MTF_MA-4H
Download script
This tool is designed to help traders visualize market trends by calculating Moving Averages based on a higher timeframe than the one currently being viewed on their chart. This allows for a more comprehensive analysis of price momentum without needing to constantly switch between different timeframes manually.
Core Functionality
The primary purpose of this script is to "overlay" data from a larger timeframe (for example, a 4-hour candle period) onto a smaller, more detailed chart (like a 15-minute or 1-hour chart). By doing this, it helps traders identify the broader market direction while they are looking for specific entry points on shorter timeframes.
Key Features and Logic:
- Multi-Timeframe Synchronization: The script automatically calculates which specific bar on the higher timeframe corresponds to the current price point on your lower timeframe. It does this by looking at the exact timestamp of the candles, ensuring that the moving average lines are accurately aligned with the current price movement.
- Dual Moving Averages: The indicator provides two distinct lines on the chart:
- Fast Line: A quicker moving average that reacts more rapidly to recent price changes.
- Slow Line: A larger, smoother moving average that represents the long-term trend.
- Customizable Calculation Methods: Users can choose between different types of moving averages (such as Simple, Exponential, Smoothed, or Linear Weighted) depending on how "reactive" they want the indicator to be.
- Dynamic Visuals: The script identifies the correct price data (such as Close, Open, or Typical prices) and draws two distinct colored lines—Red for the fast average and Medium Sea Green for the slow average—making it easy to spot crossovers or trend shifts visually.
How it Benefits the User
Instead of guessing whether a short-term move is significant, this script provides a "big picture" context. By viewing the higher timeframe's moving averages on your current chart, you can see if the overall market trend is in your favor before making a trade on smaller fluctuations. It effectively bridges the gap between long-term trends and short-term execution.
Indicators Used
Miscellaneous
9
Views
0
Downloads
0
Favorites
MTF_MA-4H
//+------------------------------------------------------------------+
//| Ma_4H_all_timeframe.mq4 |
//| Copyright © 2006, lukas1 |
//| MA from all timeframe |
//| enable for visual mode |
//+------------------------------------------------------------------+
#property copyright "Copyright © february 2007, lukas1"
//---- indicator settings
#property indicator_chart_window
#property indicator_buffers 2
#property indicator_color1 Red
#property indicator_color2 MediumSeaGreen
#property indicator_width1 2
#property indicator_width2 2
//---- indicator parameters
extern int Ma = 8;
extern int SecondMa = 21;
extern int Mode = 1; /* MODE_SMA 0 Ïðîñòîå ñêîëüçÿùåå ñðåäíåå
MODE_EMA 1 Ýêñïîíåíöèàëüíîå ñêîëüçÿùåå ñðåäíåå
MODE_SMMA 2 Ñãëàæåííîå ñêîëüçÿùåå ñðåäíåå
MODE_LWMA 3 Ëèíåéíî-âçâåøåííîå ñêîëüçÿùåå ñðåäíåå
*/
extern int AppliedPrice = 0; // 0=PRICE_CLOSE; 1=PRICE_OPEN; 5=PRICE_TYPICAL
extern int VarPeriod = 240; // old timeframe
//PERIOD_M5 5 5 minutes
//PERIOD_M15 15 15 minutes
//PERIOD_M30 30 30 minutes
//PERIOD_H1 60 1 hour
//PERIOD_H4 240 4 hours
//PERIOD_D1 1440 1 day
//PERIOD_W1 10080 1 week
//PERIOD_MN1 43200 1 month
//---- indicator buffers
extern bool second_Ma = true;
double MaFBuffer[], MaSBuffer[];
int p; // current period
int k; // repetition factor old timeframe
//+------------------------------------------------------------------+
//| Custom indicator initialization function |
//+------------------------------------------------------------------+
int init()
{
//---- drawing settings
SetIndexStyle(0, DRAW_LINE);
SetIndexStyle(1, DRAW_LINE);
SetIndexDrawBegin(0, SecondMa);
SetIndexDrawBegin(1, SecondMa);
IndicatorDigits(Digits + 1);
//---- indicator buffers mapping
SetIndexBuffer(0, MaFBuffer);
SetIndexBuffer(1, MaSBuffer);
//---- name for DataWindow and indicator subwindow label
IndicatorShortName("MA 4H (" + Ma + ", " + SecondMa +
", " + VarPeriod + " min)");
SetIndexLabel(0, "MA 4H fast(" + Ma + ", " + VarPeriod + ")");
SetIndexLabel(1, "MA 4H slow(" + SecondMa + ", " + VarPeriod + ")");
//----
Comment("Ma_4H_all_timeframe(" + Ma + ", " + SecondMa +
", " + VarPeriod + " min)");
//---- initialization done
return(0);
}
//+------------------------------------------------------------------+
//| Custom indicator deinitialization function |
//+------------------------------------------------------------------+
int deinit()
{
Comment("");
//----
return(0);
}
//+-------------------------------------------------------------+
//| Moving Averages (MA) for all timeframe |
//+-------------------------------------------------------------+
int start()
{
int i, limit;
int counted_bars = IndicatorCounted();
//---- check for possible errors
if(counted_bars < 0)
return(-1);
if(counted_bars <= SecondMa)
limit = Bars - SecondMa ;
else
limit = Bars - counted_bars;
p = Period();
k = VarPeriod / p; // repetition factor old timeframe
i = limit - 1;
while(i>=0)
{
// definition of HighBar, having symbol, lowTF,
int bb = HighBar(Symbol(), 0, i, VarPeriod);
// and bar's number in lowTF, calculated highTF;
// (symbol, lowTF, bar's number, highTF)
if(bb == -1)
continue;
MaFBuffer[i] = iMA(Symbol(), VarPeriod, Ma, 0, Mode, AppliedPrice, bb);
if(second_Ma)
MaSBuffer[i] = iMA(Symbol(), VarPeriod, SecondMa, 0, Mode, AppliedPrice, bb);
i--;
}
//---- done
return(0);
}
//+------------------------------------------------------------------+
//| Definition of HighBar, having symbol, lowTF, and bar's number |
//| in lowTF, calculated highTF; |
//| (symbol, lowTF, bar's number, highTF) |
//+------------------------------------------------------------------+
int HighBar(string symbol,int TFLow,int BarLow,int TFHigh)
{
// time's value of bar means in BarLow
datetime BarTimeLow = iTime(symbol, TFLow, BarLow);
int error = GetLastError();
if(error == 4066)
return (-1);
// displacement of bar means in BarTimeLow
int res = iBarShift(symbol, TFHigh, BarTimeLow, false);
error = GetLastError();
if(error == 4066)
return (-1);
return (res);
}
//+------------------------------------------------------------------+
