D_RSI

Indicator Logic Overview

This script is designed to generate a specialized Relative Strength Index (RSI) for use in financial trading charts. While it builds upon the foundational logic of a standard RSI, it incorporates advanced smoothing layers to refine the visual data and potentially reduce market "noise."

Here is a breakdown of how the logic operates:

1. Core Calculation (The Foundation)

The script begins by looking at price changes over a specific timeframe (defined by the period setting). It identifies whether the price moved up or down between consecutive candles:

  • Positive Movement: Gains are summed together.
  • Negative Movement: Losses are summed separately.
  • Relative Strength: It calculates the ratio of these gains against the losses to determine the "momentum" of the asset. This is then converted into a scale of 0 to 100.

2. Smoothing & Data Handling

Unlike a basic RSI that might react sharply to every minor price tick, this script uses a multi-stage process to stabilize the line:

  • Initial Accumulation: It establishes a starting point by looking back at the historical data to ensure the indicator has enough context to begin drawing.
  • Moving Average Integration: As it calculates new values, it blends current performance with previous results. This prevents the indicator from jumping erratically and helps maintain a more fluid trend line.

3. Advanced Mathematical Filtering

The most unique aspect of this specific script is the use of complex weighted multipliers at the end of its calculation. The logic takes the calculated RSI value and runs it through two distinct rounds of heavy mathematical filtering:

  • Weighting Systems: It looks back at a large window of previous data points (up to 63 previous values) and applies specific, precise decimal weights to each one.
  • Double Smoothing: By running the data through these two consecutive layers of multipliers, the script aims to "filter" out insignificant fluctuations. This results in an indicator that prioritizes significant structural trends over minor price ripples.

Summary for the User

In plain terms, this script takes standard market momentum (RSI), applies a smoothing technique so it isn't jumpy, and then passes that data through a series of highly specific mathematical filters. The goal is to provide a cleaner, more refined trend line that highlights significant price movements while ignoring minor market "jitter."

Miscellaneous
Implements a curve of type %1
17 Views
0 Downloads
0 Favorites
D_RSI
//+------------------------------------------------------------------+
//|                                                          RSI.mq4 |
//|                      Copyright © 2004, MetaQuotes Software Corp. |
//|                                       http://www.metaquotes.net/ |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2004, MetaQuotes Software Corp."
#property link      "http://www.metaquotes.net/"

#property indicator_separate_window
#property indicator_minimum 0
#property indicator_maximum 100
#property indicator_buffers 1
#property indicator_color1 Blue
#property indicator_level1 30
#property indicator_level2 70

//---- input parameters
extern int RSIPeriod=11;
//---- buffers
double RSIBuffer[];
//double RSIBuffer1[];
double PosBuffer[];
double NegBuffer[];
//+------------------------------------------------------------------+
//| Custom indicator initialization function                         |
//+------------------------------------------------------------------+
int init()
  {
   string short_name;
//---- 2 additional buffers are used for counting.
   IndicatorBuffers(3);
   SetIndexBuffer(1,PosBuffer);
   SetIndexBuffer(2,NegBuffer);
//---- indicator line
   SetIndexStyle(0,DRAW_LINE);
   SetIndexBuffer(0,RSIBuffer);
//---- name for DataWindow and indicator subwindow label
   short_name="D_RSI("+RSIPeriod+")";
   IndicatorShortName(short_name);
   SetIndexLabel(0,short_name);
//----
   SetIndexDrawBegin(0,RSIPeriod);
//----
   return(0);
  }
//+------------------------------------------------------------------+
//| Relative Strength Index                                          |
//+------------------------------------------------------------------+
int start()
  {
   int    i,counted_bars=IndicatorCounted();
   double rel,negative,positive;
//----
   if(Bars<=RSIPeriod) return(0);
//---- initial zero
   if(counted_bars<1)
      for(i=1;i<=RSIPeriod;i++) RSIBuffer[Bars-i]=0.0;
//----
   i=Bars-RSIPeriod-1;
   if(counted_bars>=RSIPeriod) i=Bars-counted_bars-1;
   while(i>=0)
     {
      double sumn=0.0,sump=0.0;
      if(i==Bars-RSIPeriod-1)
        {
         int k=Bars-2;
         //---- initial accumulation
         while(k>=i)
           {
            rel=Close[k]-Close[k+1];
            if(rel>0) sump+=rel;
            else      sumn-=rel;
            k--;
           }
         positive=sump/RSIPeriod;
         negative=sumn/RSIPeriod;
        }
      else
        {
         //---- smoothed moving average
         rel=Close[i]-Close[i+1];
         if(rel>0) sump=rel;
         else      sumn=-rel;
         positive=(PosBuffer[i+1]*(RSIPeriod-2)+sump)/RSIPeriod;
         negative=(NegBuffer[i+1]*(RSIPeriod-2)+sumn)/RSIPeriod;

        }
      PosBuffer[i]=positive;
      NegBuffer[i]=negative;


 if(negative==0.0) RSIBuffer[i]=0.0;
 else RSIBuffer[i]=100.0-100.0/(1+positive/negative);


RSIBuffer[i] =
 0.433154403793*RSIBuffer[i+0]
 +0.364936248838*RSIBuffer[i+1]
 +0.2483161287091*RSIBuffer[i+2]
 +0.1159127094262*RSIBuffer[i+3]
 +0.001920177025782*RSIBuffer[i+4]
 -0.0690619159350*RSIBuffer[i+5]
 -0.0890366343384*RSIBuffer[i+6]
 -0.0670352313955*RSIBuffer[i+7]
 -0.02354570920082*RSIBuffer[i+8]
 +0.01860246173456*RSIBuffer[i+9]
 +0.0426761569010*RSIBuffer[i+10]
 +0.0429876844454*RSIBuffer[i+11]
 +0.02477765082083*RSIBuffer[i+12]
 -0.0001576627378414*RSIBuffer[i+13]
 -0.01967662445848*RSIBuffer[i+14]
 -0.02646547548004*RSIBuffer[i+15]
 -0.02024560032283*RSIBuffer[i+16]
 -0.00623702818584*RSIBuffer[i+17]
 +0.00780018663194*RSIBuffer[i+18]
 +0.01584087110996*RSIBuffer[i+19]
 +0.01529850741755*RSIBuffer[i+20]
 +0.00776771039355*RSIBuffer[i+21]
 -0.002822554123202*RSIBuffer[i+22]
 -0.01184238041638*RSIBuffer[i+23]
 -0.01459330298226*RSIBuffer[i+24]
 -0.00702238938753*RSIBuffer[i+25]
 +0.01182599304835*RSIBuffer[i+26]
 +0.02754073932338*RSIBuffer[i+27]
 -0.02827477612793*RSIBuffer[i+28]
 +0.00665965547380*RSIBuffer[i+29];



RSIBuffer[i] =
  0.462339155006*RSIBuffer[i+0]
 +0.380746443532*RSIBuffer[i+1]
 +0.2435911690640*RSIBuffer[i+2]
 +0.0930418466471*RSIBuffer[i+3]
 -0.02835684040755*RSIBuffer[i+4]
 -0.0928288862464*RSIBuffer[i+5]
 -0.0956528361680*RSIBuffer[i+6]
 -0.0539388169505*RSIBuffer[i+7]
 +0.002654987501491*RSIBuffer[i+8]
 +0.0454612622799*RSIBuffer[i+9]
 +0.0580001102616*RSIBuffer[i+10]
 +0.0402785468641*RSIBuffer[i+11]
 +0.00614866359189*RSIBuffer[i+12]
 -0.02531425814679*RSIBuffer[i+13]
 -0.0395272802058*RSIBuffer[i+14]
 -0.0321281404710*RSIBuffer[i+15]
 -0.00999834894376*RSIBuffer[i+16]
 +0.01411758199119*RSIBuffer[i+17]
 +0.02799907845255*RSIBuffer[i+18]
 +0.02616839245397*RSIBuffer[i+19]
 +0.01148168026699*RSIBuffer[i+20]
 -0.00716063840872*RSIBuffer[i+21]
 -0.02000122316853*RSIBuffer[i+22]
 -0.02129591639566*RSIBuffer[i+23]
 -0.01171727150172*RSIBuffer[i+24]
 +0.002714077142857*RSIBuffer[i+25]
 +0.01417503605156*RSIBuffer[i+26]
 +0.01719491293035*RSIBuffer[i+27]
 +0.01115628436530*RSIBuffer[i+28]
 +0.0001091928592001*RSIBuffer[i+29]
 -0.00982781479638*RSIBuffer[i+30]
 -0.01370579701559*RSIBuffer[i+31]
 -0.01021209353832*RSIBuffer[i+32]
 -0.001840552264328*RSIBuffer[i+33]
 +0.00662015497002*RSIBuffer[i+34]
 +0.01084278724001*RSIBuffer[i+35]
 +0.00907911490258*RSIBuffer[i+36]
 +0.002807403486449*RSIBuffer[i+37]
 -0.00430091936446*RSIBuffer[i+38]
 -0.00853651829218*RSIBuffer[i+39]
 -0.00797780175591*RSIBuffer[i+40]
 -0.00331517566666*RSIBuffer[i+41]
 +0.002697670688571*RSIBuffer[i+42]
 +0.00685111113574*RSIBuffer[i+43]
 +0.00709078390938*RSIBuffer[i+44]
 +0.00353516270592*RSIBuffer[i+45]
 -0.001722941012513*RSIBuffer[i+46]
 -0.00584447134884*RSIBuffer[i+47]
 -0.00662609869769*RSIBuffer[i+48]
 -0.00365461380634*RSIBuffer[i+49]
 +0.001483708889269*RSIBuffer[i+50]
 +0.00592939018204*RSIBuffer[i+51]
 +0.00693617932732*RSIBuffer[i+52]
 +0.00340198228418*RSIBuffer[i+53]
 -0.003034976534982*RSIBuffer[i+54]
 -0.00826283181286*RSIBuffer[i+55]
 -0.00766354484560*RSIBuffer[i+56]
 +0.000368305995778*RSIBuffer[i+57]
 +0.01089806279931*RSIBuffer[i+58]
 +0.01226998232534*RSIBuffer[i+59]
 -0.00558538690631*RSIBuffer[i+60]
 -0.02808106424832*RSIBuffer[i+61]
 +0.02711041260296*RSIBuffer[i+62]
 -0.00718757578535*RSIBuffer[i+63];
     i--;
     }



//----
   return(0);
  }
//+------------------------------------------------------------------+
