StepChoppy_v1.3_001
Download scriptThis script is a visual trading tool designed to categorize market trends into specific phases based on momentum and direction. Instead of just showing a simple "up" or "down" arrow, it breaks the market movement down into four distinct stages for both bullish (upward) and bearish (downward) trends.
Core Logic Overview
The tool works by combining three different types of technical data:
- Trend Identification: It looks at a specialized moving average to determine if the overall market is currently leaning upward or downward.
- Momentum Analysis: It uses a specialized Relative Strength Index (RSI) to measure how "fast" and "strong" the current price movement is.
- Comparative Filtering: By comparing three different versions of these momentum readings (Fast, Slow, and Standard), the script identifies where the price currently sits within its larger trend cycle.
How it Interprets the Market
The indicator translates these calculations into a visual histogram that tells you the "health" of a trend:
For Upward Trends:
- Strong UpTrend: The market is moving up with high momentum and strong conviction.
- Retrace UpTrend: The market is still in an upward trend, but is currently experiencing a slight pullback or "breather."
- Choppy UpTrend: The trend is weak, showing sideways movement or indecision despite the general upward bias.
- Ready to Change: A warning signal suggesting that the upward momentum is exhausted and a reversal may be coming soon.
For Downward Trends:
- Strong DownTrend: The market is dropping rapidly with high and consistent momentum.
- Retrace DownTrend: The market is in a downtrend but is currently experiencing a temporary bounce or relief rally.
- Choppy DownTrend: The downward move is stalling, showing significant horizontal movement and lack of direction.
- Ready to Change: A warning signal suggesting that the downward pressure is fading and an upward move might be imminent.
Summary for the User
Essentially, this script acts as a "mood ring" for the market. It helps traders distinguish between a steady, healthy trend (where you might want to stay in a position) and a "choppy" or "exhausted" trend (where you might want to be cautious or prepare to exit). By visualizing these eight different states, it allows you to see not just where the price is going, but how it is getting there.
//+------------------------------------------------------------------+
//| StepChoppy_v1.3.mq4 |
//| Copyright © 2006, Forex-TSD.com |
//| Written by IgorAD,igorad2003@yahoo.co.uk |
//| http://finance.groups.yahoo.com/group/TrendLaboratory |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2006, Forex-TSD.com "
#property link "http://www.forex-tsd.com/"
#property indicator_separate_window
#property indicator_minimum -0.05
#property indicator_maximum 1.05
#property indicator_buffers 8
//---- input parameters
extern int Length =10;
extern double Kv = 1.0;
extern double StepSize =0;
extern int MA_Mode = 0;
extern bool HighLow = false;
extern double StepSizeFast=5;
extern double StepSizeSlow=15;
int MAPeriod=1;
int Price=0;
int Mode=2;
//---- buffers
double UpBuffer1[];
double UpBuffer2[];
double UpBuffer3[];
double UpBuffer4[];
double DnBuffer1[];
double DnBuffer2[];
double DnBuffer3[];
double DnBuffer4[];
//+------------------------------------------------------------------+
//| Custom indicator initialization function |
//+------------------------------------------------------------------+
int init()
{
//----
SetIndexStyle(0,DRAW_HISTOGRAM,0,3,MediumBlue);
SetIndexStyle(1,DRAW_HISTOGRAM,0,3,DodgerBlue);
SetIndexStyle(2,DRAW_HISTOGRAM,0,3,LightBlue);
SetIndexStyle(3,DRAW_HISTOGRAM,0,3,Aqua);
SetIndexStyle(4,DRAW_HISTOGRAM,0,3,Crimson);
SetIndexStyle(5,DRAW_HISTOGRAM,0,3,Tomato);
SetIndexStyle(6,DRAW_HISTOGRAM,0,3,Orange);
SetIndexStyle(7,DRAW_HISTOGRAM,0,3,Yellow);
SetIndexBuffer(0,UpBuffer1);
SetIndexBuffer(1,UpBuffer2);
SetIndexBuffer(2,UpBuffer3);
SetIndexBuffer(3,UpBuffer4);
SetIndexBuffer(4,DnBuffer1);
SetIndexBuffer(5,DnBuffer2);
SetIndexBuffer(6,DnBuffer3);
SetIndexBuffer(7,DnBuffer4);
//----
string short_name="StepChoppy";
IndicatorShortName(short_name);
SetIndexLabel(0,"Strong UpTrend");
SetIndexLabel(1,"Retrace UpTrend");
SetIndexLabel(2,"Choppy UpTrend");
SetIndexLabel(3,"Be ready to change UpTrend");
SetIndexLabel(4,"Strong DownTrend");
SetIndexLabel(5,"Retrace DownTrend");
SetIndexLabel(6,"Choppy DownTrend");
SetIndexLabel(7,"Be ready to change DownTrend");
//----
SetIndexDrawBegin(0,Length);
SetIndexDrawBegin(1,Length);
SetIndexDrawBegin(2,Length);
SetIndexDrawBegin(3,Length);
SetIndexDrawBegin(4,Length);
SetIndexDrawBegin(5,Length);
SetIndexDrawBegin(6,Length);
SetIndexDrawBegin(7,Length);
//----
return(0);
}
//+------------------------------------------------------------------+
//| StepChoppy_v1.3 |
//+------------------------------------------------------------------+
int start()
{
int i,counted_bars=IndicatorCounted();
double RSI, FastRSI, SlowRSI, StepMA, UpTrendMA, DnTrendMA;
//----
if(Bars<=Length) return(0);
//---- initial zero
if(counted_bars<1)
for(i=1;i<=Length;i++)
{
UpBuffer1[Bars-i]=0.0;
UpBuffer2[Bars-i]=0.0;
UpBuffer3[Bars-i]=0.0;
UpBuffer4[Bars-i]=0.0;
DnBuffer1[Bars-i]=0.0;
DnBuffer2[Bars-i]=0.0;
DnBuffer3[Bars-i]=0.0;
DnBuffer4[Bars-i]=0.0;
}
//----
if ( counted_bars > 0 ) int limit=Bars-counted_bars;
if ( counted_bars ==0 ) limit=Bars-Length-1;
for(i=limit;i>=0;i--)
{
UpTrendMA = iCustom(NULL,0,"StepMA_v7",Length,Kv,StepSize,MA_Mode,0,0,HighLow,2,0,1,i);
DnTrendMA = iCustom(NULL,0,"StepMA_v7",Length,Kv,StepSize,MA_Mode,0,0,HighLow,2,0,2,i);
RSI=iCustom(NULL,0,"StepRSI_v5.2",Length,StepSizeFast,MAPeriod,Price,Mode,0,i);
FastRSI=iCustom(NULL,0,"StepRSI_v5.2",Length,StepSizeFast,MAPeriod,Price,Mode,1,i);
SlowRSI=iCustom(NULL,0,"StepRSI_v5.2",Length,StepSizeSlow,MAPeriod,Price,Mode,1,i);
UpBuffer1[i] =UpBuffer1[i+1];
UpBuffer2[i] =UpBuffer2[i+1];
UpBuffer3[i] =UpBuffer3[i+1];
UpBuffer4[i] =UpBuffer4[i+1];
DnBuffer1[i] =DnBuffer1[i+1];
DnBuffer2[i] =DnBuffer2[i+1];
DnBuffer3[i] =DnBuffer3[i+1];
DnBuffer4[i] =DnBuffer4[i+1];
if (FastRSI > SlowRSI && RSI > FastRSI && UpTrendMA!=EMPTY_VALUE)
{UpBuffer1[i] = 1.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = 0.0;
DnBuffer1[i] = 0.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = 0.0;}
else if (FastRSI > SlowRSI && RSI < FastRSI && UpTrendMA!=EMPTY_VALUE)
{UpBuffer1[i] = 0.0;UpBuffer2[i] = 1.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = 0.0;
DnBuffer1[i] = 0.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = 0.0;}
else if (FastRSI < SlowRSI && RSI > FastRSI && UpTrendMA!=EMPTY_VALUE)
{UpBuffer1[i] = 0.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = 1.0;UpBuffer4[i] = 0.0;
DnBuffer1[i] = 0.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = 0.0;}
else if (FastRSI < SlowRSI && RSI < FastRSI && UpTrendMA!=EMPTY_VALUE)
{UpBuffer1[i] = 0.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = 1.0;
DnBuffer1[i] = 0.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = 0.0;}
else if (FastRSI < SlowRSI && RSI < FastRSI && DnTrendMA!=EMPTY_VALUE)
{UpBuffer1[i] = 0.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = 0.0;
DnBuffer1[i] = 1.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = 0.0;}
else if (FastRSI < SlowRSI && RSI > FastRSI && DnTrendMA!=EMPTY_VALUE)
{UpBuffer1[i] = 0.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = 0.0;
DnBuffer1[i] = 0.0;DnBuffer2[i] = 1.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = 0.0;}
else if (FastRSI > SlowRSI && RSI < FastRSI && DnTrendMA!=EMPTY_VALUE)
{UpBuffer1[i] = 0.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = 0.0;
DnBuffer1[i] = 0.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = 1.0;DnBuffer4[i] = 0.0;}
else if (FastRSI > SlowRSI && RSI > FastRSI && DnTrendMA!=EMPTY_VALUE)
{UpBuffer1[i] = 0.0;UpBuffer2[i] = 0.0;UpBuffer3[i] = 0.0;UpBuffer4[i] = 0.0;
DnBuffer1[i] = 0.0;DnBuffer2[i] = 0.0;DnBuffer3[i] = 0.0;DnBuffer4[i] = 1.0;}
}
//----
return(0);
}
//+------------------------------------------------------------------+
