NonLagMA_v7_HIST

Download script
Author: Copyright � 2006, TrendLaboratory
NonLagMA_v7_HIST

This indicator is designed to provide a smoother, more responsive analysis of market trends by utilizing a sophisticated mathematical approach to moving averages. Its primary goal is to identify the direction of market momentum while minimizing the "lag" (the delay between a price movement and the indicator's reaction) that typically affects standard moving averages.

Core Logic and Methodology

1. Advanced Smoothing Technique Unlike basic moving averages that treat all past data points equally or in a simple linear sequence, this script employs a customized weighting system. It calculates a "Non-Lag" coefficient based on trigonometric functions (specifically cosines) and specialized weights. This allows the indicator to prioritize information in a way that emphasizes current price action more effectively than standard models, helping to reduce the visual delay on the chart.

2. Dynamic Filtering and Stability The script includes a built-in volatility filter. When enabled, it calculates the standard deviation of recent price movements. It then compares the current movement against this volatility. If a price change is too small to be considered significant (falling below a specific threshold), the indicator holds its previous value. This prevents "market noise" or tiny, insignificant price flickers from causing the indicator to jump around unnecessarily, ensuring it only reacts to meaningful trend changes.

3. Trend Identification and Visualization The indicator processes price data into three distinct visual components:

  • Trend Detection: It constantly compares the current calculated value against the previous one to determine if the momentum is moving upward or downward.
  • Visual Histogram: It paints the chart with specific colors (typically Lime Green for up-trends and Red for down-trends) to make the direction of the market immediately obvious to the user.
  • Color Continuity: It features a logic that ensures smooth color transitions on the chart, preventing "stuttering" colors and making it easier to see exactly where a trend reversal occurred.

4. Automated Alert System Beyond the visual display, the script contains a logic layer dedicated to notifications. It monitors for specific "crosses"—moments where the trend flips from negative to positive (Buy signal) or positive to negative (Sell signal). When these reversals occur, and provided there is active trading volume, the script can trigger:

  • Visual Alerts: On-screen pop-up messages identifying the specific asset and timeframe.
  • Audio Alerts: Sound files that play to notify the trader of a trend change in real-time.

Summary for the User

In essence, this tool acts as a sophisticated filter for market movement. It takes raw price data, applies a mathematical formula to smooth out unnecessary noise without sacrificing speed, and translates that into a color-coded visual map. It tells you not just what the price is doing now, but which way the "weight" of the market is leaning, while alerting you the moment that lean shifts in direction.

Indicators Used
Moving average indicator
Miscellaneous
Implements a curve of type %1It plays sound alerts
16 Views
0 Downloads
0 Favorites
NonLagMA_v7_HIST
//+------------------------------------------------------------------+
//|                                                  NonLagMA_v7.mq4 |
//|                                Copyright © 2006, TrendLaboratory |
//|            http://finance.groups.yahoo.com/group/TrendLaboratory |
//|                                   E-mail: igorad2003@yahoo.co.uk |
//|                                                                  |
//|             March 20/2008 Added separate window & histogram mode |
//|                                         GoingForward - Forex-Tsd |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2006, TrendLaboratory"
#property link      "http://finance.groups.yahoo.com/group/TrendLaboratory"


#property indicator_separate_window
#property indicator_buffers 3
#property indicator_color1 Orange
#property indicator_width1 2
#property indicator_color2 LimeGreen
#property indicator_width2 2
#property indicator_color3 Red
#property indicator_width3 2


//---- input parameters
extern int     Price          = 0;  //Apply to Price(0-Close;1-Open;2-High;3-Low;4-Median price;5-Typical price;6-Weighted Close)
extern int     Length         = 21;  //Period of NonLagMA
extern int     Displace       = 0;  //DispLace or Shift
extern double  PctFilter      = 0;  //Dynamic filter in decimal
extern int     Color          = 1;  //Switch of Color mode (1-color)
extern int     ColorBarBack   = 1;  //Bar back for color mode
extern double  Deviation      = 0;  //Up/down deviation
extern int     SoundAlertMode = 0;  //Sound Alert switch
//---- indicator buffers
double MABuffer[];
double UpBuffer[];
double DnBuffer[];
double trend[];
double Del[];
double AvgDel[];

double alfa[];
int i, Phase, Len, Cycle=4;
double Coeff, beta, t, Sum, Weight, g;
double pi = 3.1415926535;
bool   UpTrendAlert=false, DownTrendAlert=false;
//+------------------------------------------------------------------+
//| Custom indicator initialization function                         |
//+------------------------------------------------------------------+
  int init()
  {
   IndicatorBuffers(6);
   SetIndexStyle(0,DRAW_HISTOGRAM);
   SetIndexBuffer(0,MABuffer);
   SetIndexStyle(1,DRAW_HISTOGRAM);
   SetIndexBuffer(1,UpBuffer);
   SetIndexStyle(2,DRAW_HISTOGRAM);
   SetIndexBuffer(2,DnBuffer);
   SetIndexBuffer(3,trend);
   SetIndexBuffer(4,Del);
   SetIndexBuffer(5,AvgDel);
   string short_name;
//---- indicator line

   IndicatorDigits(MarketInfo(Symbol(),MODE_DIGITS));
//---- name for DataWindow and indicator subwindow label
   short_name="NonLagMA_Hist("+Length+")";
   IndicatorShortName(short_name);
   SetIndexLabel(0,"NonLagMA_Hist");
   SetIndexLabel(1,"Up");
   SetIndexLabel(2,"Dn");
//----
   SetIndexShift(0,Displace);
   SetIndexShift(1,Displace);
   SetIndexShift(2,Displace);

   SetIndexEmptyValue(0,EMPTY_VALUE);
   SetIndexEmptyValue(1,EMPTY_VALUE);
   SetIndexEmptyValue(2,EMPTY_VALUE);

   SetIndexDrawBegin(0,Length*Cycle+Length+1);
   SetIndexDrawBegin(1,Length*Cycle+Length+1);
   SetIndexDrawBegin(2,Length*Cycle+Length+1);
//----

   Coeff =  3*pi;
   Phase = Length-1;
   Len = Length*Cycle + Phase;
   ArrayResize(alfa,Len);
   Weight=0;

      for (i=0;i<Len-1;i++)
      {
      if (i<=Phase-1) t = 1.0*i/(Phase-1);
      else t = 1.0 + (i-Phase+1)*(2.0*Cycle-1.0)/(Cycle*Length-1.0);
      beta = MathCos(pi*t);
      g = 1.0/(Coeff*t+1);
      if (t <= 0.5 ) g = 1;
      alfa[i] = g * beta;
      Weight += alfa[i];
      }

   return(0);
  }

//+------------------------------------------------------------------+
//| NonLagMA_v7                                                      |
//+------------------------------------------------------------------+
int start()
{
   int    i,shift, counted_bars=IndicatorCounted(),limit;
   double price;
   if ( counted_bars > 0 )  limit=Bars-counted_bars;
   if ( counted_bars < 0 )  return(0);
   if ( counted_bars ==0 )  limit=Bars-Len-1;
   if ( counted_bars < 1 )

   for(i=1;i<Length*Cycle+Length;i++)
   {
   MABuffer[Bars-i]=0;
   UpBuffer[Bars-i]=0;
   DnBuffer[Bars-i]=0;
   }

   for(shift=limit;shift>=0;shift--)
   {
      Sum = 0;
      for (i=0;i<=Len-1;i++)
	   {
      price = iMA(NULL,0,1,0,3,Price,i+shift);
      Sum += alfa[i]*price;

      }

	if (Weight > 0) MABuffer[shift] = (1.0+Deviation/100)*Sum/Weight;


      if (PctFilter>0)
      {
      Del[shift] = MathAbs(MABuffer[shift] - MABuffer[shift+1]);

      double sumdel=0;
      for (i=0;i<=Length-1;i++) sumdel = sumdel+Del[shift+i];
      AvgDel[shift] = sumdel/Length;

      double sumpow = 0;
      for (i=0;i<=Length-1;i++) sumpow+=MathPow(Del[shift+i]-AvgDel[shift+i],2);
      double StdDev = MathSqrt(sumpow/Length);

      double Filter = PctFilter * StdDev;

      if( MathAbs(MABuffer[shift]-MABuffer[shift+1]) < Filter ) MABuffer[shift]=MABuffer[shift+1];
      }

      if (Color>0)
      {
      trend[shift]=trend[shift+1];
      if (MABuffer[shift]-MABuffer[shift+1] > Filter) trend[shift]= 1;
      if (MABuffer[shift+1]-MABuffer[shift] > Filter) trend[shift]=-1;
         if (trend[shift]>0)
         {
         UpBuffer[shift] = MABuffer[shift];
         if (trend[shift+ColorBarBack]<0) UpBuffer[shift+ColorBarBack]=MABuffer[shift+ColorBarBack];
         DnBuffer[shift] = EMPTY_VALUE;
         if (SoundAlertMode>0 && trend[shift+1]<0 && shift==0) PlaySound("alert2.wav");
         }
         if (trend[shift]<0)
         {
         DnBuffer[shift] = MABuffer[shift];
         if (trend[shift+ColorBarBack]>0) DnBuffer[shift+ColorBarBack]=MABuffer[shift+ColorBarBack];
         UpBuffer[shift] = EMPTY_VALUE;
         if (SoundAlertMode>0 && trend[shift+1]>0 && shift==0) PlaySound("alert2.wav");
         }
      }
   }
//----------
   string Message;

   if ( trend[2]<0 && trend[1]>0 && Volume[0]>1 && !UpTrendAlert)
	{
	Message = " "+Symbol()+" M"+Period()+": Signal for BUY";
	if ( SoundAlertMode>0 ) Alert (Message);
	UpTrendAlert=true; DownTrendAlert=false;
	}

	if ( trend[2]>0 && trend[1]<0 && Volume[0]>1 && !DownTrendAlert)
	{
	Message = " "+Symbol()+" M"+Period()+": Signal for SELL";
	if ( SoundAlertMode>0 ) Alert (Message);
	DownTrendAlert=true; UpTrendAlert=false;
	}
//----
	return(0);
}
