MatrixInd_2

This script functions as a sophisticated data processing tool designed to organize and "level the playing field" for different financial instruments. Instead of simply looking at price movements in isolation, it treats multiple currency pairs as a collective dataset, ensuring that their different price scales do not distort the analysis.

Core Functionality: Multi-Instrument Analysis

The script captures historical price data from three specific sources simultaneously:

  1. The current symbol you are trading.
  2. The EUR/GBP currency pair.
  3. The USD/JPY currency pair.

By gathering this data into a shared matrix, the tool allows for a comparative view of how different markets behave relative to one another over a set period of time.

Data Normalization Logic

The primary "intelligence" of this script lies in its normalization engine. Because different assets have different price values (for example, 1.20 vs 150.00), they cannot be compared directly without adjustment. The script provides four distinct methods to standardize this data so that fluctuations are weighted equally:

  • Standard Deviation Method: This calculates the average price and how much the price typically deviates from that average. It then adjusts the data so that each instrument's movement is measured by its own "volatility footprint."
  • Range and Midrange Method: This identifies the highest and lowest prices reached during the sample period. It then centers the data around the midpoint and scales it based on the total distance between the high and the low.

The "Train" vs. "Test" Framework

The script distinguishes between two types of data processing to help maintain consistency:

  • Sample/Train Data: This acts as the reference point. The script calculates the mathematical "rules" (like averages or ranges) based on this historical window.
  • Test Data: This is the active data being processed. Depending on your settings, the script can either calculate new rules for the current data or—more importantly—apply the rules learned from the "Train" data to the "Test" data.

User Experience and Behavior

From a visual standpoint, the script updates its calculations only when a new candle forms on a 1-minute timeframe. This prevents the platform from over-calculating and ensures smooth performance. The final result is presented as three distinct lines in a separate window, providing a normalized view of the selected markets that makes it easier to identify patterns across different assets regardless of their individual price magnitudes.

Price Data Components
Series array that contains close prices for each bar
Miscellaneous
Implements a curve of type %1
2 Views
0 Downloads
0 Favorites
MatrixInd_2
//+------------------------------------------------------------------+
//|                                                  MatrixInd_1.mq4 |
//|                      Copyright © 2008, MetaQuotes Software Corp. |
//|                                        http://www.metaquotes.net |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2008, MetaQuotes Software Corp."
#property link      "http://www.metaquotes.net"

#property indicator_separate_window
//#property indicator_chart_window
#property indicator_buffers 3
#property indicator_color1 Yellow
#property indicator_color2 Red
#property indicator_color3 LightSeaGreen
#property indicator_level1 0.0

#define LIN1 100 //sample lines
#define LIN2 100 //test lines
#define COL 3  //attributes


extern bool normalize_bufers = true;
extern   int normalize_type=1;


double M_test_attr[LIN2][COL];
double M_sample_attr[LIN1][COL];

double Buffer1[];
double Buffer2[];
double Buffer3[];


//+------------------------------------------------------------------+
//| Custom indicator initialization function                         |
//+------------------------------------------------------------------+
int init()
  {
//---- indicators
   SetIndexStyle(0,DRAW_LINE);
   SetIndexBuffer(0,Buffer1);
   SetIndexStyle(1,DRAW_LINE);
   SetIndexBuffer(1,Buffer2);
   SetIndexStyle(2,DRAW_LINE);
   SetIndexBuffer(2,Buffer3);
//----
   return(0);
  }
//+------------------------------------------------------------------+
//| Custom indicator deinitialization function                       |
//+------------------------------------------------------------------+
int deinit()
  {
//----

//----
   return(0);
  }
//+------------------------------------------------------------------+
//| Custom indicator iteration function                              |
//+------------------------------------------------------------------+
int start()
  {
   int    counted_bars=IndicatorCounted();
//----
if(isNewBar1(PERIOD_M1))
{
  main();
}
//----
   return(0);
  }
//+------------------------------------------------------------------+
//+------------------------------------------------------------------+
//| Custom indicator iteration function                              |
//+------------------------------------------------------------------+
int myBars1;

bool isNewBar1(int tf1)
  {
//----
   bool res=false;
   if (myBars1!=iBars(Symbol(),tf1))
   {
      res=true;
      myBars1=iBars(Symbol(),tf1);
   }

//----
   return(res);
  }

void main()
{
  int i,j;

  for(i=0;i<LIN1;i++)
  {
      M_sample_attr[i][0]=iClose(Symbol(),0,i);
      M_sample_attr[i][1]=iClose("EURGBP",0,i);
      M_sample_attr[i][2]=iClose("USDJPY",0,i);
  }
  for(i=0;i<LIN2;i++)
  {
      M_test_attr[i][0]=iClose(Symbol(),0,i);
      M_test_attr[i][1]=iClose("EURGBP",0,i);
      M_test_attr[i][2]=iClose("USDJPY",0,i);
  }


  if(normalize_bufers)
    svm_normalize_test(M_sample_attr,M_test_attr,normalize_type);
  for(i=0; i < LIN2;i++)
  {
     Buffer1[i]=M_test_attr[i][0];
     Buffer2[i]=M_test_attr[i][1];
     Buffer3[i]=M_test_attr[i][2];
  }
}


/////////////////////////////////////////////////////////////////
#define DBL_MAX 99999999999999999999
//+------------------------------------------------------------------+
//|
//+------------------------------------------------------------------+
double MAX(double x, double y)
{
  if(x>y)
    return(x);
  else
    return(y);
}

//+------------------------------------------------------------------+
//|
//+------------------------------------------------------------------+
double MIN(double x, double y)
{
  if(x<y)
    return(x);
  else
    return(y);
}

//+------------------------------------------------------------------+
//| Normalize matrix 'fmx' using precomputed 'xmean', 'std'. The
//| normalization is: for each column, subtract 'xmean' and, if the
//| column 'std' is non-zero, divide by 'std'.
//| d=nr_of_attrib
//| nv=nr_of_sample_lines
//| double **x --> double **svm_samples_attrib_scaled_dyn_
//| double *xmean = fmx_mean(x2, nv, d);
//| double *std = fmx_std(x2, nv, d);
//| fmx_prenorm(x, nv, d, xmean, std);
//|       X  - mean
//|        i
//|   S = ---------
//|    i     std
//+------------------------------------------------------------------+
void fmx_prenorm(
                 double &fmx[][],
                 double xmean[], //  double *xmean = fmx_mean(x2, nv, d);
                 double std[]   //  double *std = fmx_std(x2, nv, d);
                 )
{
  int    i;
  int    j;
  double  f;
  int rows = ArrayRange(fmx,0);
  int columns = ArrayRange(fmx,1);

    for (i = 0; i < columns; i++)
      for (j = 0; j < rows; j++)
	  {
	    f = fmx[j][i];
	      if (std[i] != 0)
		     fmx[j][i] = (f-xmean[i])/std[i];
	      else
		     fmx[j][i] = f-xmean[i];
	 }



}

//+------------------------------------------------------------------+
//|              max X  +  min X
//|               i   i     i   i
//|   midrange = ----------------
//|                     2
//|   range = max X  -  min X
//|            i   i     i   i
//|
//|       X  - midrange
//|        i
//|   S = -------------
//|    i     range / 2
//+------------------------------------------------------------------+
void fmx_prenorm_range(
                       double &fmx[][],
                       double xrange[],
                       double xmidrange[]
                       )
{
  int    i;
  int    j;
  double  f;
  int rows = ArrayRange(fmx,0);
  int columns = ArrayRange(fmx,1);

  for (i = 0; i < columns; i++)
    for (j = 0; j < rows; j++)
    {
	    f = fmx[j][i];
	      if (xrange[i] != 0)
		    fmx[j][i] = (f-xmidrange[i])/(xrange[i]/2);
	      else
		    fmx[j][i] = f-xmidrange[i];

	  }
}

//+------------------------------------------------------------------+
//|
//+------------------------------------------------------------------+
void fmx_midrange(double  &xmidrange[],double fmx[][])
{
  int    i;
  int    j;
  double smax = -DBL_MAX;
  double smin = DBL_MAX;
  int rows = ArrayRange(fmx,0);
  int columns = ArrayRange(fmx,1);
  ArrayResize(xmidrange,columns);
  for (i = 0; i < columns; i++)
  {
     smax = -DBL_MAX;
     smin = DBL_MAX;
     for (j = 0; j < rows; j++)
	  {
	      smax=MAX(fmx[j][i],smax);
         smin=MIN(fmx[j][i],smin);
     }
	  xmidrange[i] = (smax+smin)/2;
  }
}
//+------------------------------------------------------------------+
//|
//+------------------------------------------------------------------+
void fmx_range(double  &xrange[], double fmx[][])
{
  int    i;
  int    j;
  double smax = -DBL_MAX;
  double smin = DBL_MAX;
  int rows = ArrayRange(fmx,0);
  int columns = ArrayRange(fmx,1);
  ArrayResize(xrange,columns);
  for (i = 0; i < columns; i++)
  {
     smax = -DBL_MAX;
     smin = DBL_MAX;
     for (j = 0; j < rows; j++)
	  {
	     smax=MAX(fmx[j][i],smax);
        smin=MIN(fmx[j][i],smin);
     }
	  xrange[i] = smax-smin;
   }

}


//+------------------------------------------------------------------+
//|
//+------------------------------------------------------------------+
void fmx_max(double &xrange[],double fmx[][])
{
  int    i;
  int    j;
  double smax = -DBL_MAX;
  int rows = ArrayRange(fmx,0);
  int columns = ArrayRange(fmx,1);

  ArrayResize(xrange,columns);
  for (i = 0; i < columns; i++)
  {
    smax = -DBL_MAX;
	 for (j = 0; j < rows; j++)
	 {
	   smax=MAX(fmx[j][i],smax);
    }
    xrange[i] = smax;
  }
}

//+------------------------------------------------------------------+
//|
//+------------------------------------------------------------------+
void fmx_min(double &xrange[],double fmx[][])
{
  int    i;
  int    j;
  double smin = DBL_MAX;
  int rows = ArrayRange(fmx,0);
  int columns = ArrayRange(fmx,1);

  ArrayResize(xrange,columns);
  for (i = 0; i < columns; i++)
  {
    smin = DBL_MAX;
    for (j = 0; j < rows; j++)
	 {
      smin=MIN(fmx[j][i],smin);
    }
    xrange[i] = smin;
  }
}

//+------------------------------------------------------------------+
//| Return mean values of columns in 'fmx'.
//+------------------------------------------------------------------+
void fmx_mean(double &xmean[], double fmx[][])
{
  int    i;
  int    j;
  double s;
  int rows = ArrayRange(fmx,0);
  int columns = ArrayRange(fmx,1);

  ArrayResize(xmean,columns);
  if (rows > 1)
  {
    for (i = 0; i < columns; i++)
	 {
	   s = 0.0;
	   for (j = 0; j < rows; j++)
	     s += fmx[j][i];
		  xmean[i] = s/rows;
	 }
  }
  else
  {
    for (i = 0; i < columns; i++)
	   xmean[i] = fmx[0][i];
  }
}

//+------------------------------------------------------------------+
//| Set elements of 'vec' to 'value'.
//+------------------------------------------------------------------+
void fvec_set(double &vec[], int len, double value)
{
  int i;
  ArrayResize(vec,len);
  for (i = 0; i < len; i++)
    vec[i] = value;
}

//+------------------------------------------------------------------+
//|  Return standard deviations of columns in 'fmx'.
//+------------------------------------------------------------------+
void fmx_std(double  &std[], double fmx[][])
{
  int    i;
  int    j;
  double  xmean;
  double s;
  int rows = ArrayRange(fmx,0);
  int columns = ArrayRange(fmx,1);

  ArrayResize(std,columns);
  if (rows > 1)
  {
    for (i = 0; i < columns; i++)
    {
	      s = 0.0;
	      for (j = 0; j < rows; j++)
		s += fmx[j][i];
	      xmean = s/rows;
	      s = 0.0;
	      for (j = 0; j < rows; j++)
		s += (fmx[j][i]-xmean)*(fmx[j][i]-xmean);
	      std[i] = MathSqrt(s/(rows-1));
    }
  }
  else
   fvec_set(std, columns, 0.0);
}

//+------------------------------------------------------------------+
//| 1-normalize TRAIN lines from std and mean calculated from TRAIN lines
//| 1-normalize TEST lines from std and mean calculated from TEST lines
//| ..................................................................
//| 2-normalize TRAIN lines from std and mean calculated from TRAIN lines
//| 2-normalize TEST lines from std and mean calculated from TRAIN lines
//| ..................................................................
//| 3-normalize TRAIN lines from range and midrange calculated from TRAIN lines
//| 3-normalize TEST lines from range and midrange calculated from TEST lines
//| ..................................................................
//| 4-normalize TEST lines from range and midrange calculated from TRAIN lines
//+------------------------------------------------------------------+
void svm_normalize_sample(
								double &svm_samples_attrib[][],
								int normalize
							 )
{

  double xmean[];
  double std[];
  double xrange[];
  double xmidrange[];


  if(normalize==1 || normalize==2)
  { //normalize TRAIN lines from std and mean calculated from TRAIN lines
    fmx_mean(xmean,svm_samples_attrib);
    fmx_std(std,svm_samples_attrib);
    fmx_prenorm(svm_samples_attrib,xmean, std);
  }
  else if(normalize==3)
  { //normalize TRAIN lines from range and midrange calculated from TRAIN lines
    fmx_range(xrange,svm_samples_attrib);
    fmx_midrange(xmidrange,svm_samples_attrib);
    fmx_prenorm_range(svm_samples_attrib,xrange, xmidrange);
  }

}

//+------------------------------------------------------------------+
//| 1-normalize TEST lines from std and mean calculated from TEST lines
//| 2-normalize TEST lines from std and mean calculated from TRAIN lines
//| 3-normalize TEST lines from range and midrange calculated from TEST lines
//| 4-normalize TEST lines from range and midrange calculated from TRAIN lines
//+------------------------------------------------------------------+
void svm_normalize_test(
	                     double svm_samples_attrib[][],
								double &svm_test_attrib[][],
								int normalize
							)

{

  if(normalize==1)
  {  //normalize TEST lines from std and mean calculated from TEST lines
    double xmean2[];
    fmx_mean(xmean2,svm_test_attrib);
    double std2[];
    fmx_std(std2,svm_test_attrib);
    fmx_prenorm(svm_test_attrib,xmean2, std2);
  }
  else if(normalize==2)
  { //normalize TEST lines from std and mean calculated from TRAIN lines
    double xmean1[];
    fmx_mean(xmean1,svm_samples_attrib);
    double std1[];
    fmx_std(std1,svm_samples_attrib);
    fmx_prenorm(svm_test_attrib, xmean1, std1);
  }
  else if(normalize==3)
  { //normalize TEST lines from range and midrange calculated from TEST lines
    double xrange2[];
    fmx_range(xrange2,svm_test_attrib);
    double xmidrange2[];
    fmx_midrange(xmidrange2,svm_test_attrib);
    fmx_prenorm_range(svm_test_attrib, xrange2, xmidrange2);
  }
  else if(normalize==4)
  { //normalize TEST lines from range and midrange calculated from TRAIN lines
    double xrange1[];
    fmx_range(xrange1,svm_samples_attrib);
    double xmidrange1[];
    fmx_midrange(xmidrange1,svm_samples_attrib);
    fmx_prenorm_range(svm_test_attrib, xrange1, xmidrange1);
  }

}
