Vasily Pip Sniper bar v3.1

The Vasily Pip Sniper is a technical analysis tool designed to identify market momentum and trend direction by analyzing price fluctuations. It operates by calculating the relationship between two different moving averages, which helps smooth out market "noise" to reveal the underlying trend.

Core Logic and Operation

1. Smart Configuration (Timeframe Awareness) The script is designed to be intelligent regarding the timeframe you are viewing. Depending on your settings, it can either use manually defined periods or automatically adjust its internal calculations based on the chart's timeframe (e.g., identifying specific settings for 1-minute charts versus Monthly charts). This ensures that the mathematical "weight" of the data remains consistent regardless of whether you are day trading or swing trading.

2. Multi-Layered Data Processing The logic functions through a three-step calculation process:

  • Primary Smoothing: The script first calculates two distinct moving averages (Fast and Slow). These act as the foundation for identifying price trends.
  • Secondary Analysis: It then performs a secondary calculation on those initial results. By calculating a "moving average of the moving averages," the tool creates a more refined layer of data that reacts to changes in volatility.
  • Delta Calculation: Finally, it compares these layers to determine the difference between current price momentum and historical averages.

3. Signal Generation (The "Sniper" Logic) The ultimate goal of the script is to provide a clear binary signal:

  • Upward Momentum: When the calculated upward force exceeds the downward force, the indicator identifies a bullish trend.
  • Downward Momentum: When the downward force exceeds the upward force, it identifies a bearish trend.

Visual Representation

The results are displayed in a separate window below your main chart as a histogram.

  • Blue Bars: Represent periods where the logic detects positive (upward) momentum.
  • Red Bars: Represent periods where the logic detects negative (downward) momentum.

By translating complex price movements into these two distinct visual cues, the tool allows traders to quickly see whether the current market environment favors a move higher or lower based on the mathematical relationship between short-term and long-term price actions.

Indicators Used
Moving average indicatorMoving average indicator
Miscellaneous
Implements a curve of type %1
10 Views
0 Downloads
0 Favorites
Vasily Pip Sniper bar v3.1
//+------------------------------------------------------------------+
//|                                            Vasily Pip Sniper.mq4 |
//|                                                            By: E |
//|                                             Bar version by V-X   |
//+------------------------------------------------------------------+
#property copyright "By: E"

//----
#property indicator_separate_window
#property indicator_buffers 2
#property indicator_color1 Blue
#property indicator_color2 Red
#property indicator_width1 2
#property indicator_width2 2


extern int    TimeFrame = 0;
extern int    Price     = 6;
extern int    Method    = 3;
extern string estr      = "If UseUserVariables set to false, variables are automatically chosen";
extern bool   UseUserVariables = True;
extern int    FastPeriod = 21;
extern int    SlowPeriod = 144;
//---- parameters



int per1, per2;
//---- buffers
double up[];
double dn[];
double WorkBuffer[];
double WorkBuffer2[];
//+------------------------------------------------------------------+
//| Custom indicator initialization function                         |
//+------------------------------------------------------------------+
int init()
  {
//----
if (!UseUserVariables)
{
// for monthly
int mn_per = 12;
int mn_fast = 3;
// for weekly
int w_per = 9;
int w_fast = 3;
// for daily
int d_per = 5;
int d_fast = 3;
// for H4
int h4_per = 12;
int h4_fast = 2;
// for H1
int h1_per = 24;
int h1_fast = 8;
// for M30
int m30_per = 16;
int m30_fast = 2;
// for M15
int m15_per = 16;
int m15_fast = 4;
// for M5
int m5_per = 12;
int m5_fast = 3;
// for M1
int m1_per = 30;
int m1_fast = 10;
//----
}
//----
     if (UseUserVariables)
     {
     per1=SlowPeriod;
     per2=FastPeriod;
     }
     else
     {
      switch(Period())
     {
       case 1:     per1 = m1_per;  per2 = m1_fast;  break;
       case 5:     per1 = m5_per;  per2 = m5_fast;  break;
       case 15:    per1 = m15_per; per2 = m15_fast; break;
       case 30:    per1 = m30_per; per2 = m30_fast; break;
       case 60:    per1 = h1_per;  per2 = h1_fast;  break;
       case 240:   per1 = h4_per;  per2 = h4_fast;  break;
       case 1440:  per1 = d_per;   per2 = d_fast;   break;
       case 10080: per1 = w_per;   per2 = w_fast;   break;
       case 43200: per1 = mn_per;  per2 = mn_fast;  break;
     }
     }
    int Timef;
    if(TimeFrame != 0)
    {
    Timef=TimeFrame;
    }
    else
    {
    Timef=Period();
    }
string Indicator_Name = "Vasily Pip Sniper ZL ("+Timef+"):    ";
//-----
IndicatorBuffers(4);
   SetIndexStyle(0, DRAW_HISTOGRAM,0,4);
   SetIndexBuffer(0, up);

   SetIndexStyle(1, DRAW_HISTOGRAM,0,4);
   SetIndexBuffer(1, dn);

   SetIndexBuffer(2, WorkBuffer);
   SetIndexBuffer(3, WorkBuffer2);

   SetIndexDrawBegin(0, per1 + per2);
   SetIndexDrawBegin(1, per1 + per2);

   IndicatorShortName(Indicator_Name);
   return(0);
  }
//+------------------------------------------------------------------+
//| Custom indicator deinitialization function                       |
//+------------------------------------------------------------------+
int deinit()
  {
//----
   return(0);
  }
//+------------------------------------------------------------------+
//| Custom indicator iteration function                              |
//+------------------------------------------------------------------+
int start()
  {
   int limit;
   int counted_bars = IndicatorCounted();

//----
   if(counted_bars < 0)
       return(-1);
//----
   if(counted_bars > 0)
       counted_bars -= 10;
   limit = Bars - counted_bars/Period();
//----
  for(int i = 0; i < limit; i++)
       {
       WorkBuffer[i] = iMA(NULL, TimeFrame, per1, 0, Method, Price, i);
       WorkBuffer2[i]= iMA(NULL, TimeFrame, per2, 0, Method, Price, i);
       }

       for(i = 0; i < limit; i++)
       {
       double wMA, wMA2, lMA, sMA, pr;

       wMA = iMAOnArray(WorkBuffer, TimeFrame, per1, 0, Method, i);
       lMA = WorkBuffer[i] + WorkBuffer[i] - wMA;

       wMA2 = iMAOnArray(WorkBuffer2, TimeFrame, per2, 0, Method, i);
       sMA = WorkBuffer2[i] + WorkBuffer2[i] - wMA2;

       up[i]=sMA-lMA;
       dn[i]=lMA-sMA;

       if(up[i]>dn[i])
      {
         up[i]=1;
         dn[i]=0;
      }
      else
      {
         up[i]=0;
         dn[i]=1;
      }

      }
//----
   return(0);
  }
//+------------------------------------------------------------------+
//|                                                                  |
//+------------------------------------------------------------------+
