This tool is designed to perform a sophisticated mathematical analysis of price movements to identify underlying cycles and trends. Rather than simply looking at raw price action, it uses advanced statistical methods to decompose market data into its core components.

Here is a breakdown of how the logic functions:

1. Data Foundation (Linear Regression)

The process begins by taking a specific segment of historical price data (defined by a user-set period). The script applies Linear Regression, which is a statistical method used to determine the "line of best fit" for a series of data points.

It calculates where the price would be if it were moving in a perfectly straight line.
It then measures the "deviation"—the difference between the actual market price and that theoretical straight line. By removing this linear trend, the script isolates the "noise" or cyclic fluctuations of the market.

2. Frequency Analysis (Fourier Transform)

Once the linear trend is removed, the script applies a Fourier Transform. This is a complex mathematical process used to break down a complicated wave into simpler sine and cosine waves.

Think of this like a prism: just as a prism breaks white light into different colors, this logic breaks down complex market movements into distinct frequencies (cycles).
The script identifies the strength and frequency of these cycles, allowing it to "see" repeating patterns that are often invisible to the naked eye.

3. Dynamic Visualization

After processing the data, the tool provides several visual outputs on your chart:

Cycle Mapping: It calculates eight different mathematical components based on the Fourier analysis. These are mapped as lines on a separate window, representing the various rhythmic frequencies discovered in the price action.
Real-Time Forecasts: The script projects "trend lines" into the future (specifically 3 to 17 units ahead) based on the primary cycle results ($R$ values). These appear as horizontal dashed lines on your chart, indicating potential levels where a cycle might peak or trough in the near future.
Live Tracking: It includes an automated labeling system that updates the current period and start points dynamically, ensuring the analysis remains synchronized with the latest market data.

Summary for the User

Essentially, this script acts like a "spectrometer" for price action. It strips away the general upward or downward trend to find the hidden "heartbeat" of the market. By identifying these recurring cycles, it attempts to show you where the price might be heading next based on its mathematical rhythm, rather than just guessing based on past price levels.

Indicators Used

Miscellaneous

17 Views

0 Downloads

0 Favorites

Spectrometr_Separate

#property copyright ""
#property link      ""

#property indicator_separate_window
#property indicator_buffers 8
#property indicator_color1 Red
#property indicator_color2 Orange
#property indicator_color3 Yellow
#property indicator_color4 Lime
#property indicator_color5 Blue
#property indicator_color6 DodgerBlue
#property indicator_color7 DarkViolet
#property indicator_color8 DimGray

//---- input parameters

extern int       iPeriod=240;
extern int       iStartFrom=1;
extern string    AddToObjName="1";
extern color     HandlerColor=Gray;
extern color     TextColor=Black;

string ObjNPref="Spectrometr";
string ShortName;

int LastTime;
double A[],B[],R[],F[];

//---- buffers
double ExtMapBuffer1[];
double ExtMapBuffer2[];
double ExtMapBuffer3[];
double ExtMapBuffer4[];
double ExtMapBuffer5[];
double ExtMapBuffer6[];
double ExtMapBuffer7[];
double ExtMapBuffer8[];


int LastLeftBar;
int LastRightBar;
int LastLeftTime;
int LastRightTime;
int LastStartFrom;
int LastiStartFrom;
int LastiPeriod;

//+------------------------------------------------------------------+
//| Custom indicator initialization function                         |
//+------------------------------------------------------------------+
int init(){
   ShortName=ObjNPref+"_"+AddToObjName;
   ObjNPref=ObjNPref+"_"+AddToObjName+"_";



   IndicatorShortName(ShortName);

   SetIndexStyle(0,DRAW_LINE,DRAW_LINE,2);
   SetIndexBuffer(0,ExtMapBuffer1);

   SetIndexStyle(1,DRAW_LINE,DRAW_LINE,2);
   SetIndexBuffer(1,ExtMapBuffer2);

   SetIndexStyle(2,DRAW_LINE,DRAW_LINE,2);
   SetIndexBuffer(2,ExtMapBuffer3);

   SetIndexStyle(3,DRAW_LINE,DRAW_LINE,2);
   SetIndexBuffer(3,ExtMapBuffer4);

   SetIndexStyle(4,DRAW_LINE,DRAW_LINE,2);
   SetIndexBuffer(4,ExtMapBuffer5);

   SetIndexStyle(5,DRAW_LINE,DRAW_LINE,2);
   SetIndexBuffer(5,ExtMapBuffer6);

   SetIndexStyle(6,DRAW_LINE,DRAW_LINE,2);
   SetIndexBuffer(6,ExtMapBuffer7);

   SetIndexStyle(7,DRAW_LINE,DRAW_LINE,2);
   SetIndexBuffer(7,ExtMapBuffer8);

//----
   return(0);
  }
//+------------------------------------------------------------------+
//| Custom indicator deinitialization function                       |
//+------------------------------------------------------------------+
int deinit()
  {
//----
   fObjDeleteByPrefix(ObjNPref);
//----
   return(0);
  }
//+------------------------------------------------------------------+
//| Custom indicator iteration function                              |
//+------------------------------------------------------------------+

int start(){


      string ObjName=ObjNPref+"Íóëåâàÿ ëèíèÿ";

         if(ObjectFind(ObjName)!=WindowFind(ShortName)){
            LastStartFrom=iStartFrom;//
            LastLeftBar=iStartFrom+iPeriod-1;
            LastRightBar=iStartFrom;
            LastLeftTime=Time[LastLeftBar];
            LastRightTime=Time[LastRightBar];
            fObjTrendLine(ObjName,LastLeftTime,0,LastRightTime,0,false,HandlerColor,3,WindowFind(ShortName),0,true);
         }

      int NowLeftTime=ObjectGet(ObjName,OBJPROP_TIME1);
      int NowRightTime=ObjectGet(ObjName,OBJPROP_TIME2);
      if(NowRightTime>Time[1])NowRightTime=Time[1];

      int NowLeftBar=iBarShift(NULL,0,NowLeftTime,false);
      int NowRightBar=iBarShift(NULL,0,NowRightTime,false);
      iPeriod=NowLeftBar-NowRightBar+1;
      int LastStartFromTime=iBarShift(NULL,0,LastRightTime,false);
      iStartFrom=(NowRightBar-LastStartFromTime)+LastStartFrom;

      LastStartFrom=iStartFrom;
      LastLeftBar=iStartFrom+iPeriod-1;
      LastRightBar=iStartFrom;
      LastLeftTime=Time[LastLeftBar];
      LastRightTime=Time[LastRightBar];
      fObjTrendLine(ObjName,LastLeftTime,0,LastRightTime,0,false,HandlerColor,3,WindowFind(ShortName),0,true);

      ObjName=ObjNPref+"iPeriod";
      fObjLabel(ObjName,80,5,"Period: "+iPeriod,3,TextColor,8,WindowFind(ShortName),"Arial Black",false);
      ObjName=ObjNPref+"iStartFrom";
      fObjLabel(ObjName,10,5,"StartFrom: "+iStartFrom,3,TextColor,8,WindowFind(ShortName),"Arial Black",false);


   //=====================================================================================================

      static int LastBars=0;

      if(iStartFrom==LastiStartFrom && iPeriod==LastiPeriod)if(Bars<LastBars+1)return(0);
      LastiStartFrom=iStartFrom;
      LastiPeriod=iPeriod;
      LastBars=Bars;

      ArrayInitialize(ExtMapBuffer1,EMPTY_VALUE);
      ArrayInitialize(ExtMapBuffer2,EMPTY_VALUE);
      ArrayInitialize(ExtMapBuffer3,EMPTY_VALUE);
      ArrayInitialize(ExtMapBuffer4,EMPTY_VALUE);
      ArrayInitialize(ExtMapBuffer5,EMPTY_VALUE);
      ArrayInitialize(ExtMapBuffer6,EMPTY_VALUE);
      ArrayInitialize(ExtMapBuffer7,EMPTY_VALUE);
      ArrayInitialize(ExtMapBuffer8,EMPTY_VALUE);

   //=====================================================================================================

      int tPeriod;
      double tVal_0;
      double tVal_1;
      double tB;
      double tMaxDev;
      double tStdError;
      double tRSquared;
      double Arr[];

      fLinearRegressionAll2(iStartFrom,iStartFrom+iPeriod-1,0,tPeriod,tVal_0,tVal_1,tB,tMaxDev,tStdError,tRSquared,Arr);

   //======================================================================================================

      fFurie(Arr,A,B,R,F);
   //======================================================================================================

      int N=ArraySize(Arr);
         for(int i=0;i<N;i++){
            int ii=i+iStartFrom;
            ExtMapBuffer1[ii]=A[1]*MathSin(1*6.28*i/(N-1))+B[1]*MathCos(1*6.28*i/(N-1));
            ExtMapBuffer2[ii]=A[2]*MathSin(2*6.28*i/(N-1))+B[2]*MathCos(2*6.28*i/(N-1));
            ExtMapBuffer3[ii]=A[3]*MathSin(3*6.28*i/(N-1))+B[3]*MathCos(3*6.28*i/(N-1));
            ExtMapBuffer4[ii]=A[4]*MathSin(4*6.28*i/(N-1))+B[4]*MathCos(4*6.28*i/(N-1));
            ExtMapBuffer5[ii]=A[5]*MathSin(5*6.28*i/(N-1))+B[5]*MathCos(5*6.28*i/(N-1));
            ExtMapBuffer6[ii]=A[6]*MathSin(6*6.28*i/(N-1))+B[6]*MathCos(6*6.28*i/(N-1));
            ExtMapBuffer7[ii]=A[7]*MathSin(7*6.28*i/(N-1))+B[7]*MathCos(7*6.28*i/(N-1));
            ExtMapBuffer8[ii]=A[8]*MathSin(8*6.28*i/(N-1))+B[8]*MathCos(8*6.28*i/(N-1));
         }

   //======================================================================================================
                                   //ëèíèè ñïðàâà
      fObjTrendLine(ObjNPref+"1",Time[0]+Period()*60*3,R[1],Time[0]+Period()*60*3,-R[1],false,indicator_color1,8,WindowFind(ShortName),0,false);
      fObjTrendLine(ObjNPref+"2",Time[0]+Period()*60*5,R[2],Time[0]+Period()*60*5,-R[2],false,indicator_color2,8,WindowFind(ShortName),0,false);
      fObjTrendLine(ObjNPref+"3",Time[0]+Period()*60*7,R[3],Time[0]+Period()*60*7,-R[3],false,indicator_color3,8,WindowFind(ShortName),0,false);
      fObjTrendLine(ObjNPref+"4",Time[0]+Period()*60*9,R[4],Time[0]+Period()*60*9,-R[4],false,indicator_color4,8,WindowFind(ShortName),0,false);
      fObjTrendLine(ObjNPref+"5",Time[0]+Period()*60*11,R[5],Time[0]+Period()*60*11,-R[5],false,indicator_color5,8,WindowFind(ShortName),0,false);
      fObjTrendLine(ObjNPref+"6",Time[0]+Period()*60*13,R[6],Time[0]+Period()*60*13,-R[6],false,indicator_color6,8,WindowFind(ShortName),0,false);
      fObjTrendLine(ObjNPref+"7",Time[0]+Period()*60*15,R[7],Time[0]+Period()*60*15,-R[7],false,indicator_color7,8,WindowFind(ShortName),0,false);
      fObjTrendLine(ObjNPref+"8",Time[0]+Period()*60*17,R[8],Time[0]+Period()*60*17,-R[8],false,indicator_color8,8,WindowFind(ShortName),0,false);


   return(0);
}
//+------------------------------------------------------------------+

                                //íàäïèñü íèæíèé ëåâûé óãîë
void fObjLabel(
   string aObjectName,     // 1 èìÿ
   int aX,                 // 2 õ
   int aY,                 // 3 ó
   string aText,           // 4 òåêñò
   int aCorner=0,          // 5 óãîë   0  1
                           //          2  3
   color aColor=Black,       // 6 öâåò
   int aFontSize=8,        // 7 ðàçìåð øðèôòà
   int aWindowNumber=0,    // 8 îêíî
   string aFont="Arial Black",   // 9 øðèôò
   bool aBack=false        // 10 ôîí
   ){


      if(ObjectFind(aObjectName)!=aWindowNumber){
         ObjectCreate(aObjectName,OBJ_LABEL,aWindowNumber,0,0);
      }
   ObjectSet(aObjectName,OBJPROP_XDISTANCE,aX);
   ObjectSet(aObjectName,OBJPROP_YDISTANCE,aY);
   ObjectSetText(aObjectName,aText,aFontSize,aFont,aColor);
   ObjectSet(aObjectName,OBJPROP_BACK,aBack);
   ObjectSet(aObjectName,OBJPROP_CORNER,aCorner);
}

                               //îòðèñîâêà âåðòèê ëèíèé
void fObjTrendLine(
   string aObjectName,  // 1 èìÿ
   datetime aTime_1,    // 2 âðåìÿ 1
   double aPrice_1,     // 3 öåíà 1
   datetime aTime_2,    // 4 âðåìÿ 2
   double aPrice_2,     // 5 öåíà 2
   bool aRay=false,     // 6 ëó÷
   color aColor=Black,    // 7 öâåò
   int aWidth=1,        // 8 òîëùèíà
   int aWindowNumber=0, // 9 îêíî
   int aStyle=1,        // 10 0-STYLE_SOLID, 1-STYLE_DASH, 2-STYLE_DOT, 3-STYLE_DASHDOT, 4-STYLE_DASHDOTDOT
   bool aBack=false     // 11 ôîí
   ){
      if(ObjectFind(aObjectName)!=aWindowNumber){
         ObjectCreate(aObjectName,OBJ_TREND,aWindowNumber,aTime_1,aPrice_1,aTime_2,aPrice_2);
      }
   ObjectSet(aObjectName,OBJPROP_TIME1,aTime_1);
   ObjectSet(aObjectName,OBJPROP_PRICE1,aPrice_1);
   ObjectSet(aObjectName,OBJPROP_TIME2,aTime_2);
   ObjectSet(aObjectName,OBJPROP_PRICE2,aPrice_2);
   ObjectSet(aObjectName,OBJPROP_RAY,aRay);
   ObjectSet(aObjectName,OBJPROP_COLOR,aColor);
   ObjectSet(aObjectName,OBJPROP_WIDTH,aWidth);
   ObjectSet(aObjectName,OBJPROP_BACK,aBack);
   ObjectSet(aObjectName,OBJPROP_STYLE,aStyle);
}


int fLinearRegressionAll2(int i0,int i1, int aPrice, int & aPeriod, double & aVal_0, double & aVal_1, double & aB, double & aMaxDev, double & aStdError, double & aRSquared,double & aArr[]){
   int rRetError=0;
   double x,y,y1,y2,sumy,sumx,sumxy,sumx2,sumy2,sumx22,sumy22,div1,div2;
   aPeriod=i1-i0+1;
   sumy=0.0;sumx=0.0;sumxy=0.0;sumx2=0.0;sumy2=0.0;
      for(int i=0; i<aPeriod; i++){
         y=iMA(NULL,0,1,0,0,aPrice,i0+i);
         x=i;
         sumy+=y;
         sumxy+=y*i;
         sumx+=x;
         sumx2+=MathPow(x,2);
         sumy2+=MathPow(y,2);
      }
   sumx22=MathPow(sumx,2);
   sumy22=MathPow(sumy,2);
   div1=sumx2*aPeriod-sumx22;
   div2=MathSqrt((aPeriod*sumx2-sumx22)*(aPeriod*sumy2-sumy22));

   //---- regression line ----

      if(div1!=0.0){
         aB=(sumxy*aPeriod-sumx*sumy)/div1;
         aVal_0=(sumy-sumx*aB)/aPeriod;
         aVal_1=aVal_0+aB*(aPeriod-1);
         rRetError+=-1;
      }
      else{
         rRetError+=-1;
      }

   //--- stderr & maxdev

   aMaxDev=0;aStdError=0;

      for(i=0;i<aPeriod;i++){
         y1=iMA(NULL,0,1,0,0,aPrice,i0+i);
         y2=aVal_0+aB*i;
         aMaxDev=MathMax(MathAbs(y1-y2),aMaxDev);
         aStdError+=MathPow(y1-y2,2);
      }

   aStdError=MathSqrt(aStdError/aPeriod);

   //--- rsquared ---

      if(div2!=0){
         aRSquared=MathPow((aPeriod*sumxy-sumx*sumy)/div2,2);
      }
      else{
         rRetError+=-2;
      }

   //----

   ArrayResize(aArr,aPeriod);
      for(i=0; i<aPeriod; i++){
         y=iMA(NULL,0,1,0,0,aPrice,i0+i);
         x=aVal_0+i*(aVal_1-aVal_0)/aPeriod;
         aArr[i]=y-x;
      }
   return(rRetError);
}

void fFurie(double aArr[],double & aA[],double & aB[],double & aR[], double & aF[]){
   int tN=ArraySize(aArr);
   int tM=tN/2;

   ArrayResize(aA,tM);
   ArrayResize(aB,tM);
   ArrayResize(aR,tM);
   ArrayResize(aF,tM);

      for (int ti=1;ti<tM;ti++){
         aA[ti]=0;
         aB[ti]=0;
            for(int tj=0;tj<tN;tj++){
               aA[ti]+=aArr[tj]*MathSin(ti*6.28*tj/tN);
               aB[ti]+=aArr[tj]*MathCos(ti*6.28*tj/tN);
            }
         aA[ti]=2*aA[ti]/tN;
         aB[ti]=2*aB[ti]/tN;
         aR[ti]=MathSqrt(MathPow(aA[ti],2)+MathPow(aB[ti],2));
         aF[ti]=fMyArcTan(aB[ti],aA[ti]);
      }

}

double fMyArcTan(double aS,double aC){
   if(aS==0){
      return(0);
   }
   if(aC==0){
      if(aS>0){
         return(MathArctan(1)*2);
      }
      else{
         if(aS<0){
            return(MathArctan(1)*6);
         }
      }
   }
   else{
      if(aS>0){
         if(aC>0){
            return(MathArctan(aS/aC));
         }
         else{
            return(MathArctan(aS/aC)+MathArctan(1)*4);
         }
      }
      else{
         if(aC>0){
            return(MathArctan(aS/aC)+MathArctan(1)*8);
         }
         else{
            return(MathArctan(aS/aC)+MathArctan(1)*4);
         }
      }
   }
}



void fObjDeleteByPrefix(string aPrefix){
   for(int i=ObjectsTotal()-1;i>=0;i--){
      if(StringFind(ObjectName(i),aPrefix,0)==0){
         ObjectDelete(ObjectName(i));
      }
   }
}
