ninetfmovement

Download script
Author: Copyright 2014 - By 3RJ ~ Roy Philips-Jacobs ~ 27/11/2014
ninetfmovement

This script is a multi-timeframe dashboard designed for the MetaTrader platform. It provides traders with a comprehensive, real-time visual overview of market conditions across nine different timeframes simultaneously, ranging from 1-minute charts to monthly charts.

Instead of forcing you to switch between different tabs to see what is happening, this tool aggregates that data into a single "at-a-glance" display window. Here is the breakdown of how the logic functions:

Timeframe Monitoring

The script tracks nine specific intervals: M1, M5, M15, M30, H1, H4, D1, W1, and MN1. For each of these timeframes, it identifies three key pieces of information:

  • Directional Movement: It determines if the current price candle is moving up, down, or remaining neutral (flat).
  • Price Range: It calculates the volatility (the distance between the high and low) for each timeframe and converts it into a readable format.
  • Visual Cues: It uses distinct symbols and colors (Blue for up, White for down, and Yellow for neutral) to represent the immediate movement of each period.

Dynamic Market Analysis

Beyond just showing where the price is currently going, the script performs deeper calculations to help identify momentum:

  • Trend Consistency: The logic compares the behavior of multiple timeframes to see if they are in "consensus." For example, it checks if short-term movements align with broader trends.
  • Momentum Indicators: It utilizes technical calculations (specifically variations of the Williams %R and Moving Averages) to detect changes in market strength.
  • Action Signals: Based on these calculations, the dashboard generates specific text alerts such as "UP," "DOWN," or "HOLD." These signals appear dynamically based on whether the momentum is strengthening or weakening relative to other timeframes.

Contextual Information

To help with trade planning, the dashboard includes environmental data:

  • Live Clock: It displays a precise breakdown of the current time in Hours, Minutes, and Seconds.
  • Session Tracking: The script automatically identifies which global financial sessions are currently active (e.g., NYC, London, Tokyo, etc.) based on the server time. This helps traders understand which markets are providing the most liquidity at any given moment.

Visual Layout

The logic is designed to be highly organized. It places labels for the timeframes, price movements, and high/low ranges in a structured grid. By calculating the specific coordinates of these elements, it ensures that the data remains legible and doesn't overlap, providing a clean, professional dashboard for active monitoring.

Price Data Components
Series array that contains open prices of each barSeries array that contains close prices for each barSeries array that contains the highest prices of each barSeries array that contains the lowest prices of each bar
Indicators Used
Larry William percent range indicatorMoving average indicator
4 Views
0 Downloads
0 Favorites
ninetfmovement
//+------------------------------------------------------------------+
//|                                               NineTFMovement.mq4 |
//|                        Copyright 2014, MetaQuotes Software Corp. |
//|                                              http://www.mql5.com |
//+------------------------------------------------------------------+
#property copyright "Copyright 2014 - By 3RJ ~ Roy Philips-Jacobs ~ 27/11/2014"
#property link      "http://www.mql5.com"
#property link      "http://www.gol2you.com ~ Forex Videos"
#property version   "1.00"
//---
#property indicator_separate_window
//--
extern string NineTFMovement="Copyright © 2014 By 3RJ ~ Roy Philips-Jacobs";
//--
//--- spacing
int scaleX=60,scaleY=40,scaleYt=18,offsetX=250,offsetY=3,fontSize=9; // coordinate
double scaleXp=45;
double scaleYp=29;
//--- arrays for various things
int TF[]={1,5,15,30,60,240,1440,10080,43200};
int xx;
int wp=56;
int ndigs=0;
double er;
double digs;
//--
string periodStr[] = {" M1"," M5","M15","M30"," H1"," H4"," D1"," W1","MN1"}; // Text Timeframes
string labelNameStr[] = {"TIMEFRAMES","PRICEMOVEMENT","HIGHLOWRANGE"}; // Indicator labels
//--
string CRight;
string symbol;
//--
void EventSetTimer();
//---
//+------------------------------------------------------------------+
//| Custom indicator initialization function                         |
//+------------------------------------------------------------------+
int OnInit()
  {
//--- indicator buffers mapping
   symbol=_Symbol;
   CRight="Copyright © 2014 By 3RJ ~ Roy Philips-Jacobs";
   //--
//---- indicators
   //--
   IndicatorShortName("NineTFMovement ("+symbol+")");
   //--
   IndicatorDigits(Digits);
//----
   // Checking the Digits Point
   digs=Digits;
   if (digs==3 || digs==5)
      {er=Point*10; ndigs=1; xx=10;}
   else {er=Point; ndigs=0; xx=1;}
//---
   return(INIT_SUCCEEDED);
  }
//----
//+------------------------------------------------------------------+
//| Custom indicator deinitialization function                       |
//+------------------------------------------------------------------+
//----
void OnDeinit(const int reason)
  {
//----
   EventKillTimer();
   GlobalVariablesDeleteAll();
   //--
   int x=0,y=0,yy=0;
   for(x=0;x<9;x++)
      {ObjectDelete("txPeriod"+x);}
   for(y=0;y<3;y++)
      {ObjectDelete("txLabel"+y);}
   for(y=0;y<4;y++)
      {ObjectDelete("txTime"+y);}
   //y=0;
   ObjectDelete("txCons"+"3");
   ObjectDelete("txCons"+"3"+"a");
   ObjectDelete("txCons"+"3"+"a"+"1");
   for(x=0;x<9;x++)
      {ObjectDelete("barMove"+x);}
   for(x=0;x<9;x++)
      {ObjectDelete("txPips"+x);}
   //--
//----
   return;
  }
//----
//+------------------------------------------------------------------+
//| Custom indicator iteration function                              |
//+------------------------------------------------------------------+
//----
int start()
  {
//----
   if(NineTFMovement!=CRight) return(0);
//--- Set Last error value to Zero
   ResetLastError();
   ChartSetInteger(0,CHART_AUTOSCROLL,0,true);
   WindowRedraw();
   ChartRedraw(0);
   Sleep(500);
   RefreshRates();
   int w,x,y;
   int ocB,ocS;
   int ntf=WindowFirstVisibleBar();
   //---
   RefreshRates();
   string hr=StringSubstr(TimeToStr(TimeCurrent(),TIME_MINUTES),0,2);
   string mi=StringSubstr(TimeToStr(TimeCurrent(),TIME_MINUTES),3,2);
   string sc=StringSubstr(TimeToStr(TimeCurrent(),TIME_SECONDS),6,2);
   string tztxt;
   int tcurr=TimeHour(TimeCurrent()); // Server Time == GMT+2 == (05:00 AM WIB-Jakarta Time)
   if (tcurr==23) {tztxt="NYC/NZD";} // 04 WIB -> (23+5-24= 04:00 AM WIB -> Server Time + 5 Hours = WIB or Jakarta Time)
   if (tcurr==0) {tztxt="NZD";}  // 05 WIB
   if (tcurr==1) {tztxt="NZD/AUS";} // 06 WIB
   if (tcurr>=2 && tcurr<=4) {tztxt="NZD/AUS/TOK";} // 07 -> <= 09 WIB
   if (tcurr>=5 && tcurr<=8) {tztxt="AUS/TOK";} // 10 -> <= 13 WIB
   if (tcurr>=9 && tcurr<=10) {tztxt="AUS/TOK/LON";} // 14 -> <= 15 WIB
   if (tcurr>=11 && tcurr<=13) {tztxt="LON";}  // 16 -> <= 18 WIB
   if (tcurr>=14 && tcurr<=18) {tztxt="LON/NYC";} // 19 -> <= 23 WIB
   if (tcurr>=19 && tcurr<=22) {tztxt="NYC";} // 24(00) -> <= 03 WIB
   //--
   //--- create timeframe text labels
   //--
   for(x=0;x<9;x++)
      {
        ObjectCreate(0,"txPeriod"+x,OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
        ObjectSetText("txPeriod"+x,periodStr[x],fontSize,"Bodoni MT Black",clrGold);
        ObjectSetInteger(0,"txPeriod"+x,OBJPROP_CORNER,0);
        ObjectSetInteger(0,"txPeriod"+x,OBJPROP_XDISTANCE,scaleXp+x*scaleX+offsetX);
        ObjectSetInteger(0,"txPeriod"+x,OBJPROP_YDISTANCE,y*scaleY+offsetY+7);
      }
   //--
   //--- create indicator labels time
   ObjectCreate(0,"txTime"+"0",OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
   ObjectSetText("txTime"+"0",StringConcatenate("H: ",hr),11,"Arial Bold",clrGold);
   ObjectSetInteger(0,"txTime"+"0",OBJPROP_CORNER,0);
   ObjectSetInteger(0,"txTime"+"0",OBJPROP_XDISTANCE,offsetX-230);
   ObjectSetInteger(0,"txTime"+"0",OBJPROP_YDISTANCE,0*scaleYt+offsetY+scaleYp);
   //--
   ObjectCreate(0,"txTime"+"1",OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
   ObjectSetText("txTime"+"1",StringConcatenate("M: ",mi),11,"Arial Bold",clrGold);
   ObjectSetInteger(0,"txTime"+"1",OBJPROP_CORNER,0);
   ObjectSetInteger(0,"txTime"+"1",OBJPROP_XDISTANCE,offsetX-232);
   ObjectSetInteger(0,"txTime"+"1",OBJPROP_YDISTANCE,1*scaleYt+offsetY+scaleYp);
   //--
   ObjectCreate(0,"txTime"+"2",OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
   ObjectSetText("txTime"+"2",StringConcatenate("S: ",sc),11,"Arial Bold",clrGold);
   ObjectSetInteger(0,"txTime"+"2",OBJPROP_CORNER,0);
   ObjectSetInteger(0,"txTime"+"2",OBJPROP_XDISTANCE,offsetX-229);
   ObjectSetInteger(0,"txTime"+"2",OBJPROP_YDISTANCE,2*scaleYt+offsetY+scaleYp);
   //--
   ObjectCreate(0,"txTime"+"3",OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
   ObjectSetText("txTime"+"3",StringConcatenate("EST TZ:  ",tztxt),8,"Arial Bold",clrGold);
   ObjectSetInteger(0,"txTime"+"3",OBJPROP_CORNER,0);
   ObjectSetInteger(0,"txTime"+"3",OBJPROP_XDISTANCE,offsetX-243);
   ObjectSetInteger(0,"txTime"+"3",OBJPROP_YDISTANCE,3*scaleYt+offsetY+35);
   //--
   //--- create indicator arrow trend consideration
   RefreshRates();
   ObjectDelete("txCons"+"3");
   ObjectDelete("txCons"+"3"+"a");
   ObjectDelete("txCons"+"3"+"a"+"1");
   //--
   double Wpr[];
   double MAOnL[];
   double MAOnW[];
   ArrayResize(Wpr,ntf);
   ArrayResize(MAOnL,ntf);
   ArrayResize(MAOnW,ntf);
   ArraySetAsSeries(Wpr,true);
   ArraySetAsSeries(MAOnL,true);
   ArraySetAsSeries(MAOnW,true);
   double doppr=iOpen(symbol,TF[6],0);
   double divcl15=iClose(symbol,TF[2],0);
   for(w=ntf-1;w>=0;w--) {Wpr[w]=iWPR(symbol,TF[2],wp,w);}
   MAOnL[0]=MathAbs(iMAOnArray(Wpr,0,5,0,3,0));
   MAOnL[1]=MathAbs(iMAOnArray(Wpr,0,5,0,3,1));
   MAOnW[0]=MathAbs(iMAOnArray(MAOnL,0,10,0,3,0));
   MAOnW[1]=MathAbs(iMAOnArray(MAOnL,0,10,0,3,1));
   double divdhl1=MAOnL[0]-MAOnW[0];
   double divdhl0=MAOnL[1]-MAOnW[1];
   //--
   for(x=0;x<3;x++)
      {
        if(iClose(symbol,TF[x],0)>iOpen(symbol,TF[x],0))
          {ocB++;}
        if(iClose(symbol,TF[x],0)<iOpen(symbol,TF[x],0))
          {ocS++;}
      }
   //--
   bool BCons=ocB>ocS;
   bool SCons=ocB<ocS;
   if(ocB==3) {bool up15=true;}
   if(ocS==3) {bool dn15=true;}
   //--
   if((divcl15>doppr) && (divdhl0>divdhl1) && (BCons))
      {
        //--
        ObjectDelete("txCons"+x);
        ObjectDelete("txCons"+x+"a");
        ObjectDelete("txCons"+x+"a"+"1");
        //--
        ObjectCreate(0,"txCons"+x,OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
        ObjectSetText("txCons"+x,CharToStr(164),25,"Wingdings",clrLime);
        ObjectSetInteger(0,"txCons"+x,OBJPROP_CORNER,0);
        ObjectSetInteger(0,"txCons"+x,OBJPROP_XDISTANCE,offsetX-172);
        ObjectSetInteger(0,"txCons"+x,OBJPROP_YDISTANCE,1*scaleYt+offsetY+19);
        //--
        ObjectCreate(0,"txCons"+x+"a",OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
        ObjectSetText("txCons"+x+"a",CharToStr(217),18,"Wingdings",clrLime);
        ObjectSetInteger(0,"txCons"+x+"a",OBJPROP_CORNER,0);
        ObjectSetInteger(0,"txCons"+x+"a",OBJPROP_XDISTANCE,offsetX-168);
        ObjectSetInteger(0,"txCons"+x+"a",OBJPROP_YDISTANCE,0*scaleYt+offsetY+24);
        //--
        if((BCons)&&(up15))
          {
            ObjectCreate(0,"txCons"+x+"a"+"1",OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
            ObjectSetText("txCons"+x+"a"+"1","UP",6,"Bodoni MT Black",clrYellow);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_CORNER,0);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_XDISTANCE,offsetX-164);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_YDISTANCE,2*scaleYt+offsetY+33);
          }
        //--
        else
          {
            ObjectCreate(0,"txCons"+x+"a"+"1",OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
            ObjectSetText("txCons"+x+"a"+"1","HOLD",6,"Bodoni MT Black",clrYellow);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_CORNER,0);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_XDISTANCE,offsetX-171);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_YDISTANCE,2*scaleYt+offsetY+33);
          }
      }
   //--
   //--
   if((divcl15<doppr) && (divdhl0>divdhl1) && (BCons))
      {
        //--
        ObjectDelete("txCons"+x);
        ObjectDelete("txCons"+x+"a");
        ObjectDelete("txCons"+x+"a"+"1");
        //--
        ObjectCreate(0,"txCons"+x,OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
        ObjectSetText("txCons"+x,CharToStr(164),25,"Wingdings",clrRed);
        ObjectSetInteger(0,"txCons"+x,OBJPROP_CORNER,0);
        ObjectSetInteger(0,"txCons"+x,OBJPROP_XDISTANCE,offsetX-172);
        ObjectSetInteger(0,"txCons"+x,OBJPROP_YDISTANCE,1*scaleYt+offsetY+19);
        //--
        ObjectCreate(0,"txCons"+x+"a",OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
        ObjectSetText("txCons"+x+"a",CharToStr(217),18,"Wingdings",clrLime);
        ObjectSetInteger(0,"txCons"+x+"a",OBJPROP_CORNER,0);
        ObjectSetInteger(0,"txCons"+x+"a",OBJPROP_XDISTANCE,offsetX-168);
        ObjectSetInteger(0,"txCons"+x+"a",OBJPROP_YDISTANCE,0*scaleYt+offsetY+24);
        //--
        if((BCons)&&(up15))
          {
            ObjectCreate(0,"txCons"+x+"a"+"1",OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
            ObjectSetText("txCons"+x+"a"+"1","UP",6,"Bodoni MT Black",clrYellow);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_CORNER,0);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_XDISTANCE,offsetX-164);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_YDISTANCE,2*scaleYt+offsetY+33);
          }
        //--
        else
          {
            ObjectCreate(0,"txCons"+x+"a"+"1",OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
            ObjectSetText("txCons"+x+"a"+"1","HOLD",6,"Bodoni MT Black",clrYellow);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_CORNER,0);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_XDISTANCE,offsetX-171);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_YDISTANCE,2*scaleYt+offsetY+33);
          }
      }
   //--
   //--
   if((divcl15<doppr) && (divdhl0>divdhl1) && (SCons))
      {
        //--
        ObjectDelete("txCons"+x);
        ObjectDelete("txCons"+x+"a");
        ObjectDelete("txCons"+x+"a"+"1");
        //--
        ObjectCreate(0,"txCons"+x,OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
        ObjectSetText("txCons"+x,CharToStr(164),25,"Wingdings",clrLime);
        ObjectSetInteger(0,"txCons"+x,OBJPROP_CORNER,0);
        ObjectSetInteger(0,"txCons"+x,OBJPROP_XDISTANCE,offsetX-172);
        ObjectSetInteger(0,"txCons"+x,OBJPROP_YDISTANCE,1*scaleYt+offsetY+19);
        //--
        ObjectCreate(0,"txCons"+x+"a",OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
        ObjectSetText("txCons"+x+"a",CharToStr(218),18,"Wingdings",clrRed);
        ObjectSetInteger(0,"txCons"+x+"a",OBJPROP_CORNER,0);
        ObjectSetInteger(0,"txCons"+x+"a",OBJPROP_XDISTANCE,offsetX-168);
        ObjectSetInteger(0,"txCons"+x+"a",OBJPROP_YDISTANCE,2*scaleYt+offsetY+22);
        //--
        if((SCons)&&(dn15))
          {
            ObjectCreate(0,"txCons"+x+"a"+"1",OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
            ObjectSetText("txCons"+x+"a"+"1","DOWN",6,"Bodoni MT Black",clrYellow);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_CORNER,0);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_XDISTANCE,offsetX-171);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_YDISTANCE,0*scaleYt+offsetY+31);
          }
        //--
        else
          {
            ObjectCreate(0,"txCons"+x+"a"+"1",OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
            ObjectSetText("txCons"+x+"a"+"1","HOLD",6,"Bodoni MT Black",clrYellow);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_CORNER,0);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_XDISTANCE,offsetX-171);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_YDISTANCE,0*scaleYt+offsetY+31);
          }
      }
   //--
   //--
   if((divcl15<doppr) && (divdhl0<divdhl1) && (SCons))
      {
        //--
        ObjectDelete("txCons"+x);
        ObjectDelete("txCons"+x+"a");
        ObjectDelete("txCons"+x+"a"+"1");
        //--
        ObjectCreate(0,"txCons"+x,OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
        ObjectSetText("txCons"+x,CharToStr(164),25,"Wingdings",clrRed);
        ObjectSetInteger(0,"txCons"+x,OBJPROP_CORNER,0);
        ObjectSetInteger(0,"txCons"+x,OBJPROP_XDISTANCE,offsetX-172);
        ObjectSetInteger(0,"txCons"+x,OBJPROP_YDISTANCE,1*scaleYt+offsetY+19);
        //--
        ObjectCreate(0,"txCons"+x+"a",OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
        ObjectSetText("txCons"+x+"a",CharToStr(218),18,"Wingdings",clrRed);
        ObjectSetInteger(0,"txCons"+x+"a",OBJPROP_CORNER,0);
        ObjectSetInteger(0,"txCons"+x+"a",OBJPROP_XDISTANCE,offsetX-168);
        ObjectSetInteger(0,"txCons"+x+"a",OBJPROP_YDISTANCE,2*scaleYt+offsetY+22);
        //--
        if((SCons)&&(dn15))
          {
            ObjectCreate(0,"txCons"+x+"a"+"1",OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
            ObjectSetText("txCons"+x+"a"+"1","DOWN",6,"Bodoni MT Black",clrYellow);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_CORNER,0);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_XDISTANCE,offsetX-171);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_YDISTANCE,0*scaleYt+offsetY+31);
          }
        //--
        else
          {
            ObjectCreate(0,"txCons"+x+"a"+"1",OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
            ObjectSetText("txCons"+x+"a"+"1","HOLD",6,"Bodoni MT Black",clrYellow);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_CORNER,0);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_XDISTANCE,offsetX-171);
            ObjectSetInteger(0,"txCons"+x+"a"+"1",OBJPROP_YDISTANCE,0*scaleYt+offsetY+31);
          }
      }
   //--
   //--
   else
      {
        //--
        ObjectCreate(0,"txCons"+x,OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
        ObjectSetText("txCons"+x,CharToStr(164),25,"Wingdings",clrYellow);
        ObjectSetInteger(0,"txCons"+x,OBJPROP_CORNER,0);
        ObjectSetInteger(0,"txCons"+x,OBJPROP_XDISTANCE,offsetX-172);
        ObjectSetInteger(0,"txCons"+x,OBJPROP_YDISTANCE,1*scaleYt+offsetY+19);
        //--
      }
   //--
   //--- create indicator text labels
   //--
   for(y=0;y<3;y++)
      {
        ObjectCreate(0,"txLabel"+y,OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
        ObjectSetText("txLabel"+y,labelNameStr[y],fontSize,"Bodoni MT Black",clrGold);
        ObjectSetInteger(0,"txLabel"+y,OBJPROP_CORNER,0);
        ObjectSetInteger(0,"txLabel"+y,OBJPROP_XDISTANCE,offsetX-100);
        ObjectSetInteger(0,"txLabel"+y,OBJPROP_YDISTANCE,y*scaleY+offsetY+7);
      }
   //--
   //--- create arrow movement for each timeframes
   RefreshRates();
   for(x=0;x<9;x++)
      {ObjectDelete("barMove"+x);}
   //--
   for(x=0;x<9;x++)
      {
        if(iClose(symbol,TF[x],0)>iOpen(symbol,TF[x],0))
          {
            //--
            ObjectCreate(0,"barMove"+x,OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
            ObjectSetString(0,"barMove"+x,OBJPROP_TEXT,CharToStr(217));
            ObjectSetString(0,"barMove"+x,OBJPROP_FONT,"Wingdings");
            ObjectSetInteger(0,"barMove"+x,OBJPROP_FONTSIZE,27);
            ObjectSetInteger(0,"barMove"+x,OBJPROP_COLOR,clrBlue);
            ObjectSetInteger(0,"barMove"+x,OBJPROP_CORNER,0);
            ObjectSetInteger(0,"barMove"+x,OBJPROP_XDISTANCE,scaleXp+x*scaleX+offsetX-3);
            ObjectSetInteger(0,"barMove"+x,OBJPROP_YDISTANCE,1*scaleY+offsetY-3);
          }
        else if(iClose(symbol,TF[x],0)<iOpen(symbol,TF[x],0))
          {
            ObjectCreate(0,"barMove"+x,OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
            ObjectSetString(0,"barMove"+x,OBJPROP_TEXT,CharToStr(218));
            ObjectSetString(0,"barMove"+x,OBJPROP_FONT,"Wingdings");
            ObjectSetInteger(0,"barMove"+x,OBJPROP_FONTSIZE,27);
            ObjectSetInteger(0,"barMove"+x,OBJPROP_COLOR,clrWhite);
            ObjectSetInteger(0,"barMove"+x,OBJPROP_CORNER,0);
            ObjectSetInteger(0,"barMove"+x,OBJPROP_XDISTANCE,scaleXp+x*scaleX+offsetX-3);
            ObjectSetInteger(0,"barMove"+x,OBJPROP_YDISTANCE,1*scaleY+offsetY-3);
          }
        else
          {
            ObjectCreate(0,"barMove"+x,OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
            ObjectSetString(0,"barMove"+x,OBJPROP_TEXT,CharToStr(108));
            ObjectSetString(0,"barMove"+x,OBJPROP_FONT,"Wingdings");
            ObjectSetInteger(0,"barMove"+x,OBJPROP_FONTSIZE,27);
            ObjectSetInteger(0,"barMove"+x,OBJPROP_COLOR,clrYellow);
            ObjectSetInteger(0,"barMove"+x,OBJPROP_CORNER,0);
            ObjectSetInteger(0,"barMove"+x,OBJPROP_XDISTANCE,scaleXp+x*scaleX+offsetX-3);
            ObjectSetInteger(0,"barMove"+x,OBJPROP_YDISTANCE,1*scaleY+offsetY-3);
          }
      }
   //--
   //--- create count of points range
   //--
   RefreshRates();
   for(x=0;x<9;x++)
      {
        double hilo=iHigh(symbol,TF[x],0)-iLow(symbol,TF[x],0);
        string tcent=DoubleToStr(NormalizeDouble((hilo/er)*xx,ndigs),ndigs);
        if(ndigs==1)
          {
            if(StringLen(tcent)<=4) {double ltx=3.5-StringLen(tcent);}
            else if(StringLen(tcent)==5) {ltx=4-StringLen(tcent);}
            else {ltx=4.5-StringLen(tcent);}
          }
        else {ltx=3-StringLen(tcent);}
        if(iClose(symbol,TF[x],0)>iOpen(symbol,TF[x],0))
          {
            ObjectCreate(0,"txPips"+x,OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
            ObjectSetText("txPips"+x,tcent,9,"Bodoni MT Black",clrBlue);
            ObjectSetInteger(0,"txPips"+x,OBJPROP_CORNER,0);
            ObjectSetInteger(0,"txPips"+x,OBJPROP_XDISTANCE,scaleXp+x*scaleX+offsetX+(ltx*4));
            ObjectSetInteger(0,"txPips"+x,OBJPROP_YDISTANCE,2*scaleY+offsetY+7);
          }
        else if(iClose(symbol,TF[x],0)<iOpen(symbol,TF[x],0))
          {
            ObjectCreate(0,"txPips"+x,OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
            ObjectSetText("txPips"+x,tcent,9,"Bodoni MT Black",clrWhite);
            ObjectSetInteger(0,"txPips"+x,OBJPROP_CORNER,0);
            ObjectSetInteger(0,"txPips"+x,OBJPROP_XDISTANCE,scaleXp+x*scaleX+offsetX+(ltx*4));
            ObjectSetInteger(0,"txPips"+x,OBJPROP_YDISTANCE,2*scaleY+offsetY+7);
          }
        else
          {
            ObjectCreate(0,"txPips"+x,OBJ_LABEL,WindowFind("NineTFMovement ("+symbol+")"),0,0);
            ObjectSetText("txPips"+x,tcent,9,"Bodoni MT Black",clrYellow);
            ObjectSetInteger(0,"txPips"+x,OBJPROP_CORNER,0);
            ObjectSetInteger(0,"txPips"+x,OBJPROP_XDISTANCE,scaleXp+x*scaleX+offsetX+(ltx*4));
            ObjectSetInteger(0,"txPips"+x,OBJPROP_YDISTANCE,2*scaleY+offsetY+7);
            //--
          }
      }
//----
   return(0);
//----
  } //-end start()
//+------------------------------------------------------------------+

Similar scripts

TREND_alexcud_v1

This indicator synthesizes multi-timeframe SMA slope analysis with AC oscillation filters to generate a weighted percentage score for directional bias.

TREND_alexcud[1]--2

This indicator synthesizes directional bias from multiple timeframes and Moving Average slopes to generate a weighted consensus score for trend identification.

TREND_alexcud_v2

l_OTCFX_b-clock_modified_V3_2-sw

ATM_OHMLC

This indicator projects significant price levels including daily opens, yesterday's extremes, and calculated support and resistance based on previous session volatility.

_DIGISTOCH-1

This indicator synchronizes and visualizes real-time momentum across six distinct timeframes simultaneously, utilizing dynamic color-coding to signal trend strength and exhaustion zones.

digistoch_versi_had

This indicator synchronizes stochastic momentum across six distinct timeframes to identify concurrent trend alignment and execute multi-layer bullish or bearish entry signals.

DIGISTOCH_001

This indicator displays color-coded trend signals and stochastic values from multiple timeframes, offering a quick overview of potential trading opportunities.

DIGIZEROLAG

This indicator aggregates stochastic momentum across six concurrent timeframes to visualize multi-dimensional trend direction and sentiment through dynamic color-coded signals.

MACD_Colored_v102

This indicator visualizes directional momentum by segmenting MACD values into distinct colored histograms based on price velocity and calculates real-time pip fluctuations through iterative recursive loops.

Pivot_Lines

This indicator synthesizes multi-layered support and resistance levels by integrating standard daily pivots, Camarilla break-out points, and fractional midpoint subdivisions.

Comments
