StochasticCG
Download script
This custom indicator, the Stochastic CG Oscillator, is designed to provide traders with a sophisticated visual tool for analyzing price momentum and potential turning points. Based on the mathematical principles of Cybernetics Analysis by John F. Ehlers, it moves beyond standard oscillators by utilizing weighted calculations to smooth out market "noise."
How the Logic Works
The script processes market data through three distinct mathematical stages to arrive at its final visual output:
1. The Core Foundation (CG Calculation) Instead of looking at just the current price, the indicator begins by calculating a specialized weighted average. It looks at a specific look-back period (defined by the "Length" setting) and assigns more importance to recent price points than older ones. This creates a "Center of Gravity" effect, allowing the tool to identify the underlying trend more clearly than a simple moving average would.
2. The Stochastic Normalization Once the core data is established, the script identifies the highest and lowest values reached within that same look-back period. It then calculates where the current value sits relative to those extremes. This "normalizes" the data into a specific range, making it much easier for a trader to see if the market is currently overextended (at the top or bottom of its recent range) or moving toward a balanced state.
3. Smoothing and Triggering To ensure the lines on your chart are fluid and easy to read, the script applies two final layers of processing:
- Smoothing: It applies a weighted smoothing formula to the normalized data. This helps eliminate erratic "zig-zag" movements, ensuring that the primary line (Stochastic CG) represents a reliable trend rather than temporary price spikes.
- The Trigger: Finally, it generates a secondary "Trigger" line. This line follows the main oscillator with a slight offset and multiplier, acting as a reference point to help traders identify potential shifts in momentum or exhaustion in the current move.
Visual Interpretation
The indicator appears in a separate window below your main price chart. By observing the relationship between the Red line (Stochastic CG) and the Blue line (Trigger), users can visually gauge the strength of the market's current cycle. Because it is based on Cybernetic principles, it aims to provide a more mathematically stable view of market "physics" than standard retail indicators.
//+------------------------------------------------------------------+
//| StochasticCG.mq4 |
//| |
//| Stochastic CG Oscillator |
//| |
//| Algorithm taken from book |
//| "Cybernetics Analysis for Stock and Futures" |
//| by John F. Ehlers |
//| |
//| contact@mqlsoft.com |
//| http://www.mqlsoft.com/ |
//+------------------------------------------------------------------+
#property copyright "Coded by Witold Wozniak"
#property link "www.mqlsoft.com"
#property indicator_separate_window
#property indicator_buffers 2
#property indicator_color1 Red
#property indicator_color2 Blue
#property indicator_level1 0
#property indicator_minimum -1
#property indicator_maximum 1
double StocCG[];
double Trigger[];
double CG[];
double Value1[];
extern int Length = 8;
int buffers = 0;
int drawBegin = 0;
int init() {
drawBegin = Length;
initBuffer(StocCG, "Stochastic CG", DRAW_LINE);
initBuffer(Trigger, "Trigger", DRAW_LINE);
initBuffer(CG);
initBuffer(Value1);
IndicatorBuffers(buffers);
IndicatorShortName("Stochastic CG [" + Length + "]");
return (0);
}
int start() {
if (Bars <= drawBegin) return (0);
int countedBars = IndicatorCounted();
if (countedBars < 0) return (-1);
if (countedBars > 0) countedBars--;
int s, limit = Bars - countedBars - 1;
for (s = limit; s >= 0; s--) {
double Num = 0.0;
double Denom = 0.0;
for (int count = 0; count < Length; count++) {
Num += (1.0 + count) * P(s + count);
Denom += P(s + count);
}
if (Denom != 0.0) {
CG[s] = -Num / Denom + (Length + 1.0) / 2.0;
} else {
CG[s] = 0.0;
}
double hh = CG[s], ll = CG[s];
for (int i = 0; i < Length; i++) {
double tmp = CG[s + i];
hh = MathMax(hh, tmp);
ll = MathMin(ll, tmp);
}
Value1[s] = 0.0;
if (hh != ll) {
Value1[s] = (CG[s] - ll) / (hh - ll);
}
StocCG[s] = (4.0 * Value1[s] + 3.0 * Value1[s + 1] + 2.0 * Value1[s + 2] + Value1[s + 3]) / 10.0;
StocCG[s] = 2.0 * (StocCG[s] - 0.5);
Trigger[s] = 0.96 * (StocCG[s + 1] + 0.02);
}
return (0);
}
double P(int index) {
return ((High[index] + Low[index]) / 2.0);
}
void initBuffer(double array[], string label = "", int type = DRAW_NONE, int arrow = 0, int style = EMPTY, int width = EMPTY, color clr = CLR_NONE) {
SetIndexBuffer(buffers, array);
SetIndexLabel(buffers, label);
SetIndexEmptyValue(buffers, EMPTY_VALUE);
SetIndexDrawBegin(buffers, drawBegin);
SetIndexShift(buffers, 0);
SetIndexStyle(buffers, type, style, width);
SetIndexArrow(buffers, arrow);
buffers++;
}
