This script is designed as a visual dashboard for the MetaTrader 4 platform, allowing traders to monitor the price performance of multiple currency pairs simultaneously in a single, easy-to-read window.
Core Functionality
The tool provides a real-time "Rate of Change" summary. Instead of looking at multiple separate charts, you can see a list of specific currency pairs (which can be customized) displayed on one screen. For each pair, the script calculates the percentage change in price based on a user-defined timeframe (for example, Daily or Hourly).
How it Works
- Dynamic Dashboard: When you load the script, it automatically creates a layout of labels and bars. It calculates how much space is available on your screen and arranges the currency pairs neatly so they fit perfectly regardless of your window size.
- Real-Time Updates: The script runs a continuous background timer (updating every 250 milliseconds). It constantly fetches the latest "Open" and "Close" prices for all your selected currency pairs.
- Visual Indicators:
- Positive Movement: If a currency pair has increased in value, the dashboard displays its information in green. The visual bar grows upward from a center line to represent the strength of the gain.
- Negative Movement: If a currency pair has decreased in value, the dashboard displays the information in red, with the bar growing downward.
- Smart Scaling: To ensure the data is always readable, the script includes an automatic scaling logic. If the price movements are very large, it adjusts the size of the visual bars so they don't go off-screen. If the movements are small, it scales them up slightly to make them easier to see.
- Interactive Navigation: One of the unique features is the ability to jump directly to a live chart. By clicking on the name of a currency pair within the dashboard, the script will automatically open a new chart for that specific pair at your preferred time frame.
Key Benefits for the User
- Efficiency: You can monitor 9 or more currency pairs at a glance without switching tabs.
- Clarity: By converting complex price movements into simple percentage figures and color-coded bars, it provides an immediate "health check" of the market.
- Customization: Users can define which pairs they want to track, what timeframe to analyze, and see the results instantly updated with the latest market ticks.
Price Data Components
6
Views
0
Downloads
0
Favorites
rocv2.1
//+------------------------------------------------------------------+
//| ROCv2.1.mq4 |
//| Copyright 2015, mrak297. |
//| https://www.mql5.com/ru/users/mrak297 |
//+------------------------------------------------------------------+
#property copyright "Copyright 2015, mrak297."
#property link "https://www.mql5.com/ru/users/mrak297"
#property version "2.1"
#property strict
#property indicator_separate_window
//--- input parameters
input string Pairs="USDJPY,AUDUSD,EURJPY,EURCHF,EURGBP,EURUSD,GBPUSD,USDCHF,USDCAD";
input ENUM_TIMEFRAMES TimeFrame=PERIOD_D1;//Period for calculating
input ENUM_TIMEFRAMES Per = PERIOD_M15; //Period for new opened charts
input color UPcolor = clrLimeGreen; //Color when moved up
input color DownColor = clrTomato; //Color when moved down
//---
int Size=10; //Font size
string Font= "Arial Black";
int BGcolor; //Bars background color
int cF = 100; //Coefficient of scale
int num,Zero,Wbar,Hbar,Xsize,Ysize;
string PairsArray[]; //Array for Pairs Name
double ChangeArray[]; //Array for Pairs Change
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
int OnInit()
{
EventSetMillisecondTimer(250);
//---
IndicatorShortName("Rate Of Change ("+PeriodToString(TimeFrame)+")");
IndicatorSetDouble(INDICATOR_MAXIMUM,1);
IndicatorSetDouble(INDICATOR_MINIMUM,-1);
//---
BGcolor=(int)ChartGetInteger(0,CHART_COLOR_BACKGROUND);
//---
ushort sep=StringGetCharacter(Pairs,6);
num=StringSplit(Pairs,sep,PairsArray);
//---
ArrayResize(ChangeArray,num,num);
//---
Xsize = (int)ChartGetInteger(0,CHART_WIDTH_IN_PIXELS,1);
Ysize = (int)ChartGetInteger(0,CHART_HEIGHT_IN_PIXELS,1);
//---
Zero=(int)MathRound(ChartGetInteger(0,CHART_HEIGHT_IN_PIXELS,1)/2);
//---
Wbar=(int)MathRound((Xsize-15)/num);
//---
if(MathRound(Wbar/5)<MathRound(Ysize/7))
Size=PixToPoints((int)MathRound(Wbar/5));
else Size=PixToPoints((int)MathRound(Ysize/7));
//---
int j=5;
//---
for(int i=0; i<num; i++)
{
CreateRecLabel(PairsArray[i]+"Bar",j,Zero,Wbar,10);
CreateTextLabel(PairsArray[i]+"Text",j,Zero,PairsArray[i],ANCHOR_LEFT_UPPER);
CreateTextLabel(PairsArray[i]+"Change",j,Zero,"NaN",ANCHOR_LEFT_LOWER);
j+=Wbar+1;
}
//---
return(INIT_SUCCEEDED);
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
void OnDeinit(const int reason)
{
EventKillTimer();
//---
for(int i=0; i<num; i++)
{
ObjectDelete(PairsArray[i]+"Bar");
ObjectDelete(PairsArray[i]+"Text");
ObjectDelete(PairsArray[i]+"Change");
}
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
int OnCalculate(const int rates_total,
const int prev_calculated,
const datetime &time[],
const double &open[],
const double &high[],
const double &low[],
const double &close[],
const long &tick_volume[],
const long &volume[],
const int &spread[])
{
//--- return value of prev_calculated for next call
return(rates_total);
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
void OnTimer()
{
for(int i=0; i<num; i++)
{
ChangeArray[i]=SymbolChange(PairsArray[i],TimeFrame);
//---
if(ChangeArray[i]<0)
{
ObjectSetInteger(0,PairsArray[i]+"Bar",OBJPROP_YSIZE,(int)MathAbs(ChangeArray[i]*cF));
ObjectSetInteger(0,PairsArray[i]+"Bar",OBJPROP_COLOR,DownColor);
ObjectSetInteger(0,PairsArray[i]+"Text",OBJPROP_COLOR,DownColor);
ObjectSetInteger(0,PairsArray[i]+"Change",OBJPROP_COLOR,DownColor);
ObjectSetInteger(0,PairsArray[i]+"Text",OBJPROP_ANCHOR,ANCHOR_LEFT_LOWER);
ObjectSetInteger(0,PairsArray[i]+"Change",OBJPROP_ANCHOR,ANCHOR_LEFT_UPPER);
ObjectSetString(0,PairsArray[i]+"Change",OBJPROP_TEXT,DoubleToString(ChangeArray[i],2)+"%");
}
else
{
ObjectSetInteger(0,PairsArray[i]+"Bar",OBJPROP_YDISTANCE,(int)(Zero-ChangeArray[i]*cF));
ObjectSetInteger(0,PairsArray[i]+"Bar",OBJPROP_YSIZE,(int)(ChangeArray[i]*cF));
ObjectSetInteger(0,PairsArray[i]+"Bar",OBJPROP_COLOR,UPcolor);
ObjectSetInteger(0,PairsArray[i]+"Text",OBJPROP_COLOR,UPcolor);
ObjectSetInteger(0,PairsArray[i]+"Change",OBJPROP_COLOR,UPcolor);
ObjectSetInteger(0,PairsArray[i]+"Text",OBJPROP_ANCHOR,ANCHOR_LEFT_UPPER);
ObjectSetInteger(0,PairsArray[i]+"Change",OBJPROP_ANCHOR,ANCHOR_LEFT_LOWER);
ObjectSetString(0,PairsArray[i]+"Change",OBJPROP_TEXT,DoubleToString(ChangeArray[i],2)+"%");
}
}
int max = ArrayMaximum(ChangeArray, WHOLE_ARRAY, 0);
int min = ArrayMinimum(ChangeArray, WHOLE_ARRAY, 0);
//---
double tmp=0;
//---
if(ChangeArray[max]>MathAbs(ChangeArray[min])) tmp=ChangeArray[max];
else tmp=MathAbs(ChangeArray[min]);
//---
if(tmp*cF>Ysize/2) cF--;
if((Ysize/2-tmp*cF)>20) cF++;
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
void OnChartEvent(const int id,
const long &lparam,
const double &dparam,
const string &sparam)
{
if(id==CHARTEVENT_OBJECT_CLICK)
{
string name=StringSubstr(sparam,0,6);
ChartOpen(name,Per);
}
if(id==CHARTEVENT_CHART_CHANGE) OnInit();
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
double SymbolChange(string symbol,ENUM_TIMEFRAMES period)
{
SymbolSelect(symbol,true);
double perf = 0;
double open = iOpen(symbol, period, 0);
double close = iClose(symbol, period, 0);
//---
if(open!=0)
{
perf=(close-open);
perf /= open;
perf *= 100;
}
else Print("Change NaN");
//---
return(NormalizeDouble(perf, 2));
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
void CreateTextLabel(string name,int x,int y,string text,ENUM_ANCHOR_POINT anchor)
{
ObjectDelete(0,name);
ResetLastError();
//---
if(ObjectCreate(0,name,OBJ_LABEL,1,0,0))
{
ObjectSetInteger(0,name,OBJPROP_XDISTANCE,x);
ObjectSetInteger(0,name,OBJPROP_YDISTANCE,y);
ObjectSetInteger(0,name,OBJPROP_CORNER,CORNER_LEFT_UPPER);
ObjectSetString(0,name,OBJPROP_TEXT,text);
ObjectSetString(0,name,OBJPROP_FONT,Font);
ObjectSetInteger(0,name,OBJPROP_FONTSIZE,Size);
ObjectSetDouble(0,name,OBJPROP_ANGLE,0.0);
ObjectSetInteger(0,name,OBJPROP_ANCHOR,anchor);
ObjectSetInteger(0,name,OBJPROP_COLOR,clrBlue);
ObjectSetInteger(0,name,OBJPROP_BACK,false);
ObjectSetInteger(0,name,OBJPROP_SELECTABLE,false);
ObjectSetInteger(0,name,OBJPROP_HIDDEN,true);
ObjectSetInteger(0,name,OBJPROP_ZORDER,1);
ObjectSetString(0,name,OBJPROP_TOOLTIP,"\n");
}
else Print("ERROR Creating object.",GetLastError());
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
void CreateRecLabel(string name,int x,int y,int xsize,int ysize)
{
ObjectDelete(0,name);
ResetLastError();
//---
if(ObjectCreate(0,name,OBJ_RECTANGLE_LABEL,1,0,0))
{
ObjectSetInteger(0,name,OBJPROP_XDISTANCE,x);
ObjectSetInteger(0,name,OBJPROP_YDISTANCE,y);
ObjectSetInteger(0,name,OBJPROP_XSIZE,xsize);
ObjectSetInteger(0,name,OBJPROP_YSIZE,ysize);
ObjectSetInteger(0,name,OBJPROP_BGCOLOR,BGcolor);
ObjectSetInteger(0,name,OBJPROP_BORDER_TYPE,BORDER_FLAT);
ObjectSetInteger(0,name,OBJPROP_CORNER,CORNER_LEFT_UPPER);
ObjectSetInteger(0,name,OBJPROP_COLOR,clrDodgerBlue);
ObjectSetInteger(0,name,OBJPROP_STYLE,STYLE_SOLID);
ObjectSetInteger(0,name,OBJPROP_WIDTH,1);
ObjectSetInteger(0,name,OBJPROP_BACK,false);
ObjectSetInteger(0,name,OBJPROP_SELECTABLE,false);
ObjectSetInteger(0,name,OBJPROP_HIDDEN,true);
ObjectSetInteger(0,name,OBJPROP_ZORDER,0);
ObjectSetString(0,name,OBJPROP_TOOLTIP,"\n");
}
else Print("ERROR Creating object.",GetLastError());
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
int PixToPoints(int pix)
{
int pt=0;
int ems[28][2]=
{
6,8,7,9,7,10,8,11,9,12,10,13,10,14,11,15,12,16,13,17,13,18,14,19,14,20,15,21,16,22,
17,23,18,24,20,26,22,29,24,32,26,35,27,36,28,37,29,38,30,40,32,42,34,45,36,48
};
//---
if(pix<8)
return(6);
if(pix>48)
return(36);
//---
for(int i=0; i<28; i++)
{
if(pix==ems[i][1])
{
pt=ems[i][0];
break;
}
}
return(pt);
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
string PeriodToString(ENUM_TIMEFRAMES tframe)
{
string result=" ";
string PeriodArray[9][2]=
{
"M1","1",
"M5","5",
"M15","15",
"M30","30",
"H1","60",
"H4","240",
"D1","1440",
"W1","10080",
"MN1","43200"
};
for(int i=0; i<9; i++)
{
if((string)tframe==PeriodArray[i][1])
{
result=PeriodArray[i][0];
break;
}
}
return(result);
}
//+--------------------------------------------------------------------+
