This tool is designed to identify and visualize a specific price action pattern known as an "Inside Bar" across different timeframes. Its primary purpose is to help traders spot moments where price volatility shrinks, often preceding a significant breakout or trend continuation.
Core Functionality
The script scans the market history to find "Inside Bars." An Inside Bar occurs when the high and low prices of a candle are completely contained within the range of the previous candle (the "Mother Bar"). Essentially, it represents a period of consolidation where the market is testing boundaries without breaking out of them.
Key Technical Logic
- Multi-Timeframe Analysis: One of the script's standout features is its ability to look for these patterns on a higher timeframe (for example, an hourly chart) while you are viewing a lower timeframe (like a 15-minute chart). It ensures that the data being analyzed is consistent and synchronized across these different views.
- Pattern Identification: The logic specifically checks if:
- The current candle's high is lower than the previous candle's high.
- The current candle's low is higher than the previous candle's low.
- The candle has a minimum physical size to ensure it isn't just a "flat" line, but a valid price movement.
- Dynamic Projection: When an Inside Bar is detected, the script doesn't just mark that single point. It identifies the boundaries of that specific price action and projects those levels forward onto the current chart. This helps traders see exactly where the "breakout" zones are located in real-time.
- Persistence Logic: The script includes a "length" parameter. This allows it to track how long a price remains within a certain boundary. If the price stays consolidated for several periods, the script maintains those boundaries on your screen; however, if the market moves significantly outside of these established limits, the tool clears the data to signal that the previous pattern is no longer valid.
User Experience
Instead of overwhelming the user with raw numbers, this script provides a visual representation. It draws lines on the chart to indicate the High and Low levels of the identified Inside Bar. This allows traders to easily see "support" and "resistance" zones created by price consolidation, making it easier to decide when to enter or exit a trade based on whether the price breaks above or below those marked boundaries.
Price Data Components
Miscellaneous
9
Views
0
Downloads
0
Favorites
Inside_Bar
//+------------------------------------------------------------------+
//| inside_bar.mq4 |
//| © Tecciztecatl |
//+------------------------------------------------------------------+
#property copyright "© Tecciztecatl 2016"
#property link "https://www.mql5.com/en/users/tecciztecatl"
#property version "1.00"
#property strict
#property indicator_chart_window
#property indicator_buffers 2
#property indicator_color1 Green
#property indicator_color2 Red
#property indicator_style1 STYLE_SOLID
#property indicator_style2 STYLE_SOLID
#property indicator_width1 2
#property indicator_width2 2
//---- input parameters
extern ENUM_TIMEFRAMES TF_find=PERIOD_H1; //Period to find Inside Bar
//---- buffers
double HighBuff[];
double LowBuff[];
double LastHigh;
double LastLow;
int length=5, len=0;
//+------------------------------------------------------------------+
//| Custom indicator initialization function |
//+------------------------------------------------------------------+
int OnInit()
{
if (TF_find==PERIOD_CURRENT) TF_find=(ENUM_TIMEFRAMES)_Period;
LoadHist();
SetIndexStyle(0,DRAW_LINE);
SetIndexStyle(1,DRAW_LINE);
SetIndexBuffer(0,HighBuff);
SetIndexBuffer(1,LowBuff);
IndicatorShortName("Inside Bar ("+TFtoStr(TF_find)+")");
SetIndexLabel(0,"High");
SetIndexLabel(1,"Low");
SetIndexEmptyValue(0,EMPTY_VALUE);
SetIndexEmptyValue(1,EMPTY_VALUE);
ArrayInitialize(HighBuff,EMPTY_VALUE);
ArrayInitialize(LowBuff,EMPTY_VALUE);
IndicatorDigits(_Digits);
return(0);
}
//+------------------------------------------------------------------+
//| Expert deinitialization function |
//+------------------------------------------------------------------+
void OnDeinit(const int reason)
{
Comment("");
}
//+------------------------------------------------------------------+
//| Custom indicator iteration function |
//+------------------------------------------------------------------+
int OnCalculate(const int rates_total,
const int prev_calculated,
const datetime &time[],
const double &open[],
const double &high[],
const double &low[],
const double &close[],
const long& tick_volume[],
const long& volume[],
const int& spread[])
{
if (rates_total-prev_calculated<=0) return(0);
if (TF_find<_Period)
{
Comment("Time frame must be not more than 'Period to find Inside Bar' "+TFtoStr(TF_find));
return (0);
}
int limit=1;
if (prev_calculated==0 || rates_total-prev_calculated>1)
{
ArrayInitialize(HighBuff,EMPTY_VALUE);
ArrayInitialize(LowBuff,EMPTY_VALUE);
limit=iBars(_Symbol,TF_find)-2;
}
for (int i=limit; i>=1; i--)
{
datetime time1=iTime(_Symbol,TF_find,i);
datetime time2=time1+PeriodSeconds(TF_find);
int bar_now=iBarShift(_Symbol,_Period,time1,false);
if (iLow(_Symbol,TF_find,i) > iLow(_Symbol,TF_find,i+1) &&
iHigh(_Symbol,TF_find,i) < iHigh(_Symbol,TF_find,i+1) &&
iHigh(_Symbol,TF_find,i)-iLow(_Symbol,TF_find,i)>_Point/2)
{
LastHigh = iHigh(_Symbol,TF_find,i);
LastLow = iLow(_Symbol,TF_find,i);
len=1;
if (bar_now<rates_total-3 &&
((HighBuff[bar_now+1]!=LastHigh && HighBuff[bar_now+2]!=EMPTY_VALUE) ||
(LowBuff[bar_now+1]!=LastLow && LowBuff[bar_now+2]!=EMPTY_VALUE)) )
{
HighBuff[bar_now+1] = EMPTY_VALUE;
LowBuff[bar_now+1] = EMPTY_VALUE;
}
while (bar_now<rates_total-2 && time[bar_now]>=time1 && time[bar_now]<time2)
{
HighBuff[bar_now] = LastHigh;
LowBuff[bar_now] = LastLow;
bar_now--;
}
}
else
{
if (len>0 && len<length)
{
while (bar_now<rates_total-2 && time[bar_now]>=time1 && time[bar_now]<time2)
{
HighBuff[bar_now] = HighBuff[bar_now+1];
LowBuff[bar_now] = LowBuff[bar_now+1];
bar_now--;
}
len++;
}
else if (len>length)
{
len=0;
HighBuff[bar_now] = EMPTY_VALUE;
LowBuff[bar_now] = EMPTY_VALUE;
}
}
}
return(rates_total);
}
//+------------------------------------------------------------------+
string TFtoStr(int n)
{
if(n==0)n=Period();
switch(n)
{
case PERIOD_M1: return ("M1");
case PERIOD_M5: return ("M5");
case PERIOD_M15: return ("M15");
case PERIOD_M30: return ("M30");
case PERIOD_H1: return ("H1");
case PERIOD_H4: return ("H4");
case PERIOD_D1: return ("D1");
case PERIOD_W1: return ("W1");
case PERIOD_MN1: return ("MN1");
}
return("TF?");
}
void LoadHist()
{
int iPeriod[2];
iPeriod[0]=TF_find;
iPeriod[1]=_Period;
for (int i=0;i<2;i++)
{
datetime open = iTime(_Symbol, iPeriod[i], 0);
int error=GetLastError();
while(error==4066)
{
Comment("Loading history "+TFtoStr(iPeriod[i]));
Sleep(1000);
open = iTime(_Symbol, iPeriod[i], 0);
error=GetLastError();
}
Comment("");
}
}
