Stoch_Sound_Email_v2

Download script
Author: Copyright � 2004, MetaQuotes Software Corp.
Stoch_Sound_Email_v2

This script is designed as a technical analysis tool for the MetaTrader trading platform. It automates the monitoring of a specific market indicator known as the Stochastic Oscillator and provides real-time notifications when certain price movements occur.

Core Functionality

The primary purpose of this tool is to identify momentum shifts in the market. It tracks two main moving lines:

  1. The Main Line: Represents the current relative strength of the price.
  2. The Signal Line: A smoothed average of the Main Line, used to filter out minor "noise" and identify clearer trends.

How the Logic Works

The script processes market data in the following sequence:

  • Data Calculation: It scans recent price history to determine the highest highs and lowest lows over a specific period. By comparing where the current price sits relative to these extremes, it calculates a percentage value (0 to 100).
  • Trend Smoothing: It applies "Slowing" and "Moving Average" calculations to these values. This prevents the indicator from being too erratic, ensuring that the lines move in a way that is easier for a human to interpret.
  • Crossover Detection: The logic specifically looks for "crossovers." This is when the Main Line crosses above or below the Signal Line. These moments are traditionally viewed by traders as potential entry points for buy or sell opportunities.

Notification System

The script includes an automated alert system to ensure you don't have to watch the charts constantly. When a crossover occurs, the logic checks your settings to perform two possible actions:

  • Audio Alerts: It can play a specific sound file on your computer to grab your attention immediately.
  • Email Notifications: It can automatically send an email to your registered address. The email contains detailed information, including the type of crossover (UP or DOWN), the current market price, and the exact date and time the event occurred.

User Customization

The logic is flexible and allows you to define the "sensitivity" of the tool through several parameters:

  • Period Settings: You can adjust the speed at which the indicator reacts to price changes.
  • Threshold Levels: It establishes specific visual boundaries (upper and lower levels) to help distinguish between overbought and oversold conditions.
  • Toggle Switches: You can independently turn the sound alerts and email notifications on or off depending on your preference.
Indicators Used
Moving average indicator
Miscellaneous
Implements a curve of type %1It sends emailsIt plays sound alerts
9 Views
0 Downloads
0 Favorites
Stoch_Sound_Email_v2
//+------------------------------------------------------------------+
//|                                            Stoch_Sound_Email.mq4 |
//|                      Copyright © 2004, MetaQuotes Software Corp. |
//|                                       http://www.metaquotes.net/ |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2004, MetaQuotes Software Corp."
#property link      "http://www.metaquotes.net/"
#property link      " Alerts added by cja"
//----
#property indicator_separate_window
//----
#property indicator_minimum 0
#property indicator_maximum 100
#property indicator_buffers 2
#property indicator_color1 LightSeaGreen
#property indicator_color2 Red
//---- input parameters
extern int KPeriod=5;
extern int DPeriod=3;
extern int Slowing=3;
extern bool SoundAlert_ON=false;
extern string SoundFile ="alert2.wav";
extern bool SendEmail=false;
extern int StochLEVEL_UP=80;
extern int StochLEVEL_DN=20;
//---- buffers
double MainBuffer[];
double SignalBuffer[];
double HighesBuffer[];
double LowesBuffer[];
//----
int draw_begin1=0;
int draw_begin2=0;
//----
#define SIGNAL_BAR 1
//+------------------------------------------------------------------+
//| Custom indicator initialization function                         |
//+------------------------------------------------------------------+
int init()
  {
   string short_name;
//---- 2 additional buffers are used for counting.
   IndicatorBuffers(4);
   SetIndexBuffer(2, HighesBuffer);
   SetIndexBuffer(3, LowesBuffer);
//---- indicator lines
   SetIndexStyle(0,DRAW_LINE);
   SetIndexBuffer(0, MainBuffer);
   SetIndexStyle(1,DRAW_LINE);
   SetIndexBuffer(1, SignalBuffer);
//---- name for DataWindow and indicator subwindow label
   string ALRT1="",ALRT2="";
   if(SoundAlert_ON==true)ALRT1="ON";
   if(SoundAlert_ON==false)ALRT1="OFF";
   if(SendEmail==true)ALRT2="ON";
   if(SendEmail==false)ALRT2="OFF";
   short_name="Sto("+KPeriod+","+DPeriod+","+Slowing+") [ Sound Alert "+ALRT1+" ] [ Email Alert "+ALRT2+" ]";
   IndicatorShortName(short_name);
   SetIndexLabel(0,short_name);
   SetIndexLabel(1,"Signal");
//----
   draw_begin1=KPeriod+Slowing;
   draw_begin2=draw_begin1+DPeriod;
   SetIndexDrawBegin(0,draw_begin1);
   SetIndexDrawBegin(1,draw_begin2);
   SetLevelValue(0,StochLEVEL_UP);
   SetLevelValue(1,StochLEVEL_DN);
   SetLevelStyle(2,0,DarkSlateGray);
//----
   return(0);
  }
//+------------------------------------------------------------------+
//| Stochastic oscillator                                            |
//+------------------------------------------------------------------+
int start()
  {
   int    i,k;
   int    counted_bars=IndicatorCounted();
   double price;
//----
   if(Bars<=draw_begin2) return(0);
//---- initial zero
   if(counted_bars<1)
     {
      for(i=1;i<=draw_begin1;i++) MainBuffer[Bars-i]=0;
      for(i=1;i<=draw_begin2;i++) SignalBuffer[Bars-i]=0;
     }
//---- minimums counting
   i=Bars-KPeriod;
   if(counted_bars>KPeriod) i=Bars-counted_bars-1;
   while(i>=0)
     {
      double min=1000000;
      k=i+KPeriod-1;
      while(k>=i)
        {
         price=Low[k];
         if(min>price) min=price;
         k--;
        }
      LowesBuffer[i]=min;
      i--;
     }
//---- maximums counting
   i=Bars-KPeriod;
   if(counted_bars>KPeriod) i=Bars-counted_bars-1;
   while(i>=0)
     {
      double max=-1000000;
      k=i+KPeriod-1;
      while(k>=i)
        {
         price=High[k];
         if(max<price) max=price;
         k--;
        }
      HighesBuffer[i]=max;
      i--;
     }
//---- %K line
   i=Bars-draw_begin1;
   if(counted_bars>draw_begin1) i=Bars-counted_bars-1;
   while(i>=0)
     {
      double sumlow=0.0;
      double sumhigh=0.0;
      for(k=(i+Slowing-1);k>=i;k--)
        {
         sumlow+=Close[k]-LowesBuffer[k];
         sumhigh+=HighesBuffer[k]-LowesBuffer[k];
        }
      if(sumhigh==0.0) MainBuffer[i]=100.0;
      else MainBuffer[i]=sumlow/sumhigh*100;
      i--;
     }
//---- last counted bar will be recounted
   if(counted_bars>0) counted_bars--;
   int limit=Bars-counted_bars;
//---- signal line is simple movimg average
   for(i=0; i<limit; i++)
      SignalBuffer[i]=iMAOnArray(MainBuffer,Bars,DPeriod,0,MODE_SMA,i);
   // Alert code
   static int PrevSignal=0, PrevTime=0;
   if(SIGNAL_BAR > 0 && Time[0]<=PrevTime)
      return(0);
   PrevTime=Time[0];
   if(PrevSignal<=0)
     {
      if(MainBuffer[SIGNAL_BAR]>SignalBuffer[SIGNAL_BAR])
         if (SendEmail==true)SendMail("Stochastic "+Symbol()+" M"+Period()+"","Stochastic Xrossed UP"+"\n"+Symbol()+" M"+Period()+", BUY  @ "+DoubleToStr(Bid,Digits)+"\n"
         +"Time = "+TimeToStr(TimeLocal(),TIME_SECONDS)+"\n"+"Date = "+TimeToStr(TimeLocal(),TIME_DATE)+"");
        {
         PrevSignal=1;
         if(SoundAlert_ON==true)PlaySound(SoundFile);
        }
     }
   if(PrevSignal>=0)
     {
      if(MainBuffer[SIGNAL_BAR] < SignalBuffer[SIGNAL_BAR])
         if (SendEmail==true)SendMail("Stochastic "+Symbol()+" M"+Period()+"","Stochastic Xrossed DOWN"+"\n "+Symbol()+" M"+Period()+", SELL  @ "+DoubleToStr(Bid,Digits)+"\n"
        +"Time = "+TimeToStr(TimeLocal(),TIME_SECONDS)+"\n"+"Date = "+TimeToStr(TimeLocal(),TIME_DATE)+"");
        {
         PrevSignal=-1;
         if(SoundAlert_ON==true)PlaySound(SoundFile);
        }
     }
//----
   return(0);
  }
//+------------------------------------------------------------------+
