BatMA
Download script
This script is designed as a versatile technical analysis tool for the MetaTrader platform. Its primary purpose is to calculate and display various types of "Moving Averages" on a price chart. A moving average helps traders smooth out market volatility to identify the underlying trend of an asset's price over time.
Instead of being limited to just one type of calculation, this script provides users with four distinct mathematical models to choose from, depending on how they prefer to interpret price trends.
Core Functionality
The logic follows a structured flow to ensure accuracy and visual clarity:
- User Customization: Upon loading, the script allows the user to define key variables, such as the "Period" (how much historical data to look back at), the "Shift" (how far to move the resulting line forward or backward on the chart), and the specific "Method" of calculation.
- Dynamic Calculation: The script automatically detects the current state of the market history. It processes price data—specifically looking at closing prices—to generate a continuous line.
- Visual Feedback: It handles the drawing of the indicator, ensuring that the line appears correctly on the chart and identifies itself clearly with a label that shows which specific average type is currently active.
The Four Calculation Methods
The script contains independent logic blocks for four different mathematical approaches:
- Simple Moving Average (SMA): This is the most straightforward method. It calculates the arithmetic mean of a set number of past prices. Every price point in the period carries equal weight.
- Exponential Moving Average (EMA): This method reacts more quickly to recent price changes. It applies a weighting factor that gives more importance to the most recent data points while still accounting for historical prices.
- Smoothed Moving Average (SMMA): This logic is designed to reduce "noise" even further than a simple average. It uses a recursive calculation that averages the previous average with the current price, resulting in a much smoother, slower-moving line.
- Linear Weighted Moving Average (LWMA): In this model, the most recent prices are given the highest weight, and the weight decreases linearly as the data gets older. This provides a balance between the responsiveness of an EMA and the stability of an SMA.
- Butterworth Moving Average (BatEMA): This is a more complex mathematical filter used to create a very smooth line. It uses a specific coefficient to minimize fluctuations, making it highly effective for identifying long-term trends without being distracted by minor price spikes.
Summary of Operation
When the market updates, the script identifies which calculation method the user has selected, scans the historical closing prices over the chosen period, performs the relevant math (Simple, Exponential, Smoothed, Linear, or Butterworth), and draws a smooth red line on the chart to represent the current trend.
Miscellaneous
13
Views
0
Downloads
0
Favorites
BatMA
//+------------------------------------------------------------------+
//| Custom Moving Average.mq4 |
//| Copyright © 2004, MetaQuotes Software Corp. |
//| Copyright © 2008, YUBA |
//| http://www.metaquotes.net/ |
//+------------------------------------------------------------------+
#property copyright "Copyright © 2004, MetaQuotes Software Corp.,Copyright © 2008, YUBA"
#property link "http://www.metaquotes.net/"
#property indicator_chart_window
#property indicator_buffers 1
#property indicator_color1 Red
//---- indicator parameters
extern int MA_Period=13;
extern int MA_Shift=0;
extern int MA_Method=4;
//---- indicator buffers
double ExtMapBuffer[], pr;
//----
int ExtCountedBars=0;
//+------------------------------------------------------------------+
//| Custom indicator initialization function |
//+------------------------------------------------------------------+
int init()
{
int draw_begin;
string short_name;
//---- drawing settings
SetIndexStyle(0,DRAW_LINE);
SetIndexShift(0,MA_Shift);
IndicatorDigits(MarketInfo(Symbol(),MODE_DIGITS));
if(MA_Period<2) MA_Period=13;
draw_begin=MA_Period-1;
//---- indicator short name
switch(MA_Method)
{
case 1 : short_name="EMA("; draw_begin=0; break;
case 2 : short_name="SMMA("; break;
case 3 : short_name="LWMA("; break;
case 4 : short_name="BatEMA("; break;
default :
MA_Method=1;
short_name="EMA(";
}
IndicatorShortName(short_name+MA_Period+")");
SetIndexDrawBegin(0,draw_begin);
//---- indicator buffers mapping
SetIndexBuffer(0,ExtMapBuffer);
//---- initialization done
return(0);
}
//+------------------------------------------------------------------+
//| |
//+------------------------------------------------------------------+
int start()
{
if(Bars<=MA_Period) return(0);
ExtCountedBars=IndicatorCounted();
//---- check for possible errors
if (ExtCountedBars<0) return(-1);
//---- last counted bar will be recounted
if (ExtCountedBars>0) ExtCountedBars--;
//----
switch(MA_Method)
{
case 0 : sma(); break;
case 1 : ema(); break;
case 2 : smma(); break;
case 3 : lwma(); break;
case 4 : pr=MathSqrt(2.0/(1.0+MA_Period));
BatMa(pr);
}
//---- done
return(0);
}
//+------------------------------------------------------------------+
//| Simple Moving Average |
//+------------------------------------------------------------------+
void sma()
{
double sum=0;
int i,pos=Bars-ExtCountedBars-1;
//---- initial accumulation
if(pos<MA_Period) pos=MA_Period;
for(i=1;i<MA_Period;i++,pos--)
sum+=Close[pos];
//---- main calculation loop
while(pos>=0)
{
sum+=Close[pos];
ExtMapBuffer[pos]=sum/MA_Period;
sum-=Close[pos+MA_Period-1];
pos--;
}
//---- zero initial bars
if(ExtCountedBars<1)
for(i=1;i<MA_Period;i++) ExtMapBuffer[Bars-i]=0;
}
//+------------------------------------------------------------------+
//| Exponential Moving Average |
//+------------------------------------------------------------------+
void ema()
{
double pr=2.0/(MA_Period+1),Y;
int pos=Bars-2;
if(ExtCountedBars>2) pos=Bars-ExtCountedBars-1;
//---- main calculation loop
while(pos>=0)
{
if(pos==Bars-2) ExtMapBuffer[pos+1]=Close[pos+1];
ExtMapBuffer[pos]=Close[pos]*pr+ExtMapBuffer[pos+1]*(1-pr);
pos--;
}
}
//+------------------------------------------------------------------+
//| Smoothed Moving Average |
//+------------------------------------------------------------------+
void smma()
{
double sum=0;
int i,k,pos=Bars-ExtCountedBars+1;
//---- main calculation loop
pos=Bars-MA_Period;
if(pos>Bars-ExtCountedBars) pos=Bars-ExtCountedBars;
while(pos>=0)
{
if(pos==Bars-MA_Period)
{
//---- initial accumulation
for(i=0,k=pos;i<MA_Period;i++,k++)
{
sum+=Close[k];
//---- zero initial bars
ExtMapBuffer[k]=0;
}
}
else sum=ExtMapBuffer[pos+1]*(MA_Period-1)+Close[pos];
ExtMapBuffer[pos]=sum/MA_Period;
pos--;
}
}
//+------------------------------------------------------------------+
//| Linear Weighted Moving Average |
//+------------------------------------------------------------------+
void lwma()
{
double sum=0.0,lsum=0.0;
double price;
int i,weight=0,pos=Bars-ExtCountedBars-1;
//---- initial accumulation
if(pos<MA_Period) pos=MA_Period;
for(i=1;i<=MA_Period;i++,pos--)
{
price=Close[pos];
sum+=price*i;
lsum+=price;
weight+=i;
}
//---- main calculation loop
pos++;
i=pos+MA_Period;
while(pos>=0)
{
ExtMapBuffer[pos]=sum/weight;
if(pos==0) break;
pos--;
i--;
price=Close[pos];
sum=sum-lsum+price*MA_Period;
lsum-=Close[i];
lsum+=price;
}
//---- zero initial bars
if(ExtCountedBars<1)
for(i=1;i<MA_Period;i++) ExtMapBuffer[Bars-i]=0;
}
//+------------------------------------------------------------------+
//| Batterwort Moving Average |
//+------------------------------------------------------------------+
void BatMa(double Kf)
{
double p=2.0/(MA_Period+1);
double p1,p2,p3;
int pos=Bars-2;
p1=Kf*Kf;
p2=2.0*(1-Kf);
p3=(1-Kf)*(1-Kf);
if(ExtCountedBars>2) pos=Bars-ExtCountedBars-1;
//---- main calculation loop
while(pos>=0)
{
if(pos==Bars-2) ExtMapBuffer[pos+1]=Close[pos+1];
ExtMapBuffer[pos]=p1*Close[pos]+p2*ExtMapBuffer[pos+1]-p3*ExtMapBuffer[pos+2];
pos--;
}
}
//+------------------------------------------------------------------+
