SSA

Download script
Author: Copyright � 2007, MetaQuotes Software Corp.
SSA

This script is designed to perform advanced statistical data processing—specifically a technique known as Singular Value Decomposition (SVD) and Principal Component Analysis (PCA). In simple terms, it takes complex, "noisy" raw data and filters out the insignificant fluctuations to reveal the underlying core patterns or trends.

Core Logic Overview

The script follows a structured mathematical workflow to simplify data:

1. Data Organization The logic begins by taking a set of input values (a "row") and organizing them into a structured grid (a matrix). By doing this, the script can analyze how different parts of the data relate to one another relative to their position in time or sequence.

2. Identifying Key Components (Eigenvalues) The script uses a "Bisection" method combined with "Gauss Elimination."

  • Gauss Elimination is used to simplify the complex grid into a format where individual characteristics can be isolated.
  • Bisection acts like a search tool; it repeatedly halves a range of values to pinpoint the exact "strength" of the primary trends in the data.

3. Extracting Trends (Eigenvectors) Once the strengths of the trends are identified, the script calculates "Eigenvectors." Think of these as the "blueprints" for the data's shape. They tell the script which parts of the original data contribute most to the overall movement and which parts are just random noise.

4. Reconstruction and Smoothing After identifying the primary trends, the script performs a "reconstruction." It builds a new version of the data using only the most important components it found in the previous steps.

  • It applies "Diagonal Averaging," which is a smoothing technique.
  • This ensures that the final output isn't just a jagged set of points, but a clean, fluid curve that represents the true "signal" hidden within the original data.

Summary for the User

Imagine you are looking at a blurry photograph. This script acts like a high-end sharpening tool:

  • It analyzes all the pixels (data).
  • It identifies which shapes are real objects and which are just blur (Principal Components).
  • It then reconstructs a new, clear image by keeping only the real objects and discarding the blur.

In a trading or analytical context, this means the script is designed to strip away market "noise" to show you the dominant structural movement of the price or indicator.

6 Views
0 Downloads
0 Favorites
SSA
//+------------------------------------------------------------------+
//|                                                          SSA.mq4 |
//|                      Copyright © 2007, MetaQuotes Software Corp. |
//|                                        http://www.metaquotes.net |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2007, MetaQuotes Software Corp."
#property link      "http://www.metaquotes.net"
#property library

//+------------------------------------------------------------------+
//| My function                                                      |
//+------------------------------------------------------------------+
//+------------------------------------------------------------------+
int  MaxCompCol=20;
int  MaxCatLag=200;
int  MaxLen=5000;

//---
/*class Matrix{
public:
  int i;
  int j; //âûàï
  double **m;
  Matrix(int i, int j);
  ~Matrix();
};
//+------------------------------------------------------------------+
//|                                                                  |
//+------------------------------------------------------------------+
Matrix::Matrix(int ni, int nj)
{
 m=new double*[ni];
 for(int k=0;k<ni;k++) m[k]=new double[nj];
 i=ni; j=nj;
}
Matrix::~Matrix()
{
  for(int k=0;k<i;k++) delete[] m[k];
  delete[] m;
}*/
void Equal(double &x1[][], double x2[][], int t=0) //(Matrix *x1, Matrix *x2, int t=0)
{
 int N=ArrayRange(x1,0);
 int M=ArrayRange(x1,1);
 for(int i=0;i<N;i++) //(int i=0;i<x1->i;i++)
   for(int j=0;j<M;j++){ //(int j=0;j<x1->j;j++)
     if(t!=0) x1[i][j]=x2[j][i]; //x1->m[i][j]=x2->m[j][i];
     else x1[i][j]=x2[i][j]; //x1->m[i][j]=x2->m[i][j];
   }
}
//---------------------------------------------------------------------------
/*Âû÷èñëåíèå ôóíêöèè Sn, íóæíà äëÿ âû÷èñëåíèÿ ñîáñòâåííûõ çíà÷åíèé
Òàì ñ÷èòàòþòñÿ îòðèöàòåëüíûå îïðåäåëèòåëè*/
double gaussSn(double A[][],double l,int n) //(Matrix *A,double l,int n)
{
  int count,cp,i1,i,j,k;
  double B[200][200];//Matrix *B = new Matrix(MaxCatLen,MaxCatLen);
  double c;
  double w[]; ArrayResize(w,n);//double *w=new double[n]; //double w[MaxLen-MaxCatLen];
  double s1,s2;
  //------
  Equal(B,A);
  //------
  for (i=0;i<=n-1;i++)
  {
   B[i][i] = B[i][i]-l; //B->m[i][i] = B->m[i][i]-l;
  }
  cp=0;
  for(k=0;k<=n-2;k++)
  {
    for(i=k+1;i<=n-1;i++)
    {
      if(B[k,k]==0) // (B->m[k,k]==0)
      {
        for(i1=0;i1<=n-1;i1++)
        {
          w[i1] = B[i1][k]; //w[i1] = B->m[i1][k];
          B[i1][k] = B[i1][k+1]; //B->m[i1][k] = B->m[i1][k+1];
          B[i1][k+1] = w[i1]; //B->m[i1][k] = B->m[i1][k+1];
        }
        cp=cp+1;
      }
      c=B[i][k]/B[k][k]; //c=1.0*B->m[i][k]/B->m[k][k];
      for (j=0;j<=n-1;j++)
      {
        B[i][j] = B[i][j]-B[k][j]*c;//B->m[i][j] = B->m[i][j]-B->m[k][j]*c;
      }
    }
  }
   count=0;
   s1=1;
   for( i=0;i<=n-1;i++)
   {
      s2 = B[i][i]; //s2 = B->m[i][i];
      if (s2<0) count = count+1;
   }
   //delete B;
   //delete[] w;
   return (1.0*count);
}
//---------------------------------------------------------------------------
/*Âû÷èñëåíèå ñîáñòâåííûõ çíà÷åíèé ìåòîäîì áèñåêöèè}
  Õîðîø òåì ÷òî ñêîëüêî íàäî ñîáñòâåííûõ ÷èñåë ñòîëüêî è ïîñ÷èòàåò,
  ñèëüíî ýêîíîìèò ðåñóðñ*/
double gaussbisectionl(double &A[][],int k,int n) //(Matrix *A,int k,int n)
{
	double e1,maxnorm,cn,a1,b1,c;
	int i,j;
	maxnorm = 0;
	for (i=0;i<=n-1;i++)
	{
		cn = 0;
		for(j=0 ;j<=n-1;j++)
			cn = cn+A[i][j]; //cn = cn+A->m[i][j];
		if (maxnorm<cn) maxnorm=cn;
	}
	a1=0;
	b1=10*maxnorm;
	e1=1.0*maxnorm/10000000;
	while (MathAbs(b1-a1)>e1)
	{
		c = 1.0*(a1+b1)/2;
		if (gaussSn(A,c,n)<k)
		a1=c;
		else
		b1=c;
	}
 return ((a1+b1)/2.0);
}
//---------------------------------------------------------------------------
/*Âû÷èñëÿåò ñîáñòâåííûå âåêòîðà äëÿ óæå âû÷èñëåííûõ ñîáñòâåííûõ ÷èñåë l*/
void svector(double &A[][],double l,int n,double &V[]) //(Matrix *A,double l,int n,double *V)
{
	int cp,i1,i,j,k;
	double B[200][200]; //Matrix *B = new Matrix(MaxCatLen,MaxCatLen);
	double c;
	double w[]; ArrayResize(w,n); //double *w=new double[n]; //double w[MaxLen-MaxCatLen];
	Equal(B,A);
	for (i=0;i<=n-1;i++)  B[i][i]=B[i][i]-l; //B->m[i][i]=B->m[i][i]-l;
	cp=0;
	for (k=0;k<=n-2;k++)
		for (i=k+1;i<=n-1;i++)
		{
			if (B[k][k]==0) //(B->m[k][k]==0)
			{
				for (i1=0;i<=n-1;i++)
				{
					w[i1]=B[i1][k]; //w[i1]=B->m[i1][k];
					B[i1][k]=B[i1][k+1]; //B->m[i1][k]=B->m[i1][k+1];
					B[i1][k+1]=w[i1]; //B->m[i1][k+1]=w[i1];
				}
				cp=cp+1;
			}
			c=1.0*B[i][k]/B[k][k]; //c=1.0*B->m[i][k]/B->m[k][k];
			for (j=0;j<=n-1;j++)
			{
				B[i][j]=B[i][j]-B[k][j]*c; //B->m[i][j]=B->m[i][j]-B->m[k][j]*c;
			}
		}
	V[n-1]=1;
	c=1;
	for (i=n-2;i>=0;i--)
	{
		V[i]=0;
		for (j=i;j<=n-1;j++)	V[i]= V[i]-B[i][j]*V[j]; //V[i]= 1.0*V[i]-B->m[i][j]*V[j];
		V[i]=V[i]/B[i][i]; //V[i]=V[i]/B->m[i][i];
		c = c+V[i]*V[i]; //c = c+1.0*V[i]*V[i];
	}
	for (i=0;i<=n-1;i++)	V[i]= V[i]/MathSqrt(c);
	//delete B;
	//delete[] w;
}
/*À âîò è ñàìà ãóñåíèöà}
{Õ-âåêòîð èñõîäíîãî ðÿäà
n-åãî äëèíà
l-äëèíà ëàãà
s-÷èñëî ñîáñòâåííûõ êîìïîíåíò
(òàì èñõîäíûé ðÿä ðàçáèâàåòñÿ íà êîìïîíåòû, à ïîòîì âîññòàíàâëèâàåòñÿ, òóò òû è çàäàåøü ñêîëüêî êîìïîíåíò òåáå íàäî)
Y - âîññòàíîâëåííûé ðÿä (ñãëàæåííûé ãóñåíèöåé) òàì ÿ â êîíöå åùå äîáàâèë êîììåíòàðèé, ãäå íàõîäÿòñÿ îòäåëüíûå
êîìïîíåíòû ðÿäà
*/
//---------------------------------------------------------------------------
void fastsingular( double X[],int n,int l,int s,double &Y[])
{
	if( l>MaxCatLag ) l=MaxCatLag;
   if( s>MaxCompCol ) s=MaxCompCol;
   if( s>l ) s=l;
   if( n>MaxLen ) n=MaxLen;
	double A[200][200]; //Matrix *A = new Matrix(MaxCatLag,MaxCatLag);
	double B[5000][200]; //ArrayResize(B,n); //Matrix *B = new Matrix(n,MaxCatLag);
	double Bn[200][5000]; //Matrix *Bn = new Matrix(MaxCatLag,n);

	int kb,lb,m,k,i,j,i1;
	double V[200][5000]; //Matrix *V = new Matrix(MaxCompCol,n);
	double Yn[200][5000]; //Matrix *Yn = new Matrix(MaxCompCol,n);
	double ls[200];
	//---
	double Vtemp[200];
	//---
	j=0;
	k=n-l+1;
	/*Ôîðìèðóåì ìàòðèöó À â ìåòîäå êîòîðûé ÿ ñêà÷àë íà ñàéòå ñîçäàòåëåé ýòà ìàòðèöà S*/
	for (i=0;i<=l-1;i++)
	{
		for (j=0;j<=l-1;j++)
		{
			A[i][j]=0; //A->m[i][j]=0;
			for (m=0;m<=k-1;m++) // (m=0;m<=k-1;m++)
			{
				A[i][j]=A[i][j]+X[i+m]*X[m+j]; //A->m[i][j]=A->m[i][j]+1.0*X[i+m]*X[m+j];
				B[m][j]=X[m+j]; //B->m[m][j]=X[m+j];
			}
		}
   }
	/*Íàõîäèì ñîáñòâåííûå ÷èñëà è âåêòîðû ìàòðèöû À*/
	for (i=0;i<=s-1;i++)
    {
      ls[i]=gaussbisectionl(A,l-i,l);
      svector(A,ls[i],l,Vtemp); //svector(A,ls[i],l,V->m[i]);
      for( j=0;j<=l-1; j++) V[i][j]=Vtemp[j];
    }
   //------
	/*Ôîðìèðóåòñÿ âîññòàíîâëåííàÿ ìàòðèöà*/
	for (i1=0;i1<=s-1;i1++)
    {
		//------
		for (i=0;i<=k-1;i++)
		{
			Yn[i1][i]=0; //Yn->m[i1][i]=0;
			for (j=0;j<=l-1;j++)  Yn[i1][i]=Yn[i1][i]+B[i][j]*V[i1][j];
			                     //Yn->m[i1][i]=Yn->m[i1][i]+1.0*B->m[i][j]*V->m[i1][j];
		}
		//------
		for (i=0;i<=l-1;i++){
			for (j=0;j<=k-1;j++)	Bn[i][j]=V[i1][i]*Yn[i1][j];
			                     //Bn->m[i][j]=1.0*V->m[i1][i]*Yn->m[i1][j];
		}
		//-------
		//Äèàãîíàëüíîå óñðåäíåíèå (âîññòàíîâëåíèå ðÿäà)
		kb=k;
		lb=l;
		for (i=0;i<=n-1;i++)
		{
			Yn[i1][i]=0; //Yn->m[i1][i]=0;
			if (i<lb-1)
			{
				for (j=0;j<=i;j++)
				{
					if (l<=k) Yn[i1][i] = Yn[i1][i]+Bn[j][i-j]; //Yn->m[i1][i] = Yn->m[i1][i]+Bn->m[j][i-j];
					if (l>k)  Yn[i1][i] = Yn[i1][i]+Bn[i-j][j]; //Yn->m[i1][i] = Yn->m[i1][i]+Bn->m[i-j][j];
				}
				Yn[i1][i] = Yn[i1][i]/(1.0*(i+1)); //Yn->m[i1][i]=1.0*Yn->m[i1][i]/(i+1);
			}
			if ((lb-1<=i)&&(i<kb-1))
			{
				for (j=0;j<=lb-1;j++)
				{
					if (l<=k) Yn[i1][i]=Yn[i1][i]+Bn[j][i-j]; //Yn->m[i1][i]=Yn->m[i1][i]+Bn->m[j][i-j];
					if (l>k) Yn[i1][i]=Yn[i1][i]+Bn[i-j][j]; //Yn->m[i1][i]=Yn->m[i1][i]+Bn->m[i-j][j];
				}
				Yn[i1][i] = Yn[i1][i]/(1.0*lb); //Yn->m[i1][i] = 1.0*Yn->m[i1][i]/lb;
			}
			if (kb-1<=i)
			{
				for (j=i-kb+1;j<=n-kb;j++)
				{
					if (l<=k) Yn[i1][i]=Yn[i1][i]+Bn[j][i-j]; //Yn->m[i1][i]=Yn->m[i1][i]+Bn->m[j][i-j];
					if (l>k) Yn[i1][i]=Yn[i1][i]+Bn[i-j][j]; //Yn->m[i1][i]=Yn->m[i1][i]+Bn->m[i-j][j];
				}
				Yn[i1][i] = Yn[i1][i]/(1.0*(n-i));//(?! ÷òî òàêîå N)//Yn->m[i1][i]=1.0*Yn->m[i1][i]/(n-i);
				//Yn[i1][i]=1.0*Yn[i1][i]/kb;/*(?! ÷òî òàêîå N)*/
			}
		}
    }
	/* Âîò çäåñü åñëè íå ñóììèðîâàòü, òî áóäóò îòäåëüíûå êîìïîíåíòû ðàçëîæåíèÿ
	ïðîöåññà ïî ñîáñòâåííûì ôóíêöèÿì */
	for (i=0;i<=n-1;i++)
    {
		Y[i]=0;
		//Y[i]=Yn[3][i];
		for (i1=0;i1<=s-1;i1++)  Y[i]=Y[i]+Yn[i1][i]; //Y[i]=Y[i]+Yn->m[i1][i];
    }
	//delete A;
	//delete B;
	//delete Bn;
	//delete V;
	//delete Yn;
	//delete[] X;
}
//-----------------------------------------------------------------------------+
/*{Õ-âåêòîð èñõîäíîãî ðÿäà
n-åãî äëèíà
l-äëèíà ëàãà
s-÷èñëî ñîáñòâåííûõ êîìïîíåíò
(òàì èñõîäíûé ðÿä ðàçáèâàåòñÿ íà êîìïîíåòû, à ïîòîì âîññòàíàâëèâàåòñÿ, òóò òû è çàäàåøü ñêîëüêî êîìïîíåíò òåáå íàäî)
Y - âîññòàíîâëåííûé ðÿä (ñãëàæåííûé ãóñåíèöåé) òàì ÿ â êîíöå åùå äîáàâèë êîììåíòàðèé, ãäå íàõîäÿòñÿ îòäåëüíûå
êîìïîíåíòû ðÿäà
*/
//---------------------------------------------------------------------------
void singularPCA( double X[],int n,int l,int s,double &Y[])
{
	if( l>MaxCatLag ) l=MaxCatLag;
   if( s>MaxCompCol ) s=MaxCompCol;
   if( s>l ) s=l;
   if( n>MaxLen ) n=MaxLen;
	double A[200][200]; //Matrix *A = new Matrix(MaxCatLag,MaxCatLag);
	double B[5000][200]; //ArrayResize(B,n); //Matrix *B = new Matrix(n,MaxCatLag);
	double Bn[200][5000]; //Matrix *Bn = new Matrix(MaxCatLag,n);

	int kb,lb,m,k,i,j,i1;
	double V[200][5000]; //Matrix *V = new Matrix(MaxCompCol,n);
	double Yn[200][5000]; //Matrix *Yn = new Matrix(MaxCompCol,n);
	double ls[200];
	//---
	double Vtemp[200];
	//---
	j=0;
	k=n-l+1;
	/*Ôîðìèðóåì ìàòðèöó À â ìåòîäå êîòîðûé ÿ ñêà÷àë íà ñàéòå ñîçäàòåëåé ýòà ìàòðèöà S*/
	for (i=0;i<=l-1;i++)
	{
		for (j=0;j<=l-1;j++)
		{
			A[i][j]=0; //A->m[i][j]=0;
			for (m=0;m<=k-1;m++) // (m=0;m<=k-1;m++)
			{
				A[i][j]=A[i][j]+X[i+m]*X[m+j]; //A->m[i][j]=A->m[i][j]+1.0*X[i+m]*X[m+j];
				B[m][j]=X[m+j]; //B->m[m][j]=X[m+j];
			}
		}
   }
	/*Íàõîäèì ñîáñòâåííûå ÷èñëà è âåêòîðû ìàòðèöû À*/
	//for (i=0;i<=s-1;i++)
   // {
      ls[s]=gaussbisectionl(A,l-s,l);
      svector(A,ls[s],l,Vtemp); //svector(A,ls[i],l,V->m[i]);
      for( j=0;j<=l-1; j++) V[s][j]=Vtemp[j];
   // }
   //------
	/*Ôîðìèðóåòñÿ âîññòàíîâëåííàÿ ìàòðèöà*/
	i1=s;
	//for (i1=0;i1<=s-1;i1++)
   // {
		//------
		for (i=0;i<=k-1;i++)
		{
			Yn[i1][i]=0; //Yn->m[i1][i]=0;
			for (j=0;j<=l-1;j++)  Yn[i1][i]=Yn[i1][i]+B[i][j]*V[i1][j];
			                     //Yn->m[i1][i]=Yn->m[i1][i]+1.0*B->m[i][j]*V->m[i1][j];
		}
		//------
		for (i=0;i<=l-1;i++){
			for (j=0;j<=k-1;j++)	Bn[i][j]=V[i1][i]*Yn[i1][j];
			                     //Bn->m[i][j]=1.0*V->m[i1][i]*Yn->m[i1][j];
		}
		//-------
		//Äèàãîíàëüíîå óñðåäíåíèå (âîññòàíîâëåíèå ðÿäà)
		kb=k;
		lb=l;
		for (i=0;i<=n-1;i++)
		{
			Yn[i1][i]=0; //Yn->m[i1][i]=0;
			if (i<lb-1)
			{
				for (j=0;j<=i;j++)
				{
					if (l<=k) Yn[i1][i] = Yn[i1][i]+Bn[j][i-j]; //Yn->m[i1][i] = Yn->m[i1][i]+Bn->m[j][i-j];
					if (l>k)  Yn[i1][i] = Yn[i1][i]+Bn[i-j][j]; //Yn->m[i1][i] = Yn->m[i1][i]+Bn->m[i-j][j];
				}
				Yn[i1][i] = Yn[i1][i]/(1.0*(i+1)); //Yn->m[i1][i]=1.0*Yn->m[i1][i]/(i+1);
			}
			if ((lb-1<=i)&&(i<kb-1))
			{
				for (j=0;j<=lb-1;j++)
				{
					if (l<=k) Yn[i1][i]=Yn[i1][i]+Bn[j][i-j]; //Yn->m[i1][i]=Yn->m[i1][i]+Bn->m[j][i-j];
					if (l>k) Yn[i1][i]=Yn[i1][i]+Bn[i-j][j]; //Yn->m[i1][i]=Yn->m[i1][i]+Bn->m[i-j][j];
				}
				Yn[i1][i] = Yn[i1][i]/(1.0*lb); //Yn->m[i1][i] = 1.0*Yn->m[i1][i]/lb;
			}
			if (kb-1<=i)
			{
				for (j=i-kb+1;j<=n-kb;j++)
				{
					if (l<=k) Yn[i1][i]=Yn[i1][i]+Bn[j][i-j]; //Yn->m[i1][i]=Yn->m[i1][i]+Bn->m[j][i-j];
					if (l>k) Yn[i1][i]=Yn[i1][i]+Bn[i-j][j]; //Yn->m[i1][i]=Yn->m[i1][i]+Bn->m[i-j][j];
				}
				Yn[i1][i] = Yn[i1][i]/(1.0*(n-i));//(?! ÷òî òàêîå N)//Yn->m[i1][i]=1.0*Yn->m[i1][i]/(n-i);
				//Yn[i1][i]=1.0*Yn[i1][i]/kb;/*(?! ÷òî òàêîå N)*/
			}
		}
    //}
	/* Âîò çäåñü åñëè íå ñóììèðîâàòü, òî áóäóò îòäåëüíûå êîìïîíåíòû ðàçëîæåíèÿ
	ïðîöåññà ïî ñîáñòâåííûì ôóíêöèÿì */
	for (i=0;i<=n-1;i++)
    {
		Y[i]=0;
		Y[i]=Yn[s][i];
		//for (i1=0;i1<=s-1;i1++)  Y[i]=Y[i]+Yn[i1][i]; //Y[i]=Y[i]+Yn->m[i1][i];
    }
	//delete A;
	//delete B;
	//delete Bn;
	//delete V;
	//delete Yn;
	//delete[] X;
}
//-----------------------------------------------------------------------------+
