Volume with custom MA_v1
Download scriptThis script is a specialized technical analysis tool designed for the MetaTrader 4 platform. Its primary purpose is to provide a visual representation of trading volume while integrating a customizable moving average to help traders identify trends and momentum in market activity.
Core Functionality
The indicator operates by analyzing the "Volume" data—which represents the amount of asset traded within specific timeframes. It processes this information in three distinct ways:
1. Dynamic Volume Histogram Instead of showing a single generic bar for volume, this script differentiates between rising and falling activity using color-coded histograms:
- Green Bars: These appear when the current volume is higher than the previous period's volume, signaling an increase in trading intensity.
- Red Bars: These appear when the current volume is lower than the previous period's volume, indicating a decrease in trading activity.
- Consistency Logic: If the volume remains exactly the same as the previous bar, the script intelligently maintains the color of the previous bar to ensure a seamless visual transition on your chart.
2. Customizable Moving Averages The script overlays a "Moving Average" line (shown in white) over the volume data. This helps smooth out short-term fluctuations so you can see the broader trend of trading activity. The tool is highly flexible, allowing users to choose from four different calculation methods based on their preference:
- Simple Moving Average (SMA): A basic average that treats all data points equally.
- Exponential Moving Average (EMA): Gives more weight to recent data, making it more responsive to sudden price or volume shifts.
- Smoothed Moving Average (SMMA): A slower-moving average that filters out noise more aggressively.
- Linear Weighted Moving Average (LWMA): Applies a linear weight to the data, emphasizing the most recent bars even more than the SMA.
How It Benefits the Trader
By combining these elements, the script provides a "dual-layered" view of market health:
- The Histogram gives you an immediate, at-a-glance sense of whether trading momentum is accelerating or slowing down (the "heartbeat" of the market).
- The Moving Average line acts as a baseline, helping you determine if current volume levels are unusually high or low compared to recent history.
Key Settings
Users can personalize the behavior of the tool through several inputs:
- MA Period: Determines how many previous bars are used to calculate the moving average (the longer the period, the smoother the line).
- MA Shift: Adjusts the visual position of the data forward or backward on the chart.
- MA Method: Allows the user to toggle between the four different types of moving averages mentioned above.
/*-----------------------------+
| |
| Shared by www.Aptrafx.com |
| |
+------------------------------*/
//+------------------------------------------------------------------+
//| Volume with Custom Moving Average.mq4 |
//| Copyright © 2004, MetaQuotes Software Corp. |
//| http://www.metaquotes.net/ |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2004, MetaQuotes Software Corp. Modified RonT"
#property link "http://www.metaquotes.net/"
#property indicator_separate_window
#property indicator_buffers 3
#property indicator_color1 Red
#property indicator_color2 Green
#property indicator_color3 White
// User input
extern int MA_Period=13;
extern int MA_Shift=0;
extern int MA_Method=0;
// Buffers
double VolBuffer1[]; // value down
double VolBuffer2[]; // value up
double VolBuffer3[]; // moving average
//----
int ExtCountedBars=0;
int lastcolor=0;
//+------------------------------------------------------------------+
//| Custom indicator initialization function |
//+------------------------------------------------------------------+
int init()
{
int draw_begin;
string short_name;
// indicator buffers mapping, drawing settings and Shift
// Histogram downArrow Red
SetIndexBuffer(0,VolBuffer1);
SetIndexStyle(0,DRAW_HISTOGRAM);
SetIndexShift(0,MA_Shift);
// Histogram upArrow Green
SetIndexBuffer(1,VolBuffer2);
SetIndexStyle(1,DRAW_HISTOGRAM);
SetIndexShift(1,MA_Shift);
// Moving average line white
SetIndexBuffer(2,VolBuffer3);
SetIndexStyle(2,DRAW_LINE);
SetIndexShift(2,MA_Shift);
IndicatorDigits(MarketInfo(Symbol(),MODE_DIGITS));
if(MA_Period<2) MA_Period=2;
draw_begin=MA_Period-1;
switch(MA_Method)
{
case 1 : short_name="EMA(" ; draw_begin=0; break;
case 2 : short_name="SMMA("; break;
case 3 : short_name="LWMA("; break;
default : short_name="SMA(" ; MA_Method=0;
}
IndicatorShortName(short_name+MA_Period+")");
SetIndexDrawBegin(0,draw_begin);
return(0);
}
//+------------------------------------------------------------------+
//| Main |
//+------------------------------------------------------------------+
int start()
{
if(Bars<=MA_Period) return(0);
ExtCountedBars=IndicatorCounted();
// check for possible errors
if (ExtCountedBars<0) return(-1);
// last counted bar will be recounted
if (ExtCountedBars>0) ExtCountedBars--;
switch(MA_Method)
{
case 0 : sma(); break;
case 1 : ema(); break;
case 2 : smma(); break;
case 3 : lwma();
}
return(0);
}
//+------------------------------------------------------------------+
//| Simple Moving Average |
//+------------------------------------------------------------------+
void sma()
{
double sum=0;
int i,pos=Bars-ExtCountedBars-1;
// initial accumulation
if(pos<MA_Period) pos=MA_Period;
for(i=1;i<MA_Period;i++,pos--)
sum+=Volume[pos];
while(pos>=0)
{
sum+=Volume[pos];
VolBuffer3[pos]=sum/MA_Period;
sum-=Volume[pos+MA_Period-1];
Vcolor(pos);
pos--;
}
// zero initial bars
if(ExtCountedBars<1)
for(i=1;i<MA_Period;i++) VolBuffer1[Bars-i]=0;
}
//+------------------------------------------------------------------+
//| Exponential Moving Average |
//+------------------------------------------------------------------+
void ema()
{
double pr=2.0/(MA_Period+1);
int pos=Bars-2;
if(ExtCountedBars>2) pos=Bars-ExtCountedBars-1;
while(pos>=0)
{
if(pos==Bars-2) VolBuffer3[pos+1]=Volume[pos+1];
VolBuffer3[pos]=Volume[pos]*pr+VolBuffer3[pos+1]*(1-pr);
Vcolor(pos);
pos--;
}
}
//+------------------------------------------------------------------+
//| Smoothed Moving Average |
//+------------------------------------------------------------------+
void smma()
{
double sum=0;
int i,k,pos=Bars-ExtCountedBars+1;
pos=Bars-MA_Period;
if(pos>Bars-ExtCountedBars) pos=Bars-ExtCountedBars;
while(pos>=0)
{
if(pos==Bars-MA_Period)
{
// initial accumulation
for(i=0,k=pos;i<MA_Period;i++,k++)
{
sum+=Volume[k];
// zero initial bars
VolBuffer3[k]=0;
}
}
else sum=VolBuffer3[pos+1]*(MA_Period-1)+Volume[pos];
VolBuffer3[pos]=sum/MA_Period;
pos--;
}
}
//+------------------------------------------------------------------+
//| Linear Weighted Moving Average |
//+------------------------------------------------------------------+
void lwma()
{
double sum=0.0,lsum=0.0;
double price;
int i,weight=0,pos=Bars-ExtCountedBars-1;
//---- initial accumulation
if(pos<MA_Period) pos=MA_Period;
for(i=1;i<=MA_Period;i++,pos--)
{
price=Volume[pos];
sum+=price*i;
lsum+=price;
weight+=i;
}
//---- main calculation loop
pos++;
i=pos+MA_Period;
while(pos>=0)
{
VolBuffer3[pos]=sum/weight;
if(pos==0) break;
pos--;
i--;
price=Volume[pos];
sum=sum-lsum+price*MA_Period;
lsum-=Volume[i];
lsum+=price;
}
//---- zero initial bars
if(ExtCountedBars<1)
for(i=1;i<MA_Period;i++) VolBuffer3[Bars-i]=0;
}
//+------------------------------------------------------------------+
//| Color depends on gain or loss and previous volume |
//+------------------------------------------------------------------+
// 1 - histo down red
// 2 - histo up green
// 3 - line white
void Vcolor(int p)
{
if (Volume[p+1]>Volume[p])
{
VolBuffer1[p]=Volume[p];
VolBuffer2[p]=0;
lastcolor=Red;
}
if (Volume[p+1]<Volume[p])
{
VolBuffer1[p]=0;
VolBuffer2[p]=Volume[p];
lastcolor=Green;
}
if (Volume[p+1]==Volume[p])
{
if ( lastcolor==Red )
{
VolBuffer1[p]=Volume[p];
VolBuffer2[p]=0;
}
if ( lastcolor==Green )
{
VolBuffer1[p]=0;
VolBuffer2[p]=Volume[p];
}
}
}
//+------------------------------------------------------------------+
