renkotimev2

Understanding the Renko Time Indicator

This tool is designed to provide traders with a visual representation of the speed at which price action is developing on a Renko chart. Unlike standard charts that move based on fixed time intervals (like every minute or hour), Renko charts are "time-independent," meaning they only create a new block when the price moves a specific amount. Because of this, the actual time it takes for a new block to form can vary significantly depending on market volatility.

How the Logic Works:

The indicator works by measuring and calculating the "waiting time" between consecutive blocks. Here is the step-by-step breakdown of its logic:

  • Historical Analysis: The script looks back at previous blocks on your chart and calculates the exact number of seconds that passed between one block finishing and the next one appearing.
  • Real-Time Tracking: For the most recent (live) block, the script continuously calculates the difference between the current market time and the time the current block began.
  • Visual Representation: These time differences are then plotted on a separate window below your main chart as a histogram.

What This Means for the Trader:

By looking at this histogram, you can visually identify periods of high activity versus stagnation:

  • Short Time Intervals: If the bars on the indicator are small, it means blocks are forming very quickly. This signals high market volatility and rapid price movement.
  • Long Time Intervals: If the bars on the indicator are tall, it means a long period has passed without a new block forming. This signals a "sideways" market or a period of low liquidity where the price is struggling to make significant moves.

Essentially, this tool translates price action into a time dimension, allowing you to see exactly how fast (or slow) the market is moving in real-time.

Miscellaneous
Implements a curve of type %1
5 Views
0 Downloads
0 Favorites
renkotimev2
//--- Renko Time Indicator - time difference between candles / bricks / blocks
#property copyright "Copyright 2015, Paul Reed."
#property version   "2.00"
#property strict
#property indicator_separate_window
#property indicator_buffers 1
#property indicator_color1  Blue
#property indicator_width1  2
#property indicator_minimum 0 // Set indicator fixed min is 0
double timebuffer[]; // Buffer to hold the array of time differences
//+------------------------------------------------------------------+
//|                                                                  |
//+------------------------------------------------------------------+
int OnInit(void)
  {
   IndicatorDigits(0); // We don't need to display fractions of a second!
   SetIndexStyle(0,DRAW_HISTOGRAM);
   SetIndexBuffer(0,timebuffer);
   IndicatorShortName("RenkoTime v 2.0");
   SetIndexLabel(0,"Seconds");

   return(INIT_SUCCEEDED);
  }
//+------------------------------------------------------------------+
//|                                                                  |
//+------------------------------------------------------------------+
int OnCalculate(const int rates_total,
                const int prev_calculated,
                const datetime &time[],
                const double &open[],
                const double &high[],
                const double &low[],
                const double &close[],
                const long &tick_volume[],
                const long &volume[],
                const int &spread[])
  {
   int i,limit;
   limit=rates_total-prev_calculated; // Set limit to the number of candles
   if(prev_calculated>0) limit++;

   for(i=1; i<limit; i++) // For each candle...
      timebuffer[i]=(double)(time[i-1]-time[i]); // Calculate time difference and put in buffer

   timebuffer[0]=(double)(TimeCurrent()-time[0]); // Calculate last bar from the current time

   return(rates_total);
  }
//+------------------------------------------------------------------+
