precision_trend_histo_2

Download script
Author: mladen
precision_trend_histo_2

This script is designed as a visual trend indicator for the MetaTrader platform. Its primary purpose is to identify and display the current market direction by analyzing price movements and volatility over a specific period. Rather than just looking at where the price is right now, it calculates the "momentum" of the trend to help filter out minor market noise.

Core Logic Overview

The indicator works by calculating a dynamic range for each price bar (the distance between the highest and lowest prices). It then takes these ranges and averages them over a user-defined period. This average is multiplied by a sensitivity factor, which allows the user to decide how "reactive" or "smooth" the trend detection should be.

The script uses this calculated data to establish a price boundary. Think of this as a moving target:

  • Upward Trend: When the price breaks above a certain upper threshold, the indicator identifies an upward move and updates its internal records to track the new "highs."
  • Downward Trend: When the price falls below a specific lower threshold, the indicator identifies a downward move and begins tracking the new "lows."

How it Functions on the Chart

The script continuously monitors three main pieces of information:

  1. Price Boundaries: It keeps track of the highest point reached during an uptrend and the lowest point reached during a downtrend.
  2. Trend State: It maintains a memory of whether the market is currently in a positive state (1), a negative state (-1), or a neutral starting state (0).
  3. Dynamic Adjustment: As new prices arrive, the script constantly recalculates the distance between the current price and the average volatility. If the price pushes far enough to break the existing boundary, the "state" of the trend flips.

Visual Output

On your trading platform, this logic translates into a visual histogram in a separate window:

  • Green Bars: Appear when the logic confirms the market is in a prevailing upward trend.
  • Red Bars: Appear when the logic confirms the market is in a prevailing downward trend.

By using an average of past volatility rather than just the immediate last price, the script aims to provide a more "precise" view of the trend, helping traders see the broader direction of the market more clearly.

Miscellaneous
Implements a curve of type %1
8 Views
0 Downloads
0 Favorites
precision_trend_histo_2
//+------------------------------------------------------------------+
//|                                              precision trend.mq4 |
//+------------------------------------------------------------------+
#property copyright "mladen"
#property link      "mladenfx@gmail.com"

#property indicator_separate_window
#property indicator_buffers  2
#property indicator_color1   clrGreen
#property indicator_color2   clrRed
#property indicator_width1   2
#property indicator_width2   2
#property indicator_minimum  0
#property indicator_maximum  1
#property strict

//
//
//
//
//

extern int    avgPeriod   = 30; // Average period
extern double sensitivity = 3;  // Sensitivity

double upBuffer[],dnBuffer[];

//------------------------------------------------------------------
//
//------------------------------------------------------------------
//
//
//
//
//

int OnInit()
{
   SetIndexBuffer(0,upBuffer); SetIndexStyle(0,DRAW_HISTOGRAM);
   SetIndexBuffer(1,dnBuffer); SetIndexStyle(1,DRAW_HISTOGRAM);
   return(INIT_SUCCEEDED);
}
void OnDeinit(const int reason) { return; }
int OnCalculate (const int       rates_total,
                 const int       prev_calculated,
                 const datetime& btime[],
                 const double&   open[],
                 const double&   high[],
                 const double&   low[],
                 const double&   close[],
                 const long&     tick_volume[],
                 const long&     volume[],
                 const int&      spread[] )
{
   int counted_bars = prev_calculated;
      if(counted_bars < 0) return(-1);
      if(counted_bars > 0) counted_bars--;
           int limit=MathMin(rates_total-counted_bars,rates_total-1);

   //
   //
   //
   //
   //

   for(int i=limit; i>=0 && !_StopFlag; i--)
   {
      upBuffer[i] = EMPTY_VALUE;
      dnBuffer[i] = EMPTY_VALUE;
         double trend = iPrecisionTrend(high,low,close,avgPeriod,sensitivity,i,rates_total);
         if (trend ==  1) upBuffer[i] = 1;
         if (trend == -1) dnBuffer[i] = 1;
   }
   return(rates_total);
}

//------------------------------------------------------------------
//
//------------------------------------------------------------------
//
//
//
//
//

#define _ptInstances     1
#define _ptInstancesSize 7
double  _ptWork[][_ptInstances*_ptInstancesSize];
#define __range 0
#define __trend 1
#define __avg   2
#define __avgd  3
#define __avgu  4
#define __minc  5
#define __maxc  6
double iPrecisionTrend(const double& _high[], const double& _low[], const double& _close[], int _period, double _sensitivity, int i, int bars, int instanceNo=0)
{
   if (ArrayRange(_ptWork,0)!=bars) ArrayResize(_ptWork,bars); instanceNo*=_ptInstancesSize; int r=bars-i-1;

   //
   //
   //
   //
   //

   _ptWork[r][instanceNo+__range] = _high[i]-_low[i];
   _ptWork[r][instanceNo+__avg]   = _ptWork[r][instanceNo+__range];
   int k=1; for (; k<_period && (r-k)>=0; k++) _ptWork[r][instanceNo+__avg] += _ptWork[r-k][instanceNo+__range];
                                               _ptWork[r][instanceNo+__avg] /= k;
                                               _ptWork[r][instanceNo+__avg] *= _sensitivity;

      //
      //
      //
      //
      //

      if (i==(bars-1))
      {
         _ptWork[r][instanceNo+__trend] = 0;
         _ptWork[r][instanceNo+__avgd] = _close[i]-_ptWork[r][instanceNo+__avg];
         _ptWork[r][instanceNo+__avgu] = _close[i]+_ptWork[r][instanceNo+__avg];
         _ptWork[r][instanceNo+__minc] = _close[i];
         _ptWork[r][instanceNo+__maxc] = _close[i];
      }
      else
      {
         _ptWork[r][instanceNo+__trend] = _ptWork[r-1][instanceNo+__trend];
         _ptWork[r][instanceNo+__avgd]  = _ptWork[r-1][instanceNo+__avgd];
         _ptWork[r][instanceNo+__avgu]  = _ptWork[r-1][instanceNo+__avgu];
         _ptWork[r][instanceNo+__minc]  = _ptWork[r-1][instanceNo+__minc];
         _ptWork[r][instanceNo+__maxc]  = _ptWork[r-1][instanceNo+__maxc];

         //
         //
         //
         //
         //

            switch((int)_ptWork[r-1][instanceNo+__trend])
            {
               case 0 :
                     if (_close[i]>_ptWork[r-1][instanceNo+__avgu])
                     {
                        _ptWork[r][instanceNo+__minc]  = _close[i];
                        _ptWork[r][instanceNo+__avgd]  = _close[i]-_ptWork[r][instanceNo+__avg];
                        _ptWork[r][instanceNo+__trend] =  1;
                     }
                     if (_close[i]<_ptWork[r-1][instanceNo+__avgd])
                     {
                        _ptWork[r][instanceNo+__maxc]  = _close[i];
                        _ptWork[r][instanceNo+__avgu]  = _close[i]+_ptWork[r][instanceNo+__avg];
                        _ptWork[r][instanceNo+__trend] = -1;
                     }
                     break;
               case 1 :
                     _ptWork[r][instanceNo+__avgd] = _ptWork[r-1][instanceNo+__minc] - _ptWork[r][instanceNo+__avg];
                        if (_close[i]>_ptWork[r-1][instanceNo+__minc]) _ptWork[r][instanceNo+__minc] = _close[i];
                        if (_close[i]<_ptWork[r-1][instanceNo+__avgd])
                        {
                           _ptWork[r][instanceNo+__maxc] = _close[i];
                           _ptWork[r][instanceNo+__avgu] = _close[i]+_ptWork[r][instanceNo+__avg];
                           _ptWork[r][instanceNo+__trend] = -1;
                        }
                     break;
               case -1 :
                     _ptWork[r][instanceNo+__avgu] = _ptWork[r-1][instanceNo+__maxc] + _ptWork[r][instanceNo+__avg];
                        if (_close[i]<_ptWork[r-1][instanceNo+__maxc]) _ptWork[r][instanceNo+__maxc] = _close[i];
                        if (_close[i]>_ptWork[r-1][instanceNo+__avgu])
                        {
                           _ptWork[r][instanceNo+__minc]  = _close[i];
                           _ptWork[r][instanceNo+__avgd]  = _close[i]-_ptWork[r][instanceNo+__avg];
                           _ptWork[r][instanceNo+__trend] = 1;
                        }
            }
      }
   return(_ptWork[r][instanceNo+__trend]);
}
