TTM-Trend-Map V1 color mod
Download scriptOverview
The TTM-Trend-Map is a visual analytics tool designed to provide traders with a "bird's-eye view" of the current market trends across multiple currency pairs and various timeframes simultaneously. Instead of switching between different charts to see how different assets are performing, this script compiles that information into a single, organized map.
Core Functionality
The logic of this tool can be broken down into three main components:
1. Multi-Asset & Multi-Timeframe Monitoring
The script scans a specific list of currency pairs (which you can customize in the settings) and evaluates them against several different timeframes. It supports a wide range of intervals, including:
- Long-term: Monthly (MN), Weekly (W1), and Daily (D1).
- Medium-term: 4-Hour (H4) and 1-Hour (H1).
- Short-term: 30-Minute (M30), 15-Minute (M15), 5-Minute (M5), and 1-Minute (M1).
2. Trend Identification Logic
To determine the "trend" for each pair, the script relies on an external indicator called TTM-Trend. It looks at specific data points from that indicator to categorize the market into one of three states:
- Upward Trend: Represented visually by a green arrow.
- Downward Trend: Represented visually by a red arrow.
- No Trend (Neutral): Represented visually by a yellow symbol.
The script intelligently checks these conditions for every timeframe you have enabled, ensuring that you can see if a currency is trending upward on the Daily chart while potentially being in a neutral zone on the 5-Minute chart.
3. Visual Mapping & Organization
The tool organizes this data into a clean, readable layout:
- Dynamic Sorting: You can filter the map to show only pairs involving a specific "Main Currency" (e.g., only pairs involving USD). It can also automatically flip the order of these pairs for better readability.
- Spatial Layout: The script calculates the available space in its window and distributes the currency pairs vertically.
- Visual Markers: For every active currency, it places a series of markers (arrows) on a horizontal line. Each marker corresponds to one of the timeframes. This allows a trader to see at a glance where the "agreement" lies between different time periods—for example, seeing green arrows across all timeframes indicates a very strong, synchronized uptrend.
Summary of Use
This script acts as a dashboard. By looking at one window, a trader can instantly identify which currencies are showing strength across multiple timeframes and which are moving in opposite directions, allowing for faster decision-making and better market context without the need to navigate through dozens of individual charts.
/*-----------------------------+
| |
| Shared by www.Aptrafx.com |
| |
+------------------------------*/
//+------------------------------------------------------------------+
//| TTM-Trend-Map.mq4 |
//| Tamir Bleicher, +972-54-4941653 |
//| |
//+------------------------------------------------------------------+
#property copyright "Tamir Bleicher, +972-54-4941653"
#property link ""
//-- This indicator will show a "Map" of the trends at different time frames on the currencies of your choice, according to the TTM-Trend indicator.
//-- You should have the TTM-Trend indicator in your indicator's folder for this indicator to work.
#property indicator_separate_window
#property indicator_minimum 0
#property indicator_maximum 100
#property indicator_buffers 1
#property indicator_color1 Red
//---- input parameters
extern int CompBars=6;//- Do not change. This is the same parameter as in the TTM-Trend indicator.
extern string SymbolSuffix="";//- If your broker names the currency pairs with a suffix for a mini account (like an "m", for example), enter the suffix here.
extern string PairsList="GBPUSD,EURUSD,USDCHF,USDJPY";//- This is where you add the currency pairs you want to track. Add each one of them separated by a coma.
extern string MainCurrency="";//- If you want to see only pairs where the USD (or any other currency) appears just enter here USD (or the currency of your choice) and it will show all USD (or the currency you chose) pairs.
extern bool Invert=false;//- If you chose to show all USD pairs and you want to show them with the USD as the first currency, change this setting to "true".
extern color UpTrendColor=Green;
extern color DownTrendColor=Red;
extern color NoTrendColor=Yellow;
extern bool MN=true;//- Change to "false" if you don't want to show this time frame.
extern bool W1=true;//- Change to "false" if you don't want to show this time frame.
extern bool D1=true;//- Change to "false" if you don't want to show this time frame.
extern bool H4=true;//- Change to "false" if you don't want to show this time frame.
extern bool H1=true;//- Change to "false" if you don't want to show this time frame.
extern bool M30=true;//- Change to "false" if you don't want to show this time frame.
extern bool M15=true;//- Change to "false" if you don't want to show this time frame.
extern bool M5=true;//- Change to "false" if you don't want to show this time frame.
extern bool M1=true;//- Change to "false" if you don't want to show this time frame.
//---- buffers
double ExtMapBuffer1[];
string Pair[20];
int SymNo;
//+------------------------------------------------------------------+
//| Custom indicator initialization function |
//+------------------------------------------------------------------+
int init()
{
int i,j,k;
string Cur;
bool AllCur;
//---- indicators
SetIndexStyle(0,DRAW_SECTION);
SetIndexBuffer(0,ExtMapBuffer1);
SetIndexEmptyValue(0,0.0);
AllCur=(StringFind(PairsList,MainCurrency,0)==-1);
for (i=0; i<20; i++) Pair[i]="";
for (i=0, j=0, k=1; i<20 && k>0; )
{
k=StringFind(PairsList,",",j);
if (k==0) Cur=StringSubstr(PairsList,j,0);
else Cur=StringSubstr(PairsList,j,k-j);
if (AllCur || StringFind(Cur,MainCurrency,0)>-1)
{
Pair[i]=Cur;
i++;
}
j=StringFind(PairsList,",",j)+1;
if (j==0) break;
}
SymNo=i;
//----
return(0);
}
//+------------------------------------------------------------------+
//| Custom indicator deinitialization function |
//+------------------------------------------------------------------+
int deinit()
{
//----
//----
return(0);
}
int trend(string sym,int per)
{
int t1=(iCustom(sym,per,"ttm-trend",CompBars,4,1));
int t2=(iCustom(sym,per,"ttm-trend",CompBars,4,2));
if (t1==1 && t2==1) return (1);
if (t1==-1 && t2==-1) return (-1);
else return (0);
}
void output_arrow(string label, string sym,int bar, double price, int per, string per_name, bool invert, bool create)
{
datetime time = Time[bar];
string sym1;
if (invert && StringSubstr(sym,3,3)==MainCurrency)
sym1=StringSubstr(sym,3,3)+StringSubstr(sym,0,3)+SymbolSuffix;
else { sym1=sym; invert=false; }
if (sym=="Title")
{
ObjectDelete(label+per_name);
if (create)
{
ObjectCreate(label+per_name,OBJ_TEXT,1,time,price);
ObjectSetText(label+per_name,per_name);
ObjectSet(label+per_name,OBJPROP_COLOR,White);
ObjectSet(label+per_name,OBJPROP_WIDTH,2);
}
}
else if (per==0)
{
ObjectDelete(label);
if (create)
{
ObjectCreate(label,OBJ_TEXT,1,time,price);
ObjectSetText(label,sym1);
ObjectSet(label+per_name,OBJPROP_COLOR,White);
ObjectSet(label+per_name,OBJPROP_WIDTH,2);
}
}
else
{
ObjectDelete(label+per_name);
if (create)
{
int t=trend(sym,per);
if (invert) t=-t;
if (t==1)
{
ObjectCreate(label+per_name,OBJ_ARROW,1,time,price);
ObjectSet(label+per_name,OBJPROP_COLOR,UpTrendColor);
ObjectSet(label+per_name,OBJPROP_ARROWCODE,225);
ObjectSet(label+per_name,OBJPROP_WIDTH,2);
}
else if (t==-1)
{
ObjectCreate(label+per_name,OBJ_ARROW,1,time,price);
ObjectSet(label+per_name,OBJPROP_COLOR,DownTrendColor);
ObjectSet(label+per_name,OBJPROP_ARROWCODE,226);
ObjectSet(label+per_name,OBJPROP_WIDTH,2);
}
else
{
ObjectCreate(label+per_name,OBJ_ARROW,1,time,price);
ObjectSet(label+per_name,OBJPROP_COLOR,NoTrendColor);
ObjectSet(label+per_name,OBJPROP_ARROWCODE,104);
ObjectSet(label+per_name,OBJPROP_WIDTH,2);
}
}
}
}
void output_line(string label, string sym,double price, bool invert, bool create)
{
int n=MN+W1+M1+D1+H4+H1+M30+M15+M1;
int br=MathRound(BarsPerWindow()/12);
int D=MN+W1+D1;
int H=D+H4+H1;
output_arrow(label,sym,MathRound(br*10.5),price,0,"",invert,create);
output_arrow(label,sym,br*9,price,PERIOD_MN1,"MN",invert,create&&MN);
output_arrow(label,sym,br*(9-MN),price,PERIOD_W1,"W1",invert,create&&W1);
output_arrow(label,sym,br*(9-MN-W1),price,PERIOD_D1,"D1",invert,create&&D1);
output_arrow(label,sym,br*(9-D),price,PERIOD_H4,"H4",invert,create&&H4);
output_arrow(label,sym,br*(9-D-H4),price,PERIOD_H1,"H1",invert,create&&H1);
output_arrow(label,sym,br*(9-H),price,PERIOD_M30,"M30",invert,create&&M30);
output_arrow(label,sym,br*(9-H-M30),price,PERIOD_M15,"M15",invert,create&&M15);
output_arrow(label,sym,br*(9-H-M30-M15),price,PERIOD_M5,"M5",invert,create&&M5);
output_arrow(label,sym,br*(9-H-M30-M15-M1),price,PERIOD_M1,"M1",invert,create&&M1);
}
//+------------------------------------------------------------------+
//| Custom indicator iteration function |
//+------------------------------------------------------------------+
int start()
{
bool invert;
double space=(95-5)/SymNo;
if (space>10) space=10;
output_line("Title","Title",95,false,true);
for (int i=0; i<20; i++)
{
output_line(DoubleToStr(i,0),Pair[i]+SymbolSuffix,95-space*(i+1),Invert,i<SymNo);
//else output_line(DoubleToStr(i,0),"",90-5*i,Invert);
}
return(0);
}
//+------------------------------------------------------------------+
