Cronex T RSI GF

This script is a specialized technical analysis tool designed to provide traders with a smoothed and filtered view of market momentum. It takes raw price data and processes it through several layers of mathematical logic to identify significant trends, price extremes, and potential reversal points more clearly than standard indicators might allow.

Core Methodology

The logic operates through three primary stages of data processing:

1. Multi-Layered Momentum Smoothing Instead of relying on a single Relative Strength Index (RSI) calculation—which can often be "noisy" or jumpy—this script averages four different RSI calculations simultaneously. By blending these values and centering them around a zero-line, the tool creates a more stable foundation for analysis.

2. Advanced Curve Smoothing (The "T" Logic) The script applies a sophisticated smoothing technique based on a "curvature" constant. This is designed to filter out minor market fluctuations while preserving the integrity of significant price movements. It uses an exponential-style weighting system to ensure that the resulting line flows smoothly across the chart, making it easier for a trader to see the underlying direction of the momentum without being distracted by "market noise."

3. Dynamic Volatility Bands and Extremes Once the smoothed momentum line is created, the script applies Bollinger Bands directly to that line. This creates a visual "channel" of volatility:

  • The Middle Band: Acts as the baseline for current momentum.
  • Upper and Lower Bands: Define the boundaries of normal price behavior.
  • Peak Detection: The logic specifically monitors for "breakout" moments—points where the smoothed line crosses specific thresholds or moves sharply in a single direction. It identifies local maximums and minimums to highlight where the momentum is reaching its strongest (or weakest) points.

Visual Output and Utility

For the user, this logic translates into several distinct visual elements:

  • The Primary Trend Line: A smooth, smoothed RSI representation that shows the current "heartbeat" of the market.
  • Volatility Channels: The bands provide a clear visual boundary for what is considered an overextended move.
  • Key Points: The script identifies specific peaks and troughs (Max/Min points) where the momentum has reached significant levels, potentially signaling areas of exhaustion or new trend beginnings.

By combining multi-source averaging, custom curvature smoothing, and volatility banding, this tool aims to provide a "cleaned" version of market sentiment, helping traders distinguish between temporary price spikes and actual shifts in momentum.

Indicators Used
Relative strength index
Miscellaneous
Implements a curve of type %1
11 Views
0 Downloads
0 Favorites
Cronex T RSI GF
//+------------------------------------------------------------------+
//|                                              Cronex T RSI GF.mq4 |
//|                                        Copyright © 2008, Cronex. |
//|                                       http://www.metaquotes.net/ |
//+------------------------------------------------------------------+
#property  copyright "Copyright © 2008, Cronex"
#property  link      "http://www.metaquotes.net/"
//----
//#property indicator_chart_window
#property  indicator_separate_window
#property indicator_buffers 8
#property indicator_color1 DarkOrange
#property indicator_color2 SteelBlue
#property indicator_color3 Blue
#property indicator_color4 Black
#property indicator_color5 Black
#property indicator_color6 Blue
#property indicator_color7 Red
#property indicator_color8 Black


#property indicator_width1 2
#property indicator_width6 1
#property indicator_width7 1
//-----Level lines
#property  indicator_level1  10
#property  indicator_level2 -10
//#property  indicator_level3 -10
//----
extern int     RSIPeriod=16;
extern double  TCurvature=0.618;
extern int     MAPeriod=10;
extern int     BandsPeriod=20;
extern int     BandsDeviations=2;
extern int     BandsShift=0;


//extern int       RightMore=4;
//extern int       RightLess=15;
//extern int       LeftMore=20;

//----
double RSITArray[];
double RSIArray[];
double BBMDArray[];
double BBUPArray[];
double BBDNArray[];
double MaxArray[];
double MinArray[];
double MAArray[];

double e1,e2,e3,e4,e5,e6;
double c1,c2,c3,c4;
double n,w1,w2,b2,b3;
//+------------------------------------------------------------------+
//| Custom indicator initialization function                         |
//+------------------------------------------------------------------+
int init()
  {
//---- indicators setting

   SetIndexBuffer(0,RSITArray);
   SetIndexBuffer(1,RSIArray);
   SetIndexBuffer(2,BBMDArray);
   SetIndexBuffer(3,BBUPArray);
   SetIndexBuffer(4,BBDNArray);
   SetIndexBuffer(5,MaxArray);
   SetIndexBuffer(6,MinArray);
   SetIndexBuffer(7,MAArray);

//---- drawing settings
   SetIndexStyle(0,DRAW_LINE);
   SetIndexStyle(1,DRAW_LINE);

   SetIndexStyle(2,DRAW_LINE);
   SetIndexStyle(3,DRAW_LINE);
   SetIndexStyle(4,DRAW_LINE);

   SetIndexStyle(5,DRAW_ARROW);
   SetIndexStyle(6,DRAW_ARROW);
   SetIndexStyle(7,DRAW_LINE);

   SetIndexArrow(5,174);
   SetIndexArrow(6,174);

   SetIndexEmptyValue(5,0.0);
   SetIndexEmptyValue(6,0.0);
//---- name for DataWindow and indicator subwindow label
   SetIndexLabel(0,"RSI T");
   SetIndexLabel(1,"RSI");
   SetIndexLabel(2,"BB Middle");
   SetIndexLabel(3,"BB Upper");
   SetIndexLabel(4,"BB Lower");
   SetIndexLabel(5,"Max Point");
   SetIndexLabel(6,"Min Point");
   SetIndexLabel(7,"MA");
   //
   IndicatorDigits(MarketInfo(Symbol(),MODE_DIGITS));
   IndicatorShortName("Cronex T RSI GF("+RSIPeriod+")");

//---- variable reset
   e1=0; e2=0; e3=0; e4=0; e5=0; e6=0;
   c1=0; c2=0; c3=0; c4=0;
   n=0;
   w1=0; w2=0;
   b2=0; b3=0;
   //
   b2=TCurvature*TCurvature;
   b3=b2*TCurvature;
   c1=-b3;
   c2=(3*(b2+b3));
   c3=-3*(2*b2+TCurvature+b3);
   c4=(1+3*TCurvature+b3+3*b2);
   n=RSIPeriod;
   //
   if (n<1) n=1;
   n=1 + 0.5*(n-1);
   w1=2/(n + 1);
   w2=1 - w1;
//----
   return(0);
  }
//+------------------------------------------------------------------+
//| Custom indicator iteration function                              |
//+------------------------------------------------------------------+
int start()
  {
   int Limit=300;
   double Max;
   int MaxB;
//---- indicator calculation
   for(int i=Limit; i>=0; i--)
     {
//      RSIArray[i]=iRSI(NULL,0,RSIPeriod,PRICE_WEIGHTED,i);
      RSIArray[i]=(
                    iRSI(NULL,0,RSIPeriod+4*0,PRICE_WEIGHTED,i)+
                    iRSI(NULL,0,RSIPeriod+4*1,PRICE_WEIGHTED,i)+
                    iRSI(NULL,0,RSIPeriod+4*2,PRICE_WEIGHTED,i)+
                    iRSI(NULL,0,RSIPeriod+4*3,PRICE_WEIGHTED,i))/4-50;

      e1=w1*RSIArray[i] + w2*e1;
      e2=w1*e1 + w2*e2;
      e3=w1*e2 + w2*e3;
      e4=w1*e3 + w2*e4;
      e5=w1*e4 + w2*e5;
      e6=w1*e5 + w2*e6;
//=====================================================
      RSITArray[i]=c1*e6 + c2*e5 + c3*e4 + c4*e3;
//=====================================================


     }

//================================================================================================
    for(int j=Limit-1;j>=0;j--)
      {

      BBMDArray[j]=iBandsOnArray(RSITArray,0,BandsPeriod,BandsDeviations,BandsShift,MODE_MAIN,j);
      BBUPArray[j]=iBandsOnArray(RSITArray,0,BandsPeriod,BandsDeviations,BandsShift,MODE_UPPER,j);
      BBDNArray[j]=iBandsOnArray(RSITArray,0,BandsPeriod,BandsDeviations,BandsShift,MODE_LOWER,j);

       if(RSITArray[j+1]<= 1  &&   1 < RSITArray[j])MaxArray[j]=RSITArray[j];
       if(RSIArray[j+1]>= 25 &&  25 > RSIArray[j])MaxArray[j]=RSITArray[j];
       if(RSITArray[j+1]<=-10 && -10 < RSITArray[j])MaxArray[j]=RSITArray[j];

       if(RSITArray[j+1]>=-1  &&  -1 > RSITArray[j])MinArray[j]=RSITArray[j];
       if(RSIArray[j+1]<=-25 && -25 < RSIArray[j])MinArray[j]=RSITArray[j];
       if(RSITArray[j+1]>= 10 &&  10 > RSITArray[j])MinArray[j]=RSITArray[j];
      }


      for(i=0; i<=Limit; i++)
       {
         if(RSITArray[0]>0)
             if(RSITArray[i]<=0) break;

         if(RSITArray[0]<0)
             if(RSITArray[i]>=0)break;
       }

      double LastWaveArray[];
      int LWACount=ArrayResize(LastWaveArray,i);

      ArrayCopy(LastWaveArray,RSITArray,0,0,i);


      if(RSITArray[0]>0)
      {
        int Ind=ArrayMaximum(LastWaveArray);
        if (Ind!=0 && RSITArray[Ind]>5)MaxArray[Ind]=RSITArray[Ind];
      }



      if(RSITArray[0]<0)
      {
        Ind=ArrayMinimum(LastWaveArray);
        if (Ind!=0 && RSITArray[Ind]<-5)MinArray[Ind]=RSITArray[Ind];
      }


//----
   return(0);
  }
//+------------------------------------------------------------------+
