MTF_Damiani_Volt32_SideBar
Download script
This script functions as a sophisticated visual filter designed to help traders identify favorable market conditions based on volatility and momentum. Rather than predicting specific price directions, its primary goal is to distinguish between "tradeable" environments and "no-trade" zones by analyzing data from different timeframes simultaneously.
Core Operational Logic
The tool operates by comparing real-time market activity against a calculated Volatility Threshold. It essentially measures the "intensity" of the market and determines if that intensity is high enough or structured enough to warrant an entry.
How the visual indicators work: The script identifies two distinct states on your chart:
- Trade Zone (Green Indicator): This appears when the current market volatility exceeds a specific predefined level. When this signal is active, it suggests that the market has sufficient momentum or "energy" to support trading activity.
- No-Trade Zone (Gray/Blue Indicator): This appears when the market volatility falls below the required threshold. It acts as a warning system, indicating that the market might be too stagnant, choppy, or lacking the necessary strength to produce reliable results.
Multi-Timeframe Analysis
One of the key professional features of this logic is its ability to "look ahead" into larger timeframes. Instead of only showing you what is happening on your current small chart (like a 5-minute chart), it can pull data from much larger periods (such as Hourly or Daily charts).
This allows a trader to see if the broader market trend supports their immediate actions. For example, even if a small timeframe looks like a good trade, this script can alert you if the larger timeframe's volatility conditions are unfavorable.
Smart Buffer Synchronization
To ensure a smooth visual experience on your screen, the script includes a synchronization mechanism. Because it pulls data from different timeframes, there is often a "gap" in how data points align. The logic automatically fills these gaps, ensuring that the signals remain consistent and continuous across your chart, rather than appearing as disconnected dots.
Summary for the User
Think of this tool as a Market Gatekeeper. Before you take a trade, you check the sidebar:
- If the signal indicates a Trade Zone, the "gate" is open—the market has the volatility required for your strategy.
- If the signal indicates a No-Trade Zone, the "gate" is closed—the market is currently too weak or inconsistent to provide a reliable setup, and it is safer to stay out of the market.
//+------------------------------------------------------------------------+
//| MTF_ DamVolt32Sidebar Damiani_volatmeter.mq4 ik|
//| fxtsd.com Copyright © 2006, Luis Guilherme Damiani |
//| works with Damiani_volatmeter v3.2 http://www.damianifx.com.br |
//+------------------------------------------------------------------------+
//When the green line is BELOW the gray line - DON'T trade
#property copyright "Copyright © 2006, Luis Guilherme Damiani"
#property link "http://www.damianifx.com.br"
//---- indicator settings
#property indicator_separate_window
#property indicator_buffers 2
#property indicator_color1 ForestGreen
#property indicator_color2 DarkSlateBlue
#property indicator_maximum 77
#property indicator_minimum 1
extern int TimeFrame=0;
extern int DVsbLevel = 5;
extern int Vis_atr=13;
extern int Vis_std=20;
extern int Sed_atr=40;
extern int Sed_std=100;
extern double Threshold_level=1.4;
extern bool lag_supressor=true;
extern int max_bars=2000;
//---- indicator buffers
double ExtMapBuffer1[];
double ExtMapBuffer2[];
double threshold[];
double vol_t[];
//+------------------------------------------------------------------+
//| Custom indicator initialization function |
//+------------------------------------------------------------------+
int init()
{
//---- drawing settings
SetIndexStyle(0,DRAW_ARROW);
SetIndexArrow(0,59);//110;167;159;250;249;59
SetIndexBuffer(0,ExtMapBuffer1);
SetIndexLabel(0,"DV_TradeZone TF["+TimeFrame+"]");
SetIndexStyle(1,DRAW_ARROW);
SetIndexArrow(1,59);
SetIndexBuffer(1,ExtMapBuffer2);
SetIndexLabel(1,"DV_DO NOT Trade TF["+TimeFrame+"]");
IndicatorDigits(0);
//---- name for DataWindow and indicator subwindow label
switch(TimeFrame)
{
case 1 : string TimeFrameStr="Period_M1"; break;
case 5 : TimeFrameStr="Period_M5"; break;
case 15 : TimeFrameStr="Period_M15"; break;
case 30 : TimeFrameStr="Period_M30"; break;
case 60 : TimeFrameStr="Period_H1"; break;
case 240 : TimeFrameStr="Period_H4"; break;
case 1440 : TimeFrameStr="Period_D1"; break;
case 10080 : TimeFrameStr="Period_W1"; break;
case 43200 : TimeFrameStr="Period_MN1"; break;
default : TimeFrameStr="Current Timeframe";
}
IndicatorShortName("DV_Sb["+TimeFrameStr+"]");
//---- initialization done
return(0);
}
//+------------------------------------------------------------------+
//| Calculations |
//+------------------------------------------------------------------+
int start()
{
datetime TimeArray[];
int i,shift,limit,y=0,counted_bars=IndicatorCounted();
// Plot defined timeframe on to current timeframe
ArrayCopySeries(TimeArray,MODE_TIME,Symbol(),TimeFrame);
limit=Bars-counted_bars+TimeFrame/Period();
for(i=0,y=0;i<limit;i++)
{
if (Time[i]<TimeArray[y]) y++;
//---- main loop
ExtMapBuffer1[i] = EMPTY_VALUE; ExtMapBuffer2[i] = EMPTY_VALUE;
double threshold = iCustom(NULL, 0,"Damiani_volatmeter v3.2",Vis_atr,Vis_std,Sed_atr,Sed_std,Threshold_level, true, max_bars, 0,y );
double vol_t = iCustom(NULL, 0,"Damiani_volatmeter v3.2",Vis_atr,Vis_std,Sed_atr,Sed_std,Threshold_level, true, max_bars, 2,y );
if (vol_t > threshold )ExtMapBuffer1[i]=DVsbLevel;
if (vol_t < threshold)ExtMapBuffer2[i]=DVsbLevel;
}
// Refresh buffers
//++++++++++++++++++++++++++++++++++++++ upgrade by Raff
if (TimeFrame < Period()) TimeFrame = Period();
if (TimeFrame>Period()) {
int PerINT=TimeFrame/Period()+1;
datetime TimeArr[]; ArrayResize(TimeArr,PerINT);
ArrayCopySeries(TimeArr,MODE_TIME,Symbol(),Period());
for(i=0;i<PerINT+1;i++) {if (TimeArr[i]>=TimeArray[0]) {
//----
/********************************************************
Refresh buffers: buffer[i] = buffer[0];
********************************************************/
ExtMapBuffer1[i]=ExtMapBuffer1[0];
ExtMapBuffer2[i]=ExtMapBuffer2[0];
//----
} } }
//+++++++++++++++++++++++++++++++++++++++++++++++ Raff
//-----
return(0);
}
//+------------------------------------------------------------------+
