Author: Copyright � 2005, TrendLaboratory Ltd.
PriceChannel_Stop_v6

This script is designed to help traders visualize market trends and identify potential entry or exit points by establishing dynamic price "channels." Instead of simply looking at raw price action, it uses a mathematical approach to define boundaries that represent the current market momentum.

Core Logic and Functionality

1. Price Channel Construction The tool begins by analyzing a specific window of recent history (the "Channel Period"). It identifies the highest high and lowest low within this timeframe to create a baseline. From these two extremes, it calculates a middle point and a set of boundary lines. These boundaries act as the "walls" of the price channel, helping to define the current range of volatility.

2. Trend Identification (Breakout Logic) The script determines the market trend based on how the price interacts with these calculated boundaries:

  • Bullish Trend: If the price closes above a specific upper boundary, the script identifies an upward trend.
  • Bearish Trend: If the price closes below a specific lower boundary, it identifies a downward trend.
  • Dynamic Adjustment: To ensure the trend remains accurate, the boundaries "correct" themselves. For example, in an uptrend, the lower boundary will only move higher, preventing the support level from dropping and ensuring the trend logic stays consistent as new price data arrives.

3. Risk Factor and Sensitivity The tool includes a "Risk" factor which acts as a narrowing mechanism. This allows users to adjust how "tight" or "loose" the boundaries are. A lower risk factor creates a narrower channel (making the script more sensitive to price changes), while a higher factor creates a wider channel (filtering out minor market noise).

4. Visual Signals and Outputs The script translates these calculations into several visual elements on the chart:

  • Trend Lines: It draws continuous lines representing the current active "stop" or support/resistance level based on the detected trend.
  • Trend Signals: It can display specific markers (arrows) to alert the user exactly when a trend shift occurs—specifically when the price breaks out of the established channel.
  • Color Bars: Optionally, the script can highlight the high and low of a candle only when the price is trading in favor of the current trend. If the price retreats too far against the trend, these bars disappear, helping the trader focus on "strong" movements.

Summary for the User

Essentially, this tool acts as an automated filter. It looks at a block of recent price history to determine where the "floor" and "ceiling" are. When the price breaks through these levels, the script signals a new trend, redraws the support/resistance lines accordingly, and provides visual cues to help the trader stay aligned with the prevailing market direction.

Miscellaneous
Implements a curve of type %1
11 Views
0 Downloads
0 Favorites
PriceChannel_Stop_v6
//+------------------------------------------------------------------+
//|                                         PriceChannel_Stop_v6.mq4 |
//|                           Copyright © 2005, TrendLaboratory Ltd. |
//|                                       E-mail: igorad2004@list.ru |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2005, TrendLaboratory Ltd."
#property link      "E-mail: igorad2004@list.ru"

#property indicator_chart_window
#property indicator_buffers 8
#property indicator_color1 Blue
#property indicator_color2 Red
#property indicator_color3 Blue
#property indicator_color4 Red
#property indicator_color5 Blue
#property indicator_color6 Red
#property indicator_color7 Blue
#property indicator_color8 Red
//---- input parameters
extern int ChannelPeriod=9;   //Price Channel Period
extern double Risk=0.30;      //channel narrowing factor (0...0,5)
extern int Signal=1;          //Display signals mode: 1-Signals & Stops; 0-only Stops; 2-only Signals;
extern int Line=1;            //Display line mode: 0-no,1-yes
extern int ColorBar=1;        //Display color bars mode: 0-no,1-yes
extern int TimeFrame=0;       //TimeFrame in min
extern int Nbars=1000;
//---- indicator buffers
double UpTrendBuffer[];
double DownTrendBuffer[];
double UpTrendSignal[];
double DownTrendSignal[];
double UpTrendLine[];
double DownTrendLine[];
double UpTrendBar[];
double DownTrendBar[];
//+------------------------------------------------------------------+
//| Custom indicator initialization function                         |
//+------------------------------------------------------------------+
int init()
  {
   string short_name;
//---- indicator line
   SetIndexBuffer(0,UpTrendBuffer);
   SetIndexBuffer(1,DownTrendBuffer);
   SetIndexBuffer(2,UpTrendSignal);
   SetIndexBuffer(3,DownTrendSignal);
   SetIndexBuffer(4,UpTrendLine);
   SetIndexBuffer(5,DownTrendLine);
   SetIndexBuffer(6,UpTrendBar);
   SetIndexBuffer(7,DownTrendBar);
   SetIndexStyle(0,DRAW_ARROW);
   SetIndexStyle(1,DRAW_ARROW);
   SetIndexStyle(2,DRAW_ARROW);
   SetIndexStyle(3,DRAW_ARROW);
   SetIndexStyle(4,DRAW_LINE);
   SetIndexStyle(5,DRAW_LINE);
   SetIndexStyle(6,DRAW_HISTOGRAM,STYLE_SOLID,1);
   SetIndexStyle(7,DRAW_HISTOGRAM,STYLE_SOLID,1);
   SetIndexArrow(0,159);
   SetIndexArrow(1,159);
   SetIndexArrow(2,108);
   SetIndexArrow(3,108);
//---- name for DataWindow and indicator subwindow label
   short_name="PriceChannel_Stop("+ChannelPeriod+")";
   IndicatorShortName(short_name);
   SetIndexLabel(0,"UpTrend Stop");
   SetIndexLabel(1,"DownTrend Stop");
   SetIndexLabel(2,"UpTrend Signal");
   SetIndexLabel(3,"DownTrend Signal");
   SetIndexLabel(4,"UpTrend Line");
   SetIndexLabel(5,"DownTrend Line");
   SetIndexLabel(6,"UpTrend Bar");
   SetIndexLabel(7,"DownTrend Bar");
//----
   SetIndexDrawBegin(0,ChannelPeriod);
   SetIndexDrawBegin(1,ChannelPeriod);
   SetIndexDrawBegin(2,ChannelPeriod);
   SetIndexDrawBegin(3,ChannelPeriod);
   SetIndexDrawBegin(4,ChannelPeriod);
   SetIndexDrawBegin(5,ChannelPeriod);
   SetIndexDrawBegin(6,ChannelPeriod);
   SetIndexDrawBegin(7,ChannelPeriod);
//----
   return(0);
  }
//+------------------------------------------------------------------+
//| PriceChannel_Stop_v6                                             |
//+------------------------------------------------------------------+
int start()
  {
   datetime TimeArray[];
   int    i,shift,trend,y=0;
   double high, low, price, sum, VolAverage,UpBar,DnBar;
   double smax[25000],smin[25000],bsmax[25000],bsmin[25000],Mid[25000],Vol[25000];
   double LowArray[],HighArray[];

   for (shift=Nbars-1;shift>=0;shift--)
   {
   UpTrendBuffer[shift]=0.0;
   DownTrendBuffer[shift]=0.0;
   UpTrendSignal[shift]=0.0;
   DownTrendSignal[shift]=0.0;
   UpTrendLine[shift]=EMPTY_VALUE;
   DownTrendLine[shift]=EMPTY_VALUE;
   UpTrendBar[shift]=0.0;
	DownTrendBar[shift]=0.0;
   }
// Draw price channel boards + calculation : Channel middle, half channel width,


   ArrayCopySeries(TimeArray,MODE_TIME,Symbol(),TimeFrame);
   ArrayCopySeries(LowArray,MODE_LOW,Symbol(),TimeFrame);
   ArrayCopySeries(HighArray,MODE_HIGH,Symbol(),TimeFrame);

   for(i=0,y=0;i<Nbars;i++)
   {
   if (Time[i]<TimeArray[y]) y++;
   smin[i]=LowArray[Lowest(NULL,TimeFrame,MODE_LOW,ChannelPeriod,y)];
   smax[i]=HighArray[Highest(NULL,TimeFrame,MODE_HIGH,ChannelPeriod,y)];
   Mid[i]=0.5*(smin[i]+smax[i]);
   }

//

   for (shift=Nbars-ChannelPeriod-1;shift>=0;shift--)
   {
// Calculation channel stop values

     bsmax[shift]=smax[shift]-(smax[shift]-smin[shift])*Risk;
	  bsmin[shift]=smin[shift]+(smax[shift]-smin[shift])*Risk;

// Signal area : any conditions to trend determination:
// 1. Price Channel breakout

     if(Risk>0)
     {
      if(Close[shift]>bsmax[shift])  trend=1;
      if(Close[shift]<bsmin[shift])  trend=-1;
     }
     else
     {
      if(Close[shift]>bsmax[shift+1])  trend=1;
      if(Close[shift]<bsmin[shift+1])  trend=-1;
     }

// Correction boards values with existing trend

	  if(trend>0 && bsmin[shift]<bsmin[shift+1]) bsmin[shift]=bsmin[shift+1];
	  if(trend<0 && bsmax[shift]>bsmax[shift+1]) bsmax[shift]=bsmax[shift+1];

// Drawing area
	  UpBar=bsmax[shift];
	  DnBar=bsmin[shift];

	  if ( Risk == 0 ){UpBar=Mid[shift];DnBar=Mid[shift];}

	  if (trend>0)
	  {
	     if (Signal>0 && UpTrendBuffer[shift+1]==-1.0)
	     {
	        //bsmin[shift]=smin[shift];
	        UpTrendSignal[shift]=bsmin[shift];
	        if(Line>0) UpTrendLine[shift]=bsmin[shift];

	     }
	     else
	     {
	     UpTrendBuffer[shift]=bsmin[shift];
	     if(Line>0) UpTrendLine[shift]=bsmin[shift];
	     UpTrendSignal[shift]=-1;
	     }
	  if(ColorBar>0)
	        {
	           if(Close[shift]>UpBar)
	           {
	              UpTrendBar[shift]=High[shift];
	              DownTrendBar[shift]=Low[shift];
	           }
	           else
	           {
	              UpTrendBar[shift]=EMPTY_VALUE;
	              DownTrendBar[shift]=EMPTY_VALUE;
	           }

	        }
	  if (Signal==2) UpTrendBuffer[shift]=0;
	  DownTrendBuffer[shift]=-1.0;
	  DownTrendLine[shift]=EMPTY_VALUE;
	  }

	  if (trend<0)
	  {
	  if (Signal>0 && DownTrendBuffer[shift+1]==-1.0)
	     {
	     //bsmax[shift]=smax[shift];
	     DownTrendSignal[shift]=bsmax[shift];
	     if(Line>0) DownTrendLine[shift]=bsmax[shift];
	     }
	     else
	     {
	     DownTrendBuffer[shift]=bsmax[shift];
	     if(Line>0)DownTrendLine[shift]=bsmax[shift];
	     DownTrendSignal[shift]=-1;
	     }
	  if(ColorBar>0)
	        {
	           if(Close[shift]<DnBar)
	           {
	              UpTrendBar[shift]=Low[shift];
	              DownTrendBar[shift]=High[shift];
	           }
	           else
	           {
	              UpTrendBar[shift]=EMPTY_VALUE;
	              DownTrendBar[shift]=EMPTY_VALUE;
	           }
	        }
	  if (Signal==2) DownTrendBuffer[shift]=0;
	  UpTrendBuffer[shift]=-1.0;
	  UpTrendLine[shift]=EMPTY_VALUE;
	  }


   }
   return(0);
  }
//+------------------------------------------------------------------+
