The DMI (Directional Movement Index) script is a technical analysis tool designed to help traders identify the strength and direction of a market trend. Rather than just showing if a price is going up or down, this tool breaks down price action into specific components to help filter out "noise" and highlight significant movements.
Core Logic and Components
The script processes market data by calculating several distinct metrics simultaneously:
1. Directional Movement (+DI and -DI) The logic first looks at the high and low prices of each candle compared to the previous candle.
- If the new high is higher than the previous high, it registers as positive movement (+DI).
- If the new low is lower than the previous low, it registers as negative movement (-DI). The script then normalizes these values against the "True Range" (the total distance a price moved during a period) to produce two lines: one representing upward pressure and the other representing downward pressure.
2. The DX Index By comparing the +DI and -DI lines, the script calculates the DX. This represents the relative strength of the current trend. If there is a wide gap between the upward and downward pressure, the DX value increases, indicating a stronger, more established trend.
3. ADX (Average Directional Index) The ADX is one of the most important outputs of this script. It takes the DX values and smooths them over time using a moving average calculation. This produces a line that tells you how strong the trend is, regardless of its direction. A rising ADX suggests a strengthening trend, while a falling ADX suggests the market may be entering a sideways or "choppy" phase.
4. ADXR (Average Directional Index Rate of Change) The script also calculates the ADXR, which acts as a smoothed average of the ADX. This is used to observe the momentum and the rate at which the trend strength is changing over a longer period.
Key Features for the User
- Smoothing Factor: The logic uses a "Smooth" parameter (defaulting to 13). You can adjust this to change how reactive the indicator is; a lower number makes it more sensitive to quick price changes, while a higher number creates smoother lines that ignore minor fluctuations.
- Visual Customization: The script includes built-in logic to toggle specific lines on or off (such as hiding the +DI, -DI, DX, ADX, or ADXR). This allows you to clean up your chart and only view the data points relevant to your specific trading strategy.
- Dynamic Calculation: The script automatically calculates these values based on the "True Range," ensuring that gaps in price (like those seen during market opens) are accounted for correctly in the trend analysis.
Summary of Purpose
In short, this script helps a trader answer two questions:
- Direction: Is the current move primarily up or down?
- Strength: Is the current move powerful enough to be traded, or is the market just drifting sideways?
Miscellaneous
10
Views
0
Downloads
0
Favorites
dmi_v1
//+------------------------------------------------------------------+
//| DMI.mq4 |
//| Copyright © 2006, Fernando Gomes. |
//| http://www.ciavox.com/~fgomes |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2006, Fernando Gomes."
#property link "http://www.ciavox.com/~fgomes"
//---- indicator settings
#property indicator_separate_window
#property indicator_buffers 5
#property indicator_color1 Lime
#property indicator_color2 Red
#property indicator_color3 Yellow
#property indicator_color4 DeepSkyBlue
#property indicator_color5 Blue
#property indicator_minimum 0
#property indicator_level1 20
#property indicator_level2 25
#property indicator_maximum 60
//---- indicator parameters
extern int Smooth = 13;
extern bool Hide_DI_Plus = False;
extern bool Hide_DI_Minus = False;
extern bool Hide_DX = False;
extern bool Hide_ADX = False;
extern bool Hide_ADXR = False;
//---- indicator buffers
double b_di_p[]; // +DM
double b_di_m[]; // -DM
double b_dmi[]; // DX (DMI itself)
double b_adx[]; // Average Directional indeX
double b_adxr[]; // Average Directional indeX Rate
//---- non-indicator buffers
//---- NOTICE that these arrays must be included in ArraySetAsSeries()
double dm_p_avg[];
double dm_m_avg[];
double tr_avg[];
//+------------------------------------------------------------------+
//| Custom indicator initialization function |
//+------------------------------------------------------------------+
int init() {
//---- indicator buffers mapping
IndicatorBuffers(8);
if ( !SetIndexBuffer(0,b_di_p)
&& !SetIndexBuffer(1,b_di_m)
&& !SetIndexBuffer(2,b_dmi)
&& !SetIndexBuffer(3,b_adx)
&& !SetIndexBuffer(4,b_adxr)
&& !SetIndexBuffer(5,dm_p_avg)
&& !SetIndexBuffer(6,dm_m_avg)
&& !SetIndexBuffer(7,tr_avg)
) { Print("cannot set indicator buffers!"); return(-1); }
//---- name for DataWindow and indicator subwindow label
IndicatorShortName("DMI("+Smooth+")");
SetIndexLabel(0,"+DI");
SetIndexLabel(1,"-DI");
SetIndexLabel(2,"DX");
SetIndexLabel(3,"ADX");
SetIndexLabel(4,"ADXR");
//----
SetIndexStyle(0, DRAW_LINE+Hide_DI_Plus*DRAW_NONE, STYLE_SOLID, 1, indicator_color1);
SetIndexStyle(1, DRAW_LINE+Hide_DI_Minus*DRAW_NONE, STYLE_SOLID, 1, indicator_color2);
SetIndexStyle(2, DRAW_LINE+Hide_DX*DRAW_NONE, STYLE_SOLID, 1, indicator_color3);
SetIndexStyle(3, DRAW_LINE+Hide_ADX*DRAW_NONE, STYLE_SOLID, 1, indicator_color4);
SetIndexStyle(4, DRAW_LINE+Hide_ADXR*DRAW_NONE, STYLE_SOLID, 1, indicator_color5);
//----
SetIndexDrawBegin(0,Smooth);
SetIndexDrawBegin(1,Smooth);
SetIndexDrawBegin(2,Smooth);
SetIndexDrawBegin(3,2*Smooth);
SetIndexDrawBegin(4,3*Smooth);
return(0);
}
//+------------------------------------------------------------------+
//| Custor indicator deinitialization function |
//+------------------------------------------------------------------+
int deinit() {
return(0);
}
//+------------------------------------------------------------------+
//| Custom indicator iteration function |
//+------------------------------------------------------------------+
int start() {
int counted_bars=IndicatorCounted();
if (counted_bars<0) return(-1);
if (Bars < 2) return(-1);
if (Smooth < 2) return(-1);
int limit=Bars-1-counted_bars;
double smooth = 1.0 / (Smooth * 1.0);
int firstDMI = Bars-1-Smooth;
int firstADX = Bars-1-(2*Smooth);
int firstADXR = Bars-1-(3*Smooth);
for (int i=limit; i>=0; i--) {
double high;
double low;
double dm_p;
double dm_m;
if (i<firstDMI) {
high = High[i] - High[i+1];
low = Low[i+1] - Low[i];
dm_p = 0.0;
dm_m = 0.0;
if ((high > low) && (high > 0.0))
dm_p = high;
else if ((low > high) && (low > 0.0))
dm_m = low;
// calculate averages (cumulative formula)
dm_p_avg[i] = dm_p_avg[i+1] - ( smooth * dm_p_avg[i+1] ) + dm_p;
dm_m_avg[i] = dm_m_avg[i+1] - ( smooth * dm_m_avg[i+1] ) + dm_m;
tr_avg[i] = tr_avg[i+1] - ( smooth * tr_avg[i+1] ) + calcTR(i);
} else if (i==firstDMI) {
double sum_dm_p = 0.0;
double sum_dm_m = 0.0;
double sum_tr = 0.0;
for (int j=i; j<i+Smooth; j++) {
high = High[j] - High[j+1];
low = Low[j+1] - Low[j];
dm_p = 0.0 ;
dm_m = 0.0 ;
if ((high > low) && (high > 0.0))
dm_p = high;
else if ((low > high) && (low > 0.0))
dm_m = low;
sum_dm_p = sum_dm_p + dm_p;
sum_dm_m = sum_dm_m + dm_m;
sum_tr = sum_tr + calcTR(j);
}
// define current values
dm_p_avg[i] = sum_dm_p * smooth;
dm_m_avg[i] = sum_dm_m * smooth;
tr_avg[i] = sum_tr * smooth;
} else {
tr_avg[i] = 0.0;
}
// Calculate +DI and -DI
if (tr_avg[i] > 0.0) {
b_di_p[i] = 100.0 * dm_p_avg[i] / tr_avg[i];
b_di_m[i] = 100.0 * dm_m_avg[i] / tr_avg[i];
} else {
b_di_p[i] = 0.0;
b_di_m[i] = 0.0;
}
// calcule DMI
double sum = b_di_p[i] + b_di_m[i];
double diff = MathAbs( b_di_p[i] - b_di_m[i] );
if (sum > 0.0) {
b_dmi[i] = 100.0 * diff / sum;
} else {
b_dmi[i] = 0.0 ;
}
// Calculate ADX
if (i<firstADX) {
b_adx[i] = smooth*(b_adx[i+1]*(Smooth-1) + b_dmi[i]);
} else if (i==firstADX) {
double sum_dmi = 0.0;
for (int k=i+Smooth+1; k>i; k--) {
sum_dmi = sum_dmi + b_dmi[k];
}
b_adx[i] = smooth * sum_dmi;
} else {
b_adx[i] = 0.0;
}
// Calculate ADXR
if (i<=firstADXR) {
b_adxr[i] = (b_adx[i] + b_adx[i+Smooth]) / 2;
} else {
b_adxr[i] = 0.0;
}
} // for
return(0);
}
double calcTR(int bar) {
double a = High[bar] - Low[bar]; // A = Today's High - Today's Low
double b = MathAbs(Close[bar+1] - High[bar]); // B = Yesterday's Close - Today's High
double c = MathAbs(Close[bar+1] - Low[bar]); // C = Yesterday's Close - Today's Low
return(MathMax(MathMax(a,b),c));
}
//+------------------------------------------------------------------+
