StepChoppyBars_v1_v1

Author: Copyright � 2006, Forex-TSD.com
StepChoppyBars_v1_v1

This script is designed as a visual market analysis tool for the MetaTrader 4 platform. Its primary purpose is to interpret complex price action and identify different "states" of a market trend—ranging from strong momentum to volatile, choppy movements.

How it Works

The logic operates by gathering data from three distinct technical components to paint a comprehensive picture of the current market environment:

  • Trend Identification: It utilizes two specific moving averages to distinguish between an overall upward trend and an overall downward trend. This acts as the foundational filter for all other signals.
  • Momentum Measurement: The script incorporates a specialized Relative Strength Index (RSI) calculation. It specifically looks at three different "speeds" of momentum: a standard reading, a fast reading, and a slow reading.
  • State Classification: By comparing the relationship between these different momentum speeds against the identified trend, the tool categorizes the price action into one of eight distinct visual categories.

Market States Identified

Instead of simply telling you "buy" or "sell," the script categorizes the market into nuanced behaviors:

  1. Strong Trends: Identifies periods where the trend is clear and momentum is powerfully aligned in a single direction.
  2. Retracements: Detects when the market is still in a primary trend but is taking a "breather" or pulling back temporarily. This helps traders see if a trend is cooling off rather than reversing.
  3. Choppy Markets: Highlights zones where the price is moving sideways or lacks clear direction, signaling high uncertainty.
  4. Transition Warnings: Provides visual cues when the market is showing signs of being "ready" to change direction, signaling a potential shift from an uptrend to a downtrend (or vice versa).

Visual Representation

The script communicates these findings using a multi-colored histogram system. Each color corresponds to a specific market state:

  • Blue/Cyan tones generally represent upward momentum and various stages of an uptrend.
  • Red/Orange/Yellow tones generally represent downward momentum, retracements, or warnings of a bearish shift.

By providing these visual distinctions, the tool allows a trader to quickly see not just where the price is going, but the quality of that movement—helping to differentiate between a reliable trend and a noisy, unreliable market.

Miscellaneous
Implements a curve of type %1
13 Views
0 Downloads
0 Favorites
StepChoppyBars_v1_v1
/*-----------------------------+
|			       |
| Shared by www.Aptrafx.com    |
|			       |
+------------------------------*/

//+------------------------------------------------------------------+
//|                                            StepChoppyBars_v1.mq4 |
//|                                  Copyright © 2006, Forex-TSD.com |
//|                         Written by IgorAD,igorad2003@yahoo.co.uk |
//|            http://finance.groups.yahoo.com/group/TrendLaboratory |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2006, Forex-TSD.com "
#property link      "http://www.forex-tsd.com/"

#property indicator_chart_window
#property indicator_buffers 8
#property indicator_color1 MediumBlue
#property indicator_color2 Crimson
#property indicator_color3 DodgerBlue
#property indicator_color4 Tomato
#property indicator_color5 LightBlue
#property indicator_color6 Orange
#property indicator_color7 Aqua
#property indicator_color8 Yellow
//---- input parameters
int Length=10;
double StepSizeFast=5;
double StepSizeSlow=15;
int MAPeriod=1;
int Price=0;
int Mode=2;
//---- buffers
double UpBuffer1[];
double DnBuffer1[];
double UpBuffer2[];
double DnBuffer2[];
double UpBuffer3[];
double DnBuffer3[];
double UpBuffer4[];
double DnBuffer4[];

//+------------------------------------------------------------------+
//| Custom indicator initialization function                         |
//+------------------------------------------------------------------+
int init()
  {

//----
   SetIndexStyle(0,DRAW_HISTOGRAM,0,2,MediumBlue);
   SetIndexBuffer(0,UpBuffer1);
   SetIndexStyle(1,DRAW_HISTOGRAM,0,2,Crimson);
   SetIndexBuffer(1,DnBuffer1);
   SetIndexStyle(2,DRAW_HISTOGRAM,0,2,DodgerBlue);
   SetIndexBuffer(2,UpBuffer2);
   SetIndexStyle(3,DRAW_HISTOGRAM,0,2,Tomato);
   SetIndexBuffer(3,DnBuffer2);
   SetIndexStyle(4,DRAW_HISTOGRAM,0,2,LightBlue);
   SetIndexBuffer(4,UpBuffer3);
   SetIndexStyle(5,DRAW_HISTOGRAM,0,2,Orange);
   SetIndexBuffer(5,DnBuffer3);
   SetIndexStyle(6,DRAW_HISTOGRAM,0,2,Aqua);
   SetIndexBuffer(6,UpBuffer4);
   SetIndexStyle(7,DRAW_HISTOGRAM,0,2,Yellow);
   SetIndexBuffer(7,DnBuffer4);

//----
   string short_name="StepChoppyBars_v1";
   IndicatorShortName(short_name);
   SetIndexLabel(0,"Strong UpTrend");
   SetIndexLabel(1,"Strong DownTrend");
   SetIndexLabel(2,"Retrace UpTrend");
   SetIndexLabel(3,"Retrace DownTrend");
   SetIndexLabel(4,"Choppy UpTrend");
   SetIndexLabel(5,"Choppy DownTrend");
   SetIndexLabel(6,"Be ready to change UpTrend");
   SetIndexLabel(7,"Be ready to change DownTrend");
//----

   SetIndexDrawBegin(0,Length);
   SetIndexDrawBegin(1,Length);
   SetIndexDrawBegin(2,Length);
   SetIndexDrawBegin(3,Length);
   SetIndexDrawBegin(4,Length);
   SetIndexDrawBegin(5,Length);
   SetIndexDrawBegin(6,Length);
   SetIndexDrawBegin(7,Length);
//----
   return(0);
  }
//+------------------------------------------------------------------+
//| StepChoppyBars_v1                                                |
//+------------------------------------------------------------------+
int start()
  {
   int  i,counted_bars=IndicatorCounted();
   double RSI, FastRSI, SlowRSI, StepMA, UpTrendMA, DnTrendMA;
//----
   if(Bars<=Length) return(0);
//---- initial zero
   if(counted_bars<1)
      for(i=1;i<=Length;i++)
      {
      UpBuffer1[Bars-i]=0.0;
      UpBuffer2[Bars-i]=0.0;
      UpBuffer3[Bars-i]=0.0;
      UpBuffer4[Bars-i]=0.0;

      DnBuffer1[Bars-i]=0.0;
      DnBuffer2[Bars-i]=0.0;
      DnBuffer3[Bars-i]=0.0;
      DnBuffer4[Bars-i]=0.0;
      }
//----
   if ( counted_bars > 0 )  int limit=Bars-counted_bars;
   if ( counted_bars ==0 )  limit=Bars-Length-1;

   for(i=limit;i>=0;i--)
   {

   UpTrendMA = iCustom(NULL,0,"StepMA_v7",Length,1.0,0,0,0,0,true,2,0,1,i);
   DnTrendMA = iCustom(NULL,0,"StepMA_v7",Length,1.0,0,0,0,0,true,2,0,2,i);

   RSI=iCustom(NULL,0,"StepRSI_v5.2",Length,StepSizeFast,MAPeriod,Price,Mode,0,i);
   FastRSI=iCustom(NULL,0,"StepRSI_v5.2",Length,StepSizeFast,MAPeriod,Price,Mode,1,i);
   SlowRSI=iCustom(NULL,0,"StepRSI_v5.2",Length,StepSizeSlow,MAPeriod,Price,Mode,1,i);

   //UpBuffer1[i] =UpBuffer1[i+1];
   //UpBuffer2[i] =UpBuffer2[i+1];
   //UpBuffer3[i] =UpBuffer3[i+1];
   //UpBuffer4[i] =UpBuffer4[i+1];

   //DnBuffer1[i] =DnBuffer1[i+1];
   //DnBuffer2[i] =DnBuffer2[i+1];
   //DnBuffer3[i] =DnBuffer3[i+1];
   //DnBuffer4[i] =DnBuffer4[i+1];

   UpBuffer1[i] =EMPTY;
   UpBuffer2[i] =EMPTY;
   UpBuffer3[i] =EMPTY;
   UpBuffer4[i] =EMPTY;

   DnBuffer1[i] =EMPTY;
   DnBuffer2[i] =EMPTY;
   DnBuffer3[i] =EMPTY;
   DnBuffer4[i] =EMPTY;

   if (FastRSI > SlowRSI && RSI > FastRSI && UpTrendMA!=EMPTY_VALUE)
   {UpBuffer1[i] = High[i];DnBuffer1[i] = Low[i] ;}
   //{UpBuffer1[i] = High[i];UpBuffer2[i] = -1.0;UpBuffer3[i] = -1.0;UpBuffer4[i] = -1.0;
   // DnBuffer1[i] = -1.0 ;DnBuffer2[i] = -1.0;DnBuffer3[i] = -1.0;DnBuffer4[i] = Low[i];}

   else if (FastRSI > SlowRSI && RSI < FastRSI && UpTrendMA!=EMPTY_VALUE)
   {UpBuffer2[i] = High[i];DnBuffer2[i] = Low[i] ;}
   //{UpBuffer1[i] = 0.0; UpBuffer2[i] = High[i]; UpBuffer3[i] = 0.0; UpBuffer4[i] = 0.0;
   // DnBuffer1[i] = 0.0; DnBuffer2[i] = Low[i];  DnBuffer3[i] = 0.0; DnBuffer4[i] = 0.0;}

   else if (FastRSI < SlowRSI && RSI > FastRSI && UpTrendMA!=EMPTY_VALUE)
   {UpBuffer3[i] = High[i];DnBuffer3[i] = Low[i] ;}
   //{UpBuffer1[i] = 0.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = High[i];UpBuffer4[i] = 0.0;
   // DnBuffer1[i] = 0.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = Low[i];DnBuffer4[i] = 0.0;}

   else if (FastRSI < SlowRSI && RSI < FastRSI && UpTrendMA!=EMPTY_VALUE)
   {UpBuffer4[i] = High[i];DnBuffer4[i] = Low[i] ;}
   //{UpBuffer1[i] = 0.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = High[i];
   // DnBuffer1[i] = 0.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = Low[i];}


   else if (FastRSI < SlowRSI && RSI < FastRSI && DnTrendMA!=EMPTY_VALUE)
   {DnBuffer1[i] = High[i];UpBuffer1[i] = Low[i];}
   //{DnBuffer1[i] = High[i];DnBuffer2[i] = 0.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = 0.0;
   // UpBuffer1[i] = Low[i];UpBuffer2[i] = 0.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = 0.0;}

   else if (FastRSI < SlowRSI && RSI > FastRSI && DnTrendMA!=EMPTY_VALUE)
   {DnBuffer2[i] = High[i];UpBuffer2[i] = Low[i];}
   //{DnBuffer1[i] = 0.0;DnBuffer2[i] = High[i];DnBuffer3[i] = 0.0;DnBuffer4[i] = 0.0;
   //UpBuffer1[i] = 0.0;UpBuffer2[i] = Low[i];UpBuffer3[i] = 0.0;UpBuffer4[i] = 0.0;}

   else if (FastRSI > SlowRSI && RSI < FastRSI && DnTrendMA!=EMPTY_VALUE)
   {DnBuffer3[i] = High[i];UpBuffer3[i] = Low[i];}
   //{DnBuffer1[i] = 0.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = High[i];DnBuffer4[i] = 0.0;
   //UpBuffer1[i] = 0.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = Low[i];UpBuffer4[i] = 0.0;}

   else if (FastRSI > SlowRSI && RSI > FastRSI && DnTrendMA!=EMPTY_VALUE)
   {DnBuffer4[i] = High[i];UpBuffer4[i] = Low[i];}
   //{DnBuffer1[i] = 0.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = High[i];
   //UpBuffer1[i] = 0.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = Low[i];}
   }

//----
   return(0);
  }
//+------------------------------------------------------------------+

Dependencies

StepMA_v7

This indicator calculates a quantized price trajectory by determining dynamic step sizes based on average range volatility and applying trend-dependent price boundaries.

StepRSI_v5.2

This indicator applies a staircase-style quantization to relative strength values, identifying significant structural shifts in price velocity while filtering out minor volatility noise.
