MultiRSI

Author: Copyright 2015, MetaQuotes Software Corp.
MultiRSI

This tool is designed to give traders a comprehensive view of market momentum by combining multiple timeframes into a single visual window. Instead of forcing you to switch back and forth between different charts to see the "big picture," this script consolidates that information into one place.

Core Functionality

The primary purpose of this script is to display the Relative Strength Index (RSI)—a common momentum oscillator—simultaneously for seven different time periods: 1 Minute, 5 Minutes, 15 Minutes, 30 Minutes, 1 Hour, 4 Hours, and 1 Day.

How It Works

  • Multi-Timeframe Integration: The script pulls data from various intervals (from very short-term "scalping" timeframes to long-term daily trends). This allows you to see if a move on a small chart is supported by the larger trend, or if a large trend is reaching an exhausted point.
  • Customizable Visibility: You have full control over which timeframes are displayed. Through the settings, you can toggle specific periods on or off. For example, if you only care about the 1-Hour and Daily trends, you can hide the smaller minute-based data to keep your chart clean.
  • Visual Clarity: Each timeframe is assigned a unique color (such as Red, Orange, Gold, Lime, Aqua, Blue, and Purple). This makes it easy to distinguish between different timeframes at a glance.
  • Standardized Benchmarks: The tool automatically plots three horizontal levels: 30, 50, and 70. These serve as traditional reference points for identifying "oversold," "neutral," and "overbought" conditions across all active timeframes simultaneously.

Key Benefits for the Trader

By using this script, you can perform high-level analysis much faster. You can quickly identify "confluence"—where multiple timeframes align in the same direction—or spot potential reversals where a short-term timeframe is moving against a dominant long-term trend. It essentially eliminates the need to manage multiple windows, streamlining your workspace and providing a holistic view of market behavior.

Indicators Used
Relative strength index
Miscellaneous
Implements a curve of type %1
11 Views
0 Downloads
0 Favorites
MultiRSI
//+------------------------------------------------------------------+
//|                                                     MultiRSI.mq4 |
//|                        Copyright 2015, MetaQuotes Software Corp. |
//|                                             https://www.mql5.com |
//+------------------------------------------------------------------+
#property copyright "Copyright 2015, MetaQuotes Software Corp."
#property link      "https://www.mql5.com"
#property version   "1.1"
#property strict

#property indicator_separate_window
#property indicator_plots   7
#property indicator_buffers 7

input bool                 PeriodM1  = false;            // 1 Minute
input bool                 PeriodM5  = false;            // 5 Minutes
input bool                 PeriodM15 = false;            // 15 Minutes
input bool                 PeriodM30 = false;            // 30 Minutes
input bool                 PeriodH1  = false;            // 1 Hour
input bool                 PeriodH4  = false;            // 4 Hours
input bool                 PeriodD1  = false;            // 1 Day
input int                  PeriodRSI = 14;               // RSI Period
input ENUM_APPLIED_PRICE   AppliedPrice = PRICE_CLOSE;   // RSI Applied Price

double M1Buffer[];
double M5Buffer[];
double M15Buffer[];
double M30Buffer[];
double H1Buffer[];
double H4Buffer[];
double D1Buffer[];
int shiftArray[indicator_plots];
//+------------------------------------------------------------------+
//|                                                                  |
//+------------------------------------------------------------------+
int OnInit()
  {
   SetIndexBuffer(0,M1Buffer);
   SetIndexBuffer(1,M5Buffer);
   SetIndexBuffer(2,M15Buffer);
   SetIndexBuffer(3,M30Buffer);
   SetIndexBuffer(4,H1Buffer);
   SetIndexBuffer(5,H4Buffer);
   SetIndexBuffer(6,D1Buffer);

   SetIndexLabel(0,"RSI(M1)");
   SetIndexLabel(1,"RSI(M5)");
   SetIndexLabel(2,"RSI(M15)");
   SetIndexLabel(3,"RSI(M30)");
   SetIndexLabel(4,"RSI(H1)");
   SetIndexLabel(5,"RSI(H4)");
   SetIndexLabel(6,"RSI(D1)");

   SetIndexEmptyValue(0,EMPTY_VALUE);
   SetIndexEmptyValue(1,EMPTY_VALUE);
   SetIndexEmptyValue(2,EMPTY_VALUE);
   SetIndexEmptyValue(3,EMPTY_VALUE);
   SetIndexEmptyValue(4,EMPTY_VALUE);
   SetIndexEmptyValue(5,EMPTY_VALUE);
   SetIndexEmptyValue(6,EMPTY_VALUE);

   if(PeriodM1) SetIndexStyle(0,DRAW_LINE,STYLE_SOLID,1,clrRed); else SetIndexStyle(0,DRAW_NONE);
   if(PeriodM5) SetIndexStyle(1,DRAW_LINE,STYLE_SOLID,1,clrOrange); else SetIndexStyle(1,DRAW_NONE);
   if(PeriodM15) SetIndexStyle(2,DRAW_LINE,STYLE_SOLID,1,clrGold); else SetIndexStyle(2,DRAW_NONE);
   if(PeriodM30) SetIndexStyle(3,DRAW_LINE,STYLE_SOLID,1,clrLime); else SetIndexStyle(3,DRAW_NONE);
   if(PeriodH1) SetIndexStyle(4,DRAW_LINE,STYLE_SOLID,1,clrAqua); else SetIndexStyle(4,DRAW_NONE);
   if(PeriodH4) SetIndexStyle(5,DRAW_LINE,STYLE_SOLID,1,clrBlue); else SetIndexStyle(5,DRAW_NONE);
   if(PeriodD1) SetIndexStyle(6,DRAW_LINE,STYLE_SOLID,1,clrPurple); else SetIndexStyle(6,DRAW_NONE);

   IndicatorSetDouble(INDICATOR_MINIMUM,0.0);
   IndicatorSetDouble(INDICATOR_MAXIMUM,100.0);

   IndicatorSetInteger(INDICATOR_LEVELS,3);
   IndicatorSetDouble(INDICATOR_LEVELVALUE, 0, 30.0);
   IndicatorSetDouble(INDICATOR_LEVELVALUE, 1, 50.0);
   IndicatorSetDouble(INDICATOR_LEVELVALUE, 2, 70.0);
   IndicatorDigits((int)MarketInfo(Symbol(),MODE_DIGITS));

   string timeFrames=NULL;
   if(PeriodM1) timeFrames += (PeriodM1 ? "M1" : NULL);
   if(PeriodM5) timeFrames += (timeFrames == NULL ? "M5" : ",M5");
   if(PeriodM15) timeFrames += (timeFrames == NULL ? "M15" : ",M15");
   if(PeriodM30) timeFrames += (timeFrames == NULL ? "M30" : ",M30");
   if(PeriodH1) timeFrames += (timeFrames == NULL ? "H1" : ",H1");
   if(PeriodH4) timeFrames += (timeFrames == NULL ? "H4" : ",H4");
   if(PeriodD1) timeFrames += (timeFrames == NULL ? "D1" : ",D1");
   IndicatorShortName(StringFormat("MultiRSI[%s](%d)",(timeFrames==NULL ? "none" : timeFrames),PeriodRSI));

   ArrayInitialize(shiftArray,0);

   return(INIT_SUCCEEDED);
  }
//+------------------------------------------------------------------+
//|                                                                  |
//+------------------------------------------------------------------+
int OnCalculate(const int rates_total,
                const int prev_calculated,
                const datetime &time[],
                const double &open[],
                const double &high[],
                const double &low[],
                const double &close[],
                const long &tick_volume[],
                const long &volume[],
                const int &spread[])
  {
   if(rates_total <= PeriodRSI) return(0);
   int limit=rates_total-prev_calculated;
   if(prev_calculated>0)
     {
      limit+=(PeriodD1 ? PERIOD_D1 :(PeriodH4 ? PERIOD_H4 :(PeriodH1 ? PERIOD_H1 :(PeriodM30 ? PERIOD_M30 :(PeriodM15 ? PERIOD_M15 :(PeriodM5 ? PERIOD_M5 : PERIOD_M1))))));
     }

   for(int i=0; i<limit; i++)
     {
      M1Buffer[i] = (PeriodM1 ? getRSI(shiftArray, 0, PERIOD_M1, time[i]) : EMPTY_VALUE);
      M5Buffer[i] = (PeriodM5 ? getRSI(shiftArray, 1, PERIOD_M5, time[i]) : EMPTY_VALUE);
      M15Buffer[i] = (PeriodM15 ? getRSI(shiftArray, 2, PERIOD_M15, time[i]) : EMPTY_VALUE);
      M30Buffer[i] = (PeriodM30 ? getRSI(shiftArray, 3, PERIOD_M30, time[i]) : EMPTY_VALUE);
      H1Buffer[i] = (PeriodH1 ? getRSI(shiftArray, 4, PERIOD_H1, time[i]) : EMPTY_VALUE);
      H4Buffer[i] = (PeriodH4 ? getRSI(shiftArray, 5, PERIOD_H4, time[i]) : EMPTY_VALUE);
      D1Buffer[i] = (PeriodD1 ? getRSI(shiftArray, 6, PERIOD_D1, time[i]) : EMPTY_VALUE);
     }

   return(rates_total);
  }
//+------------------------------------------------------------------+
//|                                                                  |
//+------------------------------------------------------------------+
double getRSI(int &_array[],int _ind,int _tf,datetime _time)
  {
   double result=0.0;
   int shift=iBarShift(NULL,_tf,_time,false);
   if(_array[_ind]!=shift || shift==0) _array[_ind]=shift;
   result=iRSI(NULL,_tf,PeriodRSI,AppliedPrice,_array[_ind]);
   return(result > Point ? result : EMPTY_VALUE);
  }
//+------------------------------------------------------------------+
