BreakOut_BOX_5_DailyCandles_OCbox_indicator_v1

Download script
Author: hapalkos
BreakOut_BOX_5_DailyCandles_OCbox_indicator_v1

This script is designed to visually map out specific price ranges on a trading chart by drawing rectangles and lines based on historical price action. It helps traders identify significant "breakout" zones by automating the drawing of boxes over defined periods of time.

Core Logic and Functionality

Time-Based Period Analysis The tool divides the trading day into two distinct segments: Period A and Period B. You can define exactly when these periods start and end (for example, specific hours of the day). The logic automatically calculates the price movement within these timeframes to identify key levels.

Dynamic Price Mapping Depending on how you configure the tool, it monitors different types of price data:

  • High/Low Mode: By default, the script looks for the highest and lowest prices reached during the specified periods.
  • Open/Close Mode: Alternatively, it can be set to track the opening and closing prices, which is useful for analyzing candle body dynamics rather than just the "wicks."

Visual Components The script generates several types of visual markers on your chart:

  • Combined Breakout Boxes: These show the total range (from the highest high to the lowest low) covered during both Period A and Period B.
  • Individual Period Boxes: The tool draws separate rectangles for Period A and Period B, allowing you to see exactly how much price "room" was covered in each specific session.
  • Breakout Bands: It can draw small horizontal boxes at the top and bottom of Period B. These act as visual boundaries; if the price moves beyond these bands, it signals a potential breakout from the established range.
  • Alert Levels: The script can place specific trend lines at these breakout boundaries. While the logic for sending sound alerts is included, they are primarily designed to be integrated with external alert systems to notify you when the price breaches a box.

Key Features for the User

  • Historical Depth: You can choose how many days of history you want the script to plot (e.g., the last 50 days).
  • Weekend Awareness: The logic is programmed to skip Sundays, ensuring that the historical data remains clean and relevant to actual trading sessions.
  • Customizable Visuals: You can toggle whether the boxes are solid filled or just outlines, and you can choose different colors to distinguish between different price actions (such as identifying when a period closed lower than it opened).
  • Multi-Indicator Support: The script uses a "Unique ID" system. This means you can run multiple versions of this indicator on the same chart for different assets or timeframes without them interfering with one another.
  • Auto-Cleanup: Whenever the script is loaded or removed, it automatically clears previous drawings to keep your chart clean and prevent "ghost" objects from lingering.
17 Views
0 Downloads
0 Favorites
BreakOut_BOX_5_DailyCandles_OCbox_indicator_v1
//+------------------------------------------------------------------+
//|                                               BreakOut_BOX_5.mq4 |
//|                                                        hapalkos  |
//|                                                       2007.02.16 |
//|      Code based on TIME1_modified.mq4 shown below                |
//|         posted to Forex Factory by glenn5t                       |
//|      Concept of the break-out box form by Markj                  |
//|                                                                  |
//|   ++ modified so that rectangles do not overlay                  |
//|   ++ this makes color selection more versatile                   |
//|  +++ code consolidated to facilitate changes                     |
//|  +++ changed Period B rectangle and added offset value           |
//|  +++ corrected error in bar selection code                            |
//| ++++ added ability to cross 00:00(nextDayA, nextDayB)            |
//| ++++ added Unique ID to allow for multiple indicators            |
//| ++++ added ability to delete rectangles specific to an indicator |
//|+++++ added Open/Close boxes and lines per Accrete                |
//|+++++ added Alerts - can be used with Tesla's Alerter EA          |
//+------------------------------------------------------------------+
#property copyright "hapalkos"
#property link      ""

#property indicator_chart_window               // Configuration for daily candle bodies

extern string UniqueID        = "DailyCandles";  // --- Server Time --- GMT+2 ---
extern int    NumberOfDays    = 50;
extern string periodA_begin   = "00:00";     // Day0
extern string periodA_end     = "00:00";     // Day1
extern int    nextDayA        = 1;           // Set to zero if periodA_begin and periodA_end are on the same day.
                                             // Set to one if periodA_end is on the next day.
extern string periodB_end     = "00:00";     // Day1
extern int    nextDayB        = 1;           // Set to zero if periodA_begin and periodB_end are on the same day.
                                             // Set to one if periodB_end is on the next day.
extern color  rectAB_color1      = White;
extern color  rectAB_color2      = White;  // second rectangle color to indicate relative position of Open/Close
extern bool   rectAB_background  = true;        // true - filled solid; false - outline
extern color  rectA_color        = White;
extern bool   rectA_background   = false;       // true - filled solid; false - outline
extern color  rectB1_color       = White;
extern bool   rectB1_background  = false;       // true - filled solid; false - outline
extern int    rectB1_band        = 0;           // Box Break-Out Band for the Period B rectangle
extern color  rectsB2_color      = White;
extern bool   rectsB2_background = true;        // true - filled solid, false - outline
extern int    rectsB2_band       = 0;           // Box Break-Out Band for the two upper and lower rectangles
extern bool   OpenClose          = false;        // false - High/Low boxes;  true - Open/Close boxes
extern bool   rectA_close_begin  = false;        // false - period A close indication line begins at end of period A;  true - period A close line is drawn from beginning of period A
extern bool   periodB_ALERTS     = false;       // Alerts are set on the upper and lower sides of the upper and lower rectangles - rectsB2
                                                // rectsB2_band determines the location of the Alerts
                                                // Alert_xx added to the decription so that Alerts can be activated by Tesla's Alerter EA

//+------------------------------------------------------------------+
//| Custom indicator initialization function                         |
//+------------------------------------------------------------------+
void init() {
  DeleteObjects();
}

//+------------------------------------------------------------------+
//| Custor indicator deinitialization function                       |
//+------------------------------------------------------------------+
void deinit() {
  DeleteObjects();
return(0);
}

//+------------------------------------------------------------------+
//| Remove all indicator Rectangles                                  |
//+------------------------------------------------------------------+
void DeleteObjects() {
      datetime dtTradeDate=TimeCurrent();

      if(OpenClose) string sRectABname = " BoxOC  ";
         else sRectABname = " BoxHL  ";

  for (int i=0; i<NumberOfDays; i++) {

    ObjectDelete(UniqueID + sRectABname + TimeToStr(dtTradeDate,TIME_DATE));
    ObjectDelete(UniqueID + " BoxOpen  " + TimeToStr(dtTradeDate,TIME_DATE));
    ObjectDelete(UniqueID + " BoxClose  " + TimeToStr(dtTradeDate,TIME_DATE));
    ObjectDelete(UniqueID + " BoxBO_High  " + TimeToStr(dtTradeDate,TIME_DATE));
    ObjectDelete(UniqueID + " BoxBO_HIGH ALERT " + TimeToStr(dtTradeDate,TIME_DATE));
    ObjectDelete(UniqueID + " BoxBO_Low  " + TimeToStr(dtTradeDate,TIME_DATE));
    ObjectDelete(UniqueID + " BoxBO_LOW ALERT  " + TimeToStr(dtTradeDate,TIME_DATE));
    ObjectDelete(UniqueID + " BoxPeriodA  " + TimeToStr(dtTradeDate,TIME_DATE));
    ObjectDelete(UniqueID + " BoxPeriodB  " + TimeToStr(dtTradeDate,TIME_DATE));

    dtTradeDate=decrementTradeDate(dtTradeDate);
    while (TimeDayOfWeek(dtTradeDate) > 5 || TimeDayOfWeek(dtTradeDate) < 1 ) dtTradeDate = decrementTradeDate(dtTradeDate);     // Removed Sundays from plots
    }
 return(0);
}

//+------------------------------------------------------------------+
//| Custom indicator iteration function                              |
//+------------------------------------------------------------------+
void start() {
  datetime dtTradeDate=TimeCurrent();

        if(OpenClose) string sRectABname = " BoxOC  ";
         else sRectABname = " BoxHL  ";

  for (int i=0; i<NumberOfDays; i++) {

    DrawObjects(dtTradeDate, UniqueID + sRectABname+ TimeToStr(dtTradeDate,TIME_DATE), periodA_begin, periodA_end, periodB_end, rectAB_color1,rectAB_color2, 0, 1, rectAB_background,nextDayA,nextDayB,OpenClose,false);
    DrawObjects(dtTradeDate, UniqueID + " BoxOpen  " + TimeToStr(dtTradeDate,TIME_DATE), periodA_begin, periodA_end, periodB_end, rectAB_color1,rectAB_color2, 0, 6, false,nextDayA,nextDayB,OpenClose, true);
    DrawObjects(dtTradeDate, UniqueID + " BoxClose  " + TimeToStr(dtTradeDate,TIME_DATE), periodA_begin, periodA_end, periodB_end, rectAB_color1,rectAB_color2,  0, 7, false,nextDayA,nextDayB,OpenClose,false);
    DrawObjects(dtTradeDate, UniqueID + " BoxBO_High  " + TimeToStr(dtTradeDate,TIME_DATE), periodA_begin, periodA_end, periodB_end, rectsB2_color,rectAB_color2,  rectsB2_band,2,rectsB2_background,nextDayA,nextDayB,OpenClose,false);
    if(periodB_ALERTS) DrawObjects(dtTradeDate, UniqueID + " BoxBO_HIGH ALERT " + TimeToStr(dtTradeDate,TIME_DATE), periodA_begin, periodA_end, periodB_end, rectsB2_color,rectAB_color2,  rectsB2_band,8,false,nextDayA,nextDayB,OpenClose,false);
    DrawObjects(dtTradeDate, UniqueID + " BoxBO_Low  " + TimeToStr(dtTradeDate,TIME_DATE), periodA_begin, periodA_end, periodB_end, rectsB2_color,rectAB_color2,  rectsB2_band,3,rectsB2_background,nextDayA,nextDayB,OpenClose,false);
    if(periodB_ALERTS) DrawObjects(dtTradeDate, UniqueID + " BoxBO_LOW ALERT  " + TimeToStr(dtTradeDate,TIME_DATE), periodA_begin, periodA_end, periodB_end, rectsB2_color,rectAB_color2,  rectsB2_band,9,false,nextDayA,nextDayB,OpenClose,false);
    DrawObjects(dtTradeDate, UniqueID + " BoxPeriodA  " + TimeToStr(dtTradeDate,TIME_DATE), periodA_begin, periodA_end, periodA_end, rectA_color,rectAB_color2,  0,4, rectA_background,nextDayA,nextDayB,OpenClose,false);
    DrawObjects(dtTradeDate, UniqueID + " BoxPeriodB  " + TimeToStr(dtTradeDate,TIME_DATE), periodA_begin, periodA_end, periodB_end, rectB1_color,rectAB_color2,  rectB1_band,5, rectB1_background,nextDayA,nextDayB,OpenClose, false);

    dtTradeDate=decrementTradeDate(dtTradeDate);
    while (TimeDayOfWeek(dtTradeDate) > 5 || TimeDayOfWeek(dtTradeDate) < 1 ) dtTradeDate = decrementTradeDate(dtTradeDate);     // Removed Sundays from plots
  }
}

//+------------------------------------------------------------------+
//| Create Objects - Rectangles and Trend lines                      |
//+------------------------------------------------------------------+

void DrawObjects(datetime dtTradeDate, string sObjName, string sTimeBegin, string sTimeEnd, string sTimeObjEnd, color cObjColor1, color cObjColor2, int iOffSet, int iForm, bool background, int nextDayA, int nextDayB, bool OpenClose, bool rectA_close_begin) {
  datetime dtTimeBegin, dtTimeEnd, dtTimeObjEnd;
  double   dPriceHigh,  dPriceLow, dPriceOpen, dPriceClose;
  int      iBarBegin,   iBarEnd;
  string   sObjDesc;

  dtTimeBegin = StrToTime(TimeToStr(dtTradeDate, TIME_DATE) + " " + sTimeBegin);
  dtTimeEnd = StrToTime(TimeToStr(dtTradeDate, TIME_DATE) + " " + sTimeEnd);
  dtTimeObjEnd = StrToTime(TimeToStr(dtTradeDate, TIME_DATE) + " " + sTimeObjEnd);

  if(nextDayA == 1) dtTimeEnd = dtTimeEnd + 86400;
  if(nextDayB == 1) dtTimeObjEnd = dtTimeObjEnd + 86400;
  if(nextDayA == 1 && TimeDayOfWeek(dtTradeDate) == 5) dtTimeEnd = dtTimeEnd + (2 * 86400);
  if(nextDayB == 1 && TimeDayOfWeek(dtTradeDate) == 5) dtTimeObjEnd = dtTimeObjEnd + (2 * 86400);

  iBarBegin = iBarShift(NULL, 0, dtTimeBegin)+1;                                    // added 1 to bar count to correct calculation for highest price for the period
  iBarEnd = iBarShift(NULL, 0, dtTimeEnd)+1;                                        // added 1 to bar count to correct calculation for lowest price for the period

   dPriceHigh  = High[Highest(NULL, 0, MODE_HIGH, (iBarBegin)-iBarEnd, iBarEnd)];
   dPriceLow   = Low [Lowest (NULL, 0, MODE_LOW , (iBarBegin)-iBarEnd, iBarEnd)];
   dPriceOpen  = Open[iBarBegin-1];                                                 // Open/Close added to enable Open/Close rectangles
   dPriceClose = Close[iBarEnd];

      if(OpenClose){                                                                // Selection of extremes of Open/Close values
         dPriceHigh = MathMax(dPriceOpen, dPriceClose);
         dPriceLow  = MathMin(dPriceOpen, dPriceClose);
         }

//---- High-Low Rectangle - Period A and B combined
   if(iForm==1){
      ObjectCreate(sObjName, OBJ_RECTANGLE, 0, 0, 0, 0, 0);
      ObjectSet(sObjName, OBJPROP_TIME1 , dtTimeBegin);
      ObjectSet(sObjName, OBJPROP_TIME2 , dtTimeObjEnd);
      ObjectSet(sObjName, OBJPROP_PRICE1, dPriceHigh);
      ObjectSet(sObjName, OBJPROP_PRICE2, dPriceLow);
      ObjectSet(sObjName, OBJPROP_STYLE, STYLE_SOLID);
      if(dPriceClose<dPriceOpen && OpenClose==true) cObjColor1 = cObjColor2;        // Color change of rectangle dependent on Open/Close positions
      ObjectSet(sObjName, OBJPROP_COLOR, cObjColor1);
      ObjectSet(sObjName, OBJPROP_BACK, background);
   }

//---- Upper Rectangle  - Period B
  if(iForm==2){
      ObjectCreate(sObjName, OBJ_RECTANGLE, 0, 0, 0, 0, 0);
      ObjectSet(sObjName, OBJPROP_TIME1 , dtTimeEnd);
      ObjectSet(sObjName, OBJPROP_TIME2 , dtTimeObjEnd);
      ObjectSet(sObjName, OBJPROP_PRICE1, dPriceHigh);
      ObjectSet(sObjName, OBJPROP_PRICE2, dPriceHigh + iOffSet*Point);
      ObjectSet(sObjName, OBJPROP_STYLE, STYLE_SOLID);
      ObjectSet(sObjName, OBJPROP_COLOR, cObjColor1);
      ObjectSet(sObjName, OBJPROP_BACK, background);
   }

 //---- Lower Rectangle - Period B
  if(iForm==3){
      ObjectCreate(sObjName, OBJ_RECTANGLE, 0, 0, 0, 0, 0);
      ObjectSet(sObjName, OBJPROP_TIME1 , dtTimeEnd);
      ObjectSet(sObjName, OBJPROP_TIME2 , dtTimeObjEnd);
      ObjectSet(sObjName, OBJPROP_PRICE1, dPriceLow - iOffSet*Point);
      ObjectSet(sObjName, OBJPROP_PRICE2, dPriceLow);
      ObjectSet(sObjName, OBJPROP_STYLE, STYLE_SOLID);
      ObjectSet(sObjName, OBJPROP_COLOR, cObjColor1);
      ObjectSet(sObjName, OBJPROP_BACK, background);
   }

//---- Period A Rectangle
  if(iForm==4){
      ObjectCreate(sObjName, OBJ_RECTANGLE, 0, 0, 0, 0, 0);
      ObjectSet(sObjName, OBJPROP_TIME1 , dtTimeBegin);
      ObjectSet(sObjName, OBJPROP_TIME2 , dtTimeEnd);
      ObjectSet(sObjName, OBJPROP_PRICE1, dPriceHigh);
      ObjectSet(sObjName, OBJPROP_PRICE2, dPriceLow);
      ObjectSet(sObjName, OBJPROP_STYLE, STYLE_SOLID);
      ObjectSet(sObjName, OBJPROP_COLOR, cObjColor1);
      ObjectSet(sObjName, OBJPROP_WIDTH, 0);
      ObjectSet(sObjName, OBJPROP_BACK, background);
      sObjDesc = StringConcatenate("High: ",dPriceHigh,"  Low: ", dPriceLow);
      ObjectSetText(sObjName, sObjDesc,10,"Times New Roman",Black);
   }
//---- Period B Rectangle
  if(iForm==5){
      ObjectCreate(sObjName, OBJ_RECTANGLE, 0, 0, 0, 0, 0);
      ObjectSet(sObjName, OBJPROP_TIME1 , dtTimeEnd);
      ObjectSet(sObjName, OBJPROP_TIME2 , dtTimeObjEnd);
      ObjectSet(sObjName, OBJPROP_PRICE1, dPriceHigh + iOffSet*Point);
      ObjectSet(sObjName, OBJPROP_PRICE2, dPriceLow - iOffSet*Point);
      ObjectSet(sObjName, OBJPROP_STYLE, STYLE_SOLID);
      ObjectSet(sObjName, OBJPROP_COLOR, cObjColor1);
      ObjectSet(sObjName, OBJPROP_WIDTH, 0);
      ObjectSet(sObjName, OBJPROP_BACK, background);
   }

//---- Period B HIGH Alert
  if(iForm==8){
      ObjectCreate(sObjName,OBJ_TREND,0,0,0,0);
      ObjectSet(sObjName, OBJPROP_TIME1 , dtTimeEnd);
      ObjectSet(sObjName, OBJPROP_TIME2 , dtTimeObjEnd);
      ObjectSet(sObjName, OBJPROP_PRICE1, dPriceHigh + iOffSet*Point);
      ObjectSet(sObjName, OBJPROP_PRICE2, dPriceHigh + iOffSet*Point);
      ObjectSet(sObjName, OBJPROP_STYLE, STYLE_SOLID);
      ObjectSet(sObjName, OBJPROP_COLOR, cObjColor1);
      ObjectSet(sObjName, OBJPROP_WIDTH, 1);
      ObjectSet(sObjName, OBJPROP_BACK, background);
      ObjectSet(sObjName, OBJPROP_RAY,false);
      sObjDesc = StringConcatenate("Period B - HIGH Alert_01 - ",dPriceHigh + iOffSet*Point);
      ObjectSetText(sObjName, sObjDesc,10,"Times New Roman",Black);
//      if(Bid >= (dPriceHigh + iOffSet*Point)) Alert(sObjName," - ",dPriceHigh + iOffSet*Point);
   }
//---- Period B LOW Alert
  if(iForm==9){
      ObjectCreate(sObjName,OBJ_TREND,0,0,0,0);
      ObjectSet(sObjName, OBJPROP_TIME1 , dtTimeEnd);
      ObjectSet(sObjName, OBJPROP_TIME2 , dtTimeObjEnd);
      ObjectSet(sObjName, OBJPROP_PRICE1, dPriceLow - iOffSet*Point);
      ObjectSet(sObjName, OBJPROP_PRICE2, dPriceLow - iOffSet*Point);
      ObjectSet(sObjName, OBJPROP_STYLE, STYLE_SOLID);
      ObjectSet(sObjName, OBJPROP_COLOR, cObjColor1);
      ObjectSet(sObjName, OBJPROP_WIDTH, 1);
      ObjectSet(sObjName, OBJPROP_BACK, background);
      ObjectSet(sObjName, OBJPROP_RAY,false);
      sObjDesc = StringConcatenate("Period B - LOW Alert_01 - ",dPriceLow - iOffSet*Point);
      ObjectSetText(sObjName, sObjDesc,10,"Times New Roman",Black);
//      if(Bid <= (dPriceLow - iOffSet*Point)) Alert(sObjName," - ",dPriceLow - iOffSet*Point);
   }
}

//+------------------------------------------------------------------+
//| Decrement Date to draw objects in the past                       |
//+------------------------------------------------------------------+

datetime decrementTradeDate (datetime dtTimeDate) {
   int iTimeYear=TimeYear(dtTimeDate);
   int iTimeMonth=TimeMonth(dtTimeDate);
   int iTimeDay=TimeDay(dtTimeDate);
   int iTimeHour=TimeHour(dtTimeDate);
   int iTimeMinute=TimeMinute(dtTimeDate);

   iTimeDay--;
   if (iTimeDay==0) {
     iTimeMonth--;
     if (iTimeMonth==0) {
       iTimeYear--;
       iTimeMonth=12;
     }

     // Thirty days hath September...
     if (iTimeMonth==4 || iTimeMonth==6 || iTimeMonth==9 || iTimeMonth==11) iTimeDay=30;
     // ...all the rest have thirty-one...
     if (iTimeMonth==1 || iTimeMonth==3 || iTimeMonth==5 || iTimeMonth==7 || iTimeMonth==8 || iTimeMonth==10 || iTimeMonth==12) iTimeDay=31;
     // ...except...
     if (iTimeMonth==2) if (MathMod(iTimeYear, 4)==0) iTimeDay=29; else iTimeDay=28;
   }
  return(StrToTime(iTimeYear + "." + iTimeMonth + "." + iTimeDay + " " + iTimeHour + ":" + iTimeMinute));
}

//+------------------------------------------------------------------+

Comments
