NonLagMA_v7.1.mq4

Download script
Author: Copyright � 2007, TrendLaboratory
NonLagMA_v7.1.mq4

The NonLagMA is a specialized technical analysis tool designed to smooth out price fluctuations in financial charts while addressing one of the most common challenges in trading: "lag." In traditional moving averages, there is often a delay between a price change and the indicator's reaction; this script utilizes a sophisticated mathematical approach to minimize that delay, providing a more responsive view of market trends.

Core Logic and Mechanism

The script functions by calculating a non-linear weighted average. Rather than treating all past data points equally (like a simple average) or giving recent data exponentially more weight (like an exponential average), this tool applies a specific "weighting coefficient."

1. Advanced Weighting System The logic employs a trigonometric calculation (based on cosine waves) to determine how much importance to give to various historical price points. By creating a custom distribution of weights, the indicator attempts to "anticipate" the trend direction more accurately than standard methods. This allows the line to stay closer to the actual price action while remaining smooth enough to filter out insignificant "noise."

2. Dynamic Filtering and Deviation The tool includes a sophisticated filtering system to prevent the indicator from reacting to erratic, one-off price spikes.

  • Volatility Adjustment: It calculates the standard deviation (how much the price is swinging) over a specific period.
  • Threshold Logic: If the change in price is smaller than a certain percentage of that volatility, the script ignores it as "noise" and maintains its previous position. This ensures the indicator only moves when there is a meaningful shift in market momentum.

3. Trend Identification and Visual Signaling Beyond simply drawing a line, the script actively interprets the direction of the trend:

  • Color Coding: It can automatically switch between different visual states (Up vs. Down) based on whether the average is moving higher or lower.
  • Trend Persistence: The logic tracks the "state" of the trend. If the price crosses a specific threshold, it locks into an upward or downward state until the opposite condition is met.
  • Visual Bridges: When a trend flips, the script can "bridge" the colors back to the previous bar, providing a clear visual history of where the trend shifted.

User Notifications

The script also includes an automated alerting system. It monitors for specific "crossovers"—moments where the calculated trend reverses from down to up (a potential Buy signal) or up to down (a potential Sell signal). When these conditions are met, the system can trigger:

  • On-Screen Alerts: Pop-up messages providing the current symbol and timeframe.
  • Audio Warnings: Sound effects to notify the trader of a trend change in real-time.

Summary for the User

Essentially, this script acts as a "smart" moving average. It uses complex math to balance two opposing needs: it wants to be fast enough to catch a trend as soon as it starts, but smooth enough to ignore the small, jagged movements of the market. It then translates those movements into clear visual colors and alerts, helping traders identify the prevailing direction of the market more effectively.

Indicators Used
Moving average indicator
Miscellaneous
Implements a curve of type %1It plays sound alerts
12 Views
0 Downloads
0 Favorites
NonLagMA_v7.1.mq4
//+------------------------------------------------------------------+
//|                                                NonLagMA_v7.1.mq4 |
//|                                Copyright © 2007, TrendLaboratory |
//|            http://finance.groups.yahoo.com/group/TrendLaboratory |
//|                                   E-mail: igorad2003@yahoo.co.uk |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2007, TrendLaboratory"
#property link      "http://finance.groups.yahoo.com/group/TrendLaboratory"


#property indicator_chart_window
#property indicator_buffers 3
#property indicator_color1 Orange
#property indicator_width1 2
#property indicator_color2 SkyBlue
#property indicator_width2 2
#property indicator_color3 Tomato
#property indicator_width3 2


//---- input parameters
extern int     Price          = 0;  //Apply to Price(0-Close;1-Open;2-High;3-Low;4-Median price;5-Typical price;6-Weighted Close)
extern int     Length         = 15;  //Period of NonLagMA
extern int     Displace       = 0;  //DispLace or Shift
extern double  PctFilter      = 0;  //Dynamic filter in decimal
extern string note1 ="turn on Color = 1; turn off = 0";
extern int     Color          = 1;  //Switch of Color mode (1-color)
extern int     ColorBarBack   = 1;  //Bar back for color mode
extern double  Deviation      = 0;  //Up/down deviation
extern string note2 ="turn on Alert = 1; turn off = 0";
extern int     AlertMode      = 0;  //Sound Alert switch (0-off,1-on)
extern string note3 ="turn on Warning = 1; turn off = 0";
extern int     WarningMode    = 0;  //Sound Warning switch(0-off,1-on)
//---- indicator buffers
double MABuffer[];
double UpBuffer[];
double DnBuffer[];
double trend[];
double Del[];
double AvgDel[];

double alfa[];
int i, Phase, Len,Cycle=4;
double Coeff, beta, t, Sum, Weight, g;
double pi = 3.1415926535;
bool   UpTrendAlert=false, DownTrendAlert=false;
//+------------------------------------------------------------------+
//| Custom indicator initialization function                         |
//+------------------------------------------------------------------+
  int init()
  {
   IndicatorBuffers(6);
   SetIndexStyle(0,DRAW_LINE);
   SetIndexBuffer(0,MABuffer);
   SetIndexStyle(1,DRAW_LINE);
   SetIndexBuffer(1,UpBuffer);
   SetIndexStyle(2,DRAW_LINE);
   SetIndexBuffer(2,DnBuffer);
   SetIndexBuffer(3,trend);
   SetIndexBuffer(4,Del);
   SetIndexBuffer(5,AvgDel);
   string short_name;
//---- indicator line

   IndicatorDigits(MarketInfo(Symbol(),MODE_DIGITS));
//---- name for DataWindow and indicator subwindow label
   short_name="NonLagMA("+Length+")";
   IndicatorShortName(short_name);
   SetIndexLabel(0,"NonLagMA");
   SetIndexLabel(1,"Up");
   SetIndexLabel(2,"Dn");
//----
   SetIndexShift(0,Displace);
   SetIndexShift(1,Displace);
   SetIndexShift(2,Displace);

   SetIndexEmptyValue(0,EMPTY_VALUE);
   SetIndexEmptyValue(1,EMPTY_VALUE);
   SetIndexEmptyValue(2,EMPTY_VALUE);

   SetIndexDrawBegin(0,Length*Cycle+Length+1);
   SetIndexDrawBegin(1,Length*Cycle+Length+1);
   SetIndexDrawBegin(2,Length*Cycle+Length+1);
//----

   Coeff =  3*pi;
   Phase = Length-1;
   Len = Length*4 + Phase;
   ArrayResize(alfa,Len);
   Weight=0;

      for (i=0;i<Len-1;i++)
      {
      if (i<=Phase-1) t = 1.0*i/(Phase-1);
      else t = 1.0 + (i-Phase+1)*(2.0*Cycle-1.0)/(Cycle*Length-1.0);
      beta = MathCos(pi*t);
      g = 1.0/(Coeff*t+1);
      if (t <= 0.5 ) g = 1;
      alfa[i] = g * beta;
      Weight += alfa[i];
      }

   return(0);
  }

//+------------------------------------------------------------------+
//| NonLagMA_v7.1                                                      |
//+------------------------------------------------------------------+
int start()
{
   int    i,shift, counted_bars=IndicatorCounted(),limit;
   double price;
   if ( counted_bars > 0 )  limit=Bars-counted_bars;
   if ( counted_bars < 0 )  return(0);
   if ( counted_bars ==0 )  limit=Bars-Len-1;
   if ( counted_bars < 1 )

   for(i=1;i<Length*Cycle+Length;i++)
   {
   MABuffer[Bars-i]=0;
   UpBuffer[Bars-i]=0;
   DnBuffer[Bars-i]=0;
   }

   for(shift=limit;shift>=0;shift--)
   {
      Sum = 0;
      for (i=0;i<=Len-1;i++)
	   {
      price = iMA(NULL,0,1,0,3,Price,i+shift);
      Sum += alfa[i]*price;

      }

	if (Weight > 0) MABuffer[shift] = (1.0+Deviation/100)*Sum/Weight;


      if (PctFilter>0)
      {
      Del[shift] = MathAbs(MABuffer[shift] - MABuffer[shift+1]);

      double sumdel=0;
      for (i=0;i<=Length-1;i++) sumdel = sumdel+Del[shift+i];
      AvgDel[shift] = sumdel/Length;

      double sumpow = 0;
      for (i=0;i<=Length-1;i++) sumpow+=MathPow(Del[shift+i]-AvgDel[shift+i],2);
      double StdDev = MathSqrt(sumpow/Length);

      double Filter = PctFilter * StdDev;

      if( MathAbs(MABuffer[shift]-MABuffer[shift+1]) < Filter ) MABuffer[shift]=MABuffer[shift+1];
      }
      else
      Filter=0;

      if (Color>0)
      {
      trend[shift]=trend[shift+1];
      if (MABuffer[shift]-MABuffer[shift+1] > Filter) trend[shift]= 1;
      if (MABuffer[shift+1]-MABuffer[shift] > Filter) trend[shift]=-1;
         if (trend[shift]>0)
         {
         UpBuffer[shift] = MABuffer[shift];
         if (trend[shift+ColorBarBack]<0) UpBuffer[shift+ColorBarBack]=MABuffer[shift+ColorBarBack];
         DnBuffer[shift] = EMPTY_VALUE;
         if (WarningMode>0 && trend[shift+1]<0 && shift==0) PlaySound("alert2.wav");
         }
         if (trend[shift]<0)
         {
         DnBuffer[shift] = MABuffer[shift];
         if (trend[shift+ColorBarBack]>0) DnBuffer[shift+ColorBarBack]=MABuffer[shift+ColorBarBack];
         UpBuffer[shift] = EMPTY_VALUE;
         if (WarningMode>0 && trend[shift+1]>0 && shift==0) PlaySound("alert2.wav");
         }
      }
   }
//----------
   string Message;

   if ( trend[2]<0 && trend[1]>0 && Volume[0]>1 && !UpTrendAlert)
	{
	Message = " "+Symbol()+" M"+Period()+": Signal for BUY";
	if ( AlertMode>0 ) Alert (Message);
	UpTrendAlert=true; DownTrendAlert=false;
	}

	if ( trend[2]>0 && trend[1]<0 && Volume[0]>1 && !DownTrendAlert)
	{
	Message = " "+Symbol()+" M"+Period()+": Signal for SELL";
	if ( AlertMode>0 ) Alert (Message);
	DownTrendAlert=true; UpTrendAlert=false;
	}
//----
	return(0);
}
