MTF_4TF_Supertrend_BarM

Download script
Author: Copyright � 2006, Eli hayun
MTF_4TF_Supertrend_BarM

This script is a multi-timeframe (MTF) technical indicator designed to give traders a visual summary of market trends across four different time horizons simultaneously. Instead of forcing you to switch between various charts to see the "big picture," it consolidates this information into a single view.

Core Functionality

Dynamic Timeframe Selection The script is intelligent enough to recognize which timeframe chart you are currently viewing. It automatically selects a logical sequence of four timeframes relative to your current view. For example, if you are looking at a 1-hour chart, it will automatically pull data from smaller increments (like minutes) up to larger ones (like 4-hour blocks). This ensures that the data displayed is always relevant to the scale of your current trading activity.

Supertrend Integration The logic relies on an external "Supertrend" calculation. It looks at these trends across all four selected timeframes and determines whether the market is in an "Up" (Bullish) or "Down" (Bearish) state for each period.

Visual Representation To keep the chart clean and readable, the script uses a system of colored arrows or bars displayed in a separate window:

  • Color Coding: It uses distinct colors (typically Red and Lime/Blue) to represent bearish and bullish trends respectively.
  • Stacking Logic: Rather than overlapping all the data on top of each other, the script "stacks" the results vertically using a set gap. This allows you to see four distinct rows of information at once.
  • Labeling: It automatically generates text labels for each row so you can easily identify which row corresponds to which timeframe (e.g., identifying which row is the M15 trend versus the H4 trend).

How it Works for the User

When you load this onto your platform, the script performs the following behind-the-scenes actions:

  1. Identifies your current chart period.
  2. Calculates the trends for four related timeframes simultaneously.
  3. Plots the results as a series of marks in a dedicated window.
  4. Organizes those marks into a vertical list, allowing you to see at a glance if all timeframes are aligned (e.g., all rows showing "Up") or if there is a conflict between short-term and long-term movements.
Miscellaneous
Implements a curve of type %1
9 Views
0 Downloads
0 Favorites
MTF_4TF_Supertrend_BarM
//+------------------------------------------------------------------+
//|                                      MTF_4TF_Supertrend_BarM.mq4 |
//|    Modified  from :  " FF Add-on to be used with 4TF HAS Bar.mq4 |
//|                 Modified by Matsu, from #MTF Supertrend Bar.mq4 "|
//|   M:Up/Dn TF[0/TF+4]     (inc.order top to bottom)            ik                                   Copyright © 2006, Eli hayun |
//|                                          http://www.elihayun.com |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2006, Eli hayun"
#property link      "http://www.elihayun.com"

#property indicator_separate_window
#property indicator_minimum 0
#property indicator_maximum 5
#property indicator_buffers 8
#property indicator_color1 Red
#property indicator_color2 Lime
#property indicator_color3 Red
#property indicator_color4 Lime
#property indicator_color5 Red
#property indicator_color6 Lime
#property indicator_color7 Red
#property indicator_color8 Lime

//---- parameters
//extern int MaMetod  = 2;
//extern int MaPeriod = 6;
//extern int MaMetod2  = 3;
//extern int MaPeriod2 = 2;
extern int BarWidth = 0;//3;
extern color UpBarColor = Blue;
extern color DownBarColor = Red;
extern color TextColor = White;

double Gap = 1; // Gap between the lines of bars
//---- buffers
double buf4_up[];
double buf4_down[];
double buf3_up[];
double buf3_down[];
double buf2_up[];
double buf2_down[];
double buf1_up[];
double buf1_down[];
double haOpen;
double haClose;


/*
extern int Period_1 = 15;
extern int Period_2 = 30;
extern int Period_3 = 60;
extern int Period_4 = 240;

extern bool AutoDisplay      = false;
*/
string shortname = "";
bool firstTime = true;

int ArrSize = 110;//112;//168;//158;//159;
int UniqueNum = 228;

//+------------------------------------------------------------------+
//| Custom indicator initialization function                         |
//+------------------------------------------------------------------+
int init()
  {

   //SetAutoDisplay();


   firstTime = true;

   //IndicatorShortName(shortname);
//---- indicators
   SetIndexStyle(0,DRAW_ARROW,0,BarWidth,UpBarColor);
   SetIndexArrow(0,ArrSize);
   SetIndexBuffer(0,buf1_up);
   SetIndexEmptyValue(0,0.0);
   SetIndexStyle(1,DRAW_ARROW,0,BarWidth,DownBarColor);
   SetIndexArrow(1,ArrSize);
   SetIndexBuffer(1,buf1_down);
   SetIndexEmptyValue(1,0.0);
   SetIndexStyle(2,DRAW_ARROW,0,BarWidth,UpBarColor);
   SetIndexArrow(2,ArrSize);
   SetIndexBuffer(2,buf2_up);
   SetIndexEmptyValue(2,0.0);
   SetIndexStyle(3,DRAW_ARROW,0,BarWidth,DownBarColor);
   SetIndexArrow(3,ArrSize);
   SetIndexBuffer(3,buf2_down);
   SetIndexEmptyValue(3,0.0);
   SetIndexStyle(4,DRAW_ARROW,0,BarWidth,UpBarColor);
   SetIndexArrow(4,ArrSize);
   SetIndexBuffer(4,buf3_up);
   SetIndexEmptyValue(4,0.0);
   SetIndexStyle(5,DRAW_ARROW,0,BarWidth,DownBarColor);
   SetIndexArrow(5,ArrSize);
   SetIndexBuffer(5,buf3_down);
   SetIndexEmptyValue(5,0.0);
   SetIndexStyle(6,DRAW_ARROW,0,BarWidth,UpBarColor);
   SetIndexArrow(6,ArrSize);
   SetIndexBuffer(6,buf4_up);
   SetIndexEmptyValue(6,0.0);
   SetIndexStyle(7,DRAW_ARROW,0,BarWidth,DownBarColor);
   SetIndexArrow(7,ArrSize);
   SetIndexBuffer(7,buf4_down);
   SetIndexEmptyValue(7,0.0);
   //
 //
   IndicatorDigits(0);
//----
   return(0);
  }
//+------------------------------------------------------------------+
//| Custom indicator deinitialization function                       |
//+------------------------------------------------------------------+
int deinit()
  {
//----
   //SetAutoDisplay();

//   shortname = "# Forex Freedom("+Period_1+","+Period_2+","+Period_3+","+Period_4+")";
   firstTime = true;
//----
   return(0);
  }
//+------------------------------------------------------------------+
//| Custom indicator iteration function                              |
//+------------------------------------------------------------------+
int start()
  {
   int    counted_bars=IndicatorCounted();
   int i=0, y15m=0, y4h=0, y1h=0, y30m=0, yy;
   int limit=Bars-counted_bars;

   int Period_1, Period_2, Period_3, Period_4;
   switch(Period())
      {
         case 1:
            Period_1=1; Period_2=5; Period_3=15; Period_4=30;
            break;
         case 5:
            Period_1=5; Period_2=15; Period_3=30; Period_4=60;
            break;
         case 15:
            Period_1=15; Period_2=30; Period_3=60; Period_4=240;
            break;
         case 30:
            Period_1=30; Period_2=60; Period_3=240; Period_4=1440;
            break;
         case 60:
            Period_1=60; Period_2=240; Period_3=1440; Period_4=10080;
            break;
         case 240:
            Period_1=240; Period_2=1440; Period_3=10080; Period_4=43200;
            break;
         case 1440:
            Period_1=1440; Period_2=10080; Period_3=43200; Period_4=43200;
            break;
         case 10080:
            Period_1=10080; Period_2=43200; Period_3=43200; Period_4=43200;
            break;
         case 43200:
            Period_1=43200; Period_2=43200; Period_3=43200; Period_4=43200;
            break;

      }


   shortname = "MTF_4TF_Supertrend_BarM("+Period_1+","+Period_2+","+Period_3+","+Period_4+")";
   IndicatorShortName(shortname);


   SetIndexLabel(0,"MTF_ST,"+Period_4+"");
   SetIndexLabel(1,"MTF_SV,"+Period_4+"");
   SetIndexLabel(2,"MTF_ST,"+Period_3+"");
   SetIndexLabel(3,"MTF_ST,"+Period_3+"");
   SetIndexLabel(4,"MTF_ST,"+Period_2+"");
   SetIndexLabel(5,"MTF_ST,"+Period_2+"");
   SetIndexLabel(6,"MTF_ST,"+Period_1+"");
   SetIndexLabel(7,"MTF_ST,"+Period_1+"");




   datetime TimeArray_4H[], TimeArray_1H[], TimeArray_30M[], TimeArray_15M[];
//----



   if (firstTime || NewBar())
   {
      firstTime = false;
      int win = UniqueNum; // WindowFind(shortname);
      double dif = Time[0] - Time[1];
      for (int ii=ObjectsTotal()-1; ii>-1; ii--)
      {
         if (StringFind(ObjectName(ii),"FF_"+win+"_") >= 0)
            ObjectDelete(ObjectName(ii));
         else
            ii=-1;
      }

      double shift = 0.2;
      for (ii=0; ii<4; ii++)
      {
         string txt = "??";
         double gp;
         switch (ii)
         {
            case 0: txt = tf2txt(Period_4);  gp = 1 + shift;
break;
            case 1: txt = tf2txt(Period_3);  gp = 1 + Gap + shift;
break;
            case 2: txt = tf2txt(Period_2);  gp = 1 + Gap*2 + shift;
break;
            case 3: txt = tf2txt(Period_1);  gp = 1 + Gap*3 + shift;
break;
         }
         string name = "ST_"+win+"_"+ii+"_"+txt;
         ObjectCreate(name, OBJ_TEXT, WindowFind(shortname),
iTime(NULL,0,0)+dif*3, gp);
         ObjectSetText(name, txt,6,"Arial", TextColor);

      }




   }

   ArrayCopySeries(TimeArray_4H,MODE_TIME,Symbol(),Period_4);
   ArrayCopySeries(TimeArray_1H,MODE_TIME,Symbol(),Period_3);
   ArrayCopySeries(TimeArray_30M,MODE_TIME,Symbol(),Period_2);
   ArrayCopySeries(TimeArray_15M,MODE_TIME,Symbol(),Period_1);

   for(i=0, y15m=0,  y4h=0,  y1h=0,  y30m=0;i<limit;i++)
   {
      if (Time[i]<TimeArray_15M[y15m]) y15m++;
      if (Time[i]<TimeArray_4H[y4h])   y4h++;
      if (Time[i]<TimeArray_1H[y1h])   y1h++;
      if (Time[i]<TimeArray_30M[y30m]) y30m++;

      for (int tf = 0; tf < 4; tf++)
      {
         int prd;
         switch (tf)
         {
            case 0: prd = Period_1; yy = y15m;  break;
            case 1: prd = Period_2; yy = y30m;  break;
            case 2: prd = Period_3;  yy = y1h;   break;
            case 3: prd = Period_4;  yy = y4h;   break;
         }


         haOpen = iCustom(NULL,prd,"Supertrend",1,yy) ;
         haClose = iCustom(NULL,prd,"Supertrend",0,yy) ;

         double dUp = EMPTY_VALUE; //   iCustom(NULL, prd, "SuperTrend", false, 1, yy);
         double dDn = EMPTY_VALUE; //iCustom(NULL, prd, "SuperTrend", false, 0, yy);

         if (haOpen<haClose) dDn = 1; else dUp = 1;

         switch (tf)
         {
            case 3: if (dUp == EMPTY_VALUE)  buf1_down[i] = 1;
else buf1_up[i] = 1; break;
            case 2: if (dUp == EMPTY_VALUE)  buf2_down[i] = 1 + Gap *
1; else buf2_up[i] = 1 + Gap * 1; break;
            case 1: if (dUp == EMPTY_VALUE)  buf3_down[i]  = 1 + Gap *
2; else buf3_up[i]  = 1 + Gap * 2; break;
            case 0: if (dUp == EMPTY_VALUE)  buf4_down[i]  = 1  + Gap *
3; else buf4_up[i]  = 1 + Gap * 3; break;
         }


      }


   }

   return(0);
  }
//+------------------------------------------------------------------+

string tf2txt(int tf)
{
   if (tf == PERIOD_M1)    return("M1");
   if (tf == PERIOD_M5)    return("M5");
   if (tf == PERIOD_M15)    return("M15");
   if (tf == PERIOD_M30)    return("M30");
   if (tf == PERIOD_H1)    return("H1");
   if (tf == PERIOD_H4)    return("H4");
   if (tf == PERIOD_D1)    return("D1");
   if (tf == PERIOD_W1)    return("W1");
   if (tf == PERIOD_MN1)    return("MN1");

   return("??");
}

/*void SetValues(int p1, int p2, int p3, int p4)
{
   Period_1 = p1;   Period_2 = p2; Period_3 = p3; Period_4 = p4;
}


void SetAutoDisplay()
{
   if (AutoDisplay)
   {
      switch (Period())
      {
         case PERIOD_M1  :  SetValues(PERIOD_M1,  PERIOD_M5,
PERIOD_M15,PERIOD_M30); break;
         case PERIOD_M5  :  SetValues(PERIOD_M5,
PERIOD_M15,PERIOD_M30,PERIOD_H1); break;
         case PERIOD_M15 :  SetValues(PERIOD_M5,
PERIOD_M15,PERIOD_M30,PERIOD_H1); break;
         case PERIOD_M30 :  SetValues(PERIOD_M5, PERIOD_M15,PERIOD_M30,
PERIOD_H1); break;
         case PERIOD_H1  :  SetValues(PERIOD_M15, PERIOD_M30,PERIOD_H1,
PERIOD_H4);  break;
         case PERIOD_H4  :  SetValues(PERIOD_M30, PERIOD_H1, PERIOD_H4,
PERIOD_D1);  break;
         case PERIOD_D1  :  SetValues(PERIOD_H1,  PERIOD_H4, PERIOD_D1,
PERIOD_W1); break;
         case PERIOD_W1  :  SetValues(PERIOD_H4,  PERIOD_D1,
PERIOD_W1,PERIOD_MN1); break;
         case PERIOD_MN1 :  SetValues(PERIOD_H4,  PERIOD_D1,
PERIOD_W1,PERIOD_MN1);  break;
      }
   }

}
*/
bool NewBar()
{
   static datetime dt = 0;

   if (Time[0] != dt)
   {
      dt = Time[0];
      return(true);
   }
   return(false);
}
