rbf-dda

This script implements a sophisticated machine learning algorithm designed to categorize data into two distinct groups. It utilizes a method known as Radial Basis Function - Direct Discriminant Analysis (RBF-DDA). In simple terms, it is a system that "learns" the boundaries between two different types of information by creating mathematical models of what those types look like.

Core Logic and Workflow

The script operates through three primary functional stages: Learning, Classification, and Testing.

1. The Learning Process (Data Organization)

The primary goal of the learning phase is to identify the characteristics of two classes (labeled as +1 and -1). Instead of using rigid rules, the script creates "prototypes"—essentially representative landmarks in a multi-dimensional space.

  • Prototype Creation: As the script processes data points, it checks if a new piece of information is significantly different from existing prototypes. If it is unique enough, the script creates a new prototype to represent that area.
  • Dynamic Adjustment (Shrinking): The system continuously refines the boundaries of these prototypes. It "shrinks" or adjusts the influence area of each prototype based on how close new data points are to them. This ensures the model remains precise and doesn't become over-generalized.
  • Weighting: Not all prototypes are treated equally. The script assigns weights to each one, ensuring that the most representative "landmarks" have a stronger influence on the final classification.

2. The Classification Process (Evaluation)

Once the model has learned the prototypes for both classes, it can be used to evaluate new, unseen data.

  • Similarity Scoring: When presented with a new data point, the script calculates its "closeness" to every prototype established during the learning phase.
  • Probability Calculation: It combines these closeness scores with the weights of the prototypes to determine the likelihood of the data point belonging to one class versus the other.
  • Normalization: The final output is a normalized ratio, allowing you to see the relative confidence of the model's decision (e.g., "How much does this look like Class A vs. Class B?").

3. Iterative Refinement

The logic includes a feedback loop. If a new data point is processed that significantly deviates from current knowledge, the script triggers an update to its internal prototype list and restarts its analysis of that specific set. This allows the model to adapt dynamically as it encounters more diverse information.

Summary for the User

In practical terms, this script acts like a sophisticated sorting machine. It doesn't just look at a single value; it looks at a "profile" of data. It builds a mental map of what "Type A" and "Type B" look like based on historical examples, constantly refining that map to be as accurate as possible. When you give it new information, it compares that info against its internal map to tell you which category it most likely belongs to.

3 Views
0 Downloads
0 Favorites
rbf-dda
// mt4 implementation of rbf-dda as described in:
// http://citeseer.ist.psu.edu/cache/papers/cs/6810/http:zSzzSzhttp.cs.berkeley.eduzSz~bertholdzSzFTPzSzberthold.neuroc98.pdf/berthold98constructive.pdf

#define MAX_I 1000  // Max number of samples
#define MAX_E 10    // Max number of dimensions in input
#define M_PI 3.141592653589793

int init()
  {
  TestSpiral();
  return(0);
  }

int deinit()
  {
  return(0);
  }

int start()
  {
  return(0);
  }

// Warning ! this version works with only two classes: -1 and +1
void DDALearn(int Nbi, int Nbe, double Spi[MAX_I][MAX_E], int CSpi[MAX_I], double tm, double tp,
			  int& Nbm, double& Mum[MAX_I][MAX_E], double& Sigm[MAX_I], double& Am[MAX_I],
			  int& Nbp, double& Mup[MAX_I][MAX_E], double& Sigp[MAX_I], double& Ap[MAX_I])
{
int i, j, k, nj, iter;
double ltm, a, x, mnj, minx;

ltm = MathLog(tm);
Nbm = 0;
Nbp = 0;
iter = 1;
while (iter == 1)
  {
  iter = 0;
  for (i=0;i<Nbi;i++)
    {
	 if (CSpi[i] == 1)
	   {
	   minx = 1000000000.0;

// Shrink
      for (j=0;j<Nbm;j++)
	     {
		  a = 0.0;
        for (k=0;k<Nbe;k++)
		    {
		    x = Spi[i][k]-Mum[j][k];
		    a += (x*x);
		    }
		  x = MathSqrt(-a/ltm);
		  if (x < Sigm[j])
		    Sigm[j] = x;
		  if (x < minx)
		    minx = x;
		  }

// Search for a valid prototype
	  nj = -1;
	  mnj = tp;
      for (j=0;j<Nbp;j++)
	    {
		a = 0.0;
        for (k=0;k<Nbe;k++)
		  {
		  x = Spi[i][k]-Mup[j][k];
		  a += (x*x);
		  }
		x = MathExp(-a/(Sigp[j]*Sigp[j]));
		if (x >= mnj)
		  {
		  mnj = x;
		  nj = j;
		  }
	    }

// New prototype
	  if (nj == -1)
	    {
	    Ap[Nbp] = 1.0;
       for (k=0;k<Nbe;k++)
		  Mup[Nbp][k] = Spi[i][k];
		Sigp[Nbp] = minx;  // may be 1e10
		Nbp++;
		iter = 1;
	    }
	    else
	    Ap[nj]++;
	  }

	if (CSpi[i] == -1)
	  {
	  minx = 1000000000.0;

// Shrink
      for (j=0;j<Nbp;j++)
	    {
		a = 0.0;
        for (k=0;k<Nbe;k++)
		  {
		  x = Spi[i][k]-Mup[j][k];
		  a += (x*x);
		  }
		x = MathSqrt(-a/ltm);
		if (x < Sigp[j])
		  Sigp[j] = x;
		if (x < minx)
		  minx = x;
		}

// Search for a valid prototype
	  nj = -1;
	  mnj = tp;
     for (j=0;j<Nbm;j++)
	    {
		 a = 0.0;
       for (k=0;k<Nbe;k++)
		  {
		  x = Spi[i][k]-Mum[j][k];
		  a += (x*x);
		  }
		x = MathExp(-a/(Sigm[j]*Sigm[j]));
		if (x >= mnj)
		  {
		  mnj = x;
		  nj = j;
		  }
	    }

// New prototype
	  if (nj == -1)
	    {
	    Am[Nbm] = 1.0;
        for (k=0;k<Nbe;k++)
		  Mum[Nbm][k] = Spi[i][k];
		Sigm[Nbm] = minx;  // may be 1e10
		Nbm++;
		iter = 1;
	    }
	    else
	    Am[nj]++;
	  }
    }

  if (iter == 1)
	Print("Nm = ", Nbm, " Np = ", Nbp);
  }

x = 0.0;
for (j=0;j<Nbm;j++)
  x += Am[j];
for (j=0;j<Nbm;j++)
  Am[j] /= x;

x = 0.0;
for (j=0;j<Nbp;j++)
  x += Ap[j];
for (j=0;j<Nbp;j++)
  Ap[j] /= x;
}

void DDAclass(int Nbi, int Nbe, double Spi[MAX_I][MAX_E], double tm,
			  int Nbm, double Mum[MAX_I][MAX_E], double Sigm[MAX_I], double Am[MAX_I],
			  int Nbp, double Mup[MAX_I][MAX_E], double Sigp[MAX_I], double Ap[MAX_I],
			  double& om[MAX_I], double& op[MAX_I])
{
int i, j, k;
double a, x;

for (i=0;i<Nbi;i++)
  {
  om[i] = 0.0;
  for (j=0;j<Nbm;j++)
    {
	a = 0.0;
    for (k=0;k<Nbe;k++)
      {
	  x = Spi[i][k]-Mum[j][k];
	  a += x*x;
	  }
	x = MathExp(-a/(Sigm[j]*Sigm[j]));
	om[i] += x*Am[j];
    }

  op[i] = 0.0;
  for (j=0;j<Nbp;j++)
    {
	a = 0.0;
    for (k=0;k<Nbe;k++)
      {
	  x = Spi[i][k]-Mup[j][k];
	  a += x*x;
	  }
	x = MathExp(-a/(Sigp[j]*Sigp[j]));
	op[i] += x*Ap[j];
    }

  x = op[i] + om[i] + tm;
  op[i] /= x;
  om[i] /= x;
  }
}

void DDAStep(int Nbe, double tm, double tp,
			 int Nbi1, double Spi1[MAX_I][MAX_E], int CSpi1[MAX_I],
			 int Nbi2, double Spi2[MAX_I][MAX_E],
			 double& om[MAX_I], double& op[MAX_I])
{
static int Nbm, Nbp;
static double Mum[MAX_I][MAX_E], Sigm[MAX_I], Am[MAX_I];
static double Mup[MAX_I][MAX_E], Sigp[MAX_I], Ap[MAX_I];

DDALearn(Nbi1, Nbe, Spi1, CSpi1, tm, tp, Nbm, Mum, Sigm, Am, Nbp, Mup, Sigp, Ap);
DDAclass(Nbi2, Nbe, Spi2, tm, Nbm, Mum, Sigm, Am, Nbp, Mup, Sigp, Ap, om, op);
}

void TestSpiral()
{
int i;
double ri, spi1[98][2], spi2[98][2];
static double Spi[MAX_I][MAX_E];
static int CSpi[MAX_I];
int Nbi, Nbe;
static double Mum[MAX_I][MAX_E], Sigm[MAX_I], Am[MAX_I];
static double Mup[MAX_I][MAX_E], Sigp[MAX_I], Ap[MAX_I];
static double om[MAX_I], op[MAX_I];
double tm, tp;

Nbi = 98;
Nbe = 2;
for (i=0;i<Nbi;i++)
  {
  ri = ((140.0-i)/140.0);
  ri = ri*ri*ri;
  spi1[i][0] = ri*MathSin(i*M_PI/16.0);
  spi1[i][1] = ri*MathCos(i*M_PI/16.0);
  spi2[i][0] = -ri*MathSin(i*M_PI/16.0);
  spi2[i][1] = -ri*MathCos(i*M_PI/16.0);
  }

for (i=0;i<Nbi;i++)
  {
  ri = ((140.0-i)/140.0);
  ri = ri*ri*ri;
  Spi[2*i][0] = spi1[i][0];
  Spi[2*i][1] = spi1[i][1];
  CSpi[2*i] = 1;
  Spi[2*i+1][0] = spi2[i][0];
  Spi[2*i+1][1] = spi2[i][1];
  CSpi[2*i+1] = -1;
  }

tm = 0.2;
tp = 0.4;
// Test: learning samples and test samples are the same
DDAStep(Nbe, tm, tp, 2*Nbi, Spi, CSpi, 2*Nbi, Spi, om, op);

for (i=0;i<2*Nbi;i++)
  {
  Print(i, " ", CSpi[i], " ", op[i] - om[i]);
  }

}
