V-TBv6
Download scriptThis technical indicator is designed to identify specific price action patterns on a trading chart, specifically focusing on "wicks" (the thin lines on a candlestick) relative to the size of the candle's main body. It aims to highlight moments of potential price rejection or exhaustion by scanning for specific geometric relationships between consecutive candles.
Core Logic and Detection Mechanisms
The script functions by analyzing several distinct layers of data simultaneously:
1. Wick and Body Proportions The primary logic revolves around "Wick Ratios." The tool calculates the length of a candle's upper and lower wicks and compares them to the size of the candle’s actual body. It looks for instances where the wick is significantly larger than the body, which often suggests that the price tried to move in one direction but was pushed back quickly.
2. Price Movement Context (The "State Table") To ensure the signals are meaningful, the script doesn't just look at one candle in isolation. It compares the current candle's direction (Bullish or Bearish) against the direction of the previous candle. It categorizes these interactions into four distinct "states":
- Bearish followed by Bullish
- Bearish followed by Bearish
- Bullish followed by Bullish
- Bullish followed by Bearish
3. Penetration and Confirmation The indicator includes a "Penetration" check. This determines if the price action was strong enough to actually reach into the previous candle's territory. It calculates a percentage of the wick's length to see if the current price movement "pierced" the previous candle's area, adding a layer of verification to ensure the move has significant momentum or intent.
4. Volatility Filtering ("Juice") Not every price movement is considered a valid signal. The script utilizes a volatility calculation (Standard Deviation) to determine if there is enough "Juice"—or sufficient market activity—to trigger an alert. If the market is too stagnant or the movement is too minor, the indicator will ignore the pattern, filtering out "noise" and focusing only on high-energy price movements.
Visual Outputs and Alerts
- Visual Markers: When the specific conditions for a top or bottom rejection are met, the script places colored arrows on the chart (Red for tops, Green for bottoms).
- Audio Notifications: The logic includes an optional sound alert system that triggers whenever a "Top" or "Bottom" signal is identified in real-time.
- Dynamic Adjustment: The script is designed to be sensitive to different timeframes, automatically adjusting its internal sensitivity levels (such as the Juice Level) when used on shorter 5-minute charts to maintain accuracy across different market speeds.
//+------------------------------------------------------------------+
//| V-T&B.mq4 |
//| Don Lawson (don_forex) |
//+------------------------------------------------------------------+
#property copyright "Coded by Don Lawson (don_forex)"
#property link "d_n_d_enterprises@sbcglobal.net"
//----
#property indicator_chart_window
#property indicator_buffers 2
#property indicator_color1 Red
#property indicator_width1 2
#property indicator_color2 Green
#property indicator_width2 2
//----
extern double WickRatio =0.5;
extern double WickPercent =50;
extern int JuicePeriod =7;
extern int JuiceLevelForAlert=5;
//----
extern bool Notify=false;
extern bool UseNew=true;
//----
double VTop[];
double VBottom[];
double DistanceFromCandle;
int Level=5;
//+------------------------------------------------------------------+
//| Custom indicator initialization function |
//+------------------------------------------------------------------+
int init()
{
//---- indicators
SetIndexStyle(0, DRAW_ARROW, EMPTY);
SetIndexArrow(0, 234);
SetIndexBuffer(0, VTop);
SetIndexStyle(1, DRAW_ARROW, EMPTY);
SetIndexArrow(1, 233);
SetIndexBuffer(1, VBottom);
//----
return(0);
}
//+------------------------------------------------------------------+
//| Custom indicator deinitialization function |
//+------------------------------------------------------------------+
int deinit()
{
//----
//----
return(0);
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
void SetVTop(int index)
{
double Juice, JuiceLevel;
// Check for Juice
JuiceLevel=Level*Point;
if (Period()==5)JuiceLevel=JuiceLevel/2;
//----
Juice=iStdDev (NULL,0,JuicePeriod,MODE_EMA,0,PRICE_CLOSE,index)-JuiceLevel;
if (Juice > JuiceLevelForAlert*Point) {
VTop[index]=High[index]+ DistanceFromCandle;
if (Notify) PlaySound("V-Top.wav");
}
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
void SetVBottom(int index)
{
double Juice, JuiceLevel;
// Check for Juice
JuiceLevel=Level*Point;
if (Period()==5)JuiceLevel=JuiceLevel/2;
//----
Juice=iStdDev (NULL,0,JuicePeriod,MODE_EMA,0,PRICE_CLOSE,index)-JuiceLevel;
if (Juice > JuiceLevelForAlert*Point)
{
VBottom[index]=Low[index]- DistanceFromCandle;
if (Notify) PlaySound("V-Bottom.wav");
}
}
//+------------------------------------------------------------------+
//| Custom indicator iteration function |
//+------------------------------------------------------------------+
int start()
{
int limit, i,State;
double WickPenetration;
double BullWickPenHi,BullWickPenLow;
double BearWickPenHi,BearWickPenLow;
double BullWickHi,BullWickLow,BullBody;
double BearWickHi,BearWickLow,BearBody;
int counted_bars=IndicatorCounted();
//---- check for possible errors
if(counted_bars<0) return(-1);
//---- last counted bar will be recounted
if(counted_bars>0) counted_bars--;
limit=Bars-counted_bars;
//----
WickPenetration=WickPercent/100.0;
DistanceFromCandle=Point*8;
for(i=1; i<=limit; i++)
{
bool CurrentBull =false,
CurrentBear =false,
Bull =false,
Bear =false,
HiWick =false,
LoWick =false;
//----
if (Open[i-1]<Close[i-1])
CurrentBull=true;
else
CurrentBear=true;
if (Open[i]<Close[i])
Bull=true;
else
Bear=true;
//----
BullWickHi=High[i] - Close[i];
BullWickLow=Open[i] - Low[i];
BullBody=Close[i] - Open[i];
BearWickHi=High[i] - Open[i];
BearWickLow=Close[i] - Low[i];
BearBody=Open[i] - Close[i];
// Check for VTOP
if (High[i] > High[i+1])
{
if (Bull)
{
if ((BullWickHi > BullBody * WickRatio))// && (BullWickHi > BullWickLow)
HiWick=true;
}
if (Bear)
{
if ((BearWickHi > BearBody * WickRatio))// && (BearWickHi > BearWickLow)
HiWick=true;
}
}
// Check for VBottom
if (Low[i] < Low[i+1])
{
if (Bull)
{
if ((BullWickLow > BullBody * WickRatio))// && (BullWickLow > BullWickHi)
LoWick=true;
}
if (Bear)
{
if ((BearWickLow > BearBody * WickRatio))// && (BearWickLow > BearWickHi)
LoWick=true;
}
}
// Set up State Table
if (CurrentBear && Bull) State=1;
if (CurrentBear && Bear) State=2;
if (CurrentBull && Bull) State=3;
if (CurrentBull && Bear) State=4;
// Set Arrow
if (HiWick)
{
BullWickPenHi=Close[i] + BullWickHi * WickPenetration;
BearWickPenHi=Open[i] + BearWickHi * WickPenetration;
switch(State)
{
case 1 : // CurrentBear && Bull
if (UseNew)
{
if(Open[i-1] < BullWickPenHi) SetVTop(i);
}
else
{
SetVTop(i);
}
break;
case 2 : // CurrentBear && Bear
if (UseNew)
{
if (Open[i-1] < BearWickPenHi) SetVTop(i);
}
else
{
SetVTop(i);
}
break;
case 3 : // CurrentBull && Bull
if (UseNew)
{
if (Close[i-1] < BullWickPenHi) SetVTop(i);
}
else
{
SetVTop(i);
}
break;
case 4 : // CurrentBull && Bear
if (UseNew)
{
if (Close[i-1] < BearWickPenHi) SetVTop(i);
}
else
{
SetVTop(i);
}
break;
}
}
if (LoWick)
{
BullWickPenLow=Open[i] - BullWickLow * WickPenetration;
BearWickPenLow=Close[i] - BearWickLow * WickPenetration;
//----
switch(State)
{
case 1 : // CurrentBear && Bull
if (UseNew)
{
if (Close[i-1] > BullWickPenLow) SetVBottom(i);
}
else
{
SetVBottom(i);
}
break;
case 2 : // CurrentBear && Bear
if (UseNew)
{
if (Close[i-1] > BearWickPenLow) SetVBottom(i);
}
else
{
SetVBottom(i);
}
break;
case 3 : // CurrentBull && Bull
if (UseNew)
{
if (Open[i-1] > BullWickPenLow) SetVBottom(i);
}
else
{
SetVBottom(i);
}
break;
case 4 : //CurrentBull && Bear)
if (UseNew)
{
if (Open[i-1] > BearWickPenLow) SetVBottom(i);
}
else
{
SetVBottom(i);
}
break;
}
}
}
return(0);
}
//+------------------------------------------------------------------+
