exoticwavein_v1
Download script
This script is designed as a data management tool for MetaTrader, specifically created to export historical market data into external CSV files. It automates the process of organizing price history so that it can be easily accessed or analyzed in other spreadsheet applications.
Core Functionality
The primary purpose of this script is to scan your current trading chart and save every individual candle—including its time, opening price, high, low, closing price, and volume—into a structured text file.
How the Logic Works
1. Identification and Organization The script automatically detects which timeframe you are currently viewing (for example, one minute, five minutes, one hour, or one day). It then creates a specific folder structure based on that timeframe. This ensures that your data remains organized; for instance, "daily" data will be saved separately from "hourly" data to prevent files from overlapping.
2. Data Processing Loop Once the script identifies the correct file destination, it begins a systematic backward scan of the chart history. It moves through every single bar on your screen, one by one, starting from the most recent data point and moving toward the oldest.
3. Time Formatting For every candle processed, the script extracts the exact date and time information. It intelligently formats these numbers into a standardized string (e.g., ensuring that months or hours like "5" are recorded as "05"). This uniform formatting is crucial for maintaining chronological order when you open the data later in other software.
4. File Generation The script performs a "clean slate" operation by deleting any existing file of the same name before starting, then creates a brand new CSV file. It writes every piece of gathered information—the formatted date/time, price points, and volume—into this file as a continuous list.
5. User Feedback To keep the user informed during the process, the script provides visual updates on the chart screen. It displays "Tick" counts to show that it is running correctly and provides a confirmation message once the data export for a specific period has been successfully completed.
/*-----------------------------+
| |
| Shared by www.Aptrafx.com |
| |
+------------------------------*/
//+------------------------------------------------------------------+
//| Copyright © 2005, FX Waves :)
//+------------------------------------------------------------------+
#property copyright "Copyright © 2005, Sprrite&Lemon"
#property link "wladimir447@yandex.ru"
#property indicator_chart_window
#property indicator_buffers 1
#property indicator_color1 Blue
//---- input parameters
int Bar;
extern int LastBar=0;
extern int cnttik = 3 ;
double ExtMapBuffer1[];
// ??????? ???? ? ?? ?????? N-? ??? ????????? ???? ?????????
int tick = 0 ;
int init()
{
//---- indicators
SetIndexStyle(0,DRAW_LINE);
SetIndexBuffer(0,ExtMapBuffer1);
//----
return(0);
}
//+------------------------------------------------------------------+
//| Custor indicator deinitialization function |
//+------------------------------------------------------------------+
int deinit()
{
//----
//----
return(0);
}
//+------------------------------------------------------------------+
//| Custom indicator iteration function |
//+------------------------------------------------------------------+
int start()
{
string sName="",ss1=" ",ss2=" ";
int file=0, NumBar=0, shift=0;
int Ye=0,Mo=0,Da=0,Ho=0,Mi=0,Se=0,Ti=0;
int counted_bars=IndicatorCounted();
//---- check for possible errors
if (counted_bars<0) return(-1);
// ??????? ???? ;
tick++;
if ( tick <= cnttik )
{
Print(" Tick = ", tick);
Comment( tick ,"/", cnttik ," | " , Bars);
// ????? ???? ! - ?????????
return(0) ;
}
else
{
tick = 0 ;
// ??????? ??????????? ????
//int rfile = FileOpen("sprrite.csv",FILE_CSV|FILE_WRITE,",");
//FileWrite(rfile,"yes");
//FileClose(rfile);
}
//int filesh = FileOpen("zag.csv",FILE_CSV|FILE_READ);
// string sh = FileReadString(filesh);
// FileClose( filesh );
//----
if ( 1 == 1)
{
// ???
if (Period()==10080) sName="monthly"+"\\"+Symbol()+Period()+".csv";
if (Period()==43200) sName="weekly"+"\\"+Symbol()+Period()+".csv";
if (Period()==1440) sName="daily"+"\\"+Symbol()+Period()+".csv";
if (Period()==240) sName="4_hour"+"\\"+Symbol()+Period()+".csv";
if (Period()==60) sName="1_hour"+"\\"+Symbol()+Period()+".csv";
if (Period()==30) sName="half_hour"+"\\"+Symbol()+Period()+".csv";
if (Period()==15) sName="quarter_hour"+"\\"+Symbol()+Period()+".csv";
if (Period()==5) sName="5_min"+"\\"+Symbol()+Period()+".csv";
if (Period()==1) sName="1_min"+"\\"+Symbol()+Period()+".csv";
// ??????? ??????????
FileDelete(sName);
file =FileOpen(sName,FILE_CSV|FILE_WRITE,",");
// FileWrite(file,sh);
shift=Bars+LastBar-1;
while(shift>=0)
{
Ti=Time[shift];
Ye=TimeYear(Ti);
Mo=TimeMonth(Ti);
Da=TimeDay(Ti);
Ho=TimeHour(Ti);
Mi=TimeMinute(Ti);
if ( Ho == 0 && Mi == 0 ) Mi = 1 ;
Se=TimeSeconds(Ti);
ss1=Ye;
if (Mo<10) ss1=ss1+"0"+Mo; else ss1=ss1+Mo;
if (Da<10) ss1=ss1+"0"+Da; else ss1=ss1+Da;
if (Ho<10) ss2="0"+Ho; else ss2=Ho;
if (Mi<10) ss2=ss2+"0"+Mi; else ss2=ss2+Mi;
FileWrite(file,ss1,ss2,Open[shift],High[shift],Low[shift],Close[shift],Volume[shift]);
shift--;
}
Comment( " Save of "+ss1+" "+ss2+" is ok" , " === " , Bars);
NumBar=counted_bars;
FileClose(file);
Print(" ???????? " , Bars);
}
//----
return(0);
}
