RBCI_hist_v1

This script functions as a specialized visual indicator for the MetaTrader 4 platform, designed to help traders identify directional momentum in financial markets. Instead of showing standard price movements, it translates complex historical data into a simplified visual histogram.

Core Logic and Functionality

1. Weighted Historical Analysis The core of this script relies on a heavy mathematical calculation that looks back at a significant number of past price points (specifically 73 bars). It applies unique "weights" to each of these prices—some values are added, while others are subtracted. This means the indicator doesn't just look at where the price is now; it calculates a specific relationship between current prices and historical data to determine underlying trends.

2. Dual Comparison System The script performs this complex calculation twice:

Primary Calculation: It evaluates the weighted data for the most recent timeframe.
Secondary Calculation: It repeats the exact same process but shifts the perspective slightly forward by one step.

By calculating these two different values, the script can compare "Current Momentum" against "Immediate Shift."

3. Directional Filtering (The Result) The final output is a binary "Up or Down" signal. The logic works as follows:

If the Primary Calculation results in a higher value than the Secondary Calculation, the script identifies an upward trend and displays this in Green.
If the Secondary Calculation is higher, it identifies a downward trend and displays this in Red.

Visual Representation

The indicator appears in its own separate window below the main price chart. Rather than drawing a continuous line, it uses a histogram format:

Green Bars: Indicate periods where the mathematical conditions favor upward movement.
Red Bars: Indicate periods where the conditions favor downward movement.

Summary for the User

In plain terms, this script acts as a momentum filter. It takes a large amount of historical "noise" and compresses it into a clear visual signal. By looking at the histogram, a trader can quickly see whether the current market weight is leaning toward an increase or a decrease based on the specific mathematical formula provided by the developer.

Miscellaneous

11 Views

0 Downloads

0 Favorites

RBCI_hist_v1

/*-----------------------------+
|			       |
| Shared by www.Aptrafx.com    |
|			       |
+------------------------------*/

//+------------------------------------------------------------------+
//| RBCI_hist.mq4
//| Ramdass - Conversion only
//+------------------------------------------------------------------+

#property indicator_separate_window
#property indicator_buffers 2
#property indicator_color1 Green
#property indicator_color2 Red

extern int CountBars=300;
//---- buffers
double Up[];
double Down[];
//+------------------------------------------------------------------+
//| Custom indicator initialization function                         |
//+------------------------------------------------------------------+
int init()
  {
   string short_name;
//---- indicator line
   IndicatorBuffers(2);
   SetIndexStyle(0,DRAW_HISTOGRAM);
   SetIndexBuffer(0,Up);
   SetIndexStyle(1,DRAW_HISTOGRAM);
   SetIndexBuffer(1,Down);
//----
   return(0);
  }
//+------------------------------------------------------------------+
//| RBCI                                                             |
//+------------------------------------------------------------------+
int start()
  {
   SetIndexDrawBegin(0,Bars-CountBars+73);
   SetIndexDrawBegin(1,Bars-CountBars+73);
   int i,i2,counted_bars=IndicatorCounted();
   double RBCI,RBCI1,value1,value2,value3,value4;
//----
   if(CountBars<=73) return(0);
//---- initial zero
   if(counted_bars<73)
   {
      for(i=1;i<=0;i++) Up[CountBars-i]=0.0;
      for(i=1;i<=0;i++) Down[CountBars-i]=0.0;
   }
//----
   i=CountBars-73-1;
//   if(counted_bars>=73) i=Bars-counted_bars-1;
   while(i>=0)
     {

value2 =
0.08269258*Close[i+0]
+0.08210489*Close[i+1]
+0.08093874*Close[i+2]
+0.07921003*Close[i+3]
+0.07694005*Close[i+4]
+0.07415944*Close[i+5]
+0.07090508*Close[i+6]
+0.06722010*Close[i+7]
+0.06314921*Close[i+8]
+0.05874928*Close[i+9]
+0.05407277*Close[i+10]
+0.04918011*Close[i+11]
+0.04413127*Close[i+12]
+0.03898817*Close[i+13]
+0.03381087*Close[i+14]
+0.02866037*Close[i+15]
+0.02359602*Close[i+16]
+0.01867285*Close[i+17]
+0.01394154*Close[i+18]
+0.00945020*Close[i+19]
+0.00524380*Close[i+20]
+0.00135856*Close[i+21]
-0.00217576*Close[i+22]
-0.00533362*Close[i+23]
-0.00809235*Close[i+24]
-0.01044596*Close[i+25]
-0.01238246*Close[i+26]
-0.01390515*Close[i+27]
-0.01501922*Close[i+28]
-0.01573813*Close[i+29]
-0.01607903*Close[i+30]
-0.01606501*Close[i+31]
-0.01572265*Close[i+32]
-0.01508076*Close[i+33]
-0.01417155*Close[i+34]
-0.01303199*Close[i+35]
-0.01170149*Close[i+36]
-0.01021570*Close[i+37]
-0.00860941*Close[i+38]
-0.00692232*Close[i+39]
-0.00519812*Close[i+40]
-0.00345733*Close[i+41]
-0.00174477*Close[i+42]
-0.00008354*Close[i+43]
+0.00149695*Close[i+44]
+0.00297402*Close[i+45]
+0.00432644*Close[i+46]
+0.00553786*Close[i+47]
+0.00659613*Close[i+48]
+0.00749328*Close[i+49]
+0.00822608*Close[i+50]
+0.00879528*Close[i+51]
+0.00920238*Close[i+52]
+0.00944568*Close[i+53]
+0.00952717*Close[i+54]
+0.00946588*Close[i+55]
+0.00929962*Close[i+56]
+0.00898757*Close[i+57]
+0.00859207*Close[i+58]
+0.00810829*Close[i+59]
+0.00755924*Close[i+60]
+0.00696141*Close[i+61]
+0.00633350*Close[i+62]
+0.00569343*Close[i+63]
+0.00505929*Close[i+64]
+0.00444999*Close[i+65]
+0.00388521*Close[i+66]
+0.00338555*Close[i+67]
+0.00297397*Close[i+68]
+0.00267839*Close[i+69]
+0.00253170*Close[i+70]
+0.00257620*Close[i+71]
-0.00816217*Close[i+72];

value1 =
0.36423990*Close[i+0]
+0.33441085*Close[i+1]
+0.25372851*Close[i+2]
+0.14548806*Close[i+3]
+0.03934469*Close[i+4]
-0.03871426*Close[i+5]
-0.07451349*Close[i+6]
-0.06903411*Close[i+7]
-0.03611022*Close[i+8]
+0.00422528*Close[i+9]
+0.03382809*Close[i+10]
+0.04267885*Close[i+11]
+0.03120441*Close[i+12]
+0.00816037*Close[i+13]
-0.01442877*Close[i+14]
-0.02678947*Close[i+15]
-0.02525534*Close[i+16]
-0.01272910*Close[i+17]
+0.00350063*Close[i+18]
+0.01565175*Close[i+19]
+0.01895659*Close[i+20]
+0.01328613*Close[i+21]
+0.00252297*Close[i+22]
-0.00775517*Close[i+23]
-0.01301467*Close[i+24]
-0.01164808*Close[i+25]
-0.00527241*Close[i+26]
+0.00248750*Close[i+27]
+0.00793380*Close[i+28]
+0.00897632*Close[i+29]
+0.00583939*Close[i+30]
+0.00059669*Close[i+31]
-0.00405186*Close[i+32]
-0.00610944*Close[i+33]
-0.00509042*Close[i+34]
-0.00198138*Close[i+35]
+0.00144873*Close[i+36]
+0.00373774*Close[i+37]
+0.01047723*Close[i+38]
-0.00022625*Close[i+39];



value4 =
0.08269258*Close[i+0+1]
+0.08210489*Close[i+1+1]
+0.08093874*Close[i+2+1]
+0.07921003*Close[i+3+1]
+0.07694005*Close[i+4+1]
+0.07415944*Close[i+5+1]
+0.07090508*Close[i+6+1]
+0.06722010*Close[i+7+1]
+0.06314921*Close[i+8+1]
+0.05874928*Close[i+9+1]
+0.05407277*Close[i+10+1]
+0.04918011*Close[i+11+1]
+0.04413127*Close[i+12+1]
+0.03898817*Close[i+13+1]
+0.03381087*Close[i+14+1]
+0.02866037*Close[i+15+1]
+0.02359602*Close[i+16+1]
+0.01867285*Close[i+17+1]
+0.01394154*Close[i+18+1]
+0.00945020*Close[i+19+1]
+0.00524380*Close[i+20+1]
+0.00135856*Close[i+21+1]
-0.00217576*Close[i+22+1]
-0.00533362*Close[i+23+1]
-0.00809235*Close[i+24+1]
-0.01044596*Close[i+25+1]
-0.01238246*Close[i+26+1]
-0.01390515*Close[i+27+1]
-0.01501922*Close[i+28+1]
-0.01573813*Close[i+29+1]
-0.01607903*Close[i+30+1]
-0.01606501*Close[i+31+1]
-0.01572265*Close[i+32+1]
-0.01508076*Close[i+33+1]
-0.01417155*Close[i+34+1]
-0.01303199*Close[i+35+1]
-0.01170149*Close[i+36+1]
-0.01021570*Close[i+37+1]
-0.00860941*Close[i+38+1]
-0.00692232*Close[i+39+1]
-0.00519812*Close[i+40+1]
-0.00345733*Close[i+41+1]
-0.00174477*Close[i+42+1]
-0.00008354*Close[i+43+1]
+0.00149695*Close[i+44+1]
+0.00297402*Close[i+45+1]
+0.00432644*Close[i+46+1]
+0.00553786*Close[i+47+1]
+0.00659613*Close[i+48+1]
+0.00749328*Close[i+49+1]
+0.00822608*Close[i+50+1]
+0.00879528*Close[i+51+1]
+0.00920238*Close[i+52+1]
+0.00944568*Close[i+53+1]
+0.00952717*Close[i+54+1]
+0.00946588*Close[i+55+1]
+0.00929962*Close[i+56+1]
+0.00898757*Close[i+57+1]
+0.00859207*Close[i+58+1]
+0.00810829*Close[i+59+1]
+0.00755924*Close[i+60+1]
+0.00696141*Close[i+61+1]
+0.00633350*Close[i+62+1]
+0.00569343*Close[i+63+1]
+0.00505929*Close[i+64+1]
+0.00444999*Close[i+65+1]
+0.00388521*Close[i+66+1]
+0.00338555*Close[i+67+1]
+0.00297397*Close[i+68+1]
+0.00267839*Close[i+69+1]
+0.00253170*Close[i+70+1]
+0.00257620*Close[i+71+1]
-0.00816217*Close[i+72+1];

value3 =
0.36423990*Close[i+0+1]
+0.33441085*Close[i+1+1]
+0.25372851*Close[i+2+1]
+0.14548806*Close[i+3+1]
+0.03934469*Close[i+4+1]
-0.03871426*Close[i+5+1]
-0.07451349*Close[i+6+1]
-0.06903411*Close[i+7+1]
-0.03611022*Close[i+8+1]
+0.00422528*Close[i+9+1]
+0.03382809*Close[i+10+1]
+0.04267885*Close[i+11+1]
+0.03120441*Close[i+12+1]
+0.00816037*Close[i+13+1]
-0.01442877*Close[i+14+1]
-0.02678947*Close[i+15+1]
-0.02525534*Close[i+16+1]
-0.01272910*Close[i+17+1]
+0.00350063*Close[i+18+1]
+0.01565175*Close[i+19+1]
+0.01895659*Close[i+20+1]
+0.01328613*Close[i+21+1]
+0.00252297*Close[i+22+1]
-0.00775517*Close[i+23+1]
-0.01301467*Close[i+24+1]
-0.01164808*Close[i+25+1]
-0.00527241*Close[i+26+1]
+0.00248750*Close[i+27+1]
+0.00793380*Close[i+28+1]
+0.00897632*Close[i+29+1]
+0.00583939*Close[i+30+1]
+0.00059669*Close[i+31+1]
-0.00405186*Close[i+32+1]
-0.00610944*Close[i+33+1]
-0.00509042*Close[i+34+1]
-0.00198138*Close[i+35+1]
+0.00144873*Close[i+36+1]
+0.00373774*Close[i+37+1]
+0.01047723*Close[i+38+1]
-0.00022625*Close[i+39+1];



RBCI=value1-value2;
RBCI1=value3-value4;


if (RBCI>RBCI1) {Up[i]=RBCI;Down[i]=0.0;} else {Down[i]=RBCI;Up[i]=0.0;}

      i--;
     }
   return(0);
  }
//+------------------------------------------------------------------+
