframe you choose to activate, the script calculates the status of the market based on specific moving average settings.
2. The "Fan" Logic The "Fan" refers to a collection of multiple moving averages calculated for a specific timeframe. The logic checks these averages to determine market direction:
- Upward Trend: If all active moving averages in the fan are arranged in an ascending order (from smallest to largest value).
- Downward Trend: If all active moving averages in the fan are arranged in a descending order.
- Neutral/Wrong Status: If the moving averages are tangled or not clearly trending in one direction, the tool flags the status as "neutral" or "wrong."
3. Price Position Tracking Beyond just looking at the trend of the averages, the script also monitors the current price's relationship to that same "fan." It identifies whether the current market price is trading above or below the moving average group, providing an additional layer of confirmation for entry or exit signals.
4. Real-Time Visual Dashboard The script creates a text-based dashboard on your chart. This dashboard displays:
- Trend Indicators: Icons (such as arrows) that change color and direction based on whether the "fan" is pointing up, down, or is in an undecided state.
- Price Status: Indicators showing exactly where the price sits relative to the trend.
- Dynamic Labels: Clear text labels for each timeframe so you can easily identify which data belongs to which period.
5. Interactive Tracking Features The script includes a specific "Tracking" mode that allows users to pin a vertical line to a specific moment in history.
- Historical Review: You can move this line to analyze how the various timeframes interacted with the moving averages during a past market event.
- Sliding Mode: A "sliding" feature ensures that as new candles form, the tracked point moves accurately with the price action, allowing for real-time observation of historical data behavior.
Summary of User Experience
For a non-programmer, this tool acts as a high-level "sentiment dashboard." Instead of looking at eight different charts to see how the M5, H1, and Daily trends align, you can view them all in one corner of your screen. The script simplifies complex mathematical calculations into simple visual cues: if the arrows are aligned and pointing up across multiple timeframes, it suggests a synchronized bullish trend; if they are mixed or pointing down, it signals a lack of momentum or a bearish turn.
Price Data Components
Indicators Used
Miscellaneous
14
Views
0
Downloads
0
Favorites
FanSimple8_4MEn
//+------------------------------------------------------------------+
//| |
//| Copyright © 2000-2007, MetaQuotes Software Corp. |
//| http://www.metaquotes.ru |
//+------------------------------------------------------------------+
#include <stdlib.mqh>
//----
#property indicator_chart_window
#property indicator_buffers 8
/* Here's possible to change values, used by default */
/* Colors of a set of averages (put cursor on a name of the color, press F1 and to see names of other colors) */
#property indicator_color1 Gold
#property indicator_color2 Blue
#property indicator_color3 PaleTurquoise
#property indicator_color4 DodgerBlue
#property indicator_color5 Aqua
#property indicator_color6 Magenta
#property indicator_color7 Gray
#property indicator_color8 White
/* Main switch of display of correctness of a fan, allows to cut off display of set of periods */
extern bool DisplayFanStatus=true;
/* Main switch of display of averages, allows to cut off display of all set of averages */
extern bool DisplayFan=true;
/* Values of the periods of a set timeframes, from left to right (recurrences are possible, "0" and wrong values will not be included in a set) */
extern int Timeframe1=PERIOD_M1;
extern int Timeframe2=PERIOD_M5;
extern int Timeframe3=PERIOD_M15;
extern int Timeframe4=PERIOD_M30;
extern int Timeframe5=PERIOD_H1;
extern int Timeframe6=PERIOD_H4;
extern int Timeframe7=PERIOD_D1;
extern int Timeframe8=PERIOD_W1;
extern int Timeframe9=0;
extern datetime TrackingTime=0;
/* Date and time for which correctness of a fan displayed */
extern bool Tracking=false;
/*to draw (or not) a vertical line through a traced bar */
extern bool Sliding=true;
/* to shift (or not) a point of tracking with formation of a following bar ïðàâèëüíîñòü êîòîðîãî îòñëåæèâàåòñÿ (0-âûå è íåïðàâèëüíûå çíà÷åíèÿ âêëþ÷åíû â íàáîð íå áóäóò) */
extern string SlidingSound="";
/*Name of a soundfile played at shift of a tracking point*/
extern int MA1=55;
extern int MA2=21;
extern int MA3=5;
extern int MA4=0;
extern int MA5=0;
extern int MA6=0;
extern int MA7=0;
extern int MA8=0;
/* Values of the periods of a set of averages combined into a fan, correctness of which is traced ("0" and wrong values will not be included in a set) */
/*Individual knife switch to display of each average*/
extern bool DisplayMA1=true;
extern bool DisplayMA2=true;
extern bool DisplayMA3=true;
extern bool DisplayMA4=true;
extern bool DisplayMA5=true;
extern bool DisplayMA6=true;
extern bool DisplayMA7=true;
extern bool DisplayMA8=true;
/* Font Name */
extern string FontName="Wingdings";
/* Font Size */
extern int FontSize=12;
/* Symbols of the drawn and erased index of position of the price in regard to a fan */
extern int PriceOnSymbol=108; // Circle
extern int PriceOffSymbol=32; // Space
/* Colors of the drawn index of position of the price relative to a fan */
extern color PriceColor=LimeGreen;
/* Symbols of the index of correctness of a fan */
extern int FanWrongSymbol=117; // Diamond
extern int FanUpSymbol=233; // Up Arrow
extern int FanDownSymbol=234; // Down Arrow
/* Colors of the index of correctness of a fan */
extern color FanWrongColor=DarkGray;
extern color FanUpColor=DodgerBlue;
extern color FanDownColor=OrangeRed;
/* Displacement to the left (X) and to the right (Y) from the right top corner */
extern int X=0;
extern int Y=0;
// Tracking vertical line label and color
#define TRACKING_NAME "Bar, traced by indicator FanSimple"
#define TRACKING_COLOR DarkGray
//----
string RowName[3]={ "Price above the Fan",
"Fan Status",
"Price below the Fan" };
// Type of rendering codes
#define is_down 0
#define is_none 1
#define is_up 2
//----
int Timeframe[9];
string TimeframeNames[9];
int TimeframeInUse=0;
//----
int MAs[8];
int Xlat[8];
int MAsInUse=0;
//----
double MA1Buf[], MA2Buf[], MA3Buf[], MA4Buf[], MA5Buf[], MA6Buf[], MA7Buf[], MA8Buf[];
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
string LabelName(int i, int j) { return(RowName[j] + "(" + (i + 1) + "): " + TimeframeNames[i]); }
//----
int symcolor[3][2];
int syms[3][2];
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
void UpdateFanStatus(int i, int how)
{
string s=" ";
ObjectSetText(LabelName(i, 1), StringSetChar(s, 0, symcolor[how][0]), FontSize, FontName, symcolor[how][1]);
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
void UpdatePriceStatus(int i, int how)
{
string s=" ";
ObjectSetText(LabelName(i, 0), StringSetChar(s, 0, syms[how][0]), FontSize, FontName, PriceColor);
ObjectSetText(LabelName(i, 2), StringSetChar(s, 0, syms[how][1]), FontSize, FontName, PriceColor);
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
void InitTimeframe(int &P[], int PV)
{
if(PV!=0)
{
switch(PV)
{
case PERIOD_M1: TimeframeNames[TimeframeInUse]="M1"; break;
case PERIOD_M5: TimeframeNames[TimeframeInUse]="M5"; break;
case PERIOD_M15: TimeframeNames[TimeframeInUse]="M15"; break;
case PERIOD_M30: TimeframeNames[TimeframeInUse]="M30"; break;
case PERIOD_H1: TimeframeNames[TimeframeInUse]="H1"; break;
case PERIOD_H4: TimeframeNames[TimeframeInUse]="H4"; break;
case PERIOD_D1: TimeframeNames[TimeframeInUse]="D1"; break;
case PERIOD_W1: TimeframeNames[TimeframeInUse]="W1"; break;
case PERIOD_MN1: TimeframeNames[TimeframeInUse]="MN1"; break;
default: return;
}
P[TimeframeInUse]=PV; TimeframeInUse++;
}
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
void InitMAs(int &P[], int MA) { if(MA > 0) { P[MAsInUse]=MA; MAsInUse++; } }
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
int init()
{
int i, j;
if(DisplayFanStatus)
{
syms[0][0]=PriceOffSymbol; syms[0][1]=PriceOnSymbol;
syms[1][0]=PriceOffSymbol; syms[1][1]=PriceOffSymbol;
syms[2][0]=PriceOnSymbol; syms[2][1]=PriceOffSymbol;
InitTimeframe(Timeframe, Timeframe1); InitTimeframe(Timeframe, Timeframe2); InitTimeframe(Timeframe, Timeframe3); InitTimeframe(Timeframe, Timeframe4);
InitTimeframe(Timeframe, Timeframe5); InitTimeframe(Timeframe, Timeframe6); InitTimeframe(Timeframe, Timeframe7); InitTimeframe(Timeframe, Timeframe8);
InitTimeframe(Timeframe, Timeframe9);
InitMAs(MAs, MA1); InitMAs(MAs, MA2); InitMAs(MAs, MA3); InitMAs(MAs, MA4);
InitMAs(MAs, MA5); InitMAs(MAs, MA6); InitMAs(MAs, MA7); InitMAs(MAs, MA8);
for(i=0; i < MAsInUse; i++) Xlat[i]=i;
for(i=0; i < MAsInUse - 1; i++)
for(j=i + 1; j < MAsInUse; j++)
if(MAs[Xlat[i]] > MAs[Xlat[j]]) { int k=Xlat[j]; Xlat[j]=Xlat[i]; Xlat[i]=k; }
for(i=0; i < TimeframeInUse; i++)
for(j=0; j < 3; j++)
{
string s=LabelName(i, j);
//----
ObjectCreate(s, OBJ_LABEL, 0, 0, 0);
ObjectSet(s, OBJPROP_XDISTANCE, (TimeframeInUse - i - 1) * 13 * FontSize/10 + 2 * FontSize/10 + X);
ObjectSet(s, OBJPROP_YDISTANCE, j * 16 * FontSize/10 + 3 * FontSize/10 + Y);
ObjectSet(s, OBJPROP_BACK, true);
ObjectSet(s, OBJPROP_CORNER, 1);
ObjectSetText(s, " ", FontSize, FontName, Black);
}
//----
if(Tracking)
{
ObjectCreate(TRACKING_NAME, OBJ_VLINE, 0, TrackingTime, 0);
ObjectSet(TRACKING_NAME, OBJPROP_COLOR, TRACKING_COLOR);
}
}
//----
if(DisplayFan)
{
string IndicatorName="FanSimple(";
symcolor[0][0]=FanDownSymbol; symcolor[0][1]=FanDownColor;
symcolor[1][0]=FanWrongSymbol; symcolor[1][1]=FanWrongColor;
symcolor[2][0]=FanUpSymbol; symcolor[2][1]=FanUpColor;
//----
if(DisplayMA1 && MA1 > 0) IndicatorName=IndicatorName + MA1; if(DisplayMA2 && MA2 > 0) IndicatorName=IndicatorName + ", " + MA2;
if(DisplayMA3 && MA3 > 0) IndicatorName=IndicatorName + ", " + MA3; if(DisplayMA4 && MA4 > 0) IndicatorName=IndicatorName + ", " + MA4;
if(DisplayMA5 && MA5 > 0) IndicatorName=IndicatorName + ", " + MA5; if(DisplayMA6 && MA6 > 0) IndicatorName=IndicatorName + ", " + MA6;
if(DisplayMA7 && MA7 > 0) IndicatorName=IndicatorName + ", " + MA7; if(DisplayMA8 && MA8 > 0) IndicatorName=IndicatorName + ", " + MA8;
IndicatorShortName(IndicatorName + ")");
IndicatorBuffers(8);
SetIndexBuffer(0, MA1Buf); SetIndexBuffer(1, MA2Buf); SetIndexBuffer(2, MA3Buf); SetIndexBuffer(3, MA4Buf);
SetIndexBuffer(4, MA5Buf); SetIndexBuffer(5, MA6Buf); SetIndexBuffer(6, MA7Buf); SetIndexBuffer(7, MA8Buf);
SetIndexLabel(0, "Fan,MA( " + MA1 + ")"); SetIndexLabel(1, "Fan, MA(" + MA2 + ")");
SetIndexLabel(2, "Fan,MA( " + MA3 + ")"); SetIndexLabel(3, "Fan, MA( " + MA4 + ")");
SetIndexLabel(4, "Fan,MA( " + MA5 + ")"); SetIndexLabel(5, "Fan, MA( " + MA6 + ")");
SetIndexLabel(6, "Fan,MA( " + MA7 + ")"); SetIndexLabel(7, "Fan, MA(" + MA8 + ")");
//----
for(i=0; i < 7; i++)
{
SetIndexStyle(i, DRAW_LINE, EMPTY, 1);
SetIndexEmptyValue(i, 0);
}
//----
ArraySetAsSeries(MA1Buf, true); ArraySetAsSeries(MA2Buf, true); ArraySetAsSeries(MA3Buf, true); ArraySetAsSeries(MA4Buf, true);
ArraySetAsSeries(MA5Buf, true); ArraySetAsSeries(MA6Buf, true); ArraySetAsSeries(MA7Buf, true); ArraySetAsSeries(MA8Buf, true);
for(i=Bars - 1; i>=0; i--)
{
MA1Buf[i]=0; MA2Buf[i]=0; MA3Buf[i]=0; MA4Buf[i]=0; MA5Buf[i]=0; MA6Buf[i]=0; MA7Buf[i]=0; MA8Buf[i]=0;
}
}
return(0);
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
int deinit()
{
for(int i=0; i < TimeframeInUse; i++)
for(int j=0; j < 3; j++)
ObjectDelete(LabelName(i, j));
//----
if(Tracking)
ObjectDelete(TRACKING_NAME);
return(0);
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
int start()
{
int i;
datetime NewTrackingTime=TrackingTime;
static datetime time=0;
//----
if(time==0)
{
if(TrackingTime==0)
TrackingTime=Time[0];
i=((TimeDay(TrackingTime) * 24 + TimeHour(TrackingTime)) * 60 + TimeMinute(TrackingTime)) * 60 + TimeSeconds(TrackingTime);
TrackingTime-=i;
i/=60;
i-=i%Period();
TrackingTime+=i * 60;
if(Tracking)
ObjectSet(TRACKING_NAME, OBJPROP_TIME1, TrackingTime);
else
NewTrackingTime=TrackingTime;
}
//-----
if(Tracking)
NewTrackingTime=ObjectGet(TRACKING_NAME, OBJPROP_TIME1);
/* Ïîëüçîâàòåëü ñäâèíóë òî÷êó ñëåæåíèÿ èëè òî÷êà ñëåæåíèÿ - ïîñëåäíèé áàð èëè ïîÿâèëñÿ íîâûé áàð */
if(NewTrackingTime!=TrackingTime || (CurTime() - TrackingTime)/60 < Period() || time!=Time[0])
{
if(DisplayFanStatus)
for(i=0; i < TimeframeInUse; i++)
{
bool Up=true, Down=true;
bool PriceUp=true, PriceDown=true;
int LocalShift=iBarShift(Symbol(), Timeframe[i], NewTrackingTime + (Period() - 1) * 60);
double PrevMA=0;
//----
for(int j=0; j < MAsInUse; j++)
{
double MA=iMA(Symbol(), Timeframe[i], MAs[Xlat[j]], 0, MODE_EMA, PRICE_CLOSE, LocalShift);
if(j > 0) { if(Up && PrevMA < MA) Up=false; if(Down && PrevMA > MA) Down=false; }
if(PriceUp && MA > iClose(Symbol(), Timeframe[i], LocalShift)) PriceUp=false;
if(PriceDown && MA < iClose(Symbol(), Timeframe[i], LocalShift)) PriceDown=false;
PrevMA=MA;
}
//----
if(Up) UpdateFanStatus(i, is_up); else if(Down) UpdateFanStatus(i, is_down); else UpdateFanStatus(i, is_none);
if(PriceUp) UpdatePriceStatus(i, is_up); else if(PriceDown) UpdatePriceStatus(i, is_down); else UpdatePriceStatus(i, is_none);
}
if(DisplayFan)
for(i=Bars - IndicatorCounted() - 1; i>=0; i--)
{
if(DisplayMA1 && MA1 > 0) MA1Buf[i]=iMA(Symbol(), 0, MA1, 0, MODE_SMMA, PRICE_TYPICAL, i);
if(DisplayMA2 && MA2 > 0) MA2Buf[i]=iMA(Symbol(), 0, MA2, 0, MODE_SMMA, PRICE_TYPICAL, i);
if(DisplayMA3 && MA3 > 0) MA3Buf[i]=iMA(Symbol(), 0, MA3, 0, MODE_SMMA, PRICE_TYPICAL, i);
if(DisplayMA4 && MA4 > 0) MA4Buf[i]=iMA(Symbol(), 0, MA4, 0, MODE_EMA, PRICE_CLOSE, i);
if(DisplayMA5 && MA5 > 0) MA5Buf[i]=iMA(Symbol(), 0, MA5, 0, MODE_EMA, PRICE_CLOSE, i);
if(DisplayMA6 && MA6 > 0) MA6Buf[i]=iMA(Symbol(), 0, MA6, 0, MODE_EMA, PRICE_CLOSE, i);
if(DisplayMA7 && MA7 > 0) MA7Buf[i]=iMA(Symbol(), 0, MA7, 0, MODE_EMA, PRICE_CLOSE, i);
if(DisplayMA8 && MA8 > 0) MA8Buf[i]=iMA(Symbol(), 0, MA8, 0, MODE_EMA, PRICE_CLOSE, i);
}
//----
if(time!=Time[0])
{
if(Sliding && time!=0)
NewTrackingTime+=Time[0] - time;
time=Time[0];
}
if(Tracking && NewTrackingTime!=TrackingTime)
ObjectSet(TRACKING_NAME, OBJPROP_TIME1, NewTrackingTime);
if(StringLen(SlidingSound)!=0 && NewTrackingTime!=TrackingTime)
PlaySound(SlidingSound);
TrackingTime=NewTrackingTime;
}
return(0);
}
//+------------------------------------------------------------------+
