WcciChart_v2

Download script
Author: Copyright � 2005, Gaba
WcciChart_v2

This custom indicator is designed to help traders visualize price momentum and identify prevailing market trends by utilizing the Commodity Channel Index (CCI). It provides a multi-layered visual approach to analyzing whether the market is currently trending upwards, downwards, or moving sideways.

Core Logic and Mechanics

The script operates by calculating two different versions of the CCI: a "Fast" version and a "Slow" version. By comparing these two different speeds of momentum, the tool helps filter out minor price fluctuations to reveal the broader direction of the market.

1. Momentum Tracking (The Lines) The indicator plots two primary lines on your chart:

  • Fast CCI: Reacts quickly to recent price changes, capturing immediate moves.
  • Slow CCI: Moves more deliberately, providing a stabilized view of the momentum over a longer period.

2. Trend Identification (The Histograms) Beyond just plotting lines, the script performs a deeper analysis of the "Slow CCI" to determine the strength and direction of the current trend. It looks at a sequence of recent data points to validate the movement:

  • UpTrend Detection: The logic checks a window of recent bars. If the majority of these points show positive momentum, it highlights an "UpTrend" histogram.
  • DownTrend Detection: Conversely, if the majority of those points show negative momentum, it identifies a "DownTrend" histogram.

3. Visual Hierarchy The indicator uses different visual styles to organize this information:

  • Histograms: These are used to represent the volume and strength of the Slow CCI, as well as specific highlights for upward and downward trends.
  • Lines: These provide the continuous flow of both the Fast and Slow momentum indicators, allowing you to see how quickly the price is accelerating or decelerating relative to its recent history.

Summary for the Trader

Essentially, this tool acts as a "trend filter." While the lines show you the current speed of the market, the histograms serve as a confirmation system. By looking at where the trend highlights appear in relation to the CCI lines, traders can better identify whether a move has enough sustained momentum to be considered a significant trend or if it is merely a temporary fluctuation.

Indicators Used
Commodity channel index
Miscellaneous
Implements a curve of type %1
13 Views
0 Downloads
0 Favorites
WcciChart_v2
/*-----------------------------+
|			       |
| Shared by www.Aptrafx.com    |
|			       |
+------------------------------*/

#property copyright "Copyright © 2005, Gaba"
#property link      "http://www.metaquotes.net"

#property indicator_separate_window
#property indicator_buffers 5
#property indicator_color1 Silver
#property indicator_color2 LimeGreen
#property indicator_color3 OrangeRed
#property indicator_color4 Silver
#property indicator_color5 Black

#property indicator_minimum -300
#property indicator_maximum  300

#property indicator_level1  200
#property indicator_level2  100
#property indicator_level3 -100
#property indicator_level4 -200


//////////////////////////////////////////////////////////////////////
// Ïàðåìåòû
//////////////////////////////////////////////////////////////////////

extern int fastPeriod  = 6;
extern int slowPeriod  = 14;
extern int histLength  = 500;

//////////////////////////////////////////////////////////////////////
// Áóôåðû äàííûõ
//////////////////////////////////////////////////////////////////////

double FastBuffer[];    // Áûñòðûé CCI
double SlowBuffer[];    // Ìåäëåííûé CCI
double HistBuffer[];
double UpTrBuffer[];
double DnTrBuffer[];

//////////////////////////////////////////////////////////////////////
// Èíèöèàëèçàöèÿ
//////////////////////////////////////////////////////////////////////

int init()
{
   string short_name;
   IndicatorBuffers(5);
   IndicatorDigits(MarketInfo(Symbol(),MODE_DIGITS));
   short_name="WoodiesCCI("+fastPeriod+","+slowPeriod+")";
   IndicatorShortName(short_name);
   // indicator lines ////////////////////////////////
   SetIndexStyle(0, DRAW_HISTOGRAM);
   SetIndexBuffer(0, HistBuffer);
   SetIndexDrawBegin(0, slowPeriod);
   SetIndexLabel(0,"SlowCCI histogram");
   SetIndexEmptyValue(0, EMPTY_VALUE);
   //////////////////////////////////////////////////
   SetIndexStyle(1, DRAW_HISTOGRAM);
   SetIndexBuffer(1, UpTrBuffer);
   SetIndexDrawBegin(1, slowPeriod);
   SetIndexLabel(1,"UpTrend histogram");
   SetIndexEmptyValue(1, EMPTY_VALUE);
   //////////////////////////////////////////////////
   SetIndexStyle(2, DRAW_HISTOGRAM);
   SetIndexBuffer(2, DnTrBuffer);
   SetIndexDrawBegin(2, slowPeriod);
   SetIndexLabel(2,"DnTrend histogram");
   SetIndexEmptyValue(2, EMPTY_VALUE);
   //////////////////////////////////////////////////
   SetIndexStyle(3, DRAW_LINE,1,3);
   SetIndexBuffer(3, SlowBuffer);
   SetIndexDrawBegin(3, slowPeriod);
   SetIndexLabel(3,"SlowCCI("+slowPeriod+")");
   SetIndexEmptyValue(3, EMPTY_VALUE);
   //////////////////////////////////////////////////
   SetIndexStyle(4, DRAW_LINE);
   SetIndexBuffer(4, FastBuffer);
   SetIndexDrawBegin(4, slowPeriod);
   SetIndexLabel(4,"FastCCI("+fastPeriod+")");
   SetIndexEmptyValue(4, EMPTY_VALUE);
   //////////////////////////////////////////////////
   return(0);
}

//////////////////////////////////////////////////////////////////////
// Custor indicator deinitialization function
//////////////////////////////////////////////////////////////////////

int deinit()
{
   // TODO: add your code here
   return(0);
}

//////////////////////////////////////////////////////////////////////
// Custom indicator iteration function
//////////////////////////////////////////////////////////////////////

int start()
{
   string symbolName;
   int i, shift, checksum, counted_bars=IndicatorCounted();
   double slowCCI=0.0;
   if (Bars<slowPeriod) return(0);
   // check for possible errors
   if (counted_bars<0) return(-1);
   // last counted bar will be recounted
   if (counted_bars>0) counted_bars++;
   int limit=Bars-counted_bars;
   if (counted_bars<1 || checksum!=(histLength+fastPeriod+slowPeriod+Period()) || symbolName!=Symbol())
   {
      // Ïàðàìåòðû èçìåíåíû, ïðîâîäèì ðåèíèöèàëèçàöèþ
      for(i=Bars-1; i<=Bars-histLength; i++)
      {
         FastBuffer[i]=EMPTY_VALUE;    // Áûñòðûé CCI
         SlowBuffer[i]=EMPTY_VALUE;    // Ìåäëåííûé CCI
         HistBuffer[i]=EMPTY_VALUE;    // Ãèñòîãðàììà ìåäëåííîãî CCI
         UpTrBuffer[i]=EMPTY_VALUE;    // Íàïðàâëåíèå òðåíäà
         DnTrBuffer[i]=EMPTY_VALUE;    // Íàïðàâëåíèå òðåíäà
      }
      checksum = histLength+fastPeriod+slowPeriod+Period();
      symbolName=Symbol();
      limit = histLength;
   }
   for (shift=limit; shift>=0; shift--)
   {
      FastBuffer[shift] = iCCI(NULL,0,fastPeriod,PRICE_TYPICAL,shift);
      SlowBuffer[shift] = iCCI(NULL,0,slowPeriod,PRICE_TYPICAL,shift);
      HistBuffer[shift] = SlowBuffer[shift];
      UpTrBuffer[shift] = EMPTY_VALUE;
      DnTrBuffer[shift] = EMPTY_VALUE;
      //	Çàïîëíåíèå ìàññèâà òî÷åê è îïðåäåëåíèå òðåíäà
      int a, up=0, dn=0;
      for (a=0;a<8;a++)
      {
         slowCCI=iCCI(NULL,0,slowPeriod,PRICE_TYPICAL,shift+a);
         if (slowCCI>0) up++;
         if (slowCCI<=0) dn++;
		}
      if (up>=6) UpTrBuffer[shift]=SlowBuffer[shift];
      if (dn>=6) DnTrBuffer[shift]=SlowBuffer[shift];
   }
   return(0);
}

//////////////////////////////////////////////////////////////////////
