Easy_iCustom_and_Alerts_v2
Download scriptThis script is designed to simplify how traders monitor multiple technical indicators simultaneously without needing to write complex code. It acts as a "bridge" or a "container" that allows you to load various external indicators and receive automatic alerts based on the interaction between them—specifically when their data lines cross each other.
Core Functionality
The primary purpose of this tool is to monitor three different indicators (or three different lines from an indicator) at once. It looks for "crossings," which occur when one indicator's value moves from being below another to above it (an upward cross), or vice versa (a downward cross).
How the Logic Works
The script follows a structured process to monitor your trading environment:
1. Indicator Loading (The Input) Instead of manually watching three different windows, you provide the script with the details of the indicators you want to track. You can specify:
- The specific currency pair (e.g., EURUSD).
- The name of the indicator file.
- The timeframe (e.g., 15-minute, Hourly).
- Specific parameters (settings) for those indicators, such as periods or methods.
2. Data Retrieval The script runs a background process to "fetch" the current numerical values from these three indicators. It maps these values onto your chart so you can see them visually, just like a standard indicator would appear.
3. Crossing Detection Logic This is the "brain" of the script. It continuously compares the values of the loaded indicators against one another in three specific combinations:
- Comparison A: Indicator 1 vs. Indicator 2
- Comparison B: Indicator 2 vs. Indicator 3
- Comparison C: Indicator 1 vs. Indicator 3
The logic tracks the "direction" of these values. It remembers which indicator was on top in the previous moment and compares it to the current moment. If the relationship changes (e.g., Indicator 1 was lower than Indicator 2 but is now higher), the script identifies this as a "cross."
4. Alert System When a cross is detected, the script triggers an automatic alert. These alerts are customized based on your settings:
- It tells you which currency pair the action occurred on.
- It identifies which specific indicators crossed.
- It specifies the direction of the move (Upward or Downward).
User Flexibility
The script is built to be modular. By using a special "null" value (-100) in the settings, you can choose to disable certain parts of the logic. This allows you to customize the behavior:
- Full Monitoring: You can track all three indicators interacting with each other.
- Selective Monitoring: You can choose to only monitor two specific indicators while ignoring the third, or only monitor specific pairings (like 1 vs 3) while ignoring others.
In essence, this tool transforms a manual observation task into an automated notification system, allowing you to stay informed about key market shifts across multiple signals simultaneously.
//+------------------------------------------------------------------+
//| Easy iCustom and Alerts.mq4 |
//| Codersguru |
//| http://www.forex-tsd.com |
//+------------------------------------------------------------------+
#property copyright "Codersguru and cockeyedcowboy"
#property link "http://www.forex-tsd.com"
#property indicator_chart_window
#property indicator_buffers 3
#property indicator_color1 Red
#property indicator_color2 Blue
#property indicator_color3 Yellow
double ExtMapBuffer1[];
double ExtMapBuffer2[];
double ExtMapBuffer3[];
extern bool Alert_On_Crossing=true;
extern string Pair_1="EURUSD";
extern string Indicator_Name_1="Moving Averages";
extern int TimeFrame_1=0;
extern int Line_1=0;
extern double Parameter1_1=12;
extern double Parameter2_1=0;
extern double Parameter3_1=1;
extern double Parameter4_1=-100;
extern double Parameter5_1=-100;
extern string Pair_2="EURUSD";
extern string Indicator_Name_2="Moving Averages";
extern int TimeFrame_2=0;
extern int Line_2=0;
extern double Parameter1_2=144;
extern double Parameter2_2=0;
extern double Parameter3_2=1;
extern double Parameter4_2=-100;
extern double Parameter5_2=-100;
extern string Pair_3="EURUSD";
extern string Indicator_Name_3="Moving Averages";
extern int TimeFrame_3=0;
extern int Line_3=0;
extern double Parameter1_3=169;
extern double Parameter2_3=0;
extern double Parameter3_3=1;
extern double Parameter4_3=-100;
extern double Parameter5_3=-100;
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
int Crossed_1 (double line1 , double line2)
{
static int last_direction=0;
static int current_direction=0;
static bool first_time=true;
if(first_time==true)
{
first_time=false;
return(0);
}
if(line1>line2)current_direction=1; //up
if(line1<line2)current_direction=2; //down
if(current_direction!=last_direction) //changed
{
last_direction=current_direction;
return(last_direction);
}
else
{
return(0); //not changed
}
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
int Crossed_2 (double line1 , double line2)
{
static int last_direction=0;
static int current_direction=0;
static bool first_time=true;
if(first_time==true)
{
first_time=false;
return(0);
}
if(line1>line2)current_direction=1; //up
if(line1<line2)current_direction=2; //down
if(current_direction!=last_direction) //changed
{
last_direction=current_direction;
return(last_direction);
}
else
{
return(0); //not changed
}
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
int Crossed_3 (double line1 , double line2)
{
static int last_direction=0;
static int current_direction=0;
static bool first_time=true;
if(first_time==true)
{
first_time=false;
return(0);
}
if(line1>line2)current_direction=1; //up
if(line1<line2)current_direction=2; //down
if(current_direction!=last_direction) //changed
{
last_direction=current_direction;
return(last_direction);
}
else
{
return(0); //not changed
}
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
int init()
{
SetIndexStyle(0,DRAW_LINE);
SetIndexBuffer(0,ExtMapBuffer1);
SetIndexStyle(1,DRAW_LINE);
SetIndexBuffer(1,ExtMapBuffer2);
SetIndexStyle(2,DRAW_LINE);
SetIndexBuffer(2,ExtMapBuffer3);
if (Pair_1=="NULL") Pair_1=NULL;
if (Pair_2=="NULL") Pair_2=NULL;
if (Pair_3=="NULL") Pair_3=NULL;
return(0);
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
int deinit()
{
return(0);
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
int start()
{
int counted_bars=IndicatorCounted();
if (counted_bars>0) counted_bars--;
int pos=Bars-counted_bars;
while(pos>=0)
{
ExtMapBuffer1[pos]= GetIcustomValue(1,pos);
ExtMapBuffer2[pos]= GetIcustomValue(2,pos);
ExtMapBuffer3[pos]= GetIcustomValue(3,pos);
pos--;
}
static int isCrossed_1 =0;
static int isCrossed_2 =0;
static int isCrossed_3 =0;
if (Alert_On_Crossing)
{
if(Parameter1_1!=-100 && Parameter2_1!=-100 && Parameter3_1!=-100) //1 - 2 - 3
{
isCrossed_1=Crossed_1(GetIcustomValue(1,0),GetIcustomValue(2,0));
if (isCrossed_1==1) Alert (Pair_1 + ": " + Indicator_Name_1 + " (" + Parameter1_1 + ") has been crossed " + Indicator_Name_2 + " (" + Parameter1_2 + ") Upward!" );
if (isCrossed_1==2) Alert (Pair_1 + ": " + Indicator_Name_1 + " (" + Parameter1_1 + ") has been crossed " + Indicator_Name_2 + " (" + Parameter1_2 + ") Downward!" );
isCrossed_2=Crossed_2(GetIcustomValue(2,0),GetIcustomValue(3,0));
if (isCrossed_2==1) Alert (Pair_1 + ": " + Indicator_Name_2 + " (" + Parameter1_2 + ") has been crossed " + Indicator_Name_3 + " (" + Parameter1_3 + ") Upward!" );
if (isCrossed_2==2) Alert (Pair_1 + ": " + Indicator_Name_2 + " (" + Parameter1_2 + ") has been crossed " + Indicator_Name_3 + " (" + Parameter1_3 + ") Upward!" );
isCrossed_3=Crossed_3(GetIcustomValue(1,0),GetIcustomValue(3,0));
if (isCrossed_3==1) Alert (Pair_1 + ": " + Indicator_Name_1 + " (" + Parameter1_1 + ") has been crossed " + Indicator_Name_3 + " (" + Parameter1_3 + ") Upward!" );
if (isCrossed_3==2) Alert (Pair_1 + ": " + Indicator_Name_1 + " (" + Parameter1_1 + ") has been crossed " + Indicator_Name_3 + " (" + Parameter1_3 + ") Upward!" );
}
if(Parameter1_1!=-100 && Parameter2_1!=-100 && Parameter3_1==-100) // 1 - 2
{
isCrossed_1=Crossed_1(GetIcustomValue(1,0),GetIcustomValue(2,0));
if (isCrossed_1==1) Alert (Pair_1 + ": " + Indicator_Name_1 + " (" + Parameter1_1 + ") has been crossed " + Indicator_Name_2 + " (" + Parameter1_2 + ") Upward!" );
if (isCrossed_1==2) Alert (Pair_1 + ": " + Indicator_Name_1 + " (" + Parameter1_1 + ") has been crossed " + Indicator_Name_2 + " (" + Parameter1_2 + ") Upward!" );
}
if(Parameter1_1!=-100 && Parameter2_1==-100 && Parameter3_1!=-100) // 1 - 3
{
isCrossed_1=Crossed_1(GetIcustomValue(1,0),GetIcustomValue(3,0));
if (isCrossed_1==1) Alert (Pair_1 + ": " + Indicator_Name_1 + " (" + Parameter1_1 + ") has been crossed " + Indicator_Name_3 + " (" + Parameter1_3 + ") Upward!" );
if (isCrossed_1==2) Alert (Pair_1 + ": " + Indicator_Name_1 + " (" + Parameter1_1 + ") has been crossed " + Indicator_Name_3 + " (" + Parameter1_3 + ") Upward!" );
}
if(Parameter1_1==-100 && Parameter2_1!=-100 && Parameter3_1!=-100) // 2 - 3
{
isCrossed_1=Crossed_1(GetIcustomValue(2,0),GetIcustomValue(3,0));
if (isCrossed_1==1) Alert (Pair_2 + ": " + Indicator_Name_2 + " (" + Parameter1_2 + ") has been crossed " + Indicator_Name_3 + " (" + Parameter1_3 + ") Upward!" );
if (isCrossed_1==2) Alert (Pair_2 + ": " + Indicator_Name_2 + " (" + Parameter1_2 + ") has been crossed " + Indicator_Name_3 + " (" + Parameter1_3 + ") Upward!" );
}
}
return(0);
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
double GetIcustomValue(int level ,int shift)
{
double value =0;
switch(level)
{
case 1 :
{
if(Parameter1_1!=-100 && Parameter2_1==-100 && Parameter3_1==-100 && Parameter4_1==-100 && Parameter5_1==-100)
value=iCustom(Pair_1,TimeFrame_1,Indicator_Name_1,Parameter1_1,Line_1,shift);
if(Parameter1_1!=-100 && Parameter2_1!=-100 && Parameter3_1==-100 && Parameter4_1==-100 && Parameter5_1==-100)
value=iCustom(Pair_1,TimeFrame_1,Indicator_Name_1,Parameter1_1,Parameter2_1,Line_1,shift);
if(Parameter1_1!=-100 && Parameter2_1!=-100 && Parameter3_1!=-100 && Parameter4_1==-100 && Parameter5_1==-100)
value=iCustom(Pair_1,TimeFrame_1,Indicator_Name_1,Parameter1_1,Parameter2_1,Parameter3_1,Line_1,shift);
if(Parameter1_1!=-100 && Parameter2_1!=-100 && Parameter3_1!=-100 && Parameter4_1!=-100 && Parameter5_1==-100)
value=iCustom(Pair_1,TimeFrame_1,Indicator_Name_1,Parameter1_1,Parameter2_1,Parameter3_1,Parameter4_1,Line_1,shift);
if(Parameter1_1!=-100 && Parameter2_1!=-100 && Parameter3_1!=-100 && Parameter4_1!=-100 && Parameter5_1!=-100)
value=iCustom(Pair_1,TimeFrame_1,Indicator_Name_1,Parameter1_1,Parameter2_1,Parameter3_1,Parameter4_1,Parameter5_1,Line_1,shift);
break;
}
case 2 :
{
if(Parameter1_2!=-100 && Parameter2_2==-100 && Parameter3_2==-100 && Parameter4_2==-100 && Parameter5_2==-100)
value=iCustom(Pair_2,TimeFrame_2,Indicator_Name_2,Parameter1_2,Line_2,shift);
if(Parameter1_2!=-100 && Parameter2_2!=-100 && Parameter3_2==-100 && Parameter4_2==-100 && Parameter5_2==-100)
value=iCustom(Pair_2,TimeFrame_2,Indicator_Name_2,Parameter1_2,Parameter2_2,Line_2,shift);
if(Parameter1_2!=-100 && Parameter2_2!=-100 && Parameter3_2!=-100 && Parameter4_2==-100 && Parameter5_2==-100)
value=iCustom(Pair_2,TimeFrame_2,Indicator_Name_2,Parameter1_2,Parameter2_2,Parameter3_2,Line_2,shift);
if(Parameter1_2!=-100 && Parameter2_2!=-100 && Parameter3_2!=-100 && Parameter4_2!=-100 && Parameter5_2==-100)
value=iCustom(Pair_2,TimeFrame_2,Indicator_Name_2,Parameter1_2,Parameter2_2,Parameter3_2,Parameter4_2,Line_2,shift);
if(Parameter1_2!=-100 && Parameter2_2!=-100 && Parameter3_2!=-100 && Parameter4_2!=-100 && Parameter5_2!=-100)
value=iCustom(Pair_2,TimeFrame_2,Indicator_Name_2,Parameter1_2,Parameter2_2,Parameter3_2,Parameter4_2,Parameter5_2,Line_2,shift);
break;
}
case 3 :
{
if(Parameter1_3!=-100 && Parameter2_3==-100 && Parameter3_3==-100 && Parameter4_3==-100 && Parameter5_3==-100)
value=iCustom(Pair_3,TimeFrame_3,Indicator_Name_3,Parameter1_3,Line_3,shift);
if(Parameter1_3!=-100 && Parameter2_3!=-100 && Parameter3_3==-100 && Parameter4_3==-100 && Parameter5_3==-100)
value=iCustom(Pair_3,TimeFrame_3,Indicator_Name_3,Parameter1_3,Parameter2_3,Line_3,shift);
if(Parameter1_3!=-100 && Parameter2_3!=-100 && Parameter3_3!=-100 && Parameter4_3==-100 && Parameter5_3==-100)
value=iCustom(Pair_3,TimeFrame_3,Indicator_Name_3,Parameter1_3,Parameter2_3,Parameter3_3,Line_3,shift);
if(Parameter1_3!=-100 && Parameter2_3!=-100 && Parameter3_3!=-100 && Parameter4_3!=-100 && Parameter5_3==-100)
value=iCustom(Pair_3,TimeFrame_3,Indicator_Name_3,Parameter1_3,Parameter2_3,Parameter3_3,Parameter4_3,Line_3,shift);
if(Parameter1_3!=-100 && Parameter2_3!=-100 && Parameter3_3!=-100 && Parameter4_3!=-100 && Parameter5_3!=-100)
value=iCustom(Pair_3,TimeFrame_3,Indicator_Name_3,Parameter1_3,Parameter2_3,Parameter3_3,Parameter4_3,Parameter5_3,Line_3,shift);
break;
}
}
return(value);
}
/*»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»««««««««««««««««««««««««««««««««««««««««««««««««««««
//»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»» DOCUMENTATION DIVISION ««««««««««««««««««««««««««««««««««
//»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»««««««««««««««««««««««««««««««««««««««««««««««««««««
««« PURPOSE, SCOPE, AND FUNCTION: »»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»
I know very much the pain of using iCustom function and thousand of requests asking me
about Alerts on crossing an indicator another indicator.
If you get tired of iCustom usage and Alerts embedding, this indicator for you!
You can use this indicator to load the indicators you want using iCustom function but
you will not write a line of code. All what will you do is entering the inputs of the
indicators you want to load in the Easy iCustom and Alerts input window and when the
indicator alerts you.
««« DESCRIPTION OF PROGRAM USAGE: »»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»
Parameters:
Alert_On_Crossing
Set this option to true if you want the indicator alerts you when any of the loaded
indicators has been crossed.
Pair_1
Set here the currency pair string you want to use with the first indicator. Use "NULL"
if you want to work with the current currency.
EXAMPLE: "EURUSD".
Indicator_Name_1
The name of the first indicator you want to load. This name must be the same as the
file name of the indicator without the .ex4 extension.
EXAMPLE: "Moving Averages" (the original file name is Moving Averages.ex4)
TimeFrame_1
The timeframe (in minutes) of the first indicator you want to load. use 0 if you want
to work with the current time frame.
EXAMPLE: 30
PERIOD_M1 1
PERIOD_M5 5
PERIOD_M15 15
PERIOD_M30 30
PERIOD_H1 60
PERIOD_H4 240
PERIOD_D1 1440
PERIOD_W1 10080
PERIOD_MN1 43200
Line_1
The line of the indicator you are loading that you want to use. It's zero based
number which means the first line is 0 and the second line is 1 and the last line
is 7 (The maximum value of lines allowed in any indicator are 8 and starts from 0,
then the last line is 7). The most of the indicator uses only one line, so you will
use 0 here.
Parameter1_1
Set the first parameter of the indicator you want to load as the first line. The
parameters of the indicator are any values declared as external variables. For
example the Moving Averages indicator accepts three parameters:
extern int MA_Period
extern int MA_Shift
extern int MA_Method
So, you have to enter the MA_Period here as the first parameter.
Parameter2_1
The second parameter of the indicator you want to load as the first line.
Parameter3_1
The third parameter of the indicator you want to load as the first line.
Parameter4_1
The fourth parameter of the indicator you want to load as the first line.
Parameter5_1
The fifth parameter of the indicator you want to load as the first line.
Pair_2
Set here the currency pair string you want to use with the second line.
Indicator_Name_2
The name of the second line you want to load.
TimeFrame_2
The timeframe (in minutes) of the second line you want to load.
Line_2
The line of the second indicator you are loading that you want to use.
Parameter1_2
Set the first parameter of the indicator you want to load as the second line.
Parameter2_2
The second parameter of the indicator you want to load as the second line.
Parameter3_2
The third parameter of the indicator you want to load as the second line.
Parameter4_2
The fourth parameter of the indicator you want to load as the second line.
Parameter5_2
The fifth parameter of the indicator you want to load as the second line.
Pair_3
Set here the currency pair string you want to use with the third line.
Indicator_Name_3
The name of the third line you want to load.
TimeFrame_3
The timeframe (in minutes) of the third line you want to load.
Line_3
The line of the second line you are loading that you want to use.
Parameter1_3
Set the first parameter of the indicator you want to load as the third line.
Parameter2_3
The second parameter of the indicator you want to load as the third line.
Parameter3_3
The third parameter of the indicator you want to load as the third line.
Parameter4_3
The fourth parameter of the indicator you want to load as the third line.
Parameter5_3
The fifth parameter of the indicator you want to load as the third line.
««« FILES DISCRIPTIONS: »»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»
««« TESTING AND SCRIP DEBUGING: »»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»
««« VERSION UPDATES: »»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»
Current Revisions:
Version 1.00.01 KTL 00-00-2006
*
Future Enhancement:
-
««« CODING, SCRIPT NOTES: »»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»
NOTE 1:
How to know how many lines (buffers) in an indicator?
Just open the source code of the indicator in MetaTrader and check the line:
#property indicator_buffers 1
The number 1 means 1 line and 2 means 2 line etc (up to 8 lines).
NOTE 2:
How to know how many parameters the indicator accept?
AS I told you before the parameters are the external functions that the indicator uses.
So, Open the indicator source code and check how many external functions it uses.
NOTE 3:
The order of the external functions declaration in the source code of the indicator
are the order of the parameters the indicator accept.
EXAMPLE:
extern int MA_Period = 13; <-- Parameter 1
extern int MA_Shift = 0; <-- Parameter 2
extern int MA_Method = 0; <-- Parameter 3
««« CODE STORAGE AREA: »»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»
//»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»«««««««««««««««««««««««««««««««««««««««««««««««««««««
//»»»»»»»»»»»»»»»»» END PROGRAM SCRIPT; MetaQuote Source Code [ mq4 ] ««««««««««««««««
//»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»««««««««««««««««««««««««««««««««« [rev.09-20-05] «««*/
//+------------------------------------------------------------------+
Comments
