MLP_cannonball5
Download scriptThis script implements a mathematical model designed to solve a specific physics-based prediction problem known as the "cannonball problem." In simple terms, the software aims to predict exactly where a projectile (like a bullet) will land in a 2D space based on its starting conditions.
Core Objective
The goal of the script is to determine the final horizontal (X) and vertical (Y) positions of a bullet at a specific point in time. To do this, it takes two primary pieces of information as input:
- The initial speed of the projectile.
- The angle at which the projectile is launched.
How the Logic Works
1. Data Simulation (The "Experience") Because the script needs to learn how physics works, it first generates a large synthetic dataset. It simulates hundreds of different scenarios by randomly assigning various speeds and launch angles. For each scenario, it uses standard physics equations to calculate the correct landing coordinates. This creates a "training manual" where the software can see examples of "Input (Speed/Angle) $\rightarrow$ Result (Position)."
2. The Neural Network Structure (The "Brain") The script utilizes a Multi-Layer Perceptron (MLP), which is a foundational type of Artificial Neural Network. It mimics the way biological neurons interact by processing information through different layers:
- Input Layer: Receives the raw data (the speed and angle variables).
- Hidden Layer: Processes the inputs using "weights" (importance values) and a mathematical activation function. This layer allows the system to identify complex relationships between the variables that aren't immediately obvious.
- Output Layer: Produces the final estimate of the X and Y coordinates.
3. The Learning Process (Training) The script doesn't "know" the answer at the start; it learns through a process called Stochastic Gradient Descent. Here is the step-by-step flow:
- Forward Pass: The script takes an input, passes it through the network layers, and makes a guess at the landing position.
- Error Calculation: It compares its guess against the actual "correct" answer from the simulation data to calculate the error (Mean Squared Error).
- Backward Pass (Backpropagation): This is the "learning" step. The script works backward from the error to see which weights in the network caused the mistake. It then slightly adjusts those weights to reduce the error the next time.
- Momentum: It includes a "momentum" feature, which helps the learning process stay smooth and prevents it from making erratic adjustments during training.
4. Testing and Validation After training on one set of data, the script is tested against a completely separate set of data that it has never seen before. This ensures that the script hasn't just "memorized" the answers but has actually learned the underlying logic of projectile motion. The results are recorded in CSV files, allowing you to track how accurately the "brain" improves over several hundred iterations.
//+------------------------------------------------------------------+
//| MLP_cannonball.mq4 |
//| Copyright © 2008, MetaQuotes Software Corp. |
//| http://www.metaquotes.net |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2008, MetaQuotes Software Corp."
#property link "http://www.metaquotes.net"
/* This program implements a simple Multi Layer Perceptron to solve the canonball problem (regression)
Adapted by Sebastien Marcel (2003-2004) from D. Collobert
The goal is to estimate the position X of a bullet at time t (fixed) given the initial speed (v) and angle (a)
y
/ \
|
|
|
| . X
| .
| .
| .
| .
| .
| .
| .
| .
| .
|. (v,a)
--------------------------> x
*/
#define PI 3.14159265358979323846
#define RAND_MAX 32767.0
//
// Datasets
#define N_PATTERNS_TRAIN 500
#define N_PATTERNS_TEST 500
#define N_PATTERNS_TRAIN_TEST 1000 //N_PATTERNS_TRAIN + N_PATTERNS_TEST
// w1[N_HU1][IN1]=>w1[4][3]
// H In
// | |
// w1[0][0] w1[0][1] w1[0][2]
// w1[1][0] w1[1][1] w1[1][2]
// w1[2][0] w1[2][1] w1[2][2]
// w1[3][0] w1[3][1] w1[3][2]
// forward train:
// aHidden[0] = xBias;
// aHidden[1] = xBias*w1[1][0] + (In0)*w1[1][1] + (In1)*w1[1][2];
// aHidden[2] = xBias*w1[2][0] + (In0)*w1[2][1] + (In1)*w1[2][2];
// aHidden[3] = xBias*w1[3][0] + (In0)*w1[3][1] + (In1)*w1[3][2];
// yHidden[0] = xBias;
// yHidden[1] = f(aHidden[1]);
// yHidden[2] = f(aHidden[2]);
// yHidden[3] = f(aHidden[3]);
//
// w2[OUT][N_HU1]=>w2[2][4]
//
// w2[0][0] w2[0][1] w2[0][2] w2[0][3]
// w2[1][0] w2[1][1] w2[1][2] w2[1][3]
// | |
// Out H
// forward train:
// aOutput[0] = 0.0;
// aOutput[1] = 0.0;
// aOutput[0] = aOutput[0] + yHidden[0]*w2[0][0];
// aOutput[1] = aOutput[1] + yHidden[0]*w2[1][0];
// aOutput[0] = aOutput[0] + yHidden[1]*w2[0][1];
// aOutput[1] = aOutput[1] + yHidden[1]*w2[1][1];
// aOutput[0] = aOutput[0] + yHidden[2]*w2[0][2];
// aOutput[1] = aOutput[1] + yHidden[2]*w2[1][2];
// aOutput[0] = aOutput[0] + yHidden[3]*w2[0][3];
// aOutput[1] = aOutput[1] + yHidden[3]*w2[1][3];
//
// out0 = f(aOutput[0]);
// out1 = f(aOutput[1]);
#define IN 6
#define IN1 7 //IN+1
#define OUT 2
#define N_HU 9
#define N_HU1 10 //N_HU + 1
//*****************************
// Inputs
//
double DataIn0[N_PATTERNS_TRAIN_TEST]; // speed of bullet
double DataIn1[N_PATTERNS_TRAIN_TEST]; // angle of bullet
double DataIn2[N_PATTERNS_TRAIN_TEST]; // speed of bullet
double DataIn3[N_PATTERNS_TRAIN_TEST]; // angle of bullet
double DataIn4[N_PATTERNS_TRAIN_TEST]; // speed of bullet
double DataIn5[N_PATTERNS_TRAIN_TEST]; // angle of bullet
// X[N_PATTERNS_TRAIN + N_PATTERNS_TEST];
//*****************************
// Targets
//
double DataOut0[N_PATTERNS_TRAIN_TEST]; // x position at time t
double DataOut1[N_PATTERNS_TRAIN_TEST]; // y position at time t
// Y[N_PATTERNS_TRAIN + N_PATTERNS_TEST];
//*****************************
// to create the data
//
double vmax;
double gravity;
//*****************************
// to train the MLP
//
double lambda = 0.01; // learning rate
double mu = 0.6; // inertia momentum rate
double mse_min = 0.001; // minimum Mean Squared Error
int max_iterations = 500; // maximum number of iterations
//*****************************
// MLP data
// weights between hidden neurons and inputs
double w1[N_HU1][IN1];
double w1old[N_HU1][IN1];
// weights between outputs and hidden neurons
double w2[OUT][N_HU1];
double w2old[OUT][N_HU1];
// values of integration function
double aHidden[N_HU1];
double aOutput[OUT];
// values of transfert function
double yHidden[N_HU1];
// constant value of bias
double xBias = 1.0;
int init()
{
vmax = 1.0/10;
gravity = 1.0/200;
return(0);
}
//+------------------------------------------------------------------+
//| script program start function |
//+------------------------------------------------------------------+
int start()
{
//----
initrand();
main();
//----
return(0);
}
//+------------------------------------------------------------------+
//*****************************
// Sigmoid transfer function
//
double f(double x)
{
return (1.0 /(1.0 + MathExp(-x)));
}
//*****************************
// Derivative of Sigmoid
//
double f_prime(double x)
{
double z = MathExp(-x);
double one_plus_z = 1.0 + z;
return (z / (one_plus_z * one_plus_z));
}
//*****************************
// Compute the x position of bullet at time t
//
double xpos(double t, double v, double teta)
{
return( v * t * MathCos(teta*PI/180.0));
}
//*****************************
// Compute the y position of bullet at time t
//
double ypos(double t, double v, double teta)
{
return( -0.5 * gravity * t * t + v * t * MathSin(teta*PI/180.0));
}
//*****************************
// Compute the MSE
//
double MSE(
double a0,
double a1,
double b0,
double b1
)
{
return (0.5*((a0 - b0)*(a0 - b0) + (a1 - b1)*(a1 - b1)));
}
//*****************************
// Create the MLP
//
void createMLP()
{
int i, j;
// weights between hidden neurons and inputs
for (i = 0; i<IN1; i++)
{
for (j = 0; j< N_HU1; j++)
{
w1[j][i] = Random(-1.0, 1.0);
w1old[j][i] = w1[j][i];
}
}
// weights between outputs and hidden neurons
for (i = 0; i<OUT; i++)
{
for (j = 0; j< N_HU1; j++)
{
w2[i][j] = Random(-1.0, 1.0);
w2old[i][j] = w2[i][j];
}
}
}
//*****************************
// Create the datasets
//
void createDatasets()
{
int i;
i = 0;
while (i < (N_PATTERNS_TRAIN + N_PATTERNS_TEST))
{
DataIn0[i] = (Random(0.0, vmax)) / vmax;
DataIn1[i] = (Random(0.0, 90.0)) / 90.0;
DataIn2[i] = (Random(0.0, vmax)) / vmax;
DataIn3[i] = (Random(0.0, 90.0)) / 90.0;
DataIn4[i] = (Random(0.0, vmax)) / vmax;
DataIn5[i] = (Random(0.0, 90.0)) / 90.0;
DataOut0[i] = xpos(10, DataIn0[i] * vmax, (DataIn1[i])*90.0);
DataOut1[i] = ypos(10, DataIn0[i] * vmax, (DataIn1[i])*90.0);
if (DataOut1[i] > 0.0) i = i + 1;
}
}
//*****************************
// Forward the input in the MLP
//
void forward(
double In0,
double In1,
double In2,
double In3,
double In4,
double In5,
double &out0,
double &out1
)
{
int i;
aHidden[0] = xBias;
yHidden[0] = xBias;
for (i = 1; i <= N_HU; i++)
{
aHidden[i] = xBias*w1[i][0] + (In0)*w1[i][1] + (In1)*w1[i][2] +
(In2)*w1[i][3] + (In3)*w1[i][4] +
(In4)*w1[i][5] + (In5)*w1[i][6];
yHidden[i] = f(aHidden[i]);
}
aOutput[0] = 0.0;
aOutput[1] = 0.0;
for (i = 0; i <= N_HU; i++)
{
aOutput[0] = aOutput[0] + yHidden[i]*w2[0][i];
aOutput[1] = aOutput[1] + yHidden[i]*w2[1][i];
}
out0 = f(aOutput[0]);
out1 = f(aOutput[1]);
}
//*****************************
// Backward (back-propagate the gradient of error)
//
void backward(
double Yestimate0,
double Yestimate1,
double Outwant0,
double Outwant1,
double In0,
double In1,
double In2,
double In3,
double In4,
double In5,
double lambda,
double mu
)
{
double wnew, Goutput[OUT], Ghidden[N_HU1];
int i,j;
//
Goutput[0] = (Yestimate0 - Outwant0) * f_prime(aOutput[0]);
Goutput[1] = (Yestimate1 - Outwant1) * f_prime(aOutput[1]);
//
for (i = 0; i<=N_HU; i++)
Ghidden[i] = (Goutput[0]*w2[0][i] + Goutput[1]*w2[1][i])*f_prime(aHidden[i]);
//
for (j = 0; j<OUT;j++)
{
for (i = 0; i<=N_HU; i++)
{
wnew = w2[j][i] - lambda * yHidden[i] * Goutput[j] + mu * (w2[j][i] - w2old[j][i]);
w2old[j][i] = w2[j][i];
w2[j][i] = wnew;
}
}
//
for (i = 0; i<=N_HU; i++)
{
wnew = w1[i][0] - lambda * xBias * Ghidden[i] + mu * (w1[i][0] - w1old[i][0]);
w1old[i][0] = w1[i][0];
w1[i][0] = wnew;
wnew = w1[i][1] - lambda * In0 * Ghidden[i] + mu * (w1[i][1] - w1old[i][1]);
w1old[i][1] = w1[i][1];
w1[i][1] = wnew;
wnew = w1[i][2] - lambda * In1 * Ghidden[i] + mu * (w1[i][2] - w1old[i][2]);
w1old[i][2] = w1[i][2];
w1[i][2] = wnew;
wnew = w1[i][3] - lambda * In2 * Ghidden[i] + mu * (w1[i][3] - w1old[i][3]);
w1old[i][3] = w1[i][3];
w1[i][3] = wnew;
wnew = w1[i][4] - lambda * In3 * Ghidden[i] + mu * (w1[i][4] - w1old[i][4]);
w1old[i][4] = w1[i][4];
w1[i][4] = wnew;
wnew = w1[i][5] - lambda * In4 * Ghidden[i] + mu * (w1[i][5] - w1old[i][5]);
w1old[i][5] = w1[i][5];
w1[i][5] = wnew;
wnew = w1[i][6] - lambda * In5 * Ghidden[i] + mu * (w1[i][6] - w1old[i][6]);
w1old[i][6] = w1[i][6];
w1[i][6] = wnew;
}
}
//*****************************
// Stochastic gradient training
//
double train(int P)
{
double Yestimate0;
double Yestimate1;
double mse_;
double mse_total;
mse_total = 0.0;
// For each train patterns
for(int p = 0 ; p < P ; p++)
{
// Forward current train pattern into the MLP
forward(
//X[p],
DataIn0[p],
DataIn1[p],
DataIn2[p],
DataIn3[p],
DataIn4[p],
DataIn5[p],
//&Yestimate
Yestimate0,
Yestimate1
);
// Computes the MSE
mse_ = MSE(
//Y[p],
DataOut0[p],
DataOut1[p],
//Yestimate
Yestimate0,
Yestimate1
);
// Accumulate the MSE
mse_total = mse_total + mse_;
// Backward MSE gradient
backward(
//Yestimate,
Yestimate0,
Yestimate1,
//Y[p],
DataOut0[p], //Outwant
DataOut1[p], //Outwant
//X[p],
DataIn0[p],
DataIn1[p],
DataIn2[p],
DataIn3[p],
DataIn4[p],
DataIn5[p],
lambda,
mu
);
}
// Return normalized train MSE
double P1=P;
return (mse_total /P1);
}
//
int main()
{
double mse_train;
double mse_test;
double mse_;
double Yestimate0;
double Yestimate1;
//*****************************
createMLP();
//*****************************
createDatasets();
//*****************************
//for (int i = 0; i< N_PATTERNS_TRAIN; i++) printf(" TRN: x=[%f %f] y=[%f %f]\n", X[i].v, X[i].a, Y[i].x, Y[i].y);
//for (int i = N_PATTERNS_TRAIN; i<(N_PATTERNS_TRAIN + N_PATTERNS_TEST); i++) printf(" TST: x=[%f %f] y=[%f %f]\n", X[i].v, X[i].a, Y[i].x, Y[i].y);
Print("Stochastic gradient training:");
//
int pf_train = FileOpen("mse_train_mt4_in6.txt",FILE_CSV|FILE_WRITE,' ');//FileOpen("mse_train.txt", "w");
int pf_test = FileOpen("mse_test_mt4_in6.txt",FILE_CSV|FILE_WRITE,' ');//FileOpen("mse_test.txt", "w");
int iter;
for(iter = 1 ; iter <= max_iterations ; iter++)
{
//*****************************
// train
//*****************************
mse_train = train(N_PATTERNS_TRAIN);
FileWrite(pf_train,mse_train);
//*****************************
// test
//*****************************
mse_test = 0.0;
// For each test pattern
// (N_PATTERNS_TRAIN + N_PATTERNS_TEST) N_PATTERNS_TRAIN 0
// +-----------------------------------------------------------+------------------------------------------+
//
for(int i = N_PATTERNS_TRAIN ; i < (N_PATTERNS_TRAIN + N_PATTERNS_TEST) ; i++)
{
Yestimate0 = 0.0;
Yestimate1 = 0.0;
// forward current pattern into the MLP
//forward(X[i], &Yestimate);
forward(
//X[p],
DataIn0[i],
DataIn1[i],
DataIn2[i],
DataIn3[i],
DataIn4[i],
DataIn5[i],
//&Yestimate
Yestimate0,
Yestimate1
);
// computes MSE
//mse_ = MSE(Y[i], Yestimate);
mse_ = MSE(
//Y[p],
DataOut0[i],
DataOut1[i],
//Yestimate
Yestimate0,
Yestimate1
);
// accumulate MSE
mse_test += mse_;
}
// Normalize the MSE
mse_test /= N_PATTERNS_TEST;
FileWrite(pf_test,mse_test);
Print("->",iter);
//fflush(stdout);
if (mse_train < mse_min) break;
}
//Print("\n");
//
FileClose(pf_test);
FileClose(pf_train);
//*****************************
// Print info about training
//
Print("Number of iterations = ", iter);
Print("Final MSE train = ", mse_train);
Print("Final MSE test = ", mse_test);
Print("End of program.");
return (0);
}
//use this first function to seed the random number generator,
//call this before any of the other functions
void initrand()
{
//srand((unsigned)(time(0)));
MathSrand(TimeLocal());
}
//generates a psuedo-random double between 0.0 and 0.999...
double randdouble0()
{
return (MathRand()/((RAND_MAX)+1));
}
//generates a psuedo-random double between min and max
double randdouble2(double min, double max)
{
if (min>max)
{
return (randdouble0()*(min-max)+max);
}
else
{
return (randdouble0()*(max-min)+min);
}
}
// Random generator
double Random(double inf, double sup)
{
return(randdouble2(inf,sup));
}
Comments
