ExportFunctions
Download script
This script acts as a specialized bridge that allows the MetaTrader platform to communicate with external software libraries. Instead of performing calculations solely within its own environment, this tool enables the trading platform to "reach out" and use advanced processing power from outside sources.
Core Functionality
The primary purpose of this logic is External Integration. It establishes a pathway for the trading platform to exchange information with a Dynamic Link Library (DLL)—a file that contains complex instructions or heavy mathematical models that may be too advanced for the standard trading environment to handle alone.
Key Operations
The script performs several types of interactions with these external tools:
- Data Conversion and Retrieval: It can send different types of information (such as whole numbers, decimals, or text) to an external program and receive processed results back. This ensures that the platform can "talk" to other software fluently.
- Advanced Data Organization: The logic includes capabilities to automatically sort and process lists of text. For example, it can take a disorganized list of information and arrange it into a specific order required by an external system.
- Machine Learning & Prediction Support: The script contains specific commands for "Training" and "Predicting." This suggests it is designed to interface with sophisticated Machine Learning models (specifically Support Vector Machines), where the platform sends current market data to an external model to receive a prediction or trend analysis.
- Dynamic Array Management: It allows the platform to share complex grids of data—like historical price rates—with external programs, modify those values on the fly, and pull specific pieces of information (such as current closing prices) back into the trading view.
Summary for the User
Think of this script as a translator and courier. It doesn't perform all the "thinking" itself; instead, it gathers your trading data, translates it into a format an external high-powered computer can understand, sends it off to be analyzed by advanced algorithms, and then brings the final results back to your screen.
//+------------------------------------------------------------------+
//| ExportFunctions.mq4 |
//| Copyright © 2005, MetaQuotes Software Corp. |
//| http://www.metaquotes.net/ |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2005, MetaQuotes Software Corp."
#property link "http://www.metaquotes.net/"
//#include <sampledll.mqh>
#import "ExpertSample.dll"
int GetIntValue(int);
double GetDoubleValue(double);
string GetStringValue(string);
double GetArrayItemValue(double arr[],int,int);
bool SetArrayItemValue(double& arr[],int,int,double);
double GetRatesItemValue(double rates[][6],int,int,int);
int SortStringArray(string& arr[],int);
int ProcessStringArray(string& arr[],int);
int SVM_Train(string, string);
int SVM_Predict(int,string, string, string);
#define TIME_INDEX 0
#define OPEN_INDEX 1
#define LOW_INDEX 2
#define HIGH_INDEX 3
#define CLOSE_INDEX 4
#define VOLUME_INDEX 5
//+------------------------------------------------------------------+
//| expert initialization function |
//+------------------------------------------------------------------+
int init()
{
double ret,some_value=10.5;
string sret;
int cnt;
string strarray[6]={ "first", "second", "third", "fourth", "fifth" };
//---- simple dll-functions call
cnt=GetIntValue(some_value);
Print("Returned value is ",cnt);
ret=GetDoubleValue(some_value);
Print("Returned value is ",ret);
sret=GetStringValue("some string");
Print("Returned value is ",sret);
//----
cnt=SortStringArray(strarray,ArraySize(strarray));
for(int i=0; i<cnt; i++) Print(i," - ",strarray[i]);
cnt=ProcessStringArray(strarray,ArraySize(strarray));
for(i=0; i<cnt; i++) Print(i," - ",strarray[i]);
//----
return(0);
}
//+------------------------------------------------------------------+
//| array functions call |
//+------------------------------------------------------------------+
int start()
{
double price;
double arr[5]={1.5, 2.6, 3.7, 4.8, 5.9 };
double rates[][6];
//---- get first item from passed array
price=GetArrayItemValue(arr,5,0);
Print("Returned from arr[0] ",price);
//---- change second item in the passed array
if(SetArrayItemValue(arr,5,1,1234.5)==true)
Print("Changed to ",arr[1]);
//---- get current close
ArrayCopyRates(rates);
price=GetRatesItemValue(rates,Bars,0,CLOSE_INDEX);
Print("Returned from Close ",price);
//----
return(0);
}
//+------------------------------------------------------------------+
